Extron electronics TouchLink TLP Pro 1020 Series User manual

68-2405-01 Rev. A
08 14
TLP Pro 720 Series and
TLP Pro 1020 Series
User Guide
TouchLink®
TouchLink Pro Touchpanel Control Systems

Safety Instructions • English
WARNING: This symbol, D, when used on the product, is intended
to alert the user of the presence of uninsulated dangerous voltage
within the product’s enclosure that may present a risk of electric shock.
ATTENTION: This symbol, I, when used on the product, is
intended to alert the user of important operating and maintenance
(servicing) instructions in the literature provided with the equipment.
For information on safety guidelines, regulatory compliances, EMI/EMF
compatibility, accessibility, and related topics, see the Extron Safety and
Regulatory Compliance Guide, part number 68-290-01, on the Extron
website, www.extron.com.
Instructions de sécurité • Français
AVERTISSEMENT : Ce pictogramme, D, lorsqu’il est utilisé sur
le produit, signale à l’utilisateur la présence à l’intérieur du boîtier du
produit d’une tension électrique dangereuse susceptible de provoquer
un choc électrique.
ATTENTION : Ce pictogramme, I, lorsqu’il est utilisé sur
le produit, signale à l’utilisateur des instructions d’utilisation ou de
maintenance importantes qui se trouvent dans la documentation
fournie avec le matériel.
Pour en savoir plus sur les règles de sécurité, la conformité à la
réglementation, la compatibilité EMI/EMF, l’accessibilité, et autres sujets
connexes, lisez les informations de sécurité et de conformité Extron,
réf. 68-290-01, sur le site Extron, www.extron.com.
Sicherheitsanweisungen • Deutsch
WARNUNG: Dieses Symbol Dauf dem Produkt soll den Benutzer
darauf aufmerksam machen, dass im Inneren des Gehäuses dieses
Produktes gefährliche Spannungen herrschen, die nicht isoliert sind
und die einen elektrischen Schlag verursachen können.
VORSICHT: Dieses Symbol Iauf dem Produkt soll dem Benutzer
in der im Lieferumfang enthaltenen Dokumentation besonders wichtige
Hinweise zur Bedienung und Wartung (Instandhaltung) geben.
Weitere Informationen über die Sicherheitsrichtlinien, Produkthandhabung,
EMI/EMF-Kompatibilität, Zugänglichkeit und verwandte Themen finden Sie
in den Extron-Richtlinien für Sicherheit und Handhabung (Artikelnummer
68-290-01) auf der Extron-Website, www.extron.com.
Instrucciones de seguridad • Español
ADVERTENCIA: Este símbolo, D, cuando se utiliza en el producto,
avisa al usuario de la presencia de voltaje peligroso sin aislar dentro del
producto, lo que puede representar un riesgo de descarga eléctrica.
ATENCIÓN: Este símbolo, I, cuando se utiliza en el producto,
avisa al usuario de la presencia de importantes instrucciones de uso y
mantenimiento recogidas en la documentación proporcionada con el
equipo.
Para obtener información sobre directrices de seguridad, cumplimiento
de normativas, compatibilidad electromagnética, accesibilidad y temas
relacionados, consulte la Guía de cumplimiento de normativas y seguridad de
Extron, referencia 68-290-01, en el sitio Web de Extron,
www.extron.com.
Инструкция по технике безопасности •Русский
ПРЕДУПРЕЖДЕНИЕ: Данный символ, D, если указан
на продукте, предупреждает пользователя о наличии
неизолированного опасного напряжения внутри корпуса
продукта, которое может привести к поражению электрическим
током.
ВНИМАНИЕ: Данный символ, I, если указан на продукте,
предупреждает пользователя о наличии важных инструкций по
эксплуатации и обслуживанию в руководстве, прилагаемом к
данному оборудованию.
Для получения информации о правилах техники безопасности,
соблюдении нормативных требований, электромагнитной
совместимости (ЭМП/ЭДС), возможности доступа и других вопросах
см. руководство по безопасности и соблюдению нормативных
требований Extron на сайте Extron: www.extron.com, номер по
каталогу - 68-290-01.
Chinese Simplified（简体中文）
警告： D产品上的这个标志意在警告用户该产品机壳内有暴露的危险 电压，
有触电危险。
注意：I产品上的这个标志意在提示用户设备随附的用户手册中有
重要的操作和维护(维修）说明。
关于我们产品的安全指南、遵循的规范、EMI/EMF 的兼容性、无障碍
使用的特性等相关内容，敬请访问 Extron 网站 www.extron.com，参见 Extron
安全规范指南，产品编号 68-290-01。
Chinese Traditional（ )
警告: D 若產品上使用此符號，是為了提醒使用者，產品機殼內存在著
可能會導致觸電之風險的未絕緣危險電壓。
注意I 若產品上使用此符號，是為了提醒使用者，設備隨附的用戶手冊中有重要
的 操 作 和 維 護（ 維 修 ）説 明 。
有關安全性指導方針、法規遵守、EMI/EMF 相容性、存取範圍和相關主題的詳細資訊，
請瀏覽 Extron 網站：www.extron.com，然後參閱《Extron 安全性與法規遵守手
冊》，準則編號 68-290-01。
Japanese
警告:この記号 D が製品上に表示されている場合は、筐体内に絶縁されて
いない高電圧が流れ、感電の危険があることを示しています。
注意:この記号 I が 製 品 上 に 表 示 さ れ て い る 場 合 は 、本 機 の 取 扱 説 明 書 に 記 載 さ れ て
いる重要な操作と保守(整備)の指示についてユーザーの注意を喚起するものです。
安全上のご注意、法令遵守、EMI/EMF適合性、その他の関連項目に
つ い て は 、エ ク スト ロ ン の ウェ ブ サ イト www.extron.com より
『Extron Safety and Regulatory Compliance Guide』 (P/N 68-290-01) をご覧く
ださい。
Korean
경고: 이 기호 D, 가 제품에 사용될 경우, 제품의 인클로저 내에 있는
접지되지 않은 위험한 전류로 인해 사용자가 감전될 위험이 있음을
경고합니다.
주의: 이 기호 I, 가 제품에 사용될 경우, 장비와 함께 제공된 책자에 나와
있는 주요 운영 및 유지보수(정비) 지침을 경고합니다.
안전 가이드라인, 규제 준수, EMI/EMF 호환성, 접근성, 그리고 관련 항목에 대한
자세한 내용은 Extron 웹 사이트(www.extron.com)의 Extron 안전 및 규제 준수
안내서, 68-290-01 조항을 참조하십시오.
Safety Instructions

FCC Class A Notice
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part15 of the FCC rules. The ClassA limits provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause interference.
This interference must be corrected at the expense of the user.
NOTE:
• This unit was tested with shielded I/O cables on the peripheral devices. Shielded
cables must be used to ensure compliance with FCC emissions limits.
• For more information on safety guidelines, regulatory compliances, EMI/EMF
compatibility, accessibility, and related topics, see the Extron Safety and
Regulatory Compliance Guide on the Extron website.
Copyright
© 2014 Extron Electronics. All rights reserved.
Trademarks
All trademarks mentioned in this guide are the properties of their respective owners.
The following registered trademarks(®), registered service marks(SM), and trademarks(TM) are the property of
RGBSystems, Inc. or Extron Electronics:
Registered Trademarks (®)
AVTrac, Cable Cubby, CrossPoint, eBUS, EDID Manager, EDID Minder, Extron, Flat Field, GlobalViewer, Hideaway, Inline, IPIntercom,
IPLink, Key Minder, LockIt, MediaLink, PlenumVault, PoleVault, PowerCage, PURE3, Quantum, SoundField, SpeedMount, SpeedSwitch,
SystemINTEGRATOR, TeamWork, TouchLink, V-Lock, VersaTools, VN-Matrix, VoiceLift, WallVault, WindoWall, XTP, XTP Systems
Registered Service Mark(SM) : S3 Service Support Solutions
Trademarks (™)
AAP, AFL (Accu-Rate Frame Lock), ADSP (Advanced Digital Sync Processing), Auto-Image, CableCover, CDRS (Class D Ripple Suppression),
DDSP (Digital Display Sync Processing), DMI (Dynamic Motion Interpolation), DriverConfigurator, DSPConfigurator, DSVP (Digital Sync
Validation Processing), EQIP, FastBite, FOXBOX, Global Configurator, IP Intercom HelpDesk, LinkLicense, MAAP, MicroDigital, ProDSP, QS-FPC
(QuickSwitch Front Panel Controller), Scope-Trigger, SIS, Simple Instruction Set, Skew-Free, SpeedNav, Triple-Action Switching, XTRA,
ZipCaddy, ZipClip

Conventions Used in this Guide
Notifications
In this user guide, the following are used:
WARNING: Potential risk of severe injury or death.
AVERTISSEMENT : Risque potentiel de blessure grave ou de mort.
CAUTION: Risk of minor personal injury.
ATTENTION : Risque de blessuremineure.
ATTENTION:
• Risk of property damage.
• Risque de dommages matériels.
NOTE: A note draws attention to important information.
Software Commands
Commands are written in the fonts shown here:
^AR Merge Scene,,Op1 scene 1,1 ^B 51 ^W^C
[01] R 0004 00300 00400 00800 00600 [02] 35 [17] [03]
E X!*X1&*X2)*X2#*X2!CE}
NOTE: For commands and examples of computer or device responses
mentioned in this guide, the character “0” is used for the number zero and “O”
represents the capital letter “o”.
Computer responses and directory paths that do not have variables are written in the font shown
here:
Reply from 208.132.180.48: bytes=32 times=2ms TTL=32
C:\Program Files\Extron
Variables are written in slanted form as shown here:
ping xxx.xxx.xxx.xxx —t
SOH R Data STX Command ETB ETX
Selectable items, such as menu names, menu options, buttons, tabs, and field names are written
in the font shown here:
From the File menu, select New.
Click the OK button.
Specifications Availability
Product specifications are available on the Extron website, www.extron.com.

Contents
Introduction............................................................ 1
About the TLP Pro 720 and
TLP Pro 1020 Series..............................................1
Features..................................................................1
Application Diagram ................................................3
Installation Overview ........................................... 4
Panel Features ...................................................... 6
TLP Pro 720 Series and TLP Pro 1020 Series Front
Panel Features .......................................................6
TLP Pro 720M and TLP Pro 1020M Front Panel with
Bezel Removed......................................................8
TLP Pro 720 Series and TLP Pro 1020 Series
Rear Panel Features...............................................9
On-screen Menus............................................... 15
Setup Menu ..........................................................15
Status Screen ...................................................15
Network Screen ................................................16
Display Screen ..................................................18
Audio Screen ....................................................18
Advanced Screen..............................................19
Touch Calibration Screen ......................................20
Configuration Software..................................... 21
Configuration Software..........................................21
Installing GUI Designer and
Global Configurator..........................................21
Using the Software............................................22
TLP Pro 720 Series and TLP Pro 1020 Series
Web Pages ..........................................................22
Updating the Firmware..........................................23
Downloading Firmware......................................23
Updating Firmware Using the Touchpanel
Web Page........................................................23
Updating Firmware Using
Global Configurator..........................................23
Mounting............................................................... 24
Mounting the TLP Pro 720M and
TLP Pro 1020M ...................................................24
Rack Mounting..................................................24
Wall Mounting the TLP Pro 720M and
TLP Pro 1020M ...............................................24
Furniture Mounting the TLP Pro 720M and
TLP Pro 1020M ...............................................26
Mounting the TLP Pro 720T and
TLP Pro 1020T ....................................................27
Desktop Mounting ............................................27
VESA Mounting.................................................29
Reference Material............................................. 31
Reset Modes.........................................................31
Use Factory Firmware .......................................31
Reset All IP Settings..........................................32
Reset to Factory Defaults..................................32
Licensed Third-Party Software Used in the
Touchpanels.........................................................33
TLP Pro 720 Series and TLP Pro 1020 Series • Contents v

TLP Pro 720 Series and TLP Pro 1020 Series • Contents vi

Introduction
This guide describes the function, installation, and operation of the following Extron TLPPro720
Series and TLP Pro 1020 Series of Touchlink Pro Touchpanels:
zTLP Pro 720M
zTLPPro720T
zTLPPro1020M
zTLPPro1020T
Unless otherwise stated, the term TLP Pro refers to all four models. The terms TLPPro720
or TLPPro720 Series refer to the TLPPro720M and TLPPro720T models. The terms
TLPPro1020 or TLPPro1020 Series refer to the TLPPro1020M and TLPPro1020T models.
The touchpanels are ideal for any AV applications requiring medium or large touchpanels with
flexible mounting options and fully customizable interfaces.
This section provides an overview of these products:
zAbout the TLP Pro 720 and TLP Pro 1020 Series
zFeatures
zApplication Diagram
About the TLP Pro 720 and TLP Pro 1020 Series
The TLP Pro 720 Series touchpanels have 7-inch screens with a resolution of 800x480.
zTLP Pro 720M is a wall-mount touchpanel.
zTLPPro720T is a tabletop touchpanel.
The TLP Pro 1020 Series touchpanels have 10-inch screens with a resolution of 1024x600.
zTLPPro1020M is a wall-mount touchpanel.
zTLPPro1020T is a tabletop touchpanel.
A range of mounting options are available (see Mounting on page23).
The screen layout is designed with the Extron GUI Designer software. The functions are
assigned to the screen objects with the Extron Global Configurator Plus and Global Configurator
Professional software. The user can define the graphics and the functions associated with those
graphics, providing versatility and adaptability to the configuration and control of an AV system.
A motion sensor, light sensor, and a speaker provide sleep mode, auto dimming, and audible
feedback.
Features
LCD touchscreen with 18-bit color depth —
z7-inch screen with 800x480 resolution (TLPPro720 Series)
z10-inch screen with 1024x600 resolution (TLPPro1020 Series)
Faster processing and more memory — Allows for quicker configuration uploads and more
storage for GUI pages.
Compatible with the full range of Extron IPL Pro and IPCP Pro control processors —
allows easy integration into existing systems.
Power over Ethernet (PoE 802.3af, class3) compliance — receives power and control
over a single Ethernet cable, eliminating the need for a local power supply (power injector
sold separately).
TLP Pro 720 Series and TLP Pro 1020 Series • Introduction 1

Built-in speakers — one speaker (TLP Pro 720 Series) or two (TLP Pro 1020 Series), with
improved audio performance provide audible feedback from button presses.
Light sensor — adjusts screen brightness as the ambient room lighting changes.
Configurable red and green status lights — indicate the availability or call status of a room.
System connection status indicator — the communication LED provides visual feedback if
the touchpanel is not communicating with a control processor.
Automatic clock synchronization — allows touchpanel to display the accurate time and date.
Energy-saving features —
zAdjustable sleep timer puts touchpanel into sleep mode
zMotion detector wakes touchpanel
Mounting options for tilt models (TLP Pro 720T or TLP Pro 1020T):
zSit on a tabletop — weighted base allows up to 45° of tilt.
zThreaded holes in baseplate allow for secure mounting to a table.
zKensington lock support allows the touchpanels to be locked to a table or other flat surface.
zSupports the optional SMA-1 Swivel Mount Adapter.
zVESA FDMI Type D 100 mm mounting pattern standard can be used for VESA mounting.
Mounting options for wall-mount models (TLP Pro 720M or TLP Pro 1020M):
zMount on a wall, lectern, or any flat surface.
zRack mount.
Fully customizable using Extron control system software — GUI Designer combined with
Global Configurator Plus and Global Configurator Professional.
Supports TouchLink for iPad and TouchLink for Web.
TLP Pro 720 Series and TLP Pro 1020 Series • Introduction 2

Application Diagram
The application diagram below shows the TLP Pro 720M. The other touchpanels in this user
guide can be used in similar configurations.
0.5A MAX
POWER
12V
1
Tx Rx
1234+V
1234G
RS-232 AUTOCONTACT
TALLY OUT
SW4 HDMI
234
INPUTS OUTPUT REMOTE
INPUT
S/PDIF ANALOG
HAE 100
OUTPUTS
AUDIO
FORMAT HDMI OUTPUT AUDIO
LR ON
OFF
EDID
STORE
12V
0.4A MAX HDMI
POWER
HDMI
ON
12
POWER
12V
0.7A MAX
LR
L
8Ω / 4Ω
CLASS 2
WIRING
R
10V
VCG
50mA
L
MPA 152 Plus
R
INPUTS
OUTPUTS REMOTE
POWER
12V
--A MAX
G
Tx Rx RTSCTS
COM 1
G
Tx Rx
COM 2
VCG
VOL RELAYS
1 2 C
1 2 3 4 G
DIGITAL I/O
PWR OUT = 6W
eBUS
+V +S -S G
LAN
IPCP PRO 250
IR/S
S G
STANDBY/ON
PQLS HDMI OPEN/CLOSE FLOFF
USB
!
1@ 2# 3$ 4% 5^ 6& 7* 8( 9) 0
_
-+
=
|
\
}
]
{
[
~
`
QWERTYUIOP
“
‘
:
;
<
,> .? /
ASDFGHJ
ZXCVBNM
KL
control
shift
capslock
tab
esc
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10F11 F12F13 F14F15 F16F17 F18F19
alt
option command
delete fn home clear
enter
=/*
8-
5
2
7
0.
4
1
+
9
6
3
page
up
page
down
enddelete
commandoptioncontrol
shift
return
MODEL80
FLAT PANEL
WiFi 1234
Extron
TLP Pro 720M
7" Wall Mount
TouchLink Pro
Touchpanel
Blu-ray
Player
PC
Extron
MPA 152 Plus
Power Amplier
Extron
HAE 100
HDMI Audio De-Embedder
Extron
SW4 HDMI
Switcher
Extron
SM 3
Full-Range Speakers
TCP/IP
Network
Satellite
Receiver
Laptop
Extron
IPCP Pro 250
IP Link Pro
Control Processor
Shade
Control
Flat Panel Display
Motion
Sensor
Ethernet/PoE
Ethernet
Digital Input
Relay
RS-232
RS-232
HDMI
HDMI
HDMI
Volume Control
HDMI HDMI
HDMI
Audio
IR
PUSH PUSH
POWERGUIDE MENU RES480 480p 720p 1080i 1080p DIRECTV HD
SELECT
DIRECTV
Extron
Help System
Off
Display
Room
Control
Off
Mute
Screen
Lighting
December 15, 2013 - 7:58 AM
Audio
Control
Volume
Mute
Tuner
12 3
VCRLaptop PC DVD Doc
Cam
Tuner
On
Channel
Last
Presets
More
Presets
321
654
987
Enter
0
Figure 1. Application Diagram
TLP Pro 720 Series and TLP Pro 1020 Series • Introduction 3

Installation
Overview
1. Before starting, download and install the latest versions of the following software:
Global Configurator Plus and Global Configurator Professional — for setting up
and configuring the control processor and touchpanel.
GUI Designer — for designing layouts for Extron TouchLink Pro touchpanels and third
party touch interfaces.
See Configuration Software on page 20.
2. Obtain the following network information from your network administrator:
DHCP status (On or Off). If DHCP is Off, you will also require
IP address
Subnet mask
Gateway
User name — by default these are either admin or user.
Passwords — by default these are either extron (for admin) or the field is left blank (for
user).
MAC address — make a note of the touchpanel MAC address.
3. Mount and cable the units:
ATTENTION:
• Do not power on the touchpanels or control processors until you have read
the Attention notice on page 10 (12 VDC power supply) or on page 12 (power
injector).
• Ne branchez pas les écrans tactiles ou les contrôleurs avant d’avoir lu les mises
en garde page10 (source d’alimentation 12VCC) ou page12 (injecteur PoE).
Mount the units. There are several mounting options for TouchLink Pro touchpanels (see
Mounting on page 23).
Connect cables to the touchpanels. See TLP Pro 720 Series and TLP Pro 1020
Series Rear Panel Features (page 8).
Connect the power cords and power on all devices (see Power Connector on page9
or Network and Power Injector Connector on page 11).
4. Set up the Touchpanels for Network Communication:
Connect the PC that you will use for setup, the control processor, and the touchpanel to
the same Ethernet subnetwork.
Use the Setup Menu (see page 14) or the Toolbelt feature of Global Configurator Plus
and Global Configurator Professional to set the DHCP status and, if necessary, the IP
address, subnet mask, gateway, and related settings for the touchpanel.
5. Configure the Touchpanels — the Global Configurator Plus and Global Configurator
Professional Help File and the GUI Designer Help File provide step-by-step instructions and
detailed information. The Global Configurator Plus and Global Configurator Professional
Help File includes an introduction to the software and sections on how to start a project and
configuration.
TLP Pro 720 Series and TLP Pro 1020 Series • Installation Overview 4

Panel Features
This section describes:
zTLP Pro 720 Series and TLP Pro 1020 Series Front Panel Features
zTLP Pro 720M and TLP Pro 1020M Front Panel with Bezel Removed
zTLP Pro 720 Series and TLP Pro 1020 Series Rear Panel Features
TLP Pro 720 Series and TLP Pro 1020 Series Front Panel Features
Extron
B
C
A
E
F
D
B
C
A
E
D
AA
C
B
A
E
D
B
A
E
F
D
C
AA
F
F
CC
TLP Pro 720M TLP Pro 1020M
TLP Pro 720T TLP Pro 1020T
Figure 2. TLP PRO 720 Series and TLP PRO 1020 Series Front Panels
AStatus Lights DAmbient Light Sensor
BMotion Sensor ELCD Screen
CSpeaker FCommunication LED
TLP Pro 720 Series and TLP Pro 1020 Series • Panel Features 5

AStatus lights — one on each side can be programmed to provide system feedback.
zLight red or green
zBlink or light continuously
BMotion sensor — detects motion between three to five feet from the touchpanel, and at
least 15° from the center axis.
zWhen no motion has been detected for a user-defined period of time, the touchpanel
enters sleep mode.
zWhen motion is detected by the sensor, the screen display is restored and active.
CSpeaker — is located below the screen and provides audible feedback for the user. The
TLPPro 720 Series touchpanels have a single speaker on the left side of the panel. The
TLPPro1020 Series touchpanels have two speakers, one on each side of the panel.
DD
Figure 3. TLP PRO 720M Top View
DAmbient light sensor — monitors ambient light level and adjusts screen brightness, based
on the settings configured using the setup menu (see page 14).
ELCD screen — has a 800x480 resolution with a touch overlay (TLP Pro 720 Series) or
1024x600 resolution with a touch overlay (TLP Pro 1020 Series).
FCommunication LED — shows the configuration and connection status of the touchpanel:
zUnlit during normal operation (the touchpanel is configured and connected to an IP Link
Pro control processor).
zBlinks red if the touchpanel has been configured but is not connected to an IP Link Pro
control processor.
zPermanently lit if the touchpanel has not been configured and is not connected to an IP
Link Pro control processor.
The indicator can be toggled between enabled and disabled, using the setup menu (see
page 14).
TLP Pro 720 Series and TLP Pro 1020 Series • Panel Features 6

TLP Pro 720M and TLP Pro 1020M Front Panel with Bezel Removed
Remove the front bezel by inserting the Extron removal tool into the slots on the bottom of
the unit and separating the bezel from the touchpanel. The following additional features are
concealed behind the bezel:
TLP Pro 720M TLP Pro 1020M
AA
B
BC
CDD
A
A
B
BC
CDD
Figure 4. TLP Pro 720M and TLP Pro 1020M Front Panel with Bezel Removed
ABezel attachment points
The TLP Pro 720M has eight attachment points: two on each side, two on the top edge and
two on the bottom edge.
The TLP Pro 1020M has ten attachment points: three on each side, two on the top edge
and two on the bottom edge.
BMenu button — activates the setup menu (see page14) and calibration screen (see
page19.
CReset button — initiates one of three reset modes for the unit (see Reset Modes on
page30).
DReset LED — indicates power status and reset status of the device (see Reset Modes on
page 30.
TLP Pro 720 Series and TLP Pro 1020 Series • Panel Features 7

TLP Pro 720 Series and TLP Pro 1020 Series Rear Panel Features
Extron
A
A
B
B
B
C
D
E
F
A
B
C
D
E
F
LAN /PoE
POWER
12 V
1.0 A MAX
33-2455-01 A
N15779
Patent(s) www.extron.com/patents
I.T.E.
1T23
TLP Pro 720T
A
LAN /PoE
POWER
12 V
1.0 A MAX
33-2453-01 A
N15779
Patent(s) www.extron.com/patents
I.T.E.
1T23
TLP Pro 1020T
Figure 5. TLP Pro 720 Series and TLP Pro 1020 Series Rear Panels
APower Connector DReset button
BNetwork and Power Injector Connector EReset LED
CMenu button FVESA mounting holes
TLP Pro 720 Series and TLP Pro 1020 Series • Panel Features 8

APower connector (see figure 5, on the previous page)— power supplies must be
purchased separately.
TLP Pro 720T and TLP Pro 1020T — Connect a 12 VDC, 1.0 A power supply with DCplug
to the rear panel power receptacle. Extron recommends using the PS 1210 P power supply
(part number 70-778-01).
TLP Pro 720M and TLP Pro 1020M — Connect a 12 VDC, 1.0 A power supply with a
captive screw connector to the rear panel receptacle. Ensure the connections have the
correct polarity as shown below. Extron recommends using the PS 1210 C power supply
(part number 70-775-01).
Power Receptacle
Captive Screw Connector
SECTION A–A
Ridges
Smooth
Power Supply
Output Cord
AA
3/16"
(5 mm) Max.
Ground
all devices.
External
Power Supply
(12 VDC, 1 A max.,
Extron PS 1210C)
– Return
+12 VDC input
Ridged
Smooth
1AMAX
100-240V 50-60Hz
Figure 6. Power Supply Connection
WARNING: The two power cord wires must be kept separate while the power
supply is plugged in. Remove power before wiring.
AVERTISSEMENT : Les deux cordons d’alimentation doivent être tenus à l’écart
l’un de l’autre quand l’alimentation est branchée. Couper l’alimentation avant de
faire l’installation électrique.
CAUTION: Risk of Explosion if battery is replaced by an incorrect type. Dispose of
used batteries according to the instructions.
ATTENTION :Risque d’explosion. Ne pas remplacer la pile par le mauvais type de
pile. Débarrassez-vous des piles utilisées selon le mode d’emploi.
ATTENTION:
• Do not power on the touchpanels or control processors until you have read
the Attention notice on page 10 (12 VDC power supply) or on page 12 (power
injector).
• Ne branchez pas les écrans tactiles ou les contrôleurs avant d’avoir lu les mises
en garde page10 (source d’alimentation 12VCC) ou page12 (injecteur PoE).
NOTES:
• These touchpanels ship without a power supply. Either the 12 VDC power supply
or the power injector must be purchased separately.
• If a 12 VDC and a PoE power supply are both connected to the touchpanel, the
power injector takes precedence. If a PoE power loss is detected, the touchpanel
switches seamlessly to the 12 VDC supply without needing a system reboot.
TLP Pro 720 Series and TLP Pro 1020 Series • Panel Features 9

ATTENTION:
• Always use a power supply provided by or specified by Extron. Use of an
unauthorized power supply voids all regulatory compliance certification and may
cause damage to the supply and the end product.
• Utilisez toujours une source d’alimentation fournie ou recommandée par Extron.
L’utilisation d’une source d’alimentation non autorisée annule toute conformité
réglementaire et peut endommager la source d’alimentation ainsi que le produit final.
• These products are intended for use with a UL Listed power source marked “Class 2”
or “LPS” and rated 12VDC, minimum 1.0 A. or 48 VDC (PoE), minimum 0.35 A.
• Ces produits sont destiné à une utilisation avec une source d’alimentation listéeUL
avec l’appellation «Classe2» ou «LPS» et normée 12Vcc, 1,0A minimum ou
48Vcc (PoE), 0,35A minimum.
• Extron power supplies are certified to UL/CSA 60950-1 and are classified as LPS
(Limited Power Source). Use of a non-LPS or unlisted power supply will void all
regulatory compliance certification.
• Les sources d’alimentation Extron sont qualifiées UL/CSA60950-1 et sont
classéesLPS(LimitedPowerSource). L’utilisation d’une source d’alimentation non-
listée ou non-listéeLPS annulera toute certification de conformité réglementaire.
• Unless otherwise stated, the AC/DC adapters are not suitable for use in air handling
spaces or in wall cavities. The power supply is to be located within the same vicinity
as the Extron AV processing equipment in an ordinary location, Pollution Degree 2,
secured to the equipment rack within the dedicated closet, podium, or desk.
• Sauf mention contraire, les adaptateurs AC/DC ne sont pas appropriés pour une
utilisation dans les espaces d’aération ou dans les cavités murales. La source
d’alimentation doit être située à proximité de l’équipement de traitement audiovisuel
dans un endroit ordinaire, avec un degré2 de pollution, fixé à un équipement de rack
à l’intérieur d’un placard, d’une estrade, ou d’un bureau.
• The installation must always be in accordance with the applicable provisions of
National Electrical Code ANSI/NFPA 70, article 725 and the Canadian Electrical Code
part 1, section 16.
• Cette installation doit toujours être en accord avec les mesures qui s’applique au
National Electrical Code ANSI/NFPA70, article725, et au Canadian Electrical Code,
partie1, section16.
• The power supply shall not be permanently fixed to the building structure or similar
structure.
• La source d’alimentation ne devra pas être fixée de façon permanente à une structure
de bâtiment ou à une structure similaire.
• The length of the exposed wires in the stripping process is critical. The ideal length is
3/16 inches (5 mm). If they are any longer, the exposed wires may touch, causing a
short circuit between them. If they are any shorter, the wires can be easily pulled out
even if tightly fastened by the captive screws.
• La longueur des câbles exposés est primordiale lorsque l’on entreprend de les
dénuder. La longueur idéale est de 5mm (3/16inches). S’ils sont un peu plus longs,
les câbles exposés pourraient se toucher et provoquer un court circuit. S’ils sont un
peu plus courts, ils pourraient sortir, même s’ils sont attachés par les vis captives.
• Do not tin the wire leads before installing into the connector. Tinned wires are not as
secure in the connector and could be pulled out.
• Ne pas étamer les conducteurs avant de les insérer dans le connecteur. Les câbles
étamés ne sont pas aussi bien fixés dans le connecteur et pourraient être retirés.
TLP Pro 720 Series and TLP Pro 1020 Series • Panel Features 10

BNetwork and Power Injector Connector (see figure 5)— is on the right side of the
recessed area.
Connect the touchpanel to the LAN using a twisted pair cable, terminated with an RJ-45
connector. Use a straight-through Ethernet cable to connect the panel to a switch or router.
Use a crossover cable to connect the panel directly to a computer.
An Extron IPL Pro Control Processor must also be connected to the same network domain
as the TouchLink Pro touchpanel. See the www.extron.com for a list of suggested models.
The network port has two LEDs. The green LED lights steadily to indicate that the
touchpanel is connected correctly to a network. The yellow LED flashes to indicate that data
is being passed to or from the touchpanel.
The connector can also be used with a PoE power injector (not provided).
ATTENTION:
• The touchpanels can use a 12 VDC desktop power supply and is also Power
over Ethernet (PoE 802.3af, class3) compliant. Do not connect either power
supply before reading the Attention notifications on page 10 or page 12.
• Les écrans tactiles peuvent utiliser une source d’alimentation externe 12 Vcc, et
sont également compatible avec l’alimentation POE via Ethernet (PoE802.3af,
classe 3). Ne branchez pas de sources d’alimentation externes avant d’avoir lu
les mises en garde dans la section «PowerSupply» sur page10 ou page 12.
To use a PoE power injector — connect a straight-through Ethernet cable to the power
supply and a switch or router. This cable carries network information from the switch or
router to the power supply input. A second straight-through cable carries the network
information and 48VDC from the power supply to the touchpanel. Connect the IEC power
cord to a convenient 100 VAC to 240 VAC, 50-60 Hz power source.
The figure below shows the Extron XTP PI 100. Your power injector may look different.
100-240V ~ 50-60Hz
0.4A MAX
XTP
PWR
XTP PWR
To network switchTo touchpanel
Figure 7. Connecting the Power Injector
CAUTION: Risk of Explosion if the battery is replaced by an incorrect type. Dispose
of used batteries according to the instructions.
ATTENTION :Risque d’explosion. Ne pas remplacer la pile par le mauvais type de
pile. Débarrassez-vous des piles utilisées selon le mode d’emploi.
TLP Pro 720 Series and TLP Pro 1020 Series • Panel Features 11

ATTENTION:
• The touchpanels are intended for connection to a Power over Ethernet circuit for
intra-building use only and are considered to be part of a Network Environment 0 per
IEC TR62101.
• Les écrans tactiles sont conçu pour une connexion à un circuit PoE pour une
utilisation intérieure seulement et est considéré comme faisant partie d’un
environnement réseau 0 par IECTR62101.
• Always use a power supply provided by or specified by Extron. Use of an
unauthorized power supply voids all regulatory compliance certification and may
cause damage to the supply and the end product.
• Utilisez toujours une source d’alimentation fournie ou recommandée par Extron.
L’utilisation d’une source d’alimentation non autorisée annule toute conformité
réglementaire et peut endommager la source d’alimentation ainsi que le produit final.
• These products are intended for use with a UL Listed power source marked “Class 2”
or “LPS” and rated 12VDC, minimum 1.0 A. or 48 VDC (PoE), minimum 0.35 A.
• Ces produits sont destiné à une utilisation avec une source d’alimentation listéeUL
avec l’appellation «Classe2» ou «LPS» et normée 12Vcc, 1,0A minimum ou
48Vcc (PoE), 0,35A minimum.
• Extron power supplies are certified to UL/CSA 60950-1 and are classified as LPS
(Limited Power Source). Use of a non-LPS or unlisted power supply will void all
regulatory compliance certification.
• Les sources d’alimentation Extron sont qualifiées UL/CSA60950-1 et sont
classéesLPS(LimitedPowerSource). L’utilisation d’une source d’alimentation non-
listée ou non-listéeLPS annulera toute certification de conformité réglementaire.
• Unless otherwise stated, the AC/DC adapters are not suitable for use in air handling
spaces or in wall cavities. The power supply is to be located within the same vicinity
as the Extron AV processing equipment in an ordinary location, Pollution Degree 2,
secured to the equipment rack within the dedicated closet, podium, or desk.
• Sauf mention contraire, les adaptateurs AC/DC ne sont pas appropriés pour une
utilisation dans les espaces d’aération ou dans les cavités murales. La source
d’alimentation doit être située à proximité de l’équipement de traitement audiovisuel
dans un endroit ordinaire, avec un degré2 de pollution, fixé à un équipement de rack
à l’intérieur d’un placard, d’une estrade, ou d’un bureau.
• Power over Ethernet (PoE) is intended for indoor use only. It is to be connected only
to networks or circuits that are not routed to the outside plant or building.
• L’alimentation via Ethernet (PoE) est destinée à une utilisation en intérieur uniquement.
Elle doit être connectée seulement à des réseaux ou des circuits qui ne sont pas
routés au réseau ou au bâtiment extérieur.
• The installation must always be in accordance with the applicable provisions of
National Electrical Code ANSI/NFPA 70, article 725 and the Canadian Electrical Code
part 1, section 16.
• Cette installation doit toujours être en accord avec les mesures qui s’applique au
National Electrical Code ANSI/NFPA70, article725, et au Canadian Electrical Code,
partie1, section16.
• The power supply shall not be permanently fixed to the building structure or similar
structure.
• La source d’alimentation ne devra pas être fixée de façon permanente à une structure
de bâtiment ou à une structure similaire.
TLP Pro 720 Series and TLP Pro 1020 Series • Panel Features 12

CMenu button (see figure 5)— activates the setup menu (see the following page) and
Calibration screen (see page19).
DReset button (see figure 5)— initiates one of three reset modes for the unit (see Reset
Modes on page30).
EReset LED (see figure 5)— indicates power status and reset status of the device (see
Reset Modes on page 30).
FVESA mounting holes (4) (see figure 5)— for use with the Extron LPVM-1 (see VESA
Mounting on page 28).
TLP Pro 720 Series and TLP Pro 1020 Series • Panel Features 13

On-screen Menus
On-screen menus allow initial configuration of the TLP Pro 720 series and TLP Pro 1020 series:
zSetup Menu
zCalibration Screen
Setup Menu
To open the setup menu, press the Menu button. For the TLP Pro 720T and TLP Pro 1020T, the
Menu button is located on the rear panel (see figure 5, Con page 8). For the TLPPro720M
and TLP Pro 1020M, the Menu button is located on the front panel and the bezel must be
removed first (see figure 4, Bon page 7).
The menus open at the Status screen. There are five different screens (Status, Network,
Display, Audio, and Advanced). These can be selected by pressing the appropriate button in
the navigation panel at the top of the screen. The button for the selected screen is yellow; the
buttons for the remaining screens are black.
There is also a red Exit button in the top right corner of the screen. Pressing this button applies
and saves any changes and closes the menu screens.
In this section, the figures will show the screens for the TLP Pro 720M. The screens for the other
touchpanels are similar.
Status Screen
Status DisplayAudioAdvanced Exit
Network
Info
Model: TLP Pro 720M
Part Number: 60-1394-02
Firmware
Version:1.00
PoE Status: On
Network
IP Address:
DHCP:
Host Name:
Off
192.168.254.251
TLP-AB-CD-EF
Display
Resolution:
Project:
Sleep Timer:
800x480
N/A
5 Minutes
Audio
Master Volume:
Master Mute:Off
99
Advanced
Controller IP:N/A
Project Size: N/A
Figure 8. Status Screen
The Status screen is a read-only screen that provides basic information about the touchpanel.
Each of the other four panels shows a summary of the information on the other screens.
Pressing any of the panels opens the corresponding screen in exactly the same way as pressing
the buttons in the top navigation panel.
The bubble in the Network panel lights green when there is a network connection or amber if
there is no connection. The bubble in the Advanced panel lights green when a control processor
is connected or amber if none is connected.
TLP Pro 720 Series and TLP Pro 1020 Series • On-screen Menus 14
