NAV E 501 and NAV E 101 • Setup Guide
This guide provides instructions for an experienced installer to install the Extron NAV E 501 and
NAV E 101 streaming encoders and to make all connections. One or more NAV encoders and one or
more compatible Extron NAV decoders form an AV distribution and switching matrix on a managed
1G IP network.
NOTE: For more information on any subject in this guide, see the NAV E 501 and NAV E 101 User Guide, available at
www.extron.com.
Installation
Step 1 — Mounting
Turn off or disconnect all equipment power sources and rack or furniture mount the encoder as required.
Step 2 — Rear Panel Connections
NAV 1G/PoE+
HDMI LOOP THRU
POWER
12V
1.5 A MAX LCONT
CTTx Rx GSG
RS-232 IRR
AUDIO
LAN
CONTROLINPUT NAV E 101
RESET
HDMI LOOP THRU
POWER
12V
2.0 A MAX L CONT
CTTx Rx GSG
5V/200 mA
RS-232 IRR
AUDIO
USB 2.0CONTROLINPUT NAV E 501
RESET
NAV 1G/PoE+EXT
LAN
CCC
AAABBBDDDJJJEEEIIIGGGFFFHHH
Figure 1. NAV E 501 and NAV E 101 Rear Panel Features
AHDMI input port — Connect an HDMI cable between this port and the HDMI output port (or DVI port, with an appropriate adapter) of
the digital video source.
BHDMI Loop Thru port — Connect a display to this female HDMI connector for local loop-through monitoring of the source signal.
NOTE: See LockIt®Lacing Brackets on page 6 to securely fasten the HDMI connectors to the encoder for Aand B.
CAUDIO input port — Connect balanced or unbalanced stereo audio input to this 5-pole, 3.5 mm captive screw connector (see Analog
audio input on page 6 to wire the connector).
DControl Contact Closure port — Connect an Extron Show Me®cable to the port to allow the encoder to select itself as the input to
the decoder, using the control system.
EControl RS-232/IR port — Connect a serial RS-232 signal, a modulated IR signal, or both to this 3.5 mm, 5-pole captive screw
connector for bidirectional RS-232 and IR communication with connected remote controlled devices. Control is accomplished using
an Extron control system (see Control connector on page 6 to wire the connector).
FUSB 2.0 port (NAV E 501 only) — Connect a USB Type-C cable from a USB host or a USB device. See LockIt®Lacing Brackets to
securely fasten the USB connector to the encoder.
NOTE: This connector is limited to supplying 200 mA in USB device mode.
GNAV 1G/PoE+ port — Connect to an Ethernet LAN on which one or more decoders also reside for streaming and control. This port
can also receive Power over Ethernet (PoE+) to power the encoder (see Power on page 3 for power options).
HExtension port (NAV E 501 only) — If desired, connect another networked device to this port. The port acts as a networked switch to
the NAV 1G/PoE+ port.
NOTE: The Extension port cannot provide PoE.
IReset button and LED — This button initiates three modes of reset (see the NAV E 501 and NAV E 101 User Guide, available at
www.extron.com, for details).
JPower connector (optional) — Plug the included external 12 VDC power supply into this 2-pole connector for local power (see Power
connector on page 6 to wire the connector and Power for power options).
IMPORTANT:
IMPORTANT:
Go to www.extron.com for the complete
user guide, installation instructions, and
specifications before connecting the
product to the power source.
QA comments addressed.

2
NAV E 501 / NAV E 101 • Setup Guide (Continued)
Step 3 — Front Panel Configuration Port Connection
NAV E 101
INPUTS
HDCP
HDMI
CONFIG STREAM LNK
ACT
ANALOG
AUDIO
HDMI AUDIO
NAV LAN ID
NAV E 501
INPUTS
HDCP
HDMI
CONFIG
USB
STREAM
ACTIVE
HOST -LNK-
-ACT-
NAVEXT
ANALOG
AUDIO
HDMI AUDIO
NAV LAN IDUSB
EEECCC
AAABBBDDDFFFGGG
Figure 2. NAV E 501 and NAV E 101 Front Panel Features
AConfiguration (CONFIG) port — Connect a PC to the encoder via this front panel USB Mini-B connector for configuration of the unit.
The port uses IP over USB technology. The IP address is always 203.0.113.22 and CANNOT be changed. The Config port is also
discoverable via Extron Toolbelt (see the NAV E 501 and NAV E 101 User Guide. The guide and Toolbelt are available for download at
www.extron.com).
Indicators
BPower LED — Indicates power and startup status, as follows:
• Blinking — The unit is receiving power, either locally or remotely (via PoE) and is booting up.
• Lit steadily — The unit is receiving power, either locally or remotely (via PoE) and is operational.
CINPUTS — Indicate status of the signal inputs, as follows:
• HDMI LED — The encoder is detecting an HDMI input.
• HDCP LED — The HDMI signal is HDCP encrypted.
• HDMI Audio LED — The embedded HDMI audio input is selected.
• Analog Audio LED — The analog audio input is selected.
DNAV LEDs — Indicate the output status of the AV and USB streams, as follows:
• Stream
• Lit steadily – The encoder is actively streaming a NAV output consisting of video, audio, or both.
• Blinking – The encoder is actively streaming a NAV output, but network errors are present.
• Unlit - The encoder is not actively streaming a NAV output.
• USB (NAV E 501 only)
• Lit steadily – The encoder is actively sending and receiving a NAV USB stream.
• Blinking – The encoder is unable to establish a NAV USB stream.
• Unlit — The encoder is not actively sending and receiving a NAV USB Stream.
EUSB LEDS (NAV E 501 only)— Indicates the status of the USB stream, as follows:
• Host
• Lit steadily – The encoder is in USB host mode, the default condition.
• Unlit – The encoder is in USB device mode.
• Active
•Lit steadily – A host or USB device is connected to the rear panel USB port.
• Unlit – No host or USB device is connected to the rear panel USB port.
• Blinking – A USB device or hub is connected to the encoder and is drawing more power than the USB port can supply.

3
FLAN LEDs (see figure 2 on page 2) — Indicate the status of the network connections, as follows:
• NAV LED (NAV E 501) or LAN LED (NAV E 101) —
• Link LED — Lit steadily indicates that a network link is established.
• Act LED — Blinking indicates network traffic. The blink rate corresponds to activity.
• EXT LED (NAV E 501 only) —
• Link LED — Lit steadily indicates that a network link is established. Blinking indicates a link speed less than 100 Mbps.
• Act LED — Blinking indicates network traffic. The blink rate corresponds to activity.
GID button and LED — The recessed ID button identifies the encoder when pressed. The LED blinks when the encoder is in pairing
mode (see Pairing devices on front panel on page 5 for details).
Operation
Power
The encoder can be powered in one of three ways:
• Locally, from the included external power supply and via the power connector (see Jon page 1).
• Remotely, receiving PoE via the NAV 1G/PoE+ port (see G), either from the network switch or from an optional PI 140 Power Injector.
• Locally (J) and remotely (G), with priority on the NAV 1G/PoE+ port. If PoE voltage drops below a threshold, the encoder
immediately transitions to the external power connector with no effect on system operation.
When power is applied, the encoder runs a series of self-tests that blink the front panel Power LED and all other indicators. The encoder
then boots the NAV operating system. It can take approximately 45 seconds for self-test and system startup to complete. When the
process is complete, the Power LED lights steadily.
NOTE: The encoder is NOT operational until the boot process is complete (the Power LED is lit steadily).
System Operation
The encoder can be congured and controlled using embedded web pages or Toolbelt software (see the NAV E 501 and NAV E 101 User
Guide available at www.extron.com).
NOTE: The “Connection via web pages,” Connection settings, and Pairing devices via front panel procedures (see page 5) may
NOT be necessary if your system includes a NAVigator System Manager.
Connection via web pages
Connection to the encoder and its embedded web pages can be made via either the front panel Conguration (USB) port (using IP over
USB technology) (see figure2, A) or the rear panel NAV 1G/PoE+ port (see figure 1, Gon page 1).
Access the encoder using HTML pages as follows:
1. Start a web browser.
NOTES:
• Suggested browsers to fully support the NAV system are: Google Chrome™, Mozilla™, Firefox™, and Microsoft®Edge™.
• The network must be properly configured for multicasting (IGMP). Failure to do so may result in degraded performance.
2. Enter the IP address of the encoder in the browser Address field.
NOTE:
• Default settings:
Port DHCP IP address Subnet mask
Config (USB)*203.0.113.22
NAV/PoE+ (RJ-45) On
* For the Config port, the address for IP over USB CANNOT be changed.
• If you use IP over USB, Extron recommends waiting a minute after plugging in the cable for your PC to identify the USB
connection as a valid Ethernet port.

4
NAV E 501 / NAV E 101 • Setup Guide (Continued)
3. Press the keyboard <Enter> key. The browser displays
a privacy error message (see figure3 at right for an
example in the Chrome browser).
4. Click Advanced (see figure 3, 1). The button changes
to Hide Advanced and explanatory text and a link
appear below the button.
5. Click Proceed to <IP address>(unsafe) (2). The
browser opens to the Login dialog box (see figure 4).
11111111111111
22222222222222
33
3333
33333333
Figure 4. Login Dialog Box
6. Complete the Username (see figure 4, 1) and Password (2) fields and click Sign In (3). The browser opens to the home page of
the embedded web pages (see figure 5 on page 5).
NOTES:
• The default username is admin.
• The factory configured passwords for all accounts on this device have been set to the device serial number. If the password
is reset, the encoder defaults to the default password, which is extron.
• Usernames and passwords are case sensitive.
1111111111
1111
1111
2222222222
2222
2222
Figure 3. Privacy Error Message (in Chrome Browser)
2

5
111111111111111111
2222222222
2222
2222
*
* NAV E 501 only
Figure 5. Home Page
NOTE: Detailed descriptions of communication, configuration, and monitoring are provided in the NAV E 501 and NAV E 101 User
Guide, available at www.extron.com.
Connection settings
View and change connection settings as follows:
1. On the home page, click Settings (see figure 5, 1) > Network
Connection (2). The Network Connection pane opens (see figure 6 at
right), showing protected views of the network connection settings.
NOTE: Editing of connection settings is disabled when the device is
assigned to an Extron NAVigator System Manager.
2. To change the settings, click Edit (see figure 6, 1). The Edit button
changes to Save.
3. Click in the desired field (2) and edit it as desired.
4. Repeat step 3 as necessary for other values.
5. Click Save.
Pairing devices via front panel
Pair devices from the front panel as follows:
NAV E 101
ID
N
NA
NA
NA
A
A
1. Use an Extron Tweeker or other small screwdriver to
press and hold the encoder front panel ID button for
approximately 3 seconds, until the ID LED blinks. The
encoder enters pairing mode, which allows decoders
to receive the AV stream (NAV E 101) or AV and USB
streams (NAV E 501 only) from encoders.
2. One at a time, use a Tweeker or other small screwdriver to press and hold
the decoder front panel ID button for approximately 3 seconds, until the
ID LED blinks. The decoder is now paired to the encoder.
3. Repeat step 2 for each decoder.
1
1111111111
1111
1111
2222222222
2222
2222
*
* NAV E 501 only
Figure 6. Network Connection Pane

6
68-2751-50 Rev. B
09 20
NAV E 501 / NAV E 101 • Setup Guide (Continued)
© 2020 Extron — All rights reserved. www.extron.com All trademarks mentioned are the property of their respective owners.
Worldwide Headquarters: Extron USA West, 1025 E. Ball Road, Anaheim, CA 92805, 800.633.9876
For information on safety guidelines, regulatory compliances, EMI/EMF compatibility,
accessibility, and related topics, see the Extron Safety and Regulatory Compliance
Guide on the Extron website.
4. Use a Tweeker or other small screwdriver to press and release the encoder front panel ID button. The encoder exits pairing mode.
5. Repeat steps 1 through 4 to pair decoders to other encoders.
After all devices are connected, powered on, and paired, the system is fully operational.
Operation in a System with a NAVigator
The Extron NAVigator is a system manager that easily congures and controls the NAV System. The NAVigator can support a 16 endpoint
system by default, but if a LinkLicense is installed, it can support up to 240 endpoints.
See the NAVigator User Guide, available at www.extron.com for details.
Connection Details
LockIt®Lacing Brackets
1. Plug the HDMI cable or USB (NAV E 501 only) into the panel connection (see 1, at right).
3
333
111
555
444
222
2. Loosen the connection mounting screw from the panel enough to allow the LockIt lacing bracket to
be placed over it (2). The screw does not have to be removed.
3. Place the LockIt lacing bracket on the screw and against the connector (3).
4. Tighten the screw to secure the bracket.
ATTENTION:
• Do not overtighten the HDMI connector mounting screw. The shield it fastens to is very
thin and can easily be stripped.
• Ne serrez pas trop la vis de montage du connecteur HDMI. Le blindage auquel elle est
attachée est très n et peut facilement être dénudé.
5. Loosely place the included tie wrap around the connector and the LockIt lacing bracket as shown (4).
6. While holding the connector securely against the lacing bracket, use pliers to tighten the tie wrap, then remove any excess length (5).
Analog audio input Control connector
Unbalanced Stereo Input Balanced Stereo Input
Do not tin the wires!
Tip
Ring
Tip
Ring
LR
Sleeves
Tip
Sleeve
Sleeve
Tip
LR
TxRx
RxTx Gnd
IR Device
RS-232 Device
RS-232
Tx Rx GSG
IR
CONTROL
NAV and EXT connectors Power connector
5
Pin
1
2
3
6
7
8
4
Wire color
White-green
Green
White-orange
White-blue
Orange
White-brown
Brown
Blue
TIA/EIA T568B
TP Wires
12345678
Pins:
Power Supply
Output Cord
Ridges
Smooth
Captive
Screw
Connector
3"
16 (5 mm) MAX
SECTION A–A
AA
