Extron electronics MTP 15HD A Series User manual

User Guide
MTP 15HD A Series
Twisted Pair
High Resolution Video and Serial Link
MTP Transmitters and Receivers
68-2206-01 Rev. B
03 13

Safety Instructions • English
WARNING:This symbol, , when used on the product, is intended to
alert the user of the presence of uninsulated dangerous voltage within
the product’s enclosure that may present a risk of electric shock.
ATTENTION: This symbol, , when used on the product, is intended
to alert the user of important operating and maintenance (servicing)
instructions in the literature provided with the equipment.
For information on safety guidelines, regulatory compliances, EMI/EMF
compatibility, accessibility, and related topics, see the Extron Safety and
Regulatory Compliance Guide, part number 68-290-01, on the Extron
website, www.extron.com.
Instructions de sécurité • Français
AVERTISSEMENT: Ce pictogramme, , lorsqu’il est utilisé sur
le produit, signale à l’utilisateur la présence à l’intérieur du boîtier
du produit d’une tension électrique dangereuse susceptible de
provoquer un choc électrique.
ATTENTION: Ce pictogramme, , lorsqu’il est utilisé sur le produit,
signale à l’utilisateur des instructions d’utilisation ou de maintenance
importantes qui se trouvent dans la documentation fournie avec le
matériel.
Pour en savoir plus sur les règles de sécurité, la conformité à la
réglementation, la compatibilité EMI/EMF, l’accessibilité, et autres sujets
connexes, lisez les informations de sécurité et de conformité Extron, réf. 68-
290-01, sur le site Extron, www.extron.fr.
Sicherheitsanweisungen • Deutsch
WARNUNG: Dieses Symbol auf dem Produkt soll den Benutzer
darauf aufmerksam machen, dass im Inneren des Gehäuses dieses
Produktes gefährliche Spannungen herrschen, die nicht isoliert sind
und die einen elektrischen Schlag verursachen können.
VORSICHT: Dieses Symbol auf dem Produkt soll dem Benutzer in
der im Lieferumfang enthaltenen Dokumentation besonders wichtige
Hinweise zur Bedienung und Wartung (Instandhaltung) geben.
Weitere Informationen über die Sicherheitsrichtlinien, Produkthandhabung,
EMI/EMF-Kompatibilität, Zugänglichkeit und verwandte Themen finden Sie in
den Extron-Richtlinien für Sicherheit und Handhabung (Artikelnummer
68-290-01) auf der Extron-Website, www.extron.de.
Instrucciones de seguridad • Español
ADVERTENCIA: Este símbolo, , cuando se utiliza en el producto,
avisa al usuario de la presencia de voltaje peligroso sin aislar dentro
del producto, lo que puede representar un riesgo de descarga
eléctrica.
ATENCIÓN: Este símbolo, , cuando se utiliza en el producto, avisa
al usuario de la presencia de importantes instrucciones de uso y
mantenimiento recogidas en la documentación proporcionada con
el equipo.
Para obtener información sobre directrices de seguridad, cumplimiento
de normativas, compatibilidad electromagnética, accesibilidad y temas
relacionados, consulte la Guía de cumplimiento de normativas y seguridad
de Extron, referencia 68-290-01, en el sitio Web de Extron, www.extron.es.
Chinese Simplified（简体中文）
警告：产品上的这个标志意在警告用户该产品机壳内有暴露的危险
电 压 ，有 触 电 危 险 。
注意：产品上的这个标志意在提示用户设备随附的用户手册中有
重要的操作和维护(维修）说明。
关于我们产品的安全指南、遵循的规范、EMI/EMF 的兼容性、无障碍
使用的特性等相关内容，敬请访问 Extron 网站 www.extron.cn，参见 Extron
安全规范指南，产品编号 68-290-01。
Chinese Traditional（繁體中文）
警告: 若產品上使用此符號，是為了提醒使用者，產品機殼內存在著
可能會導致觸電之風險的未絕緣危險電壓。
注意 若產品上使用此符號，是為了提醒使用者。
有關安全性指導方針、法規遵守、EMI/EMF 相容性、存取範圍和相關主題的詳細
資訊，請瀏覽 Extron 網站：www.extron.cn，然後參閱《Extron 安全性與法規遵
守手冊》，準則編號 68-290-01。
Japanese
警告:この記号 が製品上に表示されている場合は、筐体内に絶縁されて
いない高電圧が流れ、感電の危険があることを示しています。
注意:この記号 が製品上に表示されている場合は、本機の取扱説明書に
記載されている重要な操作と保守(整備)の指示についてユーザーの
  注意を喚起するものです。
安全上のご注意、法規厳守、EMI/EMF適合性、その他の関連項目に
つ い て は 、エ ク スト ロ ン の ウ ェブ サ イト www.extron.jpより
『Extron Safety and Regulatory Compliance Guide』 (P/N 68-290-01) をご覧ください 。
Korean
경고: 이 기호 , 가 제품에 사용될 경우, 제품의 인클로저 내에 있는
접지되지 않은 위험한 전류로 인해 사용자가 감전될 위험이 있음을
경고합니다.
주의: 이 기호 , 가 제품에 사용될 경우, 장비와 함께 제공된 책자에 나와
있는 주요 운영 및 유지보수(정비) 지침을 경고합니다.
안전 가이드라인, 규제 준수, EMI/EMF 호환성, 접근성, 그리고 관련
항목에 대한 자세한 내용은 Extron 웹 사이트(www.extron.co.kr)의
Extron 안전 및 규제 준수 안내서, 68-290-01 조항을 참조하십시오.
Safety Instructions
ii

iii
FCC Class A Notice
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part15 of the FCC rules. The ClassA limits provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is
likely to cause interference; the user must correct the interference at his own expense.
NOTE: This unit was tested with shielded I/O cables on the peripheral devices.
Shielded cables must be used to ensure compliance with FCC emissions limits.
For more information on safety guidelines, regulatory compliances, EMI/EMF
compatibility, accessibility, and related topics, see the “Extron Safety and Regulatory
Compliance Guide” on the Extron website.
Copyright
© 2013 Extron Electronics. All rights reserved.
Trademarks
All trademarks mentioned in this guide are the properties of their respective owners.
The following registered trademarks(R), registered service marks(SM), and trademarks(TM) are the property of
RGBSystems, Inc. or Extron Electronics:
Registered Trademarks (®)
AVTrac, Cable Cubby, CrossPoint, eBUS, EDID Manager, EDID Minder, Extron, Flat Field,GlobalViewer, Hideaway, Inline, IP Intercom, IP Link,
Key Minder, LockIt, MediaLink, PoleVault, PowerCage, PURE3, Quantum, SoundField, System Integrator, TouchLink, V-Lock, VersaTools,
VN-Matrix, VoiceLift, WallVault, WindoWall
Registered Service Mark (SM) : S3 Service Support Solutions
Trademarks (™)
AAP, AFL (Accu-Rate Frame Lock), ADSP (Advanced Digital Sync Processing), AIS (Advanced Instruction Set), Auto-Image, CDRS (Class D
Ripple Suppression), DDSP (Digital Display Sync Processing), DMI (Dynamic Motion Interpolation), Driver Configurator, DSP Configurator, DSVP
(Digital Sync Validation Processing), FastBite, FOXBOX, IP Intercom HelpDesk, MAAP, MicroDigital, ProDSP, QS-FPC (QuickSwitch Front Panel
Controller), Scope-Trigger, SIS, Simple Instruction Set, Skew-Free, SpeedMount, SpeedNav, SpeedSwitch, Triple-Action Switching, XTP, XTP
Systems, XTRA, ZipCaddy, ZipClip

Conventions Used in this Guide
Notifications
The following notifications are used in this guide:
WARNING: A warning indicates a situation that has the potential to result in death or
severe injury.
ATTENTION: Attention indicates a situation that may damage or destroy the product or
associated equipment.
NOTE: A note draws attention to important information.
Specifications Availability
Product specifications are available on the Extron website, www.extron.com.

Contents
Introduction ............................................ 1
About this Guide.............................................. 1
About the MTP Transmitters and Receivers ..... 2
Twisted Pair Cable Advantages.................... 2
Transmission Distance..................................... 3
Installation
and Operation......................................... 5
Installation Overview........................................ 5
Front Panel Features........................................ 6
Transmitter Rear Panel Features ...................... 9
Receiver Rear Panel Features........................ 11
Power Supply Wiring and Grounding ............. 12
Twisted Pair Cable Termination ...................... 14
Skew Delay Compensation............................ 15
SEQ Receiver Skew Compensation........... 15
Non-SEQ Receiver Skew Compensation ... 15
EDID Configuration........................................ 16
Recording a Display EDID.......................... 16
Using a Pre-Programmed or
User-Recorded EDID ................................ 16
Reference Information.......................... 17
Part Numbers, Optional Accessories,
Cables, and Connectors............................... 17
Part Numbers............................................ 17
Optional Accessories................................. 17
Cables....................................................... 18
Connectors................................................ 18
Mounting............................................... 19
Tabletop Placement....................................... 19
Under Desk and Furniture Mounting .............. 19
Rack Mounting.............................................. 19
UL Guidelines for Rack Mounting............... 19
Rack Mounting Procedure ......................... 20
Back of the Rack Mounting Procedure ...... 20
Projector Mounting........................................ 20
MTP 15HD A Series • Contents v

Introduction
This section gives an overview of the user guide. This section also describes the
MTP 15HD A Series of transmitters and receivers. Covered topics are:
•About this Guide
•About the MTP Transmitters and Receivers
•Transmission Distance
About this Guide
This guide contains installation, configuration, and operation information for two families of
Extron MTP transmitters and receivers.
•MTP products that are compatible with:
••Extron Enhanced Skew-Free™AV UTP cable
••Category (CAT) 5, 5e, and 6 shielded twisted pair (STP), unshielded twisted pair
(UTP), or foil shielded twisted pair (FTP) cable.
•MTP C7 [CAT 7, C7] products that are compatible with Shielded Twisted Pair 201
(STP201) or CAT 7 cable only.
In this guide, any reference to these products refers to either family, unless explicitly stated.
NOTE: For clarity and where applicable, in this guide, the CAT 5, 5e, 6 versions are
referred to as non-C7 MTPs.
This guide details the installation and operation of the following products:
•MTP T 15HD A twisted pair (TP) transmitter
•MTP RL 15HD A receiver with loop-through
•MTP RL 15HD A SEQ receiver with loop-through and skew equalization
In this guide:
•The term "transmitter" refers specifically to the MTP T 15HD A transmitter.
•The term "receiver" refers to either of the receiver models — the MTP RL 15HD A or
MTP RL 15HD A SEQ.
•The term "SEQ receiver" refers specifically to the MTP RL 15HD A SEQ receiver with
skew equalization capabilities.
MTP 15HD A Series • Introduction 1

About the MTP Transmitters and Receivers
The Extron MTP T 15HD A transmitter and MTP RL 15HD A and MTP RL 15HD A SEQ
receivers are a system for long-distance distribution of VGA or other high resolution video
and audio.
The MTPs are a part of the Extron compact line of basic distribution amplifiers, switchers,
transmitters and receivers, and associated video accessories.
High resolution video on a 15-pin HD connector as well as stereo audio on a 3.5 mm stereo
jack is sent to the MTP transmitter. The transmitter sums the left and right audio channels
to convert the audio to mono (L+R) format. The MTP T then converts the input video and
mono audio signals to proprietary signals and outputs them to the compatible MTP receiver
on an RJ-45 connector. A pre-peaking control allows you to boost the transmission distance
of the proprietary signal. The transmitter also makes the input video available for local use
on a 15-pin HD connector.
The transmitted proprietary signal is sent to the receiver on an RJ-45 connector and
converts the signal back into its high resolution video and mono audio components. The
receiver outputs the video on a 15-pin HD connector and the two sets of identical mono
audio signals on a single 3.5 mm captive screw connector (A series only; RS series outputs
on a RS-232 connection).
The receiver also buffers the proprietary input signal and sends it to another compatible
MTP receiver or to a daisy chain of receivers.
NOTES:
• The transmitter provides pre-peaking, which boosts the signal before it is
transmitted. The buffered output on the receiver does not provide any
pre-peaking control. The total recommended distance (see the table on page 4)
for an entire daisy chain is the same as for a single transmitter and receiver. The
Pre-Peak switch on the transmitter has the same effect on the recommended
transmission distance for a daisy chain as for a single transmitter and receiver.
• Up to eight receivers can be connected in series using Buffered Output connectors,
provided that the total distance from the twisted pair output of the transmitter to
the last receiver in the chain does not exceed the recommended distance for the
resolution being used.
The SEQ receiver also corrects the skew delay commonly encountered when CAT 5, 5e, 6,
7, or STP201 cables are used for RGB video, component video, and S-video transmission.
NOTE: An SEQ receiver should not be necessary when Extron Enhanced Skew-Free AV
UTP cable and non-C7 transmitters and receivers are used.
Each MTP transmitter and receiver model is shipped with an external desktop 12 V power
supply that accepts 100 VAC to 240 VAC, 50-60 Hz input.
Twisted Pair Cable Advantages
Twisted pair cable is smaller, lighter, more flexible, and less expensive than coaxial cable.
Termination of the cable with RJ-45 connectors is simple, quick, and economical.
MTP 15HD A Series • Introduction 2

Transmission Distance
The maximum distance is determined by the frequency and resolution of the signal that
is input to the transmitter. The table on page 4 specifies the recommended maximum
transmission distances and transmitter Pre-Peak switch positions (see figure 3, eon page
9) using Extron Enhanced Skew-Free AV UTP cable, STP201 cable, or CAT 5, 5e, 6, or 7
cable, terminated with RJ-45 connectors.
NOTES:
• The transmitter and receiver are designed for and perform best with
Extron Enhanced Skew-Free AV UTP cable terminated in accordance with the
TIA/EIA T 568 A wiring standard. CAT 5, 5e, and 6 cables are acceptable, but less
preferable. We also recommend the use of pre-terminated and tested cables. Cables
terminated on site should be tested before use to ensure that they comply with
Category 5 specifications.
• The recommendations shown in the table on page 4 apply for a single transmitter
and receiver and for a daisy chain. For example, the maximum suggested range for
1024 x 768 video is 300 feet (90 m) with the Pre-Peak switch off and 500 feet
(150 m) with the Pre-Peak switch on, whether the system consists of one transmitter
and one receiver or a transmitter and three daisy-chained receivers.
• Extron recommends using at least 25 feet of twisted pair cable between the
transmitter and the first receiver.
• For daisy-chained units, the first receiver in the chain must be at least
100 feet (30 m) from the transmitter when the Pre-Peak switch is on.
• For daisy-chained units, any receiver in the chain closer than 350 feet (105 m) may
experience some form of over-peaking when the Pre-Peak switch is on.
An over-peaked image may appear bloomed.
MTP 15HD A Series • Introduction 3

Video
Format
Pre-
Peak off
Pre-Peak
on
Max. distance
(high quality)
Max. distance
(variable quality)
Composite,
S-video,
Component
800'
(245 m)
1000'
(300 m)
640 x 480 <300'
(90 m)
>350'
(105 m)
700'
(215 m)
750'
(240 m)
800 x 600 <300'
(90 m)
>350'
(105 m)
550'
(165 m)
650'
(200 m)
1024 x 768* <300'
(90 m)
>350'
(105 m)
500'
(150 m)
600'
(185 m)
1280 x 960* <300'
(90 m)
>350'
(105 m)
400'
(120 m)
500'
(150 m)
1280 x 1024* <250'
(75 m)
>300'
(90 m)
350'
(105 m)
450'
(135 m)
1360 x 765 <250'
(75 m)
>300'
(90 m)
400'
(120 m)
500'
(150 m)
1365 x 768 <250'
(75 m)
>300'
(90 m)
400'
(120 m)
450'
(135 m)
1366 x 768 <250'
(75 m)
>300'
(90 m)
400'
(120 m)
450'
(135 m)
1400 x 1050 <250'
(75 m)
>300'
(90 m)
350'
(105 m)
400'
(120 m)
1440 x 900 <250'
(75 m)
>300'
(90 m)
350'
(105 m)
400'
(120 m)
1600 x 1200* <250'
(75 m)
>300'
(90 m)
300'
(90 m)
450'
(135 m)
1920 x 1200 <250'
(75 m)
>300'
(90 m)
300'
(90 m)
400'
(120 m)
2048 x 1080 <250'
(75 m)
>300'
(90 m)
300'
(90 m)
400'
(120 m)
HDTV 720p <250'
(75 m)
>300'
(90 m)
400'
(120 m)
500'
(150 m)
HDTV 1080i <250'
(75 m)
>300'
(90 m)
300'
(90 m)
400'
(120 m)
HDTV 1080p <250'
(75 m)
>300'
(90 m)
300'
(90 m)
400'
(120 m)
Figure 1. Recommended Pre-Peak Switch Positions and Transmission Distances
at 60 Hz
NOTES:
• Resolutions marked with an asterisk (*) in the table above have the same range
specifications at 75 Hz.
• It is possible to exceed the recommended distance; however, image quality may be
reduced.
MTP 15HD A Series • Introduction 4

Installation
and Operation
This section provides information on:
•Installation Overview
•Front Panel Features
•Transmitter Rear Panel Features
•Receiver Rear Panel Features
•Power Supply Wiring and Grounding
•Twisted Pair Cable Termination
•Skew Delay Compensation
•EDID Configuration
Installation Overview
Follow the steps below to properly install and operate any of the Extron
MTP 15HD A transmitters and receivers.
ATTENTION: Potential damage to property.
Do not connect these devices to a computer data or telecommunications network.
1. Turn off all MTPs and devices. Make sure that the input sources, the MTP, and
the output sources are all turned off and all power sources and signal cables are
disconnected.
2. Connect the transmitter inputs (see Transmitter Rear Panel Features on page 9).
3. Connect twisted pair (TP) cables between the MTP units (see Transmitter Rear Panel
Features on page 9 and Receiver Rear Panel Features on page 11).
4. Connect the receiver outputs (see Receiver Rear Panel Features on page 11).
5. Configure the receiver DIP switches (see Receiver Rear Panel Features on page 11).
6. Configure the EDID (see Front Panel Features on page 6 and EDID Configuration
on page 16)
7. Connect the power supply and turn on all devices (see Power Supply Wiring on
page 12).
8. Adjust the level and peaking (see Front Panel Features on page 6).
9. Adjust the skew delay control (see Front Panel Features on page 6).
10. If applicable, mount the MTPs (see Mounting on page 19).
MTP 15HD A Series • Installation and Operation 5

Front Panel Features
See figure 2 to identify the front panel features on the transmitter and receiver.
MTP RL 15HD A Receiver
MTP SERIES
MTP RL 15HD A SEQ Receiver
RGB
PEAKING
LEVEL
RGB
DELAY
PEAKING
LEVEL
MTP SERIES
RED
GREENADJUST
BLUE
SELECT
ON
1 2 3 4 5
H SYNC + V SYNC + S-VIDEO
END UNIT SPARE
ON
1 2 3 4 5
H SYNC + V SYNC + S-VIDEO
END UNIT SPARE
MTP T 15HD A Transmitter
MTP SERIES
50 Hz
RECORD
60 Hz SPARE
EDID
SELECT
ON
6 7
1
61098 7
1
1
45
3
2
11
11
Figure 2. MTP 15HD Front Panels
aPower LED — The LED indicator lights when the unit is receiving power.
bRecord LED — The LED indicator flashes red during the EDID recording process to
indicate a new EDID being written to memory. The LED returns to a solid green after the
write completes.
c Record button — The recessed record button is used to initiate recording of the EDID
of a display device (connected to the loop-out) to user-programmable memory position
0 on the rotary switch (e).
d Vertical frequency DIP switch — The first DIP switch selects the vertical frequency
for the pre-programmed EDID. When switched to OFF (default position), the EDID
selected by the rotary positions 1 through E are based on 60 Hz. When switched to ON,
they are based on 50 Hz. The second DIP switch, marked SPARE, is not used.
NOTE: When the EDID select rotary switch (e) is in position 0 or F, the setting of
the first DIP switch is not applicable because the user-recorded or attached display
EDID is being used.
MTP 15HD A Series • Installation and Operation 6

e EDID select rotary switch — The rotary switch is used to select specific
pre-programmed or user-recorded EDID settings. Position 0 of this 16 position rotary
switch is used to select the user recorded EDID. Position F passes the EDID from the
display connected to the loop-out back to the input. Positions 1 through E select
pre-programmed EDID resolutions.
NOTE: The refresh rate of the pre-programmed EDID resolutions is selected using
the first DIP switch (d).
fLevel control — The level control alters the video output voltage to affect the
brightness of the displayed image. Adjust the knob while viewing the displayed image to
set the level that provides the best picture quality.
NOTE: For best results when using an RL receiver, connect a load to the buffered
output on the receiver before adjusting the level.
gPeaking control —Peaking affects the sharpness of a picture. Increased peaking
can compensate for mid and high frequency detail loss from low bandwidth
system components or capacitance in long cables. The minimum setting (at the
counterclockwise limit) provides no peaking. The maximum setting (at the clockwise
limit) provides 100% peaking. Adjust this control to obtain the optimum picture
sharpness.
hSelect button (SEQ model only) —This recessed button selects the Red, Green,
or Blue video signal to adjust and resets all three video signals to a skew delay of zero
nanoseconds.
Use a small screwdriver to press and release this button to cycle among selecting the
Red, Green, or Blue video signal to adjust. The selected signal is indicated by the Red,
Green, and Blue LEDs (i).
NOTE: The SEQ receiver automatically saves the setting for the video signal that is
being deselected when you push this button or when the selection times out after
10 seconds.
Press and hold this button for approximately 3 seconds to set the skew delay for Red,
Green, and Blue to zero. The Red, Green, and Blue LEDs (i) all turn off. Release the
button.
iRed, Green, and Blue LEDs (SEQ model only) —These LEDs indicate the video
signal that is selected by the Select button (h) for skew adjustment using the Delay
control (j). The LED of the selected color flashes when skew compensation for the
selected video signal has reached the minimum or maximum limit.
jDelay (skew adjustment) control (SEQ model only) —This control delays the
selected Red, Green, or Blue video signal by up to 62 nanoseconds. The delay is
applied in incremental, 2-nanosecond steps. Rotate the control counterclockwise to
reduce the delay or clockwise to increase the delay.
NOTES:
• The control turns smoothly; it does not have mechanical steps or high and low
limit stops.
• Watch the displayed image to observe the steps of delay.
• The selected Red, Green, or Blue LED (i) flashes to indicate that the control
has reached the minimum (counterclockwise rotation) or maximum (clockwise
rotation) limit.
MTP 15HD A Series • Installation and Operation 7

kDIP switches (RL receivers only) —A 5-pole DIP switch is used to configure the
features of the MTP receivers.
••Horizontal sync (H Sync +) switch — Set this switch On (up) for positive
horizontal sync or Off (down) for negative sync.
••Vertical sync (V Sync +) switch — Set this switch On (up) for positive vertical
sync or Off (down) for negative sync.
NOTE: Most devices use negative sync for H Sync and V Sync.
••S-Video switch — This switch is used to set which pins of the 15-pin HD
connector S-video is output on.
••Set this switch On (up) to output chroma on pin 3 and luma on pin 2.
••Set this switch Off (down) to output chroma on pin 1 and luma on pin 2.
••End Unit switch — Set this switch On (up) if either of the following is true:
••The receiver being configured is the only receiver connected to the transmitter.
••The receiver being configured is the last receiver in a daisy-chained system.
Set the End Unit switch Off (down) on the receiver being configured if there are one
or more receivers connected to the Buffered Output RJ-45 connector (see
figure 6, c).
MTP 15HD A Series • Installation and Operation 8

Transmitter Rear Panel Features
Figure 3 shows an MTP T 15HD A transmitter, which has all of the connectors and other
features that are on either transmitter in the MTP 15HD A series.
MTP T 15HD A Transmitter
OUTPUT
INPUT
AUDIO
POWER
12V
.5A MAX
MONITOR
PRE-PEAK
ON
OFF
MTP T 15HD A
NOTE: A “C7” label is affixed to
transmitters designed for
STP201 or CAT 7 cable.
125 63
4
Figure 3. Transmitter Rear Panel
aPower connector — Plug the included external 12 VDC power supply into this
2-pole captive screw connector (see Power Supply Wiring on page 12 to wire the
connector).
NOTES:
• The length of the exposed wires in the stripping process is critical. The ideal
length is 3/16 inches (5 mm). If the exposed section is longer, the exposed wires
may touch, causing a short circuit between them. If it is shorter, the wires can be
easily pulled out, even if tightly fastened by the captive screws.
• Do not tin the wires. Tinned wire does not hold its shape and can become loose
over time.
bInput video connector —Connect a computer video source to this 15-pin HD
connector for high resolution video input (see figure 4).
51
15 11
610
Female
Figure 4. 15-pin HD Connector
NOTES:
• Input only sync signals (no video signals) on the sync pins (13 and 14).
• For component video, use the R (R-Y) and R return pins (pins 1 and 6),
G (Y) and G return pins (pins 2 and 7), and B (B-Y) and B return pins
(pins 3 and 8). For S-video, use the R, R return (C-chroma), G, and
G return (Y-luma) pins.
• For composite video, use the G pin and the associated return pin. For additional
genlocked video signals, use the R, B, and associated return pins.
cMonitor connector — Connect a video monitor to this 15-pin HD connector for
buffered, high resolution video loop-through.
MTP 15HD A Series • Installation and Operation 9

dAudio input connector —Plug a 3.5 mm stereo audio plug into this connector for
unbalanced audio input. Wire the plug as shown in figure 5. The stereo audio input is
summed and output on the twisted pair cable as mono audio.
Sleeve ( )
Ring
Right (
- )
Tip
Left (+)
Figure 5. 3.5 mm Stereo Audio Plug
ePre-Peak switch — The Pre-Peak switch alters the twisted pair signal output to
correct for long cable runs (see the table on page 4 for suggested switch settings
based on the transmitted video format and transmission distance).
fOutput connector —Connect one end of a twisted pair cable to this RJ-45 female
connector on the transmitter. Connect the free end of the same twisted pair cable to
the RJ-45 female connector on the receiver (see Twisted Pair Cable Termination on
page 14 to wire the RJ-45 connectors).
ATTENTION: Potential damage to property.
Do not connect these devices to a computer data or telecommunications network.
MTP 15HD A Series • Installation and Operation 10

Receiver Rear Panel Features
Figure 6 shows an MTP RL 15HD A receiver, which has all of the connectors and other
features that are on either receiver in the MTP 15HD A series.
MTP RL 15HD A Receiver
NOTE: A “C7” label is affixed to
transmitters designed for
STP201 or CAT 7 cable.
INPUT BUFFERED
OUTPUT
OUTPUTS
RGB
POWER
12V
.5A MAX
MTP RL 15HD A
L
MONO AUDIO
R
1 2 3 4
5
Figure 6. Receiver Rear Panel
aPower connector —Plug the included external 12 VDC power supply into this
2-pole captive screw connector (see Power Supply Wiring on page 12 to wire the
connector).
bInput connector —Connect one end of the twisted pair cable from the transmitter or
from the buffered output connector of an RL receiver to this RJ-45 female connector.
cBuffered output connector — Connect one end of a twisted pair cable to this female
RJ-45 connector. Connect the free end of the same twisted pair cable from the receiver
to the Input RJ-45 female connector on another receiver (see Twisted Pair Cable
Termination on page 14 to wire the RJ-45 connectors).
dOutput video connector —Connect a projector or other high resolution video device
to this 15-pin HD connector.
eMono audio output connector —Insert a 3.5 mm, 5-pole captive screw audio
connector into this connector for two mono audio outputs. Wire the connector as
shown in figure 7. Use the supplied tie-wrap to strap the audio cable to the extended
tail of the connector.
Do not tin the wires!
ATTENTION: Potential damage to property.
For unbalanced audio, connect the sleeve(s) to the ground
contact.
DO NOT connect the sleeve(s) to the negative (-) contacts.
Balanced Audio Output
Tip
Ring
Tip
Ring
Sleeves
Unbalanced Audio Output
Tip
No Ground Here
No Ground Here
Tip
Sleeves
LR
LR
Figure 7. Captive Screw Audio Connector Wiring
NOTE: The length of the exposed wires in the stripping process is critical. The ideal
length is 3/16 inches (5 mm). If the exposed section is longer, the exposed wires
may touch, causing a short circuit between them. If it is shorter, the wires can be
easily pulled out, even if tightly fastened by the captive screws.
MTP 15HD A Series • Installation and Operation 11

Power Supply Wiring and Grounding
Figure 8 shows how to wire and ground the connector.
ATTENTION:
• Potential damage to property.
Power supply voltage polarity is critical. Incorrect voltage polarity can damage the
power supply and the transmitter or receiver. Identify the power cord negative lead
by the ridges on the side of the cord.
• To verify the polarity before connection, plug in the power supply with no load and
check the output with a voltmeter.
• The length of the exposed (stripped) copper wires is important. The ideal length is
3/16 inches (5 mm). Longer bare wires can short together. Shorter wires are not as
secure in the connector and could be pulled out.
Extron twisted pair products can be adversely affected by electrostatic discharge (ESD) if
they are not grounded correctly. To prevent malfunctions or product damage, an installer
can correctly ground an Extron twisted pair product by following the diagram in figure 8.
Ground the power port by inserting one end of the grounding wire to the negative or ground
pin on the power input connector.
Power Supply
Output Cord
SECTION A–A
Ridges
Smooth
AA
Tie
Wrap
POWER
12V
0.5A MAX Rear
Panel
Ridges
Earth
Ground
3/16"
(5 mm)
Max.
Figure 8. Power Connector Wiring and Grounding
WARNING: Failure to follow these instructions may result in serious injury.
The two power cord wires must be kept separate while the power supply is plugged in.
Disconnect the power before wiring.
NOTES:
• Your transmitter/receiver pair may have shipped with a blue captive screw connector.
This blue connector can be plugged into either a blue or an orange power
receptacle. The blue connector does not have the extended tail or the included
tie-wrap.
• Do not tin the power supply leads before installing in the direct insertion connector.
Tinned wires are not as secure in the connectors and could be pulled out of the
connector.
MTP 15HD A Series • Installation and Operation 12

ATTENTION:
• Potential damage to property.
This product is intended to be supplied by a Listed Power Unit marked "Class 2"
or "LPS", rated 12 VDC, maximum 1.0 A. Always use a power supply supplied
or specified by Extron. Use of an unauthorized power supply voids all regulatory
compliance certification and may cause damage to the supply and the end product.
• The installation must always be in accordance with the applicable provisions of
National Electrical Code ANSI/NFPA 70, article 75, and the Canadian Electrical Code
part 1, section 16. The power supply shall not be permanently fixed to building
structure or similar structure.
• Unless otherwise stated, the AC/DC adapters are not suitable for use in air handling
spaces or in wall cavities. The power supply is to be located within the same vicinity
as the Extron AV processing equipment in an ordinary location, Pollution Degree 2,
secured to the equipment rack within the dedicated closet, podium, or desk.
As an alternative, an Extron PS 124 Universal 12 VDC Power Supply (part number
60-1022-01) can power multiple MTPs or other Extron 12 VDC devices using only one AC
power connector.
MTP 15HD A Series • Installation and Operation 13

Twisted Pair Cable Termination
Figure 9 details the recommended termination of twisted pair cables with RJ-45 connectors
in accordance with the TIA/EIA T568A or TIA/EIA T568B wiring standards. You can use
either standard with CAT 5, 5e, 6, 7, and STP201 cable, but ensure that you use the same
standard on both ends of the cable.
RJ-45
Connector
Insert Twisted
Pair Wires
12345678
Pins:
Pi
nS
ignal
1R
ed/V. sync +
2R
ed/V. sync -
3
Green +
4
Blue/H. sync +
5
Blue/H. sync -
6
Green -
7
Mono audio +
8
Mono audio -
Wire color
White-green
Green
White-orange
Blue
White-blue
Orange
White-brown
Brown
Wire color
TIA/EIA T 568 ATIA/EIA T 568 B
White-orange
Orange
White-green
Blue
White-blue
Green
White-brown
Brown
NOTE: When using Enhanced Skew-Free™
AV UTP cable, use the TIA/EIA T568A
standard only.
Figure 9. Twisted Pair Cable Termination Diagram
NOTES:
• RJ-45 termination with CAT 5, 5e, or 6 cable must comply with the
TIA/EIA T568A or TIA/EIA T568B wiring standards for all connections.
• RJ-45 termination with Skew-Free AV UTP cable must comply with
TIA/EIA T568A only.
• For proper grounding of shielded twisted pair cable, ensure the shield around
each wire pair are all tied to the RJ-45 connectors on both ends, in accordance with
the connector specifications provided by the manufacturer.
• Extron Enhanced Skew-Free AV cable is not recommended for
Ethernet/LAN applications. This cable is specially designed for compatibility with
Extron Twisted Pair products that are wired using the TIA/EIA T568A standard.
• The green, brown, and blue wire pairs of this cable have virtually identical lengths
and should be used to transmit the RGB signals.
• The orange wire pair of this cable has a different length and should not be used to
transmit the RGB signals.
MTP 15HD A Series • Installation and Operation 14

Skew Delay Compensation
CAT 5, 5e, 6, 7, and STP201 cable can lead to registration errors between the Red, Green,
and Blue video signals. Pair skew can be measured with test equipment or identified by
viewing a crosshatch test pattern with a critical eye to determine if either the Red, Green, or
Blue video image leads (appears to the left of) the other two video images.
NOTE: Unless the twisted pair cable is changed, the skew adjustment should need to
be made only once, during installation.
SEQ Receiver Skew Compensation
The SEQ receiver has built-in skew compensation capabilities. Adjust the equalization as
follows:
1. Zero the skew delay for Red, Green, and Blue as follows:
a. Use a small screwdriver to press and hold the Select button for 3 seconds. The
Red, Green, and Blue LEDs all go out.
b. Release the Select button.
2. Use UTP cable test equipment or examine the displayed video image with a critical eye
to determine which video signal — Red, Green, or Blue — is most shifted to the
left.
NOTE: A crosshatch test pattern or a black background with vertical white lines is
ideal for determining skew.
3. Adjust the leftmost video signal as follows:
NOTE: The SEQ receiver cannot shift the rightmost video image to the left.
a. Use a small screwdriver to press and release the Select button until the LED lights
for the left-shifted color — Red, Green, or Blue.
b. Slowly rotate the Delay control clockwise while monitoring the display.
Observe that the leftmost color shifts rightward one step at a time. Continue to
rotate the control until that color is properly converged.
NOTE: A 2-nanosecond adjustment is very fine. Up to 10 nanoseconds of delay
may be necessary before you detect a change in the display.
c. Use a small screwdriver to press the Select button one more time to save the most
recent adjustment or allow the 10-second time-out to elapse.
4. If the remaining colors are left shifted, repeat steps 2 and 3.
Non-SEQ Receiver Skew Compensation
Try using the following methods to minimize or eliminate pair skew:
•Switch to Extron Enhanced Skew-Free AV UTP cable.
•Add a skew compensation cable equal to the length of pair skew to the output of the
receiver.
•Install an SEQ 100 15HD Skew Equalizer to the video output of the receiver and adjust
the skew for the leading video image.
MTP 15HD A Series • Installation and Operation 15
