KTI KC-3000 User manual

-1-
Modular Media Converter Center System
KC-3000KC-1800
and
Slide-in10/100MediaConverterModules
Slide-inGigabitMediaConverter Modules
Operation Manual
DOC.040521-KC1800-KC3000
P/N:720-0007-001

-2-
Ó2002 KTI Networks Inc. All rights reserved. No part of this documen-
tation may be reproduced in any form or by any means or used to make
any directive work (such as translation or transformation) without per-
missionfromKTINetworksInc.
KTI Networks Inc. reserves the right to revise this documentation and to
make changes in content from time to time without obligation on the part
of KTI Networks Inc. to provide notification of such revision or change.
For more information, contact:
UnitedStates KTI NetworksInc.
P.O.BOX631008
Houston,Texas77263-1008
Phone: [phone]
Fax: [phone]
E-mail: [e-mail]
URL: http://www.ktinet.com/
International Fax: [phone]
E-mail: [email protected]
URL: http://www.ktinet.com.tw/

-3-
The information contained in this document is subject to change without prior
notice. Copyright (C) KTI. All Rights Reserved.
TRADEMARKS
Ethernet is a registered trademark of Xerox Corp.
WARNING:
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment
is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and if not installed and used in accordance
with the instruction manual may cause harmful interference in which case the
user will be required to correct the interference at his own expense.
NOTICE:
(1) The changes or modifications not expressively approved by the party re-
sponsible for compliance could void the user's authority to operate the equip-
ment.
(2) Shielded interface cables and AC power cord, if any, must be used in order
to comply with the emission limits.
CISPR A COMPLIANCE:
This device complies with EMC directive of the European Community and meets
or exceeds the following technical standard.
EN 55022 - Limits and Methods of Measurement of Radio Interference Character-
istics of Information Technology Equipment. This device complies with CISPR
Class A.
WARNING:Thisis a Class A product. In a domestic environment this product may
cause radio interference in which case the user may be required to take ad-
equate measures.
CE NOTICE
Markingbythesymbol indicatescomplianceofthisequipmenttotheEMC
directive of the European Community. Such marking is indicative that this equip-
ment meets or exceeds the following technical standards:
EN 55022: Limits and Methods of Measurement of Radio Interference character-
istics of Information Technology Equipment.
EN 50082/1:Generic Immunity Standard -Part 1: Domestic Commercial and Light
Industry.
EN 60555-2: Disturbances in supply systems caused by household appliances
and similar electrical equipment - Part 2: Harmonics.

-4-
Table of Contents
1. Introduction.........................................................6
1.1 Features ........................................................................................ 7
1.2 Technical Specifications ............................................................... 8
2. Installation.........................................................12
2.1 Unpacking ................................................................................... 12
2.2 System Units ............................................................................... 12
2.2.1 System LED Module................................................................. 15
2.2.2 Management Module................................................................ 16
2.2.3 System Power Chassis ........................................................... 18
2.3 Rack Mounting............................................................................. 25
3. Network Management ......................................27
3.1 Management Functions .............................................................. 27
3.2 Protocols Supported ................................................................... 28
3.3 Setup for Out-of-band (Console) Management .......................... 29
3.4 Setup for In-band Management .................................................. 31
4. Console and Telnet Operation.........................32
4.1 IP Menu ........................................................................................ 36
4.2 SNMP Menu ................................................................................. 37
4.3 View System Status..................................................................... 38
4.4 View Converter Slots Status........................................................ 39
4.5 Restore Default Values ............................................................... 41
4.6 Security Manager ......................................................................... 42
4.7 Update Firmware......................................................................... 43
4.8 Reboot System ............................................................................ 44
5. SNMP Management ..........................................45
5.1 Configuring SNMP Settings via Console Operation ................... 46
5.2SNMPPrivateMIB ........................................................................ 47
5.3 SNMP Traps ................................................................................ 48
6. Web Management .............................................49
6.1 Start Browser Software and Making Connection ........................ 49
6.2 Login to the System Unit ............................................................. 50
6.3 Converter Status.......................................................................... 52
6.4 System Status ............................................................................. 54

-5-
6.5 Administrator Menu ..................................................................... 55
6.5.1 Basic......................................................................................... 56
6.5.2 Console Port Information ......................................................... 60
6.5.3 Security Manager ...................................................................... 61
6.5.4 Image Refresh Time ................................................................ 62
6.5.5 Update Firmware...................................................................... 63
6.5.6 Reboot System ......................................................................... 64
6.6 Slot Icon Operations.................................................................... 65
7. Fast Ethernet Media Converter Modules ........68
7.1 Specifications .............................................................................. 70
7.2 Fiber Optic Specifications ........................................................... 71
7.3 Configuration Switch Settings for TP Interface ........................... 71
7.4 Making Single Fiber Connection ................................................. 72
7.5 LED Indications ........................................................................... 72
8. Gigabit Ethernet Media Converter Modules....73
8.1 Specifications .............................................................................. 75
8.2 Functions ..................................................................................... 76
8.3 Supported Fiber Cables.............................................................. 77
8.4 LED Indicators............................................................................. 77

-6-
1. Introduction
The Modular Converter System KC-3000 and KC-1800 are managed and un-
managed media converter racks that can host 16 slots and 18 slots respectively
ofnetworkmediaconvertermodules.Awiderangeofmediamodulesareavail-
abledependingonyourvarietyofnetworkcablingenvironment.Theseoptional
mediaconvertermodulesincludeUTPtomultimodeorsinglemodefibercablefor
Ethernet,FastEthernetandGigabitEthernetnetworks.
The rack unit provides a centered power supply to the converter mod-
ules and serves as a converter center and wiring concentrator.

-7-
1.1 Features
Some of the key features include:
• Managed modular Media Converter Center Rack
• 19-inch rack-mountable 2U chassis
• Managed system accommodates up to 16 media converter modules
• Un-managed system accommodates up to 18 media converter
modules
• Highly modularized chassis design with
- modular media converter modules
-modular SNMPmodule
-modular system LEDmodule
- modular system power module
• Provides high availability and maintainability
• Visible system status and failure LED indication
• Audio buzzer for fan failure indication
• Supports in-band Telnet, SNMP and web-based management
• Supports out-of-band direct console management
• Management from anywhere and any platform using a web browser
• Easy-to-use point and click user interface
• Photographic quality interface to configure and monitor the system
• Supports in-band event SNMP trap report
• Photographic quality interface to configure and monitor the system
• TFTP Software Upgrade

-8-
1.2 Technical Specifications
System Model KC-3000/1A KC-1800/1A KC-3000/1D KC-1800/1D
19-inch rack mount Yes Yes Yes Yes
Number of slots 19 19 19 19
Management support Managed Un-managed Managed Un-managed
System LED module Installed Installed Installed Installed
Management module Installed No Installed No
Number of MC slots 16 slots 18 slots 16 slots 18 slots
Plug-in power module Yes Yes Yes Yes
Module type AC power AC power DC power DC power
Input voltage 100~240V 100~240V 48V 48V
Power supply rating 150W 150W 150W 150W
Cooling Fan Fan Fan Fan
Mechanical
Chassis Height(2U) 88mm 88mm 88mm 88mm
Width 443mm 443mm 443mm 443mm
Depth 328mm 328mm 328mm 328mm
Weight (no MC modules) 8.2Kg 8.0Kg 7.7Kg 7.5Kg
Common Specifications
Chassis withstand static load 60Kg
Vibration
Vibration 1 X-Y-Z / 16.7Hz / 4mm / 1 hour
Vibration 2 X-Y-Z / 10-20Hz / 1.3mm / 20min
Environmental
Operating temperature -10~50oC
Storage temperature -20~70oC
Operating humidity 10~90%RH
Emission standard
Conducted emission EN55022, CISPR 22
Radiated emission EN55022, CISPR 22
Voltage harmonics EN61000-3-2
Voltage fluctuation & flicker EN61000-3-3
Susceptibility
Electrostatic discharge immunity EN61000-4-2, IEC61000-4-2
Radiated immunity EN61000-4-3, IEC61000-4-3
EFT/Burst immunity EN61000-4-4, IEC61000-4-4
Surge immunity EN61000-4-5, IEC61000-4-5
Continuous wave voltage immunity EN61000-4-6, IEC61000-4-6
Voltage DIP/Interrupt immunity EN61000-4-11, IEC61000-4-11
Certifications
FCC Part 15, Class A
CE EMC Class A, EN50081-1,EN50082-1

-9-
AC Power Chassis Module Specifications
Dimension 169.2mm x 301.8mm x 85.4mm
Installation method Plug in from system rear panel
Maintenance Modular design for easy maintenance
AC power switch System power on/off switch
AC power receptacle IEC320 type receptacle
Electric
Input voltage rating 100 ~ 240VAC
Input voltage range 100 ~ 240VAC (+/-10%)
Input frequency 50 ~ 60Hz (+/-3%)
Input current 3A maximum
Input surge current 35A max. @115VAC cold start
Efficiency 76% @115VAC full load
Output power 150W
Over current protection All output with short circuit protection
Safety UL1950, CSA22.2 950, TUV EN60950
Insulation Resistance >10M Ohm @DC500V
Dielectric withstands 1500VAC 10mA 1min.
Cooling 12V DC Fan
DC Power Chassis Module Specifications
Dimension 169.2mm x 301.8mm x 85.4mm
Installation method Plug in from system rear panel
Maintenance Modular design for easy maintenance
Input power switch System power on/off switch
Input power receptacle Terminal connector (screw type)
Electric
Input voltage rating 48VDC
Input voltage range 36 ~76VDC
Efficiency 79% full load
Output power 150W
Protection Over voltage protection
Over current protection
Over temperature protection (auto-restart)
Safety UL1950, TUV EN60950
Insulation Resistance >10M Ohm @DC500V
Dielectric withstands 1500VDC 1min.
Cooling 12V DC Fan

-10-
System LED Module
Dimension 148.7mm x 22mm x 86.4mm
Slot position Slot 1
Installation method Plug in from system front panel
Mis-insertion protection Yes
System interface DIN type connector
System power status Green LED indication
System fan failure status Red LED indication
Buzzer Beep warning for fan failure event
Buzzer reset switch Reset beep warning
Management Module Specifications
Dimension 156.5mm x 44.4mm x 86.4mm
Slot position Slot 2 and 3
Installation method Plug in from system front panel
Mis-insertion protection Yes
CPU RISC-based ARM7
RAM size 1M bytes
Flash size 512K bytes
System interface
Connector DIN type connector
Console interface
Interface RS-232 DTE
Connector 9-pin male D-SUB connector
Baud rate 38400, N, 8, 1, 0
Flow control Disabled
In-band interface
Interface 10/100M LAN port
Connector Shielded RJ-45 MDI
Standard IEEE 802.3 10BASE-T/100BASE-TX
Auto-negotiation Support
LED Indicators
Power Green LED, module power status
CPU Init. Green LED, CPU initialization
RS232 RX Green LED, Console RS-232 Rx activities
TP Link/Act. Green LED, LAN port link and activities status

-11-
Management Specifications
Management interface
Telnet Via direct RS-232 console connection
Telnet Via TCP/IP Telnet software
SNMP agent Via TCP/IP SNMP manager software
HTTP server Via browser software
Protocols
IPv4 IP version4 RFC791
TCP Transmission Control Protocol RFC793
UDP User Datagram Protocol RFC768
ICMP Internet Control Message Protocol RFC792
SNMP SNMP agent v1 RFC1157
MIB-II Standard MIB RFC1213
TFTP Trivial File Transfer Protocol RFC1350
TELNET Telnet protocol RFC854
HTTP HTTP server for web managementRFC1945
Management Objects
Password for access control Set and monitor
System status : CPU, memory, flash, software Monitor
System fan status Monitor
IP address of the system Set and monitor
Subnet mask of the system Set and monitor
Default gateway IP address Set and monitor
SNMP name information Set and monitor
SNMP location information Set and monitor
SNMP contact information Set and monitor
SNMP community names (up to 4) Set and monitor
SNMP community access right (up to 4) Set and monitor
SNMP trap host IP address (up to 3) Set and monitor
Slot status : MC module installed or not Monitor
MC Module status : media type, speed, duplex Monitor
MC Module link status of two ports Monitor
SNMP Traps
Cold Start System is powered on and completes initialization
Authentication failure SNMP community authentication failure
Power On The system is powered on.
Fan failure System fan failure occurs.
Fan failure recovery System fan recovery from failure
Slot # Port A link Slot # MC module Port A link down or up
Slot # Port B link Slot # MC module Port B link down or up
Update Firmware Via TFTP protocol
Remote boot system

-12-
2. Installation
2.1 Unpacking
The product package contains:
•The system unit
•One power cord
•One19-inch rack mounting kit
•Operation Manual
2.2 System Units
The figure below illustrates managed model KC-3000series.
The figure below illustrates un-managed model KC-1800 series.

-13-
The following figure shows the model equipped with AC power chassis.
The following figure shows the model equipped with DC power chassis.

-14-
Main Chassis : provides insertion slots on front panel for system LED
module,CPU management module, and optional add-on mediaconverter
modules. It also provides a chassis slot on rear for mounting system
power chassis.
System LED Module : provides system power and fan status indicators
together with one alarm buzzer for power or fan failure.
ManagementModule :serves as amanagement agent tomonitor system
status and add-on converter modules for in-band and out-of-band man-
agement requests.
AC System Power Chassis : provides centered power supply and cool-
ing fan for whole system unit. It can receive and auto-detect commercial
ACpower infull voltagerange from 90VAC to240VAC.
DC System Power Chassis : provides centered power supply and cool-
ing fan for whole system unit. It can receive DC 48V input.

-15-
2.2.1 System LED Module
System LED module features the following functions:
SystemPowerIndicator(GreenLED)
On : System power in normal condition
Off : System power failure
FanFailureIndicator(RedLED)
On : Cooling fan in normal condition
Off : Cooling fan failure
AlarmBuzzer(Beep)
Beep : when system power failure or fan failure occur
Silent : no failure occurs
BuzzerReset(Pushbuttonswitch)
Shut down beep sound of alarm buzzer.

-16-
2.2.2 Management Module
The system unit comes with one pre-installed Management module. The
module facilitates the following functions:
•Direct out-of-band management via RS-232 console port
•SNMP agent to serve in-band management via SNMP protocol
•Telnet console in-band management via TCP/IP protocol
•HTTP host to serve web-based in-band management
See figure below for major components on the panel:

-17-
ConsolePort
This port is a 9-pin male D-sub connector. It serves as an RS-232 DTE
port. Refer to Chapter xx for the console operation. The pin definitions
are: Pin2 RXD
Pin 3 TXD
Pin 4 DTR
Pin 5 GND
Pin 6 DSR
UTPPort
This is an auto-negotiation 10/100BASE-TX LAN port and provides a
shielded RJ-45 jack with MDI definition. This port must connect to your
TCP/IP network for all in-band management operations.
LEDIndicators
LED Color States Interpretation
POWER Green On SNMP module is powered on
CONSOLE Green On Tx activities of console port
LNK/ACT. Green On UTP port link is active
Green Blink Tx/Rxactivities of UTPport
INIT Green On Management moduleininitialization

-18-
2.2.3 System Power Chassis
The system power supply is assembled in a plug-in chassis module with
cooling fan. Two types of system power chassis are illustrated as fol-
lows:
ACSystem PowerChassisSpecifications
AC power switch System power on/off switch
AC power receptacle IEC320 type receptacle
Input voltage rating 100~240VAC
Input voltage range 100~240VAC(+/-10%)
Input frequency 50~60Hz(+/-3%)
Input current 3Amaximum
Output power 150W
AC power cord IEC320type powercord

-19-
DCSystem PowerChassisSpecifications
Input power switch System power on/off switch
Input power receptacle Terminal connector (screw type)
Input voltage rating 48VDC
Input voltage range 36~75VDC
Output power 150W
The connection definition of the DC power receptacle is:

-20-
RemovalofSystemPowerChassis
The system power chassis is pre-installed in the system unit when sys-
tem unit is shipped from factory. The chassis is designed for easy un-
installation from system unit in case of any inspection purpose. How-
ever, note that this removal only can be performed by a well-trained
technical person.
For safety reason before removing the power chassis, make sure:
•The system power switch is turned off.
•The power cord is disconnected from the power chassis.
To remove the chassis, unscrew three chassis screws until they are re-
leased from system chassis, hold the handle and pull the chassis out
from the system chassis smoothly. See the following example figure:
