Exitronix VEX Series User manual

S
E
R
I
E
S
E
X
I
T
VEX SERIES
THERMOPLASTIC LED
EMERGENCY EXIT SIGN
IMPORTANT
SAFEGUARDS
READ AND FOLLOW ALL
SAFETY INSTRUCTIONS
Do not use outdoors.
Do not mount near gas or electric
heaters.
Equipment should be mounted in
locations and at heights where it will not
readily be subjected to tampering by
unauthorized personnel.
The use of accessory equipment not
recommended by the manufacturer may
cause an unsafe condition.
Do not use equipment for other than its
intended use.
MEETS OR EXCEEDS UL 924
LISTED
9801680
MANUFACTURED BY:
A DIVISION OF
BARRON MANUFACTURING
CORPORATION
1911 WEST PARKSIDE LANE
PHOENIX, AZ 85027
(800)LED-EXIT
[phone]
FAX [phone]
[email protected]
www.exitronix.com
Designing
and
Manufacturing
Excellence
S
E
R
I
E
S
E
X
I
T
Canopy Attachment to Enclosure
Insert canopy into housing and slide to
lock into place. Quick Snap is now firmly
engaged.
CAUTION: Trying to remove canopy after
it is locked in place may cause damage.
WARRANTY
5 YEAR LIMITED*
EXITRONIX, A Division of Barron
Manufacturing Corp. will replace or
repair any components, which fail due to
manufacturer’s defects or work-manship,
for a period of 5 years. The warranty
does not cover physical damage or abuse,
and Barron Manufacturing reserves the
right to charge for such repairs if deemed
necessary.
*Battery is covered separately by a 5 year
pro-rated warranty through manufacturer.
10070040 REV 2 - 5/18/06

1 Faceplate
2 Chevron Cover
3 Red/Green Diffuser
4 Enclosure
5 Backplate
7 Junction Box
(Building Utility)
6 Wire Nuts
12
3
4
5
6
7
1 Faceplate
2 Chevron Cover
3 Red/Green Diffuser
4Enclosure
5 Backplate
7 Canopy
8 Mounting Plate
9 Wire Nuts
10 Junction Box
(Building Supply)
6 Canopy Plug
123
4
5
6
7
8
9
10
1 Faceplate
2 Chevron Cover
3 Red/Green Diffuser
4Enclosure
5 Backplate
7 Canopy
8 Mounting Plate
9 Wire Nuts
10 Junction Box
(Building Supply)
6 Canopy Plug
12
3
4
5
6
78
9
10
Back Mounting
• Drill 3/8” hole into the center of the
• back plate (5). Drill 1/4” inch holes into
• the ob-long holes on back plate (5) that
• correspond to junction box (7) being
• used.
• Feed leads through center hole and
• make the proper connections. If using
• 120VAC, connect the black and white
• leads to power supply. If using • •
• 277VAC, connect the orange and white
• leads to power supply. Route wires
• through guide posts located on back
• plate.
• Feed excess wire into junction box
• and secure back plate (5) to junction
• box (7) using screws.
• Snap in arrows (2) to faceplate (1) as
• required, storing unused arrows in a safe
• place. Then snap faceplate (1) to housing
• (4).
Ceiling Mounting
• Attach mounting plate (8) to junction
• box (10).
• Feed transformer leads through top
• hole, making sure to secure wire into
• wire guides found at the edges of the
• sign.
• Attach sign to canopy (7) by inserting
• canopy into sign then sliding to the side to
• lock (see back page of instruction
• manual).
• Make proper lead connections. If using
• 120VAC, connect the black and white
• wires to power supply. If using 277VAC,
• connect orange and white wires to
• power supply.
• Push excess wire into junction box.
• Align holes in canopy with those in
• mounting plate. Use supplied screws to
• secure canopy to mounting plate,
• tightening until canopy is pulled tight to
• ceiling.
• Snap in arrows (2) to faceplate (1) as
• required, storing unused arrows in a safe
• place. Then snap faceplate (1) to housing
• (4).
• For double-faced signs, replace
• backplate with extra EXIT faceplate.
End Mounting
• Attach mounting plate (8) to junction
• box (10).
• Feed transformer leads through side
• hole, making sure to secure wire into
• wire guides found at the edges of the
• sign.
• Attach sign to canopy (7) by inserting
• canopy into sign then sliding to the side to
• lock (see back page of instruction
• manual).
• Make proper lead connections. If using
• 120VAC, connect the black and white
• wires to power supply. If using 277VAC,
• connect orange and white wires to
• power supply.
• Push excess wire into junction box.
• Align holes in canopy with those in
• mounting plate. Use supplied screws to
• secure canopy to mounting plate,
• tightening until canopy is pulled tight to
• ceiling.
• Snap in arrows (2) to faceplate (1) as
• required, storing unused arrows in a safe
• place. Then snap faceplate (1) to housing
• (4).
• For double-faced signs, replace
• backplate with extra EXIT faceplate.
