Summit24e3 Switch
Installation and User Guide
Software Version 2.0
Published: August 2002
Part number: 100102-00 Rev. 02

2
©2002 Extreme Networks, Inc. All rights reserved. Extreme Networks and BlackDiamond are registered trademarks of
Extreme Networks, Inc. in the United States and certain other jurisdictions. ExtremeWare, ExtremeWare Vista,
ExtremeWorks, ExtremeAssist, ExtremeAssist1, ExtremeAssist2, PartnerAssist, Extreme Standby Router Protocol, ESRP,
SmartTraps, Alpine, Summit, Summit1, Summit4, Summit4/FX, Summit7i, Summit24, Summit48, Summit Virtual
Chassis, SummitLink, SummitGbX, SummitRPS and the Extreme Networks logo are trademarks of Extreme Networks,
Inc., which may be registered or pending registration in certain jurisdictions. The Extreme Turbodrive logo is a service
mark of Extreme Networks, which may be registered or pending registration in certain jurisdictions. Specifications are
subject to change without notice.
NetWare and Novell are registered trademarks of Novell, Inc. Merit is a registered trademark of Merit Network, Inc.
Solaris is a trademark of Sun Microsystems, Inc. F5, BIG/ip, and 3DNS are registered trademarks of F5 Networks, Inc.
see/IT is a trademark of F5 Networks, Inc.
“Data Fellows”, the triangle symbol, and Data Fellows product names and symbols/logos are
trademarks of Data Fellows.
F-Secure SSH is a registered trademark of Data Fellows.
All other registered trademarks, trademarks and service marks are property of their respective owners.
Authors: Megan Mahar, Hugh Bussell
Editor:
Production:
Special Thanks: Andy Jeyanandan, Victor Tseng

Summit24e3 Switch Installation and User Guide 3
Contents
Preface
Introduction 17
Conventions 17
Related Publications 18
Chapter 1 Summit24e3 Switch Overview
Summary of Features 19
Summit24e3 Switch Front View 20
Console Port 20
Reset Button 20
Summit24e3 Switch Rear View 21
Power Socket 21
Serial Number 21
MAC Address 21
Summit24e3 Switch LEDs 21
Port Connections 22
Full-Duplex 22
Mini-GBIC Type and Hardware/Software Support 22
Mini-GBIC Type and Specifications 22
Safety Information 23
Chapter 2 Switch Installation
Determining the Switch Location 25
Following Safety Information 26
Installing the Switch 26
Rack Mounting 26
Free-Standing 27
Stacking the Switch and Other Devices 27

4 - Contents Summit24e3 Switch Installation and User Guide
Connecting Equipment to the Console Port 27
Powering On the Switch 28
Checking the Installation 28
Logging In for the First Time 29
Installing or Replacing a Mini-Gigabit Interface Connector (Mini-GBIC) 30
Safety Information 30
Preparing to Install or Replace a Mini-GBIC 30
Installing and Removing a Mini-GBIC 31
Chapter 3 ExtremeWare Overview
Summary of Features 33
Virtual LANs (VLANs) 34
Spanning Tree Protocol 34
Quality of Service 35
Unicast Routing 35
Load Sharing 35
ESRP-Aware Switches 35
Software Licensing 36
Feature Licensing 36
Security Licensing 37
Obtaining a Security License 37
Security Features Under License Control 37
Software Factory Defaults 38
Chapter 4 Accessing the Switch
Understanding the Command Syntax 39
Syntax Helper 40
Command Shortcuts 40
Summit24e3 Switch Numerical Ranges 40
Names 41
Symbols 41
Line-Editing Keys 41
Command History 42
Common Commands 42
Configuring Management Access 44
User Account 44
Administrator Account 45
Default Accounts 45
Creating a Management Account 46
Domain Name Service Client Services 47

Summit24e3 Switch Installation and User Guide Contents - 5
Checking Basic Connectivity 47
Ping 48
Traceroute 48
Chapter 5 Managing the Switch
Overview 49
Using the Console Interface 50
Using Telnet 50
Connecting to Another Host Using Telnet 50
Configuring Switch IP Parameters 50
Disconnecting a Telnet Session 52
Controlling Telnet Access 52
Using Secure Shell 2 (SSH2) 53
Enabling SSH2 53
Using SNMP 54
Accessing Switch Agents 54
Supported MIBs 54
Configuring SNMP Settings 54
Displaying SNMP Settings 55
Authenticating Users 56
RADIUS Client 56
Configuring TACACS+ 60
Using Network Login 62
Using Network Login in Campus Mode 62
Using Network Login in ISP Mode 65
DHCP Server on the Switch 66
Network Login Configuration Commands 66
Displaying Network Login Settings 66
Disabling Network Login 67
Using the Simple Network Time Protocol 67
Configuring and Using SNTP 67
SNTP Configuration Commands 69
SNTP Example 70
Chapter 6 Configuring Ports on a Switch
Enabling and Disabling Switch Ports 71
Configuring Switch Port Speed and Duplex Setting 71
Switch Port Commands 72
Load Sharing on the Switch 73
Load-Sharing Algorithms 73
Configuring Switch Load Sharing 74
Load-Sharing Example 75

6 - Contents Summit24e3 Switch Installation and User Guide
Verifying the Load-Sharing Configuration 75
Switch Port-Mirroring 75
Port-Mirroring Commands 76
Port-Mirroring Example 76
Extreme Discovery Protocol 76
EDP Commands 77
Chapter 7 Virtual LANs (VLANs)
Overview of Virtual LANs 79
Benefits 79
Types of VLANs 80
Port-Based VLANs 80
Tagged VLANs 82
VLAN Names 84
Default VLAN 84
Renaming a VLAN 85
Configuring VLANs on the Switch 85
VLAN Configuration Commands 85
VLAN Configuration Examples 86
Displaying VLAN Settings 86
Chapter 8 Forwarding Database (FDB)
Overview of the FDB 87
FDB Contents 87
FDB Entry Types 87
How FDB Entries Get Added 88
Associating a QoS Profile with an FDB Entry 88
Configuring FDB Entries 88
FDB Configuration Examples 90
Displaying FDB Entries 90
Chapter 9 Access Policies
Overview of Access Policies 91
Access Control Lists 91
Rate Limits 91
Routing Access Policies 92
Using Access Control Lists 92
Access Masks 92
Access Lists 92
Rate Limits 93
How Access Control Lists Work 94

Summit24e3 Switch Installation and User Guide Contents - 7
Access Mask Precedence Numbers 94
Specifying a Default Rule 94
The permit-established Keyword 95
Adding Access Mask, Access List, and Rate Limit Entries 95
Deleting Access Mask, Access List, and Rate Limit Entries 96
Verifying Access Control List Configurations 96
Access Control List Commands 96
Access Control List Examples 100
Using Routing Access Policies 104
Creating an Access Profile 104
Configuring an Access Profile Mode 104
Adding an Access Profile Entry 104
Deleting an Access Profile Entry 105
Applying Access Profiles 105
Routing Access Policies for RIP 105
Routing Access Policies for OSPF 107
Making Changes to a Routing Access Policy 108
Removing a Routing Access Policy 108
Routing Access Policy Commands 109
Chapter 10 Network Address Translation
(NAT)
Overview 111
Internet IP Addressing 112
Configuring VLANs for NAT 112
NAT Modes 113
Configuring NAT 114
Configuring NAT Rules 114
Creating NAT Rules 114
Creating Static and Dynamic NAT Rules 115
Creating Portmap NAT Rules 115
Creating Auto-Constrain NAT Rules 115
Advanced Rule Matching 116
Configuring Timeouts 116
Displaying NAT Settings 117
Disabling NAT 117
Chapter 11 Ethernet Automatic Protection Switching
Overview of the EAPS Protocol 119
Fault Detection and Recovery 121
Restoration Operations 123

8 - Contents Summit24e3 Switch Installation and User Guide
Commands for Configuring and Monitoring EAPS 123
Creating and Deleting an EAPS Domain 124
Defining the EAPS Mode of the Switch 125
Configuring EAPS Polling Timers 125
Configuring the Primary and Secondary Ports 126
Configuring the EAPS Control VLAN 126
Configuring the EAPS Protected VLANs 127
Enabling and Disabling an EAPS Domain 127
Enabling and Disabling EAPS 128
Unconfiguring an EAPS Ring Port 128
Displaying EAPS Status Information 128
Chapter 12 Quality of Service (QoS)
Overview of Policy-Based Quality of Service 133
Applications and Types of QoS 134
Voice Applications 134
Video Applications 134
Critical Database Applications 134
Web Browsing Applications 135
File Server Applications 135
Configuring QoS for a Port or VLAN 135
Traffic Groupings 136
Access List Based Traffic Groupings 136
MAC-Based Traffic Groupings 137
Explicit Class of Service (802.1p and DiffServ) Traffic Groupings 138
Configuring DiffServ 140
Physical and Logical Groupings 142
Verifying Configuration and Performance 143
QoS Monitor 143
Displaying QoS Profile Information 143
Modifying a QoS Configuration 144
Traffic Rate-Limiting 144
Dynamic Link Context System 144
DLCS Guidelines 145
DLCS Limitations 145
DLCS Commands 145
Chapter 13 Status Monitoring and Statistics
Status Monitoring 147
Port Statistics 149
Port Errors 149

Summit24e3 Switch Installation and User Guide Contents - 9
Port Monitoring Display Keys 150
Setting the System Recovery Level 151
Logging 151
Local Logging 152
Remote Logging 153
Logging Configuration Changes 153
Logging Commands 153
RMON 155
About RMON 155
RMON Features of the Switch 155
Configuring RMON 156
Event Actions 157
Chapter 14 Spanning Tree Protocol (STP)
Overview of the Spanning Tree Protocol 159
Spanning Tree Domains 159
Defaults 160
STPD BPDU Tunneling 160
STP Configurations 160
Configuring STP on the Switch 162
STP Configuration Example 165
Displaying STP Settings 165
Disabling and Resetting STP 165
Chapter 15 IP Unicast Routing
Overview of IP Unicast Routing 167
Router Interfaces 168
Populating the Routing Table 168
Subnet-Directed Broadcast Forwarding 170
Proxy ARP 170
ARP-Incapable Devices 170
Proxy ARP Between Subnets 171
Relative Route Priorities 171
Configuring IP Unicast Routing 172
Verifying the IP Unicast Routing Configuration 172
IP Commands 172
Routing Configuration Example 177
Displaying Router Settings 178
Resetting and Disabling Router Settings 178

10 - Contents Summit24e3 Switch Installation and User Guide
Configuring DHCP/BOOTP Relay 179
Verifying the DHCP/BOOTP Relay Configuration 180
UDP-Forwarding 180
Configuring UDP-Forwarding 180
UDP-Forwarding Example 181
ICMP Packet Processing 181
UDP-Forwarding Commands 181
Chapter 16 Interior Gateway Routing Protocols
Overview 183
RIP Versus OSPF 184
Overview of RIP 184
Routing Table 185
Split Horizon 185
Poison Reverse 185
Triggered Updates 185
Route Advertisement of VLANs 185
RIP Version 1 Versus RIP Version 2 185
Overview of OSPF 186
Link-State Database 186
Areas 187
Point-to-Point Support 190
Route Re-Distribution 191
Configuring Route Re-Distribution 191
OSPF Timers and Authentication 192
Configuring RIP 192
RIP Configuration Example 195
Displaying RIP Settings 196
Resetting and Disabling RIP 196
Configuring OSPF 197
Configuring OSPF Wait Interval 201
Displaying OSPF Settings 202
OSPF LSD Display 202
Resetting and Disabling OSPF Settings 203
Chapter 17 IP Multicast Routing
Overview 205
IGMP Overview 205
Configuring IP Multicasting Routing 206
Displaying IP Multicast Routing Settings 207

Summit24e3 Switch Installation and User Guide Contents - 11
Deleting and Resetting IP Multicast Settings 208
Appendix A Safety Information
Important Safety Information 209
Power 209
Power Cord 210
Connections 210
Lithium Battery 210
Appendix B Technical Specifications
Appendix C Supported Standards
Appendix D Software Upgrade and Boot Options
Downloading a New Image 217
Rebooting the Switch 218
Saving Configuration Changes 219
Returning to Factory Defaults 219
Using TFTP to Upload the Configuration 219
Using TFTP to Download the Configuration 221
Downloading a Complete Configuration 221
Downloading an Incremental Configuration 221
Scheduled Incremental Configuration Download 222
Remember to Save 222
Upgrading and Accessing BootROM 222
Upgrading BootROM 222
Accessing the BootROM menu 223
Boot Option Commands 223
Appendix E Troubleshooting
LEDs 225
Using the Command-Line Interface 226
Port Configuration 227
VLANs 228
STP 229
Debug Tracing 229
TOP Command 229
Contacting Extreme Technical Support 229

12 - Contents Summit24e3 Switch Installation and User Guide
Index
Index of Commands

Summit24e3 Switch Installation and User Guide 13
Figures
1Summit24e3 switch front view 20
2Summit24e3 switch rear view 21
3Fitting the mounting bracket 26
4Null-modem cable pin-outs 28
5PC-AT serial null-modem cable pin-outs 28
6Mini-GBIC modules 31
7Example of a port-based VLAN on the Summit24e3 switch 80
8Single port-based VLAN spanning two switches 81
9Two port-based VLANs spanning two switches 81
10 Physical diagram of tagged and untagged traffic 83
11 Logical diagram of tagged and untagged traffic 83
12 Permit-established access list example topology 100
13 Access control list denies all TCP and UDP traffic 101
14 Access list allows TCP traffic 102
15 Host A initiates a TCP session to host B 102
16 Permit-established access list filters out SYN packet to destination 103
17 ICMP packets are filtered out 103
18 RIP access policy example 106
19 OSPF access policy example 108
20 NAT Overview 111
21 Gigabit Ethernet fiber EAPS MAN ring 120
22 EAPS operation 121
23 EAPS fault detection and protection switching 122
24 Ethernet packet encapsulation 138
25 IP packet header encapsulation 140
26 Multiple Spanning Tree Domains 161
27 Tag-based STP configuration 162
28 Routing between VLANs 168
29 Unicast routing configuration example 177
30 Virtual link using Area 1 as a transit area 189
31 Virtual link providing redundancy 190
32 Route re-distribution 191
33 RIP configuration example 195

14 - Figures Summit24e3 Switch Installation and User Guide

Summit24e3 Switch Installation and User Guide 15
Tables
1Notice Icons 17
2Text Conventions 18
3Summit24e3 Switch LED Behavior 21
4Mini-GBIC Types and Distances 23
51000BASE-SX Specifications 23
6Console Connector Pinouts 27
7ExtremeWare Summit24e3 Factory Defaults 38
8Command Syntax Symbols 41
9Line-Editing Keys 41
10 Common Commands 42
11 Default Accounts 45
12 DNS Commands 47
13 Ping Command Parameters 48
14 SNMP Configuration Commands 55
15 RADIUS Commands 57
16 TACACS+ Commands 61
17 Network Login Configuration Commands 66
18 Greenwich Mean Time Offsets 68
19 SNTP Configuration Commands 69
20 Switch Port Commands 72
21 Switch Port-Mirroring Configuration Commands 76
22 EDP Commands 77
23 VLAN Configuration Commands 85
24 FDB Configuration Commands 89
25 Access Control List Configuration Commands 97
26 Routing Access Policy Configuration Commands 109
27 NAT Configuration Commands 114
28 NAT Timeout Commands 116
29 EAPS Commands 123
30 show eaps Display Fields 129
31 Traffic Type and QoS Guidelines 135
32 QoS Configuration Commands 135
33 Traffic Groupings by Precedence 136

16 - Tables Summit24e3 Switch Installation and User Guide
34 802.1p Priority Value-to-QoS Profile to Hardware Queue Default Mapping 139
35 802.1p Configuration Commands 139
36 DiffServ Configuration Commands 140
37 Default Code Point-to-QoS Profile Mapping 141
38 DLCS Configuration Commands 145
39 Status Monitoring Commands 147
40 Port Monitoring Display Keys 150
41 Fault Levels Assigned by the Switch 151
42 Fault Log Subsystems 152
43 Logging Commands 153
44 Event Actions 157
45 STP Configuration Commands 163
46 STP Disable and Reset Commands 165
47 Relative Route Priorities 171
48 Basic IP Commands 173
49 Route Table Configuration Commands 174
50 ICMP Configuration Commands 175
51 Router Show Commands 178
52 Router Reset and Disable Commands 178
53 UDP-Forwarding Commands 181
54 LSA Type Numbers 186
55 OSPF Link Types 190
56 RIP Configuration Commands 192
57 RIP Show Commands 196
58 RIP Reset and Disable Commands 196
59 OSPF Configuration Commands 197
60 OSPF Show Commands 202
61 OSPF Reset and Disable Commands 203
62 IGMP Configuration Commands 207
63 IP Multicast Routing Show Commands 207
64 IP Multicast Routing Reset and Disable Commands 208
65 Boot Option Commands 223

Summit24e3 Switch Installation and User Guide 17
Preface
This preface provides an overview of this guide, describes guide conventions, and lists other
publications that may be useful.
Introduction
This guide provides the required information to install the Summit24e3 switch and configure the
ExtremeWare™software running on the Summit24e3 switch.
This guide is intended for use by network administrators who are responsible for installing and setting
up network equipment. It assumes a basic working knowledge of:
•Local area networks (LANs)
•Ethernet concepts
•Ethernet switching and bridging concepts
•Routing concepts
•Internet Protocol (IP) concepts
•Simple Network Management Protocol (SNMP)
NOTE
If the information in the release notes shipped with your switch differs from the information in this guide,
follow the release notes.
Conventions
Table 1 and Table 2 list conventions that are used throughout this guide.
Table 1: Notice Icons
Icon Notice Type Alerts you to...
Note Important features or instructions.

18 Summit24e3 Switch Installation and User Guide
Preface
Related Publications
The publications related to this one are:
•ExtremeWare Release Notes
•Summit24e3 Switch Release Notes
Documentation for Extreme Networks products is available on the World Wide Web at the following
location:
•http://www.extremenetworks.com/
Caution Risk of personal injury, system damage,
or loss of data.
Warning Risk of severe personal injury.
Table 2: Text Conventions
Convention Description
Screen displays This typeface indicates command syntax, or represents information
as it appears on the screen.
The words “enter”
and “type” When you see the word “enter” in this guide, you must type something, and then press the Return or Enter key. Do not press the
Return or Enter key when an instruction simply says “type.”
[Key] names Key names are written with brackets, such as [Return] or [Esc].
If you must press two or more keys simultaneously, the key names
are linked with a plus sign (+). Example:
Press [Ctrl]+[Alt]+[Del].
Words in italicized type Italics emphasize a point or denote new terms at the place where
they are defined in the text.
Table 1: Notice Icons (continued)
Icon Notice Type Alerts you to...

Summit24e3 Switch Installation and User Guide 19
1Summit24e3 Switch Overview
This chapter describes the features and functionality of the Summit24e3 switch:
•Summary of Features on page 19
•Summit24e3 Switch Front View on page 20
•Summit24e3 Switch Rear View on page 21
•Summit24e3 Switch LEDs on page 21
•Mini-GBIC Type and Hardware/Software Support on page 22
Summary of Features
The Summit24e3 supports the following ExtremeWare features:
•Virtual local area networks (VLANs) including support for IEEE 802.1Q and IEEE 802.1p
•Spanning Tree Protocol (STP) (IEEE 802.1D)
•Quality of Service (QoS) including support for IEEE 802.1p, MAC QoS, and four hardware queues
•Wire-speed Internet Protocol (IP) routing
•DHCP/BOOTP Relay
•Network Address Translation (NAT)
•Extreme Standby Router Protocol (ESRP) - Aware support
•Ethernet Automated Protection Switching (EAPS) support
•Routing Information Protocol (RIP) version 1 and RIP version 2
•Open Shortest Path First (OSPF) routing protocol
•Wire-speed IP multicast routing support
•DiffServ support
•Access-policy support for routing protocols
•Access list support for packet filtering
•Access list support for rate-limiting
•IGMP snooping to control IP multicast traffic
•Load sharing on multiple ports

20 Summit24e3 Switch Installation and User Guide
Summit24e3 Switch Overview
•RADIUS client and per-command authentication support
•TACACS+ support
•Network Login
•Console command-line interface (CLI) connection
•Telnet CLI connection
•SSH2 connection
•Simple Network Management Protocol (SNMP) support
•Remote Monitoring (RMON)
•Traffic mirroring for ports
Summit24e3 Switch Front View
Figure 1 shows the Summit24e3 switch front view.
Figure 1: Summit24e3 switch front view
The Summit24e3 switch has 24 autosensing 10BASE-T/100BASE-TX ports using RJ-45 connectors and
provides two unpopulated Extreme mini-GBIC ports using LC connectors. You can use the
1000BASE-SX mini-GBIC in the Summit24e3 switch.
Console Port
Use the console port (9-pin, “D”type connector) for connecting a terminal and carrying out local
management.
Reset Button
The reset button is used to hard reset the switch. Use a non-conductive tool to push the reset button.
NOTE
See Table 4 for information about supported mini-GBIC types and distances.
Mini-GBIC ports
Mini-GBIC
port status LEDs
Reset SH_24e3
10/100 Mbps ports
Console
port
