Extron electronics MEDIALINK MLC 206 User manual

The Extron MediaLink™ Controller (MLC 206) provides infrared (IR) and RS‑232
remote control of a display device, contact closure control of items in a room, tally
outputs, and MediaLink Switcher control.
This guide provides instructions for an experienced installer to set up and operate
the MLC 206 MediaLink Controller.
When possible in the following pages, line drawings are used to clarify steps
discussed in the text.
Setup Guide — MLC 206
68-601-50
Rev. A
11 09
MLC 206 typical application diagram
VCR
Extron
Switcher
DVD Laptop
Extron MLC 206
Lighting
Control
Switcher
Control
Screen
Control
Projector
Control
100-240V 0.2A 50/60 Hz
AUDIO OUT
INPUT 1
VIDEOR-Y
LR
YUV
Y
R-Y
B-Y
VIDEO
S-VIDEO
Y
C
INPUT 2
VIDEO
Y
R-Y
LR
INPUT 3
Y
B-Y
LR
INPUT 4
LR
INPUT 5
B
LR
RGB
RH/
HV
GV
B
LR
AUX/MIX
LR
EFFECTS
LR
SEND
LR
RETURN
COMM LINK
ABCDE
RS232
CONTACT CLOSURE
4 ohm
MONO AMPLIFIED OUTPUT
COMM8 ohm70V
Document
Camera
Extron
MLC 206
DISPLAY
POWER
VOLUME
MAX/
MIN
VCRDVDLaptop

MLC 206 Setup Guide, cont’d
2
Step 1 — Computer Connection
The MLC 206 must be connected to a PC in order to configure the controller. The
configuration port, shown in the rear panel view below, is used for system control
and for loading configuration and driver files into the MLC.
1. Connect a host computer to the MLC 206 Config port via the rear
panel 9‑pin HD female RS‑232 connector. Use a serial cable with
9‑pin D connectors.
A B C D E A B C
IR
Display/Source Control
Extron Switcher Control
Relays IR/RCM
RS-232
D E A B C A BD
1A 1B 2A 2B 3A 3B 123456
Tally Out MLS /Power
33-644-01 A 07 01
Config
9-pin
D Connector
Host Desktop
Computer
RS-232
Configuration Port
2. Connect all control modules that will be used in the system.
N Control modules must be connected at this time so they can be configured
with the software. Connections for IR and serial control can be installed
after configuration.
MLC 206
IR / RCM
port
MLC IR-IRCM wiring_01-05.eps
A B C D
IR / RCM
IRCM control
module(s)
A B C D E Control
module
connector
CC
+12 VDC
Control signal (IRCM)
Ground ( ) B
B
A
A
MLC 206 to a control module
Total distance from
MLC: 150' (45.7 m) max.
MLC 206
Extron
DISPLAY
POWER
VOLUME
MAX
MIN
VCR DVD Laptop
MLC 206
IRCM-DV+
DVD & VCR CONTROL
PLAY NEXT/FWD PAUSE STOP
TUNER
Tx
PREV/REW
ENTER
TITLE MENU
TV/VCR
DVD VCR

3
3. To power the MLC, connect a 12 VDC power supply or an optional
MediaLink Switcher (MLS) to the MLS/Power port, and connect the power
supply or the switcher to a power source.
MediaLink Switcher
MLC/RS-232
A B
MLC 206 powered by a MediaLink Switcher
Connecting an MLC 206 to an external power supply
MLC 206
MLS/Power
port
MLC
MLS/Power
port
A B
MLS / Power
Ground ( )
+12 VDC input
0 A ground wire must be connected
between the MLC and MLS.
Ground ( )
+12VDC
Transmit (Tx)
BReceive (Rx)
A
A B
MLS / Power
Transmit (Tx)
Receive (Rx)
+12VDC
Ground ( )
B
A
Ground all devices
An external
power supply
(12 VDC, 1 A max.)
Step 2 — Software Installation
The MLC must be configured before it can send commands to the projector or other
devices. Install the MediaLink Control Program software on the host PC. To install
the software, run SETUP.EXE from the Extron‑provided disk. Follow the instructions
that appear on the screen.
N The software is also available at www.extron.com.

MLC 206 Setup Guide, cont’d
4
Step 3 — Setting up projector control
Device drivers allow the MLC 206 to control projectors and other source devices via
RS‑232 or IR.
N It is strongly recommended that an RS-232 control (filenameRS1.mll) file for
controlling a projector be used whenever possible.
To load a driver and configure the MLC 206:
1. Start the MediaLink Control Program.
The appearance of the screens varies depending on which
accessories (control modules and/or MediaLink Switcher)
are connected to the MLC, as shown in the following
pictures.
MLC 206 without accessories MLC 206 with an MLS switcher,
IRCM-DV+, and RCM-SC connected
2. Load a projector driver: select the third tab, Controller (MLC) Config, and
select the Load Extron Driver button, as shown in the following illustration.
Choose the appropriate projector driver (filename.mll) from the on‑screen
menu. If the projector brand and model are not listed, check the Extron Web
site to see if a new driver is available or enter user‑defined RS‑232 strings. See
“Advanced Projector Config” in chapter 4 of the User’s Manual for details.

5
3. Configure the buttons. Use the
drop‑down box associated with each
button to select the command to be
issued or function to perform, as
shown at right.
Each configured button has a green or red dot on it.
N If a button has been previously configured, it will have a red (IR) or
green (RS-232) dot to indicate that an IR or RS-232 code has been associated
with it.
4. Choose a volume control option. Select Projector if
planning to use the projector display speakers or if using
the projector display as a preamp. Select Switcher (MLS)
when using an external switcher as an audio preamp or
amplifier.
Step 4 — IR learning
If there are no drivers available, the MLC can learn IR commands to control
projectors or other devices. IR learning is required to configure control modules to
control devices such as DVD players.
1. Select the third tab, Controller (MLC) Config.
2. Click on the appropriate button on the control module or the MLC to learn IR
codes.
N If a button has been previously configured, it will have a red (IR) or
green (RS-232) dot to indicate that an IR or RS-232 code has been associated
with it.

MLC 206 Setup Guide, cont’d
6
4. Click on OK to begin the learning process.
During IR learning hold the device remote control 4 inches to 14 inches
(10 cm to 36 cm) away from and directly in front of the MLC’s IR pickup
device.
OR
Aim the remote
control at the MLC’s
IR pickup devices,
press the remote’s
button, follow
on-screen prompts
MLC 206
Extron
MediaLink Controller
MLC 206
DISPLAY
POWER
VOLUME
MAX/
MIN
VCR DVD Laptop
1 2 3
4 5 6
7 8
0
9
4"–14"
(10–36 cm)
3. Click on the button labeled Learn IR to Button. A dialog box appears
indicating the button to which IR codes will be learned.
d
c
Once the IR commands have been successfully
learned, the button will be shown with a red dot
(shown at right) and the button/function may be
named.
5. Repeat steps 2 through 4 to set up additional buttons.

7
Step 5 — Completing the installation
1. Save the configuration by selecting Save CONFIGURATION as..., and name it
appropriately.
2. Connect the MLC 206 to the projector for RS‑232 projector control.
a. Disconnect the power from the MLC (and the optional MediaLink Switcher,
if applicable) and from the projector.
b. Plug the 9‑pin D connector of the RS‑232 projector control cable (such as an
Extron UC 50’ cable) into the projector RS‑232 port. A cable adapter may be
required.
c. Connect the other end of the projector control cable to the MLC
Display/Source Control RS‑232 port. Wiring depends on the projector. See
the diagrams below and on page 8, and the pin assignments in the projector
user manual. Also see the display driver setup document available from
the download page of the Extron Web site.
N In most cases only the transmit (Tx), receive (Rx) and ground connections will
be needed. Wiring varies depending on the projector model.
A B C D E A B C
IR
Relays IR/ RCM
RS-232
D E A B C A BD
1A 1B 2A 2B 3A 3B 123456
Tally Out
33-644-01 A 07 01
MLS/Power
Display/Source Control Extron Switcher Control
MLC RS-232 display ctrl wiring_112202.eps
Request to send (RTS)
Ground ( )
Transmit (Tx)
Receive (Rx)
Clear to send (CTS)
To the RS-232 port of
the display/projector
E
D
C
B
A

MLC 206 Setup Guide, cont’d
8
3. Install the IR Emitter(s) in the IR port as shown in the following illustration,
and attach the head of each IR Emitter to an IR‑controlled device (VCR,
DVD player, projector).
N Place the IR emitter directly over the IR pickup device of the equipment.
MLC-IR emitter_wiring_QS_112202.eps
A B C D E A B C
IR
Display/Source Control Extron Switcher Control Relays IR/RCM
RS-232
D E A B C A BD
1A 1B 2A 2B 3A 3B 123456
Tally Out MLS /Power
33-644-01 A 07 01
IR
Emitter
White striped wire only
Modulated IR
Ground
D
A
110 feet (33.5 m) maximum
0 Connect up to a maximum
of 4 IR Emitters
4. Install any optional accessories (IR Link, relays, tally out) that will be connected
to the MLC 206. Refer to chapter two of the MLC 206 User’s Manual and to the
accessory manual(s) for wiring diagrams and installation details.
5. Reconnect the power supply or optional MediaLink Switcher (MLS) to the
MLS/Power port and connect power to all controlled devices.
6. Verify the system operates correctly when selections and adjustments are made
at the front panel and/or from the User Mode section of the control software.
Adjust cabling or retry IR learning as needed.
7. Disconnect the host PC from the MLC 206, remove power from the MLC
(unplug the power supply or switcher), and label the inputs (see the
MLC 206 User’s Manual for details).
8. Mount the MLC and accessories into the wall or furniture, and restore power.
The UC cable pin assignments are shown in the following illustration.
1
59
6
7
6
5
4
3
2
1
8
9
Purple
Blue
Green
Yellow
Orange
Red
Brown
Grey
Black
Connector Shell
Pin #Color
UC Cable
Shield
UC 50', 100' Cable Color Codes
To the
projector
To the
MLC 206
