Exodraft ESP-10 User manual

Your energy. Optimized.
Electrostatic Particle Filter
ESP-10
UK |Read and save these instructions!

Your energy. Optimized.
Product description 7
Scope of supply 7
Accessories and spare parts 7
Functionality of the electrostatic precipitator 8
Automatic on/off 9
Self-cleaning function 9
Technical specications 10
Precautions and user instructions 13
Mechanical installation 14
Transportation safety 14
Minimum distance 16
Before installation onto a chimney 17
Installation onto a brick chimney 18
Installation onto a steel chimney 20
Electrical Installation 22
Start-up and conguration 23
General 23
System test 23
User operation instructions 24
User operation 24
Indications on the ESP-10 lter 25
Maintenance and troubleshooting 26
Safety precautions 26
User maintenance 27
Inspection and service 28
Cleaning procedure 30
Troubleshooting 32
Other problems and solutions 33
Particle Filter | ESP-10
Content

Disposal
Electrical and electronic equipment (EEE) often contain materials, components and substances
that may harm the environment or be hazardous to your health. Products (WEEE) marked with
the ‘crossed-out wheeled bin’ symbol should be disposed of separately from other waste at
the end of its life. Though legislation may differ from country to country we strongly advise
that electrical and electronic waste is separated from other waste and disposed of according to
national legislation to protect the environment and personnel that may come into contact with
waste.
How to use this manual
This manual has been prepared based on the specific product and
contains relevant technical information and installations guides.
Accessories and spare parts are not covered by this manual.
Please refer to the individual manuals of these components.
This installation manual does not contain any system design documentation.
Failure to observe instructions marked with a danger symbol
may result in personal injury and/or damage to the product.
Errors and omissions excepted.

Symbols
The following symbols may be used in the manual
to draw attention to danger or risk of personal
injury or damage to the product.
General prohibition
Failure to observe instructions marked with the prohibited
symbol may result in extreme danger or serious personal injury.
General warning
Failure to observe instructions marked with a danger symbol
may result in personal injury and/or damage to the product.
General attention
Marks a dangerous situation that, in the worst-case scenario,
can cause serious personal injury or significant damage to the product.
Electricity hazard/High Voltage
Marks a situation in which caution is advised due to the risk of high voltage electric
shock which can cause serious personal injury or significant damage to the product.
Connect an earth terminal to the ground
Failure to observe instructions marked with a danger symbol
may result in personal injury and/or damage to the product.
Permitted and approved
Permitted and approved method of installation.
Prohibited and not approved
Prohibited and not approved method of installation.

Warning
To minimise the risk of fire, electric shock, personal injury
and/or damage to the product please observe the following:
• Please always read the manual and only use the product in accordance with the
manufacturer’s instructions. If in doubt, contact one of the Exodraft specialized dealers.
• All installations must be carried out by properly qualifi ed personnel in accordance with
national legislation and regulations.
• This product must be earthed. Get assistance from an qualifi ed electrician when in doubt.
• The chimney fan must always remain switched on when the fireplace is in use.
• Ensure that the chimney has been swept before mounting the fan to avoid chimney fire
• The product must be accessible for service and maintenance.
• Prior to servicing the product, disconnect the power supply to the lter. Turn o the main
switch located on the lter. Ensure that the heat source and the lter cannot be turned on acci-
dentally. Let the lter cool down before service or cleaning.
• Automatic power on/off function; when the temperature in the chimney increases, high
voltage automatically switches on. Touching the electrode or the electrode holder may be
fatal.
• Exodraft always recommends the use of a smoke alarm when a solid fuel fireplace is
installed.
• If the Exodraft fan system has been designed for solid fuel/multi fuel installations, please
ensure that the design meets the requirements of BS EN15287-1. If this cannot be achie-
ved, a smoke alarm must be installed in the same room as the heat appliance.
• Undesirable stoking practice may result in problems, such as excessive soot accumulation,
chimney fi res, etc., which may damage the product.
UK
Your energy. Optimized.

UK |7
3112023_ESP-10_UK
Warning
To minimise the risk of fire, electric shock, personal injury
and/or damage to the product please observe the following:
• Please always read the manual and only use the product in accordance with the
manufacturer’s instructions. If in doubt, contact one of the Exodraft specialized dealers.
• All installations must be carried out by properly qualifi ed personnel in accordance with
national legislation and regulations.
• This product must be earthed. Get assistance from an qualifi ed electrician when in doubt.
• The chimney fan must always remain switched on when the fireplace is in use.
• Ensure that the chimney has been swept before mounting the fan to avoid chimney fire
• The product must be accessible for service and maintenance.
• Prior to servicing the product, disconnect the power supply to the lter. Turn o the main
switch located on the lter. Ensure that the heat source and the lter cannot be turned on acci-
dentally. Let the lter cool down before service or cleaning.
• Automatic power on/off function; when the temperature in the chimney increases, high
voltage automatically switches on. Touching the electrode or the electrode holder may be
fatal.
• Exodraft always recommends the use of a smoke alarm when a solid fuel fireplace is
installed.
• If the Exodraft fan system has been designed for solid fuel/multi fuel installations, please
ensure that the design meets the requirements of BS EN15287-1. If this cannot be achie-
ved, a smoke alarm must be installed in the same room as the heat appliance.
• Undesirable stoking practice may result in problems, such as excessive soot accumulation,
chimney fi res, etc., which may damage the product.
UK
Your energy. Optimized.
Product description
An Exodraft ESP-10 particle lter is designed as an electrostatic precipitator with a built-in chimney fan
for mounting on top of the chimney. The lter is equipped with a self-cleaning function (patented) and
designed to reduce the emissions from wood-burning appliances as well as facilitate easier lighting and
refueling.
The ESP-10 comes with an integrated isolation switch and a 5-metre cable with open wires for plug
installation.
The lter is designed for closed wood-burning replaces (stoves) with a nominal heat output of maximum
10 kW.
Incorrect ring may result in problems with soot, chimney res, etc. which might damage the product.
Please check out this site for advice about lighting and maintaining a re:
www.exodraft.com
Scope of supply
• ESP-10 with 5-metre connection cable (with open wires)
• Installation manual and user instructions
• Labels for chimney sweep, indicating that power to the lter must be cut off
before cleaning the chimney to be placed at replace and cleaning locations.
A mounting adapter for mounting the Exodraft ESP-10 on the chimney must be ordered separately to t the
existing chimney system.
Accessories and spare parts
The table below shows the accessories and spare parts available for the RS-models.
Accessories* Spare parts
Adapters (for steel and brick chimneys) Fan motor
Flanges (for brick chimneys) Cleaning motor
Electrode
Insulator
Controller
*This manual does not describe the specic use of accessories. We refer to the separate manuals for such components.
For more details contact your Exodraft dealer.

8|UK
Your energy. Optimized.
Functionality of the electrostatic precipitator
The Exodraft lter is an electrostatic precipitator. The lter reduces the number of ne and ultrane par-
ticles in a ue gas ow by creating an electrostatic eld between the charging electrode and the collection
electrode.
The electrostataic eld in the ESP-10 is generated by a charging electrode connected to a high voltage
generator which ionizes the gas in its surroundings and as a result charges the particles and delivers an
electrostatic eld strong enough to push the charged particles towards a collection electrode.
While the electrostataic eld is on, the precipitated particles will remain attached to the collection elec-
trode. When the temperature and oxygen inside the lter is on a certain level, most of the attached particles
will self-ignite and burn off in a complete combustion as a part of the normal operation.
The lter’s self-cleaning functionality will remove the remaining particles inside the lter.
Insulator
Electrode
Self-cleaning
particle grid
Smoke inlet
Smoke outlet
Temperature sensor

UK |9
3112023_ESP-10_UK
Automatic on/off
The Exodraft ESP-10 lter has a built-in temperature sensor that makes it possible to control the start and
stop function automatically.
After the replace is lit, the ESP-10 lter will activate as soon as the temperature sensor records an
increase in temperature. Depending on the chimney application, the start delay will be 10-30 seconds.
When no fuel is added to the wood stove, the chimney temperature will start to decrease. Once the tempe-
rature drops below 40 °C, the ESP-10 lter continues to operate for 30 minutes, after which sleep mode is
engaged.
ATTENTION! When the replace and chimney are cold, it may, depending on relevant factors
(stove model, chimney size, fuel type etc.), be necessary to turn the Exodraft ESP-10 lter off
and then back on at the power supply to get the full benet of the ventilators mechanical draft.
Self-cleaning function
The Exodraft ESP-10 lter is equipped with an automatic cleaning function that periodically cleans the lter
during operation. The user may be able to hear the lter cleaning in some situations as the self-cleaning
procedure is a mechanical movement inside the lter.
If the lter is restarted and the replace is cold, the automatic cleaning process will run for 3-5 seconds.
When the replace is in use the cleaning procedure is initiated after 5 hours, only starting when the re-
place is being refueld.

10 |UK
Your energy. Optimized.
Warranty
All Exodraft products are covered by a 2-year guarantee as per European consumer rights legislation. For
some countries an extended period of guarantee may apply depending on either national legislation or
other clearly stipulated conditions. Customer complaints must be handled by a specialised dealer or
wholesaler (preferably where the Exodraft product has been bought originally). An updated list of Exodraft
specialised dealers can be found on our website for the country in question.
Exodraft products must always be installed by properly qualied personnel. Exodraft reserves the right to
change these guidelines without prior notice.
The warranty and liability does not cover instances regarding personal injury or damage to property or the
product that can be ascribed to one or more of the following causes:
• Failure to follow this installation and operation manual
• Incorrect installation, start-up, maintenance or servicing
• Improper repairs
• Unauthorised structural modications made to the product
• Installation of additional components that have not been tested/approved with the product
• Any damage resulting from continued use of the product despite an evident defect
• Failure to use original spareparts and accessories
• Failure to use the product as intended
• Exceeding or failure to meet the limit values in the technical data
• Force majeure
Technical specications
The RS fan is designed for vertical discharge. It is available in to colors.
The body and casing are manufactured in stainless steel and equipped with a aluminum vane.
Particle lter Vane
ESP-10-STEEL
ESP-10-BLACK Aluminium vane
All models can be opened for service and cleaning purposes.
The ESP-10 vane has been developed to solve draught problems by creating a mechanical draught on
chimney, while the electrostatic precipitator lter reduces the number of ne and ultrane particles in a ue
gas ow.
The ESP-10 lter has been designed for closed wood-burning replaces and stoves with a nominal heat
output of maximum 10 kW.. The lter rst reaches its full efciency after 10-20 res or burning of approx.
15-20 kg of rewood.
The ESP-10 lter can tolerate ue gas temperatures up to 400°C.

UK |11
3112023_ESP-10_UK
B
A
F
E
D
C
Technical data
Model
Motor specications
V Amp Hz
Power
consumption
in use [W]
Power
consumption
standby [W]
High Voltage
[kV/mA]*
ESP-10-STEEL 1 x 230 0.5 50 50-90 230 / 1.7
ESP-10-BLACK 1 x 230 0.5 50 50-90 230 / 1.7
*Power consumption at min. ambient temperature of -20 °C and max. ambient temperature of 45 °C.
ESP-10 Filter without adapter
Model Weight Dimension [mm] Testing done at
kg AB [Ø] C [Ø] D E F
ESP-10-STEEL 14 957 267 220 120 44 267 DIBt: Z-7.4-3536
ESP-10-BLACK 14 957 267 220 120 44 267 DIBt: Z-7.4-3536
Top
Bottom

12 |UK
Your energy. Optimized.
Construction and components
1Aluminium fan impeller
2 Fan inlet
3Electrode
4Self-cleaning particle grid
5 Lid (smoke gas side)
6Cover (smoke gas side)
7Lid (electronic side)
8Cover (electronic side)
1
2
4
3
5
6
7
8
9
10
11
12
13
14 15
16
9 Fan motor
10 Insulator
11 Automatic cleaning motor
12 Controller
13 Main Switch
14 Temperature sensor
15 Inlet for smoke
16 Outlet for smoke

UK |13
3112023_ESP-10_UK
Precautions and user instructions
These instructions, applicable standards and relevant safety procedures from the manufacturer must be
followed and at the same time the ofcial provisions in force in the country, where the product is installed,
must be observed.
Support system
Prior to installation of a chimney fan, it must be determined if the chimney can safely carry the weight of the
chimney fan.
A steel chimney should be well supported at the roof penetration point. If the chimney extends high above
the roof, the chimney and the fan should be secured. The manufacturer’s instructions must be followed.
Brick chimneys do not usually need any kind of support to carry the weight of the chimney fan.
System type
Fireplaces and wood stoves used in private dwellings normally operate in a relatively stable environment,
where no major pressure uctuations occur. However, o ensure an optimal ring, the particle lter is equip-
ped with a vane, to create a constant draft in the chimney independently the weather outside and on the
stage of the ring process.
Chimney
type
Specications
Fireplace
performance range
[kW]
Minimum size
[mm]
Maximum size
[mm]
Minimum distance
for lter to
ammable material
[mm]
Minimum distance
for lter to replace
[m]
Steel (round) 2 – 10 Ø150 Ø250 500 3
Brick (square) 2 – 10 150 x 150 250 x 250 500 3
Precautions
Be aware that it
• must be installed on top of the chimney
• can be mounted on steel as well as brick chimneys
• must be mounted with the approved Exodraft accessories
• must be accessible for service and maintenance from the roof or from a ladder/cherry picker
• the distance to ammable materials must be at least 500 mm
• the minimum distance for the particle lter to the replace must be at least 3 metres
• the isolation switch must be easily accessible

14 |UK
Your energy. Optimized.
Mechanical installation
Exodraft products must always be installed by properly qualied personnel and according to the
manufacturer’s instructions.
Transportation safety
Do not forget to remove the transport security in the bottom of the lter, protecting the electrode, before
mounting the particle lter on the chimney.
WARNING - REMOVE BE..
WARNING-
REMOVEBEFO
Transport security
Label

UK |15
3112023_ESP-10_UK
Positioning of the particle lter
The particle lter can and must only be mounted vertically! Be aware of national law and building
regulations!

16 |UK
Your energy. Optimized.
Minimum distance
The minimum distance to ammable materials must be at least 500 mm (national legislation must be
observed)!
Min. distance according
to national legislation!
ATTENTION! The minimum distance for the particle lter to the replace must be at least 3 metres.

UK |17
3112023_ESP-10_UK
Before installation onto a chimney
Before the installation for the ESP-10, it must be ensured that the electrode and the temperature sensor are
in the correct position. If the electrode or temperature sensor is out of its correct position, the particle lter
will not function correctly.
ATTENTION! The power supply must always be off,
when the particle lters are being inspected or serviced.
Aligning the electrode
The ESP-10 comes with the charging electrode already installed. When installing the ESP-10, the charging
electrode should hang straight down inside the smoke gas side.
The position of the electrode can be determined by removing the screw and open the lid on the top of the
smoke side, look down into the lter and observe whether or not the electrode is hanging straight down
inside the lter. Should the electrode not be aligned properly, please realign or replace the electrode.
Temperature sensor position
Before mounting the ESP-10 lter on the chimney, please make sure that the temperature sensor is in posi-
tion. The temperature sensor is located at the bottom of the lter and should be sticking out from bottom
plate, approximately 3 cm.
Screw
Smoke gas side
Electrode
A
DETAIL A
1:1

18 |UK
Your energy. Optimized.
Installation onto a brick chimney
If the lter is to be tted on a brick chimney, please use Exodraft accessories - the adapter and ange for
ESP-10. See the installation guide below.
Step Action Illustration
1Measure the inside diameter of the brick chimney,
to choose the correct adapter and ange.
2
Install the ange on the brick chimney, and xate
the ange to the chimney with some screws.
3Mount the adapter on the particle lter, with the
supplied screws.
4Then cut a hole in the mineral wool mat that
matches the adapter.
Adapter inlet
diameter
Adapter plate
diameter

UK |19
3112023_ESP-10_UK
5
Mount the particle lter with adapter (and adap-
ter-brackets*), on the mineral wool mat, on the
chimney.
Note! The brackets may be necessary if the
lters wobbles.
However, please note that the lter’s adapter
incl. ttings/brackets, must not sit in tension in
the chimney pipe.
*See the guide for the mounting of the brackets.
6
To avoid rainwater from entering the ange
- the slots and around the ange must be sealed
with silicone.
7
Connect the ESP-10 power cable to the power
outlet and turn on the power switch on the lter.
See the chapter Electrical installation for more
information.
ATTENTION! The chimney sweep must be made aware that the chimney is equipped with an ESP-10 Filter!
The supplied high voltage warning label must be attached to all inspection/cleaning hatches in the chimney system.

20 |UK
Your energy. Optimized.
Installation onto a steel chimney
If the lter is to be tted on a brick chimney, please use Exodraft accessories - the adapter for ESP-10.
See the installation guide below.
Step Action Illustration
1Measure the inside diameter of the steel chimney,
to choose the correct adapter for the particle lter.
2Mount the adapter on the particle lter, with the
supplied screws.
3Then cut a hole in the mineral wool mat that
matches the adapter.
Adapter inlet
diameter
Adapter plate
diameter
