Extreme Networks Summit WM Series Operating manual

Extreme Networks, Inc.
3585 Monroe Street
Santa Clara, California 95051
[phone]
[phone]
http://www.extremenetworks.com
Summit®WM Maintenance Guide
Software Version 5.3
Published: December 2008
Part number: 120482-00 Rev 01

Summit WM Maintenance Guide, Software Version 5.32
AccessAdapt, Alpine, Altitude, BlackDiamond, EPICenter, Essentials, Ethernet Everywhere, Extreme Enabled,
Extreme Ethernet Everywhere, Extreme Networks, Extreme Standby Router Protocol, Extreme Turbodrive, Extreme
Velocity, ExtremeWare, ExtremeWorks, ExtremeXOS, Go Purple Extreme Solution, ScreenPlay, Sentriant,
ServiceWatch, Summit, SummitStack, Triumph, Unified Access Architecture, Unified Access RF Manager, UniStack,
the Extreme Networks logo, the Alpine logo, the BlackDiamond logo, the Extreme Turbodrive logo, the Summit
logos, and the Powered by ExtremeXOS logo are trademarks or registered trademarks of Extreme Networks, Inc. or
its subsidiaries in the United States and/or other countries.
sFlow is a registered trademark of InMon Corporation.
Specifications are subject to change without notice.
All other registered trademarks, trademarks, and service marks are property of their respective owners.
© 2008 Extreme Networks, Inc. All Rights Reserved.

Summit WM Maintenance Guide, Software Version 5.3 3
Table of Contents
About this Guide.............................................................................................................................. 7
Who should use this guide ...........................................................................................................7
What is in this guide ...................................................................................................................7
Formatting conventions................................................................................................................8
Documentation feedback .............................................................................................................8
Chapter 1: Backing up the existing image......................................................................................... 9
Backing up the existing V4R1 GP7 image......................................................................................9
Backing up the existing V4R1 GP7 image on the Summit WM200/2000 Controller .....................9
Backing up the existing V4R1 GP7 image on the Summit WM100/1000 Controller ...................12
Backing up the existing V5R1/V5R3 image ..................................................................................18
Backing up the existing V5R1/V5R3 image on the Summit WM20/200/2000 Controller ............18
Backing up the existing V5R1/V5R3 image on the Summit WM100/1000 Controller .................18
Backing up the existing V4R2 image on the Summit WM20 Controller ...........................................18
Chapter 2: Upgrading the Summit WM Software to V5R3 release ..................................................... 25
Upgrade matrix .........................................................................................................................25
Upgrading the Summit WM Software via GUI ...............................................................................26
Upgrading the Summit WM Software via the CLI ..........................................................................28
Migrating the platform configuration ...........................................................................................30
Upgrading the two Controllers operating in ‘Availability’ mode .......................................................32
Upgrade WM-1 from V4.1 GPx to V4R1 GP7..........................................................................34
Upgrade WM-2 from V4.1 GPx to V4R1 GP7..........................................................................34
Upgrade WM-2 to from V4R1 GP7 to V5R3 ...........................................................................34
Upgrade WM-1 from V4R1 GP7 to V5R3 ...............................................................................35
Manually move APs back to Local WM...................................................................................35
Upgrading from any past release less than V4R1 GP7 release........................................................35
Upgrading from V1R0 GP1/GP2/GP3/GP4 to V5R3 release .....................................................35
Upgrading from V1R0 GP5 or higher to V5R3 release .............................................................36
Upgrading from V1R1 GPx (Any GP) to V5R3 release..............................................................36
Chapter 3: Upgrading the Summit WM Controller from V5R3 to V5R3 General Patch (GP).................. 39
Upgrading the software from V5R3 to V5R3 GPx on the Summit WM20/200/2000 Controller via the GUI
39
Modifying a scheduled software upgrade................................................................................45
Deleting a software image ....................................................................................................46
Upgrading the software from V5R3 to V5R3 GP on the Summit WM100/1000 Controller via the GUI46
Backing up the Summit WM Controller database ..........................................................................48
Uploading a backup to an FTP server ....................................................................................50
Scheduling a backup ...........................................................................................................51
Deleting a backup ...............................................................................................................52
Restoring the Summit WM Controller database.............................................................................52
Upgrading a Summit WM Controller using SFTP...........................................................................54

Table of Contents
Summit WM Maintenance Guide, Software Version 5.34
Working with a CF card ..............................................................................................................55
Mounting a CF card .............................................................................................................56
Unmounting a CF card.........................................................................................................57
Upgrading the two Controllers operating in session availability mode ..............................................58
Chapter 4: Restoring the backed-up image ..................................................................................... 59
Restoring V4R1 GP7 image from V5R3 on the Summit WM200/2000 Controller.............................59
Restoring V5R1 image from V5R3 on the Summit WM200/2000 Controller....................................63
Restoring V5R1 image from V5R3 on the Summit WM100/1000 Controller....................................63
Restoring V4R1 GP7 image from V5R3 on the Summit WM100/1000 Controller.............................63
Downloading the image from the FTP server and then restoring it.............................................66
Restoring the image directly from the FTP server without downloading it ..................................67
Restoring V4R2 image from V5R3 on the Summit WM20 Controller...............................................69
Restoring V5R1 image from V5R3 on the Summit WM20 Controller...............................................71
Chapter 5: Using the Console Port.................................................................................................. 73
Using the Console Port in the Summit WM200/2000 Controller ....................................................73
Using the Console Port in the Summit WM20 Controller ...............................................................74
Using the Console Port in the Summit WM100/1000 Controller ....................................................78
Chapter 6: Performing system maintenance .................................................................................... 79
Changing logs levels and enabling Syslog event reporting ..............................................................80
Enabling/disabling poll timer......................................................................................................80
Forcing immediate system shut down..........................................................................................82
Resetting the Wireless APs to their factory default settings............................................................82
Resetting an Altitude AP to its factory default settings ............................................................83
Resetting the Outdoor AP to its factory default settings...........................................................84
Resetting the Altitude 450/451 (802.11n) AP to its factory default settings.............................85
Chapter 7: Logs, traces, audits, and DHCP messages ...................................................................... 87
Working with logs ......................................................................................................................87
Log severity levels ...............................................................................................................87
Viewing Summit WM Controller logs ......................................................................................89
Viewing Altitude AP logs ......................................................................................................90
Clearing Summit WM Controller logs .....................................................................................90
Working with trace messages......................................................................................................92
Viewing Summit WM Controller traces ...................................................................................93
Viewing Altitude AP traces ...................................................................................................94
Viewing Altitude 802.11n AP traces .....................................................................................95
Viewing audit messages .............................................................................................................95
Viewing DHCP messages............................................................................................................96
Viewing software upgrade and operating system patch messages....................................................96
Viewing restore/import messages.................................................................................................98
Chapter 8: Summit WM Controller’s utilities.................................................................................... 99
Using controller utilities.............................................................................................................99
Summit WM Controller TCP dump management ...................................................................100
Configuring Check Point event logging.......................................................................................102

Table of Contents
Summit WM Maintenance Guide, Software Version 5.3 5
ELA Management Station events.........................................................................................103
Enabling SNMP ......................................................................................................................103
MIB support .....................................................................................................................104
Enabling SNMP on the Summit WM Controller.....................................................................104
Chapter 9: Recovering the Summit WM Controller’s lost password ................................................. 107
Recovering the WM100/1000 Controller’s lost password .............................................................107
Recovering the WM20/200/2000 Controller’s lost password ........................................................109
Chapter 10: Maintaining the Summit WM Controller ...................................................................... 111
Maintaining the Summit WM200/2000 Controller ......................................................................111
Data ports cabling specification..........................................................................................112
Summit WM200/2000 Controller power supply ....................................................................112
Power FRUs......................................................................................................................113
Summit WM200/2000 Controller, AC-powered, redundant system ...................................113
Fan Tray...........................................................................................................................113
MF1000 Media Flash Card.................................................................................................115
NP4000 Network Processor Card........................................................................................116
SC1100 Supervisor Card....................................................................................................117
Summit WM200/2000 Controller power and maintenance procedures....................................117
Maintaining the ESD wrist strap....................................................................................118
Using electrostatic discharge prevention procedures .......................................................118
Powering off the Summit WM200/2000 Controller .........................................................120
Maintaining the Summit WM20 Controller .................................................................................121
Summit WM20 Controller power and maintenance procedures...............................................122
Chapter 11: Performing Altitude AP software maintenance ............................................................ 123
Index.......................................................................................................................................... 127

Table of Contents
Summit WM Maintenance Guide, Software Version 5.36

Summit WM Maintenance Guide, Software Version 5.3 7
About this Guide
The purpose of this guide is to assist you in performing the maintenance of the following hardware and
software components of the Extreme Networks®Summit®WM Wireless LAN (WLAN) Solution:
Hardware
●Summit WM Controller
●Altitude™Access Point (AP)
Software
●Summit WM Software
Who should use this guide
This guide is intended for personnel, who are responsible for maintaining the Summit WM WLAN
Solution.
What is in this guide
The contents in this guide are organized under the following chapters:
●“About this Guide”– Describes the purpose, the target audience and the architecture of this guide.
●Chapter 1, “Backing up the existing image” — Describes how to back up the existing software image
before performing the upgrades.
●Chapter 2, “Upgrading the Summit WM Software to V5R3 release”— Describes how to upgrade the
Summit WM Software from various past releases to V5R3 release on various platforms.
●Chapter 3, “Upgrading the Summit WM Controller from V5R3 to V5R3 General Patch (GP)”—
Describes how to upgrade the Summit WM Software from V5R3 to V5R3 GP release.
●Chapter 4, “Restoring the backed-up image”— Describes how to restore the previously backed-up
image from V5R3 on various platforms.
●Chapter 5, “Using the Console Port”— Describes how to connect to the Summit WM Controller’s
console port to access the Rescue mode.
●Chapter 6, “Performing system maintenance”— Describes how to perform the following system
maintenance tasks: Changing the log level, setting a poll interval for checking the status of the
Altitude APs (Health Checking), enabling and defining parameters for Syslog event reporting,
forcing an immediate system shutdown with, or without reboot, and resetting the Summit WM
Controller to its factory defaults
●Chapter 7, “Logs, traces, audits, and DHCP messages”— Describes how to view and interpret the
logs, traces, audits and DHCP messages.
●Chapter 8, “Summit WM Controller’s utilities”— Describes how to configure the Summit WM
Controller’s utilities.

About this Guide
Summit WM Maintenance Guide, Software Version 5.38
●Chapter 9, “Recovering the Summit WM Controller’s lost password”— Describes how to recover the
Summit WM Controller’s lost login password via the Rescue mode.
●Chapter 10, “Maintaining the Summit WM Controller”— Describes how to maintain various
platforms.
●Chapter 11, “Performing Altitude AP software maintenance”— Describes how to perform Altitude
AP software maintenance.
Formatting conventions
The Summit WM Software V5R3 documentation uses the following formatting conventions to make it
easier to find information and follow procedures:
●Bold text is used to identify components of the management interface, such as menu items and
section of pages, as well as the names of buttons and text boxes.
For example: Click Logout.
●Monospace font is used in code examples and to indicate text that you type.
For example: Type https://<SWM-address>[:mgmt-port>]
●The following symbols are used to draw your attention to additional information:
NOTE
Notes identify useful information, such as reminders and tips.
CAUTION
Cautionary notes identify essential information, which if ignored can adversely affect the operation of your
equipment or software.
WARNING!
Warning notes identify essential information, which if ignored can lead to personal injury or harm.
Documentation feedback
If you have any problems using this document, you should contact your next level of support:
●Extreme Networks employees should contact the interactive Customer Engagement Team (i-CET).
●Customers should contact the Extreme Networks Customer Support Center.
When you call, please have the following information ready. This will help us to identify the document
that you are referring to.
●Title: Summit WM Maintenance Guide, Software Version 5.3
●Part Number: 120482-00 Rev 01

Summit WM Maintenance Guide, Software Version 5.3 9
1Backing up the existing image
This chapter describes how to back up the existing software image on various controllers before starting
the upgrade process.
The topics in this chapter are organized as follows:
●Backing up the existing V4R1 GP7 image
●Backing up the existing V5R1/V5R3 image
●Backing up the existing V4R2 image on the Summit WM20 Controller
Backing up the existing V4R1 GP7 image
This section describes how to back up the existing V4R1 GP7 image before starting the upgrade process.
This topics in this section are organized as follows:
●Backing up the existing V4R1 GP7 image on the Summit WM200/2000 Controller
●Backing up the existing V4R1 GP7 image on the Summit WM100/1000 Controller
Backing up the existing V4R1 GP7 image on the Summit WM200/
2000 Controller
The V4R1 GP7 image is not backed up from the GUI or CLI, but from a low-level menu presented
shortly after the system boots.
NOTE
You must use the serial connection to the Summit WM200/2000 Controller to back up the V4R1 GP7 image. For
more information, see Chapter 5, “Using the Console Port.”
NOTE
The procedure starts with a reboot.
To back-up the V4R1 GP7 image on the Summit WM200/2000 Controller:
1Enter the Rescue mode.
To enter the Rescue mode:
aUse the serial port of the Summit WM200/2000 Controller to connect to the console.

Backing up the existing image
Summit WM Maintenance Guide, Software Version 5.310
NOTE
To enter the Rescue mode, you must connect to the serial port. You can not enter the Rescue mode by
connecting to the ESA ports, or management/ETH0 port.
bReboot the Summit WM Controller. The following menu appears during the reboot process.
----------------------------------------------------------------
0: Main Mode
1: Rescue Mode
----------------------------------------------------------------
cPress 1to enter the Rescue mode. The following Rescue Menu is displayed.
1) Force system recovery
2) Configure interface
3) Configure ftp settings
4) Network settings Menu
5) FTP settings Menu
6) Create backup
7) Reboot
WARNING! - Forcing system recovery will erase all files, and reinstall the image
installed at the factory.
Reboot will restart the system back into Normal mode.
If you have any questions about these options, please contact Support.
Your choice>
2Configure the interface.
To configure the interface:
aIn the Rescue mode, press 2, and then enter the following:
■IP address of the controller’s Management Ethernet Port
■IP mask
■IP address of gateway
Your choice> 2
Please enter Interface information
Format <ip>:<netmask> <gw optional>
Input: 192.168.1.201:255.255.255.0 192.168.1.1
Configuring interface ...
Setting up network interface ...Done!
The system configures the interface and returns to the main menu.
3Configure the FTP settings.
To configure the FTP settings:
aIn the Rescue mode, press 3 to configure the FTP settings. The following message is displayed:
Please enter ftp info:
bType the following string, specifying the following:
■User Name for your FTP Server. In the following example, the user name ftpadmin is used.
■Password
■IP address
■Directory path and the file name. The following is the example of the string.
ftp://ftpadmin:[email protected]:21//builds/ac/mainBackup/backup.tgz

Summit WM Maintenance Guide, Software Version 5.3 11
NOTE
The base directory is the home directory of the user ftpadmin. To use a directory from the root of the FTP server
you must add an extra /:, such as:
ftp://ftpadmin:[email protected]:21///home/user/backup.tgz
NOTE
You must have the write permission for the FTP Server and the specified FTP directory.
4Check Network settings.
To check the Network settings:
aIn the Rescue mode, press 4. The following menu is displayed:
Your choice> 4
NETWORK SETTINGS
----------------
1) Assign ip address
2) Assign netmask
3) Assign default gateway ip address
4) Display current settings
5) Setup interface
6) Test interface by ICMP (ping)
7) Return to the main menu
Your choice:
bEnter 4to display the current settings.
NOTE
Any network parameter can be changed from this menu.
cTest the interface by entering 6, followed by some IP address that is reachable from the controller.
dEnter 7to return to the main Rescue menu.
5Check the FTP settings.
To check the FTP settings:
aIn the Rescue menu, press 5. The following menu is displayed.
Your choice> 5
FTP SETTINGS
----------------
1) Assign ftp server ip address
2) Assign user name
3) Assign password
4) Assign ftp directory
5) Assign file name
6) Display current settings
7) Return to the main menu
Your choice:
bEnter 6to display the current FTP settings.

Backing up the existing image
Summit WM Maintenance Guide, Software Version 5.312
NOTE
Any FTP parameter can be changed from this menu by entering the corresponding parameter number and then
entering the new value for the parameter.
NOTE
The file name must end with .tgz extension.
cEnter 7to return to the main menu.
6Create a backup image.
To create a backup image:
aIn the Rescue menu, press 6.
Your choice> 6
NOTE
You must ensure that the Interface and FTP settings are entered correctly.
The following are the examples of the string.
IP: 192.168.1.211 netmask 255.255.255.0 gateway: 192.168.1.1
FTP Settings: IP 192.168.3.10, port 21, user: ftpadmin, password: abc123, directory:
builds/ac/mainBackup/file itest.tgz
Do you wish to continue with system backup (Y/N)?
Answer Y
The system now creates a backup image by creating an exact copy of the system
partitions.
NOTE
The time for creating a backup image varies between 12 to 15 minutes.
Backing up the existing V4R1 GP7 image on the Summit WM100/
1000 Controller
The V4R1 GP7 image is not backed-up from the GUI or CLI, but from a low-level menu presented
shortly after the system boots.
NOTE
You must use the serial connection to the Summit WM100/1000 Controller to back up the V4R1 GP7 image.
NOTE
The procedure starts with a reboot.

Summit WM Maintenance Guide, Software Version 5.3 13
To back up the existing V4R1 GP7 image on the Summit WM100/1000 Controller:
1Enter the Rescue mode.
To enter the Rescue mode:
aUse the serial port of the WM100/1000 Controller to connect to the console.
NOTE
To enter the Rescue mode, you must connect to the serial port of the controller. You can not enter the Rescue
mode by connecting to the ESA ports, or management/ETH0 port.
bReboot the Summit WM Controller. The following menu appears during the reboot process.
cSelect Rescue Act Start-up, and then press Enter. The first repairFS script runs after the OS
initialization.
Attempting to Repair AC_Original Filesystems
This may take several minutes. Please do not reboot the system
Repairing / of the original fs:
fsck 1.27 (8-Mar-2002)
/: 41649/3417568 files (0.7% non-contiguous), 284504/6825609 blocks
Repairing /home of the original fs:
fsck 1.27 (8-Mar-2002)
/home: 21/256512 files (0.0% non-contiguous), 16277/512064 blocks
Repairing /var/controller/log/cdr
fsck 1.27 (8-Mar-2002)
/var/log/extreme: 11/256512 files (0.0% non-contiguous), 16264/512071 blocks
Repairing /var/controller/log/logs
fsck 1.27 (8-Mar-2002)
/var/log/extreme1: 26/192000 files (11.5% non-contiguous), 14315/383544 blocks
Repairing /var/controller/log/reports
fsck 1.27 (8-Mar-2002)
/var/log/extreme2: 11/192000 files (0.0% non-contiguous), 14240/383544 blocks
Repairing /var/controller/log/trace
fsck 1.27 (8-Mar-2002)
/var/log/extreme3: 11/192000 files (0.0% non-contiguous), 14240/383544 blocks
repairFS: finished!

Backing up the existing image
Summit WM Maintenance Guide, Software Version 5.314
NOTE
The above process may take several minutes. You must not reboot the system. After the filesystem check is
completed, the main rescue menu is displayed.
Rescue AC Start-up Menu. Use with extreme caution.
1) Force system recovery
2) Create System Backup Image
3) Display Backup Images
4) FTP Menu
5) Network Interface Menu
6) Manually run File System Check Utility (fsck)
9) Reboot
WARNING! - Forcing system recovery will erase all files, and reinstall the image
installed at the factory.
Reboot will restart the system back into Normal mode.
If you have any questions about these options, please contact Support.
Your choice>
2Creating a backup image.
To create a backup image:
aIn the Rescue mode, press 2.
Your choice: 2
Warning: All logs from the main partition will be lost due to creating a backup
image.
Warning: Any previous user backup image will be deleted first.
Proceed with image backup (Y/N):
bType Y. The following screen is displayed.
Performing system backup. Please be patient and do not reboot the box
--------------- Creating 'Normal' mode backup -----------------
Please be patient. It may take a while. Do not reboot the machine
Mount the normal mode partitions:
mounting root partition...done.
mounting rest of normal mode partitions...done.
Wipe out logs...Done.
Clean home directory...Done.
Creating a backup, please wait
Unmounting partitions...
done.
Creating a Backup image is Complete!
<< Press any key to return to previous menu. >>
NOTE
You can also upload the backed-up image to the FTP server. To back up the image to the FTP server, continue
with the following procedures.
cIn Rescue Mode, press 4. The following message is displayed.
Please enter ftp info:
dType the following string, specifying the following:
■User Name for your FTP Server. In the following example, the user name ftpadmin is used.
■Password

Summit WM Maintenance Guide, Software Version 5.3 15
■IP address
■Directory path and the file name. The following is the example of the string.
ftp://ftpadmin:[email protected]:21//builds/ac/mainBackup/backup.tgz
NOTE
You must have the write permission for the FTP Server, and the specified FTP directory on the FTP Server.
NOTE
The base directory is the home directory of the user ftpadmin. To use a directory from the root of the FTP server
you must add an extra /:, such as:
ftp://ftpadmin:[email protected]:21///home/user/backup.tgz
3Enter the Rescue mode.
aIn the Rescue mode, press 5 to enter Network Interface menu.
bIn the Network Interface menu, press 1. The following screen is displayed.
Your choice: 1
Current Rescue Interface Info
-----------------------------
Rescue IP: 192.168.10.1 Mask: 255.255.255.0
Default Gateway: <not set>
<< Press any key to return to previous menu. >>
cIn the Network Interface menu, press 2. The following message is displayed.
Your choice: 2
Please enter Interface information
Format <ip>:<netmask> <gw optional>
Input: 192.168.1.210:255.255.255.0 192.168.1.1
NOTE
You can use the Network Interface menu options from 3 to 5 (IP, Netmask, and default gateway) one at a time.
4Confirm the Network Interface is functioning.
To confirm the Network Interface is functioning:
aIn the Network Interface menu, press 6. The following message is displayed.
Your choice: 6
Enter destination ip address to ping: 192.168.3.10
bEnter the destination IP address to ping. The following messages are displayed.
Enter destination ip address to ping: 192.168.3.10
PING 192.168.3.10 (192.168.3.10) from 192.168.1.210 : 56(84) bytes of data.
64 bytes from 192.168.3.10: icmp_seq=1 ttl=63 time=2.49 ms
64 bytes from 192.168.3.10: icmp_seq=2 ttl=63 time=0.881 ms
64 bytes from 192.168.3.10: icmp_seq=3 ttl=63 time=0.706 ms
64 bytes from 192.168.3.10: icmp_seq=4 ttl=63 time=0.738 ms
64 bytes from 192.168.3.10: icmp_seq=5 ttl=63 time=0.707 ms
--- 192.168.3.10 ping statistics ---
5 packets transmitted, 5 received, 0% loss, time 4031ms
rtt min/avg/max/mdev = 0.706/1.106/2.498/0.698 ms
<< Press any key to return to previous menu. >>

Backing up the existing image
Summit WM Maintenance Guide, Software Version 5.316
NOTE
If the Network Interface is not configured properly, the following screen is displayed.
PING 192.168.3.10 (192.168.3.10) from 192.168.1.210 : 56(84) bytes of data.
ping: sendmsg: Interrupted system call
--- 192.168.3.10 ping statistics ---
9 packets transmitted, 0 received, 100% loss, time 9038ms
<< Press any key to return to previous menu. >>
5To return to the main menu, press 7. The following screen is displayed.
Your choice: 7
Going back to the MAIN menu...
6Configure the FTP settings.
aIn the Rescue mode, press 4 to configure the FTP settings. The following screen is displayed:
FTP MENU
--------------
1) Enter FTP Settings
2) Change ftp server ip address
3) Change ftp port
4) Change user name
5) Change password
6) Change ftp directory
7) Change file name
8) Display current FTP Settings
9) Display Backup Images
10) Download Image from FTP server
11) Upload Image onto the FTP server
12) Return to the main menu
Your choice:
NOTE
When uploading the backup image, the file name corresponds to the image that is being uploaded (filenames
can be displayed by entering 9in the FTP menu). When downloading a backup image, the filename corresponds
to a file that is being downloaded from the FTP server.
NOTE
The file that is downloaded from the FTP Server must have either –user-rescue.tgz, or –rescue.tgz extension. If
the file does not have a proper extension, the download will not proceed. Extension determines which backup file
(default or user created) is replaced with the new file from the FTP server.
7Configure the FTP settings.
aIn the FTP menu, press 1. The following screen is displayed.
Your choice: 1
Command syntax: ftp://<user>:<password>@<ftp_ip>:<port>/<directory&file>
~port information is optional: the default value is 21~
Please enter ftp info:
ftp://tester:[email protected]:21/backup_dir/gss-V4R0.0.50-rescue-user.tgz
8Check the FTP settings.
To check the FTP settings:

Summit WM Maintenance Guide, Software Version 5.3 17
aIn the FTP menu, press 8. The following screen is displayed.
Your choice: 8
Current Settings:
-----------------
ftp ip address: 192.168.10.10 port: 21
user name: tester
password: 123456
ftp directory: "backup_dir/"
ftp file: "gss-V4R0.0.50-rescue-user.tgz"
Press Enter to continue
9To modify the FTP settings:
aIn the FTP menu, choose options from 2 to 7 to individually set/change the FTP settings:
■FTP server’s IP address
■FTP port
■User name
■Password
■FTP directory
■File Name
10 To upload the image on the FTP server:
aIn FTP menu, press 11. The following screen is displayed:
Your choice: 11
Attempting to upload an image to the ftp server. Please be patient
Please verify at the ftp server that image has successfully been uploaded
<< Press any key to return to previous menu. >>
NOTE
The minimum backup image size is around 250 MB.
11 Confirm whether the image is backed-up:
To confirm whether the image is backed up:
aIn the FTP menu, press 9. The following screen is displayed:
Your choice: 9
{new screen comes up}
Currently stored backup images:
--------------------------------
1) Default Image: gss-V4R0.0.50-rescue.tgz
2) User Image: gss-V4R0.0.50-rescue-user.tgz
Press any key to return to previous menu

Backing up the existing image
Summit WM Maintenance Guide, Software Version 5.318
Backing up the existing V5R1/V5R3 image
This section describes you how to backup the existing V5R1/V5R3 image via the low-level menu
commands.
NOTE
The Summit WM Controller's Graphical User Interface (GUI) provides you the option of automatically backing up the
existing image prior to performing a system upgrade (Main Menu>Summit WM Controller>Software Maintenance>SWM
Software). You can use this option to backup the existing image instead of the following instructions. For more
information on using the GUI for software maintenance, see the Summit WM User Guide.
The topics in this section are organized as follows:
●Backing up the existing V5R1/V5R3 image on the Summit WM20/200/2000 Controller
●Backing up the existing V5R1/V5R3 image on the Summit WM100/1000 Controller
NOTE
Before you proceed ahead with the backup, you must ensure that the Management Port is configured correctly, and
connected to the network. You can not enter the Rescue mode without the Management Port’s connectivity to the
network. To enter the Rescue mode, you must connect to the serial port.
Backing up the existing V5R1/V5R3 image on the Summit WM20/
200/2000 Controller
The procedure for backing-up the existing V5R1/V5R1 image on the Summit WM20/200/2000
Controller via the low-level menu commands is same as described in “Backing up the existing V4R1
GP7 image on the Summit WM200/2000 Controller” on page 9. The only difference is the image that is
backed up is V5R1/V5R3.
Backing up the existing V5R1/V5R3 image on the Summit
WM100/1000 Controller
The procedure for backing-up the existing V5R1/V5R1 on Summit WM100/1000 Controller is same as
described in “Backing up the existing V4R1 GP7 image on the Summit WM100/1000 Controller” on
page 12. The only difference is the image that is backed up is V5R1/V5R3.
Backing up the existing V4R2 image on the Summit
WM20 Controller
The V4R2 image is not backed-up from the GUI or CLI, but from a low-level menu presented shortly
after the system boots.

Summit WM Maintenance Guide, Software Version 5.3 19
NOTE
You must use the serial connection to the Summit WM20 Controller to back up the V4R2 image.
NOTE
The procedure starts with a reboot.
To back up the existing V4R2 image on the Summit WM20 Controller:
1Enter the Rescue mode.
To enter the Rescue mode:
aUse the serial port of the Summit WM20 Controller to connect to the console.
NOTE
To enter the Rescue mode, you must connect to the serial port. You can not enter the Rescue mode by
connecting to the ESA ports, or management/ETH0 port.
bReboot the Summit WM Controller. The following menu appears during the reboot process
.
cSelect Controller Rescue, and then press Enter. The first repairFS script runs after the OS
initialization.
NOTE
The above process may take several minutes. You must not reboot the system. After the filesystem check is
completed, the main rescue menu is displayed.
Rescue AC Start-up Menu. Use with extreme caution.
1) Force system recovery
2) Create System Backup Image
3) Display Backup Images
4) FTP Menu

Backing up the existing image
Summit WM Maintenance Guide, Software Version 5.320
5) Network Interface Menu
6) Manually run File System Check Utility (fsck)
9) Reboot
WARNING! - Forcing system recovery will erase all files, and reinstall the image
installed at the factory.
Reboot will restart the system back into Normal mode.
If you have any questions about these options, please contact Support.
Your choice>
2Create a backup image.
To create a backup image:
aIn the Rescue mode, press 2.
Your choice: 2
Warning: All logs from the main partition will be lost due to creating a backup
image.
Warning: Any previous user backup image will be deleted first.
Proceed with image backup (Y/N):
bType Y. The following screen is displayed.
Performing system backup. Please be patient and do not reboot the box
--------------- Creating 'Normal' mode backup -----------------
Please be patient. It may take a while. Do not reboot the machine
Mount the normal mode partitions:
mounting root partition...done.
mounting rest of normal mode partitions...done.
Wipe out logs...Done.
Clean home directory...Done.
Creating a backup, please wait
Unmounting partitions...
done.
Creating a Backup image is Complete!
<< Press any key to return to previous menu. >>
NOTE
You can also upload the backed-up image to the FTP Server. To backup the image to the FTP server, continue
with the following procedures.
3Enter the Rescue mode.
aIn the Rescue mode, press 5 to enter the Network Interface menu. The following screen is
displayed.
Your choice: 1
Current Rescue Interface Info
-----------------------------
Rescue IP: 192.168.10.1 Mask: 255.255.255.0
Default Gateway: <not set>
<< Press any key to return to previous menu. >>
bIn the Network Interface menu, press 2. The following screen is displayed.
Your choice: 2
Please enter Interface information
Format <ip>:<netmask> <gw optional>
Input: 192.168.1.210:255.255.255.0 192.168.1.1
