Extreme Networks Summit 200-24 User manual

Extreme Networks, Inc.
3585 Monroe Street
Santa Clara, California 95051
[phone]
http://www.extremenetworks.com
Summit 200 Series Switch
Installation and User Guide
Software Version 6.2e.2
Published: June 2003
Part Number: 100149-00 Rev 01

2
©2003 Extreme Networks, Inc. All rights reserved. Extreme Networks and BlackDiamond are registered trademarks of
Extreme Networks, Inc. in the United States and certain other jurisdictions. ExtremeWare, ExtremeWare Vista,
ExtremeWorks, ExtremeAssist, ExtremeAssist1, ExtremeAssist2, PartnerAssist, Extreme Standby Router Protocol, ESRP,
SmartTraps, Alpine, Summit, Summit1, Summit4, Summit4/FX, Summit7i, Summit24, Summit48, Summit 200 Series,
Summit 200-24, Summit 200-48, Summit Virtual Chassis, SummitLink, SummitGbX, SummitRPS and the Extreme
Networks logo are trademarks of Extreme Networks, Inc., which may be registered or pending registration in certain
jurisdictions. The Extreme Turbodrive logo is a service mark of Extreme Networks, which may be registered or pending
registration in certain jurisdictions. Specifications are subject to change without notice.
NetWare and Novell are registered trademarks of Novell, Inc. Merit is a registered trademark of Merit Network, Inc.
Solaris is a trademark of Sun Microsystems, Inc. F5, BIG/ip, and 3DNS are registered trademarks of F5 Networks, Inc.
see/IT is a trademark of F5 Networks, Inc.
“Data Fellows”, the triangle symbol, and Data Fellows product names and symbols/logos are
trademarks of Data Fellows.
F-Secure SSH is a registered trademark of Data Fellows.
All other registered trademarks, trademarks and service marks are property of their respective owners.

Summit 200 Series Switch Installation and User Guide 3
Contents
Preface
Introduction xiii
Conventions xiv
Related Publications xiv
Chapter 1 Summit 200 Series Switch Overview
Summit 200 Series Switches 15
Summary of Features 15
Summit 200-24 Switch Physical Features 16
Summit 200-24 Switch Front View 16
Summit 200-24 Switch Rear View 18
Summit 200-48 Switch Physical Features 19
Summit 200-48 Switch Front View 19
Summit 200-48 Switch Rear View 21
Mini-GBIC Type and Hardware/Software Support 22
Mini-GBIC Type and Specifications 22
Chapter 2 Switch Installation
Determining the Switch Location 27
Following Safety Information 28
Installing the Switch 28
Rack Mounting 28
Free-Standing 29
Stacking the Switch and Other Devices 29
Connecting Equipment to the Console Port 29
Powering On the Switch 30
Checking the Installation 31

4Summit 200 Series Switch Installation and User Guide
Contents
Logging In for the First Time 31
Installing or Replacing a Mini-Gigabit Interface Connector (Mini-GBIC) 32
Safety Information 32
Preparing to Install or Replace a Mini-GBIC 32
Removing and Inserting a Mini-GBIC 33
Chapter 3 ExtremeWare Overview
Summary of Features 35
Virtual LANs (VLANs) 36
Spanning Tree Protocol 36
Quality of Service 37
Unicast Routing 37
Load Sharing 37
ESRP-Aware Switches 37
Software Licensing 38
Feature Licensing 38
Security Licensing for Features Under License Control 39
SSH2 Encryption 39
Software Factory Defaults 40
Chapter 4 Accessing the Switch
Understanding the Command Syntax 41
Syntax Helper 42
Command Shortcuts 42
Summit 200 Series Switch Numerical Ranges 42
Names 43
Symbols 43
Line-Editing Keys 43
Command History 44
Common Commands 44
Configuring Management Access 46
User Account 46
Administrator Account 47
Default Accounts 47
Creating a Management Account 48
Domain Name Service Client Services 49
Checking Basic Connectivity 50
Ping 50
Traceroute 50

Summit 200 Series Switch Installation and User Guide 5
Contents
Chapter 5 Managing the Switch
Overview 53
Using the Console Interface 54
Using Telnet 54
Connecting to Another Host Using Telnet 54
Configuring Switch IP Parameters 54
Disconnecting a Telnet Session 56
Controlling Telnet Access 57
Using Secure Shell 2 (SSH2) 57
Enabling SSH2 57
Using SNMP 58
Accessing Switch Agents 58
Supported MIBs 58
Configuring SNMP Settings 58
Displaying SNMP Settings 60
Authenticating Users 60
RADIUS Client 60
Configuring TACACS+ 65
Using Network Login 66
Using Network Login in Campus Mode 67
Using Network Login in ISP Mode 69
DHCP Server on the Switch 70
Network Login Configuration Commands 70
Displaying Network Login Settings 70
Disabling Network Login 71
Using EAPOL Flooding 71
Using the Simple Network Time Protocol 72
Configuring and Using SNTP 72
SNTP Configuration Commands 75
SNTP Example 75
Chapter 6 Configuring Ports on a Switch
Enabling and Disabling Switch Ports 77
Configuring Switch Port Speed and Duplex Setting 77
Switch Port Commands 79
Load Sharing on the Switch 80
Load-Sharing Algorithms 80
Configuring Switch Load Sharing 81
Load-Sharing Example 82
Verifying the Load-Sharing Configuration 82
Switch Port-Mirroring 82

6Summit 200 Series Switch Installation and User Guide
Contents
Port-Mirroring Commands 83
Port-Mirroring Example 83
Extreme Discovery Protocol 84
EDP Commands 84
Chapter 7 Virtual LANs (VLANs)
Overview of Virtual LANs 85
Benefits 85
Types of VLANs 86
Port-Based VLANs 86
Tagged VLANs 88
VLAN Names 90
Default VLAN 90
Renaming a VLAN 91
Configuring VLANs on the Switch 91
VLAN Configuration Commands 91
VLAN Configuration Examples 92
Displaying VLAN Settings 92
MAC-Based VLANs 93
MAC-Based VLAN Guidelines 93
MAC-Based VLAN Limitations 94
MAC-Based VLAN Example 94
Timed Configuration Download for MAC-Based VLANs 94
Chapter 8 Forwarding Database (FDB)
Overview of the FDB 97
FDB Contents 97
FDB Entry Types 97
How FDB Entries Get Added 98
Associating a QoS Profile with an FDB Entry 98
Configuring FDB Entries 99
FDB Configuration Examples 100
Displaying FDB Entries 100
Chapter 9 Access Policies
Overview of Access Policies 101
Access Control Lists 101
Rate Limits 101
Routing Access Policies 102
Using Access Control Lists 102
Access Masks 102

Summit 200 Series Switch Installation and User Guide 7
Contents
Access Lists 102
Rate Limits 103
How Access Control Lists Work 104
Access Mask Precedence Numbers 104
Specifying a Default Rule 104
The permit-established Keyword 104
Adding Access Mask, Access List, and Rate Limit Entries 105
Deleting Access Mask, Access List, and Rate Limit Entries 106
Verifying Access Control List Configurations 106
Access Control List Commands 106
Access Control List Examples 110
Using Routing Access Policies 114
Creating an Access Profile 114
Configuring an Access Profile Mode 114
Adding an Access Profile Entry 114
Deleting an Access Profile Entry 115
Applying Access Profiles 115
Routing Access Policies for RIP 115
Routing Access Policies for OSPF 117
Making Changes to a Routing Access Policy 118
Removing a Routing Access Policy 118
Routing Access Policy Commands 119
Chapter 10 Network Address Translation (NAT)
Overview 121
Internet IP Addressing 122
Configuring VLANs for NAT 122
NAT Modes 123
Configuring NAT 124
Configuring NAT Rules 124
Creating NAT Rules 125
Creating Static and Dynamic NAT Rules 125
Creating Portmap NAT Rules 125
Creating Auto-Constrain NAT Rules 126
Advanced Rule Matching 126
Configuring Timeouts 127
Displaying NAT Settings 127
Disabling NAT 128

8Summit 200 Series Switch Installation and User Guide
Contents
Chapter 11 Ethernet Automatic Protection Switching
Overview of the EAPS Protocol 129
Fault Detection and Recovery 131
Restoration Operations 132
Summit 200 Series Switches in Multi-ring Topologies 133
Commands for Configuring and Monitoring EAPS 134
Creating and Deleting an EAPS Domain 135
Defining the EAPS Mode of the Switch 135
Configuring EAPS Polling Timers 135
Configuring the Primary and Secondary Ports 136
Configuring the EAPS Control VLAN 137
Configuring the EAPS Protected VLANs 137
Enabling and Disabling an EAPS Domain 138
Enabling and Disabling EAPS 138
Unconfiguring an EAPS Ring Port 138
Displaying EAPS Status Information 138
Chapter 12 Quality of Service (QoS)
Overview of Policy-Based Quality of Service 143
Applications and Types of QoS 144
Voice Applications 144
Video Applications 144
Critical Database Applications 144
Web Browsing Applications 145
File Server Applications 145
Configuring QoS for a Port or VLAN 145
Traffic Groupings 146
Access List Based Traffic Groupings 146
MAC-Based Traffic Groupings 147
Explicit Class of Service (802.1p and DiffServ) Traffic Groupings 148
Configuring DiffServ 150
Physical and Logical Groupings 152
Verifying Configuration and Performance 153
QoS Monitor 153
Displaying QoS Profile Information 153
Modifying a QoS Configuration 154
Traffic Rate-Limiting 154
Dynamic Link Context System 154
DLCS Guidelines 155
DLCS Limitations 155
DLCS Commands 155

Summit 200 Series Switch Installation and User Guide 9
Contents
Chapter 13 Status Monitoring and Statistics
Status Monitoring 157
Port Statistics 159
Port Errors 159
Port Monitoring Display Keys 160
Setting the System Recovery Level 161
Logging 161
Local Logging 162
Remote Logging 163
Logging Configuration Changes 163
Logging Commands 164
RMON 165
About RMON 165
RMON Features of the Switch 165
Configuring RMON 166
Event Actions 167
Chapter 14 Spanning Tree Protocol (STP)
Overview of the Spanning Tree Protocol 169
Spanning Tree Domains 169
Defaults 170
STPD BPDU Tunneling 170
STP Configurations 170
Configuring STP on the Switch 172
STP Configuration Example 175
Displaying STP Settings 175
Disabling and Resetting STP 175
Chapter 15 IP Unicast Routing
Overview of IP Unicast Routing 177
Router Interfaces 178
Populating the Routing Table 179
Subnet-Directed Broadcast Forwarding 180
Proxy ARP 180
ARP-Incapable Devices 181
Proxy ARP Between Subnets 181
Relative Route Priorities 181
Configuring IP Unicast Routing 182
Verifying the IP Unicast Routing Configuration 182

10 Summit 200 Series Switch Installation and User Guide
Contents
IP Commands 183
Routing Configuration Example 187
Displaying Router Settings 188
Resetting and Disabling Router Settings 189
Configuring DHCP/BOOTP Relay 190
Verifying the DHCP/BOOTP Relay Configuration 190
UDP-Forwarding 190
Configuring UDP-Forwarding 191
UDP-Forwarding Example 191
ICMP Packet Processing 191
UDP-Forwarding Commands 192
Chapter 16 Interior Gateway Routing Protocols
Overview 193
RIP Versus OSPF 194
Overview of RIP 194
Routing Table 195
Split Horizon 195
Poison Reverse 195
Triggered Updates 195
Route Advertisement of VLANs 195
RIP Version 1 Versus RIP Version 2 195
Overview of OSPF 196
Link-State Database 196
Areas 197
Point-to-Point Support 200
Route Re-Distribution 201
Configuring Route Re-Distribution 201
OSPF Timers and Authentication 202
Configuring RIP 203
RIP Configuration Example 205
Displaying RIP Settings 206
Resetting and Disabling RIP 206
Configuring OSPF 206
Configuring OSPF Wait Interval 211
Displaying OSPF Settings 212
OSPF LSD Display 212
Resetting and Disabling OSPF Settings 213

Summit 200 Series Switch Installation and User Guide 11
Contents
Chapter 17 IP Multicast Groups and IGMP Snooping
Overview 215
Configuring IGMP and IGMP Snooping 216
Displaying IGMP Snooping Configuration Information 217
Clearing, Disabling, and Resetting IGMP Functions 217
Appendix A Safety Information
Important Safety Information 219
Power 219
Power Cord 220
Connections 220
Lithium Battery 220
Appendix B Technical Specifications
Summit 200-24 Switch 223
Summit 200-48 Switch 226
Appendix C Supported Standards
Appendix D Software Upgrade and Boot Options
Downloading a New Image 231
Rebooting the Switch 232
Saving Configuration Changes 232
Returning to Factory Defaults 233
Using TFTP to Upload the Configuration 233
Using TFTP to Download the Configuration 234
Downloading a Complete Configuration 234
Downloading an Incremental Configuration 234
Scheduled Incremental Configuration Download 234
Remember to Save 235
Upgrading and Accessing BootROM 235
Upgrading BootROM 235
Accessing the BootROM menu 235
Boot Option Commands 236

12 Summit 200 Series Switch Installation and User Guide
Contents
Appendix E Troubleshooting
LEDs 233
Using the Command-Line Interface 234
Port Configuration 235
VLANs 236
STP 237
Debug Tracing 237
TOP Command 237
Contacting Extreme Technical Support 237
Index
Index of Commands

Summit 200 Series Switch Installation and User Guide 13
Preface
This preface provides an overview of this guide, describes guide conventions, and lists other
publications that may be useful.
Introduction
This guide provides the required information to install the Summit 200 series switch and configure the
ExtremeWare™software running on the Summit 200 series switch.
This guide is intended for use by network administrators who are responsible for installing and setting
up network equipment. It assumes a basic working knowledge of:
•Local area networks (LANs)
•Ethernet concepts
•Ethernet switching and bridging concepts
•Routing concepts
•Internet Protocol (IP) concepts
•Simple Network Management Protocol (SNMP)
NOTE
If the information in the release notes shipped with your switch differs from the information in this guide,
follow the release notes.

14 Summit 200 Series Switch Installation and User Guide
Conventions
Table 1 and Table 2 list conventions that are used throughout this guide.
Related Publications
The publications related to this one are:
•ExtremeWare Release Notes
•Summit 200 Series Switch Release Notes
Documentation for Extreme Networks products is available on the World Wide Web at the following
location:
•http://www.extremenetworks.com/
Table 1: Notice Icons
Icon Notice Type Alerts you to...
Note Important features or instructions.
Caution Risk of personal injury, system damage, or loss of data.
Warning Risk of severe personal injury.
Table 2: Text Conventions
Convention Description
Screen displays This typeface indicates command syntax, or represents information as
it appears on the screen.
The words “enter”
and “type” When you see the word “enter” in this guide, you must type something, and then press the Return or Enter key. Do not press the Return or
Enter key when an instruction simply says “type.”
[Key] names Key names are written with brackets, such as [Return] or [Esc].
If you must press two or more keys simultaneously, the key names are
linked with a plus sign (+). Example:
Press [Ctrl]+[Alt]+[Del].
Words in italicized type Italics emphasize a point or denote new terms at the place where they
are defined in the text.

Summit 200 Series Switch Installation and User Guide 15
1Summit 200 Series Switch Overview
This chapter describes the features and functionality of the Summit 200 series switches:
•Summit 200 Series Switches on page 15
•Summary of Features on page 15
•Summit 200-24 Switch Physical Features on page 16
•Summit 200-48 Switch Physical Features on page 19
•Mini-GBIC Type and Hardware/Software Support on page 22
Summit 200 Series Switches
The Summit 200 series switches include the following switch models:
•Summit 200-24 switch
•Summit 200-48 switch
Summary of Features
The Summit 200 series switches support the following ExtremeWare features:
•Virtual local area networks (VLANs) including support for IEEE 802.1Q and IEEE 802.1p
•Spanning Tree Protocol (STP) (IEEE 802.1D)
•Quality of Service (QoS) including support for IEEE 802.1p, MAC QoS, and four hardware queues
•Wire-speed Internet Protocol (IP) routing
•DHCP/BOOTP Relay
•Network Address Translation (NAT)
•Extreme Standby Router Protocol (ESRP) - Aware support
•Ethernet Automated Protection Switching (EAPS) support
•Routing Information Protocol (RIP) version 1 and RIP version 2
•Open Shortest Path First (OSPF) routing protocol
•DiffServ support

16 Summit 200 Series Switch Installation and User Guide
Summit 200 Series Switch Overview
•Access-policy support for routing protocols
•Access list support for packet filtering
•Access list support for rate-limiting
•IGMP snooping to control IP multicast traffic
•Load sharing on multiple ports
•RADIUS client and per-command authentication support
•TACACS+ support
•Network Login
•Console command-line interface (CLI) connection
•Telnet CLI connection
•SSH2 connection
•Simple Network Management Protocol (SNMP) support
•Remote Monitoring (RMON)
•Traffic mirroring for ports
Summit 200-24 Switch Physical Features
The Summit 200-24 switch is a compact enclosure (see Figure 1) one rack unit in height (1.75 inches or
44.45 mm) that provides 24 autosensing 10BASE-T/100BASE-TX ports using RJ-45 connectors. It also
provides two 10/100/1000BASE-T Gigabit Ethernet uplink ports using RJ-45 connectors and two optical
ports that also allow Gigabit Ethernet uplink connections through Extreme 1000BASE-SX, 1000BASE-LX,
or 1000BASE-ZX Small Form Factor pluggable (SFP) Gigabit Interface Connectors (GBICs)—also known
as mini-GBICs—using LC optical fiber connectors.
Summit 200-24 Switch Front View
Figure 1 shows the Summit 200-24 switch front view.
Figure 1: Summit 200-24 switch front view
NOTE
See Table 5 for information about supported mini-GBIC types and distances.
LC24001A
10/100 Mbps ports Console
port
Mini-GBIC
port status LEDs Unit stacking
ID LED
Mini-GBIC ports1000-baseT ports

Summit 200-24 Switch Physical Features
Summit 200 Series Switch Installation and User Guide 17
NOTE
See “Summit 200-24 Switch LEDs” on page 17 for more details.
Console Port
Use the console port (9-pin, “D” type connector) for connecting a terminal and carrying out local
management.
Port Connections
The Summit 200-24 switch has 24 10BASE-T/100BASE-TX ports using RJ-45 connectors for
communicating with end stations and other devices over 10/100Mbps Ethernet.
The switch also has four Gigabit Ethernet uplink ports. These ports are labeled 25 and 26 on the front
panel of the switch. Two of the ports are 10/100/1000BASE-T ports using RJ-45 connectors. The other
two ports are unpopulated receptacles for mini-SFP GBICs, using optical fibers with LC connectors. The
Summit 200-24 switch supports the use of 1000BASE-SX, 1000BASE-LX, or 1000BASE-ZX mini-GBICs.
NOTE
Only mini-GBICs that have been certified by Extreme Networks (available from Extreme Networks)
should be inserted into the mini-GBIC receptacles on the Summit 200 series switch.
Only two of the four Gigabit Ethernet uplink ports can be active at one time. For example, you can use
both 1000BASE-T ports, both mini-GBIC ports, or a combination of one 1000BASE-T port and one
mini-GBIC.
NOTE
For information on the mini-GBIC, see “Mini-GBIC Type and Hardware/Software Support” on page 22.
Full-Duplex
The Summit 200-24 switch provides full-duplex support for all ports. Full-duplex allows frames to be
transmitted and received simultaneously and, in effect, doubles the bandwidth available on a link. All
10/100 Mbps ports on the Summit 200-24 switch autonegotiate for half- or full-duplex operation.
Summit 200-24 Switch LEDs
Table 3 describes the light emitting diode (LED) behavior on the Summit 200-24 switch.

18 Summit 200 Series Switch Installation and User Guide
Summit 200 Series Switch Overview
Summit 200-24 Switch Rear View
Figure 2 shows the rear view of the Summit 200-24 switch.
Figure 2: Summit 200-24 switch rear view
Table 3: Summit 200-24 switch LED behavior
Unit Status LED (MGMT LED)
Color Indicates
Green solid
Green blinking
Amber
The Summit switch is operating normally.
The Summit switch POST is in progress.
The Summit switch has failed its POST or an overheat condition
is detected.
Fan LED
Color Indicates
Green
Amber blinking The fan is operating normally. A failed condition is present on the fan.
Port Status LEDs (Ports 1–26)
Color Indicates
Green
Green blinking
Off
Link is present; port is enabled.
Link is present, port is enabled, and there is activity on the port.
Link is not present or the port is disabled.
Media-Selection (Fiber) LEDs (Ports 25 and 26)
Color Indicates
Green
Off
Fiber link is selected; mini-GBIC is present and being used for the
Gigabit Ethernet uplink.
1000BASE-T link is selected; the switch is using the RJ-45 port
for the Gigabit Ethernet uplink.
Unit Stacking ID Number LED
Color Indicates
N/A When several Summit 200-24 switches are interconnected
(stacked), each switch will be assigned a unique stacking ID
number that will be visible in the unit stacking ID number LED.
The switch acting as the stack master will be assigned the
number 0, which is the default.
LC24002
Power socket

Summit 200-48 Switch Physical Features
Summit 200 Series Switch Installation and User Guide 19
Power Socket
The Summit 200-24 switch automatically adjusts to the supply voltage. The power supply operates
down to 90 V.
Serial Number
Use this serial number for fault-reporting purposes.
MAC Address
This label shows the unique Ethernet MAC address assigned to this device.
NOTE
The Summit 200-24 switch certification and safety label is located on the bottom of the switch.
Summit 200-48 Switch Physical Features
The Summit 200-48 switch is a compact enclosure (see Figure 3) one rack unit in height (1.75 inches or
44.45 mm) that provides 48 autosensing 10BASE-T/100BASE-TX ports using RJ-45 connectors. It also
provides two 10/100/1000BASE-T Gigabit Ethernet uplink ports using RJ-45 connectors and two optical
ports that also allow Gigabit Ethernet uplink connections through Extreme 1000BASE-SX, 1000BASE-LX,
or 1000BASE-ZX SFP mini-GBICs using optical fibers with LC connectors.
Summit 200-48 Switch Front View
Figure 3 shows the Summit 200-48 switch front view.
Figure 3: Summit 200-48 switch front view
NOTE
See Table 5 for information about supported mini-GBIC types and distances.
NOTE
See “Summit 200-48 Switch LEDs” on page 21 for more details.
LC48001
10/100 Mbps ports Console
port
1000-baseT ports
Mini-GBIC ports

20 Summit 200 Series Switch Installation and User Guide
Summit 200 Series Switch Overview
Console Port
Use the console port (9-pin, “D” type connector) for connecting a terminal and carrying out local
management.
Port Connections
The Summit 200-48 switch has 48 10BASE-T/100BASE-TX ports using RJ-45 connectors for
communicating with end stations and other devices over 10/100Mbps Ethernet.
The switch also has four Gigabit Ethernet uplink ports. These ports are labeled 49 and 50 on the front
panel of the switch. Two of the ports are 10/100/1000BASE-T ports using RJ-45 connectors. The other
two ports are unpopulated receptacles for mini-SFP GBICs, using optical fibers with LC connectors. The
Summit 200-48 switch supports the use of 1000BASE-SX, 1000BASE-LX, or 1000BASE-ZX mini-GBICs.
NOTE
Only mini-GBICs that have been certified by Extreme Networks (available from Extreme Networks)
should be inserted into the mini-GBIC receptacles on the Summit 200 series switch.
Only two of the four Gigabit Ethernet uplink ports can be active at one time. For example, you can use
both 1000BASE-T ports, both mini-GBIC ports, or a combination of one 1000BASE-T port and one
mini-GBIC.
NOTE
For information on the mini-GBIC, see “Mini-GBIC Type and Hardware/Software Support” on page 22.
NOTE
When configuring the Summit 200-48 switch, all ports specified as mirrored ports and mirroring port, or
ACL ingress ports and egress port, must belong to the same port group. Port group 1 consists of ports
1 through 24 and port 49; port group 2 consists of ports 25 through 48 and port 50.
Full-Duplex
The Summit 200-48 switch provides full-duplex support for all ports. Full-duplex allows frames to be
transmitted and received simultaneously and, in effect, doubles the bandwidth available on a link. All
10/100 Mbps ports on the Summit 200-48 switch autonegotiate for half- or full-duplex operation.
