Wallmount ZRTP Series • Setup Guide
IMPORTANT NOTE:
Go to www.extron.com for the complete user guide, installation instructions, and specications.
Wall Mounting the Touchpanel
The touchpanel can be wall-mounted, either using a UL-listed junction box, an external wall box, or directly into drywall or furniture.
Suitable mounting accessories can be found at www.extron.com.
ATTENTION:
• Do not install the touchpanels in a re resistant rated wall or partition assembly.
• Ne pas installer les écrans tactiles dans un mur résistant au feu ou une cloison.
• All structural steps and electrical installation must be performed by qualified personnel in accordance with local and
national building codes and electrical codes.
• Toute étape structurelle et installation électrique, doit être e󰀨ectuée par un personnel qualié, conformément aux codes
du bâtiment, aux codes incendie et sécurité, et aux codes électriques, locaux et nationaux.
With a Wall Box or Junction Box
Some local building codes require the touchpanel to be mounted
in a junction box. Junction boxes or wall boxes must be purchased
separately.
With a wall box
1. Install a junction box or wall box (see gure 1, 1), following the
instructions provided by the manufacturer.
2. Fasten the mounting plate to the wall box (2) with the provided
screws. Use mounting holes that are appropriate to the junction
box you are using (see gure 2 on page 2 ).
NOTES: Extron provides:
• Four 3/4” #6-32 Philips pan head screws for mounting
to US junction boxes
• Two 16 mm M 3.5 Philips pan head screws for
mounting to MK junction boxes
• EU junction boxes are usually provided with their own
screws.
3. Run and connect cables to the back of the touchpanel (see Rear
Panel Features on page 2).
steps 3 through 6
4. The mounting plate has four hooks (see gure 1, 3), one in each corner. Position the touch panel so that the four mounting
slots in the rear of the touchpanel align (see gure 3,D, on page 2) with these hooks.
5. Move the touchpanel inward and downward so that touchpanel sits securely on the hooks and the tongue at the bottom of the
mounting plate (see inset, gure 1, 4) sits in the groove in the bottom of the touchpanel (5).
6. Fasten the touchpanel to the mounting plate with the lock screw (6).
TOP
e
Back View
12
3
4
5
6
4
Figure 1. Mounting the Touchpanel with a Junction
Box
figure 1

2
Without a wall box
If the wall box is not required by local building codes, you can mount
the touchpanel directly into drywall.
1. Place the mounting plate (see gure 2) against the wall or
furniture in a suitable location and ensure that it is level. Use the
mounting plate as a template to mark the wall.
2. Cut a hole 3.5 inches (89 mm) wide by 2.0 inches (51 mm) high
to pass cables through the wall.
3. Use the MK slots and drill the two pilot holes (gure 2). Extron
recommends using two Molly bolts or SnapToggle bolts.
4. Secure the mounting plate to the wall (gure 1, 2, on
page 1).
5. Complete the installation as described in steps 3 through 6 on
page 1.
NORTH
AMERICAN
NORTH
AMERICAN
NORTH
AMERICAN
NORTH
AMERICAN
EU
MK
EU
EU EU
MK
3.5" (89 mm)
2.0"
(51 mm)
Figure 2. Touchpanel Mounting Plate
figure 2
Rear Panel Features
C
C
CA
A
AB
B
B
E
E
E
F
F
F
G
G
G
I
I
IJ
J
J K
K
K
H
H
H
D
D
D
D
D
D
D
D
D
D
D
D
Figure 3. Rear Panel
figure 3 AMENU Button — Allows user to enter or exit
the setup menu.
BRESET Button — Allows the user to carry out a
factory firmware reset.
CRESET LED — Provides feedback for reset
modes (see the Zoom Room Touchpanel Series
User Guide at www.extron.com).
DMounting Slots — Four, one in each corner.
The hooks on the corners of the mounting plate
(see figure 1, 3, on page 1) fit into these
slots for wall mounting.
EDigital Input Monitoring Port — This 2-pole
captive screw port (1 = signal and G = ground)
monitors digital input with or without a +5 VDC
pull-up.
FLAN/PoE Connector — Connect the
touchpanel to a PoE power injector (not
provided) using a twisted pair cable, terminated
with an RJ-45 connector. Connect the power
injector to the LAN through a nework switch. An Extron IP Link Pro control processor must also be connected to the same
network as the TouchLink Pro touchpanel.
NOTE: The touchpanel is shipped without a power injector.
The power injector must be purchased separately.
Figure 4 shows the Extron PI 115. Your power injector may look
di󰀨erent.
LAN + PWR OUT
PI 115
LAN
100/240V ~,50-60Hz
0.45A MAX
PWR
To network switchTo Touchpanel
3
12
Figure 4. Connecting to a Power Injector
ATTENTION:
• The touchpanel is Power over Ethernet (PoE 802.3af, class 3) compliant. Do not power on the touchpanels until you have
read the Attention in the “Connecting Power” section of the Zoom Room Touchpanel Series User Guide.
• L’écrans tactiles est compatible avec l’alimentation POE via Ethernet (PoE 802.3af, classe 3). Ne branchez pas les
écrans tactiles avant d’avoir lu la mise en garde dans la section « Connecting Power » du Zoom Room Touchpanel Series
User Guide.

3
GUSB Port (see figure 3 on page 2) — Compatible with USB 2.0.
HRear Panel Status Lights — Six, three on each side of the panel.
ISpeaker — A single speaker provides audible feedback for the user.
JSlot for Mounting Plate — The tongue at the bottom of the mounting plate (see figure 1, 4, on the previous page) fits into this
slot, for wall mounting.
KMounting Screw — Tightens against the tongue of the mounting plate to secure the touchpanel.
Conguration
1. When the device is powered on for the rst time, select Zoom Rooms Controller and click Next.
Figure 5. Select a Use for the Device
2. Click the Settings (gear) icon (see gure 6, 1).
Figure 6. Click Settings Icon

4
3. Click System Settings (see gure 7, 1).
Figure 7. Settings Menu
The Settings menu opens.
4. Click System (see gure 8, 1).
Figure 8. Settings Menu
The System menu allows you to congure Date &Time and Language.
Figure 9. System Menu
5. Click Languages &input and use the options to select the language used by the application.
figure 8

5
6. Return to the System menu and click Date &time. Use the options to set date and time automatically, or to set date, time,
and time zone manually. You can also toggle between a 12-hour or 24-hour clock.
7. Return to the Settings page and click Network (see gure 8, 2, on page 4).
8. Use the toggle switch to select DHCP enabled or disabled.
• If DHCP is enabled, the unit Host Name can be congured. All other network settings are read-only.
• If DHCP is disabled, consult your network administrator to obtain a valid network IP address, Gateway address, Subnet
mask, and DNS server.
NOTE: For more information about using the setup menu to congure the touchpanel, see the Zoom Room Touchpanel
Series User Guide, which is available at www.extron.com.
Updating Firmware
1. Open Toolbelt.
2. Discover or manually add the device.
Figure 10. Toolbelt — Discover Devices
3. Select one or more devices to update from the Device list.
• Single device selection — <Right click> on a single device and select Update Firmware.
• Multiple device selection — to select multiple devices:
a. Hold down <Shift> and click on a range.
b. <Right click> and select Update Firmware or click on the Update Firmware icon in the Actions column.
4. Open the Firmware Uploader window by clicking Tools >Firmware Uploader... .
Figure 11. Toolbelt — Firmware Loader
5. Enter the credentials for each device if prompted.

6
68-3744-51 Rev. B
10 23
For information on safety guidelines, regulatory compliances, EMI/EMF compatibility, accessibility, and related topics, see the Extron
Safety and Regulatory Compliance Guide on the Extron website.
© 2023 Extron — All rights reserved. www.extron.com
All trademarks mentioned are the property of their respective owners.
Worldwide Headquarters: Extron USA West, 1025 E. Ball Road, Anaheim, CA 92805, 800.633.9876
6. Click Begin. Firmware Uploader begins to upload the selected rmware to the selected device(s).
The update process goes through the following states:
• Idle — no upload taking place
• Uploading — pre-installation
• Verification — start of installation
• Installation — installing selected rmware version on device
• Completion — rmware upload successful
For more information about using Toolbelt to update rmware, see the Toolbelt Help File at www.extron.com.
