FOX II T/R DP 4K • Setup Guide
This guide provides quick start instructions for an experienced installer to set up and operate the Extron FOX II T/R DP 4K ber optic
extenders.
WARNING: These units output continuous invisible light, which may be harmful to the eyes; use with caution. For additional
safety, plug the attached dust caps into the optical transceivers when the fiber optic cable is unplugged.
CLASS 1 LASER PRODUCT, see the FOX II T/R DP 4K User Guide, at www.extron.com.
AVERTISSEMENT : Le FOX II T/R DP 4K émet une lumière invisible en continu (conforme à la classe1) qui peut être dangereux
pour les yeux, à utiliser avec précaution. Branchez les protections contre la poussière dans l’ensemble émetteur/récepteur lorsque
le câble fibre optique est débranché.
Produit laser de classe1, voir le FOX II T/R DP 4K User Guide sur www.extron.com (en anglais).
Installation
FOX II DP 4K Transmitter Rear Panel
FOX II DP 4K Receiver Rear Panel
100-240V ~ -.-A MAX
50-60 Hz
DISPLAYPORT LOOP THRU
LRRS-232
OPTICAL
Tx
RESET
LINK LINK
Rx
RS-232 IR
ALARM
Tx Rx G1 2
LR
Tx Rx Tx RxG
AUDIO
INPUTS AUDIO
RETURN OUT
REMOTE
OVER
FIBER
FOX T DP 4K
100-240V ~ -.-A MAX
50-60 Hz
DISPLAYPORT
LRRS-232
OPTICAL
Tx
RESET
LINK LINK
Rx
RS-232 IR
ALARM
Tx Rx G1 2
LR
Tx Rx Tx RxG
AUDIO
OUTPUTS AUDIO
RETURN IN
REMOTE
OVER
FIBER
FOX R DP 4K
Step 1 — Mounting
Turn off or disconnect all equipment power
sources and mount the transmitter as required.
For mounting details and considerations, see the
FOX II T/R DP 4K User Guide at www.extron.com.
Step 2 — Input and Output Connections
a. Connect a DisplayPort
DISPLAYPORT LOOP THRU
video source to the
transmitter DisplayPort input connector.
b. If desired, connect a DisplayPort video display
to the transmitter Loop-Thru connector for a
local display.
c. Connect a DisplayPort video display to the receiver DisplayPort output connector.
DISPLAYPORT
d. Connect an audio input device to either the Audio 3.5 mm mini jack or the Audio 5-pole captive screw connector
LR
AUDIO
on the transmitter. See the drawing below step 2g to make connections on the captive screw connector.
e. Connect an audio output device to either or both the 3.5 mm mini jack or the Audio 5-pole captive screw connector
on the receiver. See the drawing below step 2g to make connections on the captive screw connector.
f. For optional returned audio, connect an audio output device to the Audio Return Out 5-pole captive screw
LR
AUDIO
RETURN OUT
LR
AUDIO
RETURN IN
connector on the transmitter. See the drawing below step 2g to make connections on the captive screw
connector.
g. For optional returned audio, connect an audio input device to the Audio Return In 5-pole captive screw
connector on the receiver. See the drawing below to make connections on the
captive screw connector.
ATTENTION:
• For unbalanced audio, connect the sleeves to the ground
contact. DO NOT connect the sleeves to the negative (-)
contacts.
• Pour l’audio asymétrique, connectez les manchons
au contact au sol. NE PAS connecter les manchons
aux contacts négatifs (–).
NOTE: For returned audio, above, you must also do the following:
• Connect an audio input device to the Audio Return In 5-pole captive screw connector on the receiver.
• Install the optional Receiver-Tx-to-transmitter-Rx cable in step 3b.

2
FOX II T/R DP 4K • Setup Guide (Continued)
h. If you want the FOX II DP 4K units to pass serial or IR data or control signals, such as for serial
Rx TxGnd
Tx RxGnd
IR Device
RS-232 Device
RS-232 IR
Tx Rx Tx RxG
OVER
FIBER
control of a projector, connect the primary device to the transmitter and the controlled device to
the receiver via the Over Fiber 5-pole captive screw connectors on both units.
i. For remote monitoring of the status of the Rx optical link on either the transmitter or
RS-232 ALARM
Tx Rx G
12
REMOTE
receiver, connect a locally constructed or obtained device to the two rightmost poles
of the Alarm and Remote RS-232 5-pole captive screw connector on that unit. The
unit shorts both poles together when no light is detected.
NOTE: The transmitter port reports the status of the link from the receiver.
The receiver port reports the status of the link from the transmitter.
j. For remote control of a unit and for loading firmware, connect a host device, such as a computer or control system, to either of the
following ports on the unit to be controlled:
Configuration port — The front panel USB mini-B connector.
CONFIG
NOTE: Extron recommends performing firmware updates via the Configuration port only.
Remote RS-232 port — The rear panel Remote RS-232 port, the 3 leftmost poles of this 5-pole captive screw connector.
RS-232 ALAR
M
Tx Rx G
12
REMOTE
The protocol for the Remote port is as follows:
• 9600 baud •no parity •8 data bits
• 1 stop bit •no flow control
Step 3 — Throughput Connections
Receiver
T
ransmitter
11
22
22
11
OPTICAL
Tx
LINK
LINK
Rx
OPTICAL
Tx
LINK
LINK
Rx
NOTE: See the two fiber cable connection drawings below. You can connect the transmitter to a compatible
receiver in one of two ways:
• One way (transmitter to receiver) only, perform step 3a.
• Two way (transmitter to receiver and return), perform steps 3a and 3b.
a. Connect the fiber between the Tx port on the transmitter and the Rx port on the receiver (1, at right).
NOTE: Ensure that the transmitter and connected receiver are the same transmission mode,
singlemode (SM) or multimode (MM) and that you use the correct SM or MM fiber cable to connect the
devices
b. If you want the receiver to return serial data (such as responses from a controlled device), IR data, or returned audio
to the transmitter, connect a cable between the Tx port on the receiver and Rx port on the transmitter (2).
Tx Link and Rx Link LEDs — When lit, the link is active (light is output [Tx] or received [Rx]).
NOTE: The Link LEDs indicate transmission of light only, not whether there is data encoded in the
optical link.
Operation
After all receivers, the transmitter, and their connected devices are powered up, the system is fully operational. If any problems are
encountered, verify that the cables are routed and connected properly and that all display devices have identical resolutions and refresh
rates. If problems persist, call the Extron S3 Sales & Technical Support Hotline at the number that is closest to you. See the contact
numbers on the last page of this guide for the Extron ofce nearest you.

3
Indications
NOTE: The figure below right is of a receiver. A transmitter has similar indications.
Power ( ) LED — Indicates that power is applied to the unit.
CONFIG SIGNAL
VIDEO AUDIO
HDCP
OUTPUT
RETURN IN
Video LEDs —
Signal LED — Lights when the unit detects an input video signal.
HDCP LED — Lights when the input signal is HDCP encrypted.
Audio LEDs —
Input LED (transmitter) — Lights when an analog audio or PCM digital
audio signal remains above -35 dBV. The LED goes unlit if the audio
signal level drops below the threshold for 10 seconds or longer.
Output LED (receiver) — Lights when an analog audio or PCM digital audio signal remains above -35 dBV. The LED goes unlit if the
audio signal level drops below the threshold for 10 seconds or longer.
Return Out LED (transmitter) — Lights when analog audio is present on the transmitter Return Audio Output connector.
Return In LED (receiver) — Lights when analog audio is present on the receiver Return Audio Input connector.
EDID SELECT
EDID
EDID Minder switch — Set this switch to one of the positions at right to select the source of the DDC or a specic resolution.
Position 0 — An EDID that has previously been captured from a connected display or manually imported via an SIS
command or the Product Conguration Software.
Position 1 — The EDID is selected via the
Remote or USB port, using an SIS command or
the Extron Product Conguration Software.
Position
2— Use the EDID from the display connected to
the receiver.
NOTE: EDID from the display connected
to the receiver requires connection of both
fiber cables.
Position 3 — Use the EDID from the display connected to the transmitter loop-through.
Positions 4 through E — Specify a resolution. The table at right identies the resolutions associated with the switch positions. All
resolutions are at 60 Hz with the exception of 4096x2160 (E), which is 30 Hz.
Position F — No EDID assigned.
Remote Control
See the FOX II T/R DP 4K User Guide, available at www.extron.com, for details on operating and monitoring the transmitter using either
SIS commands or the Extron Product Conguration Software.
Pos. Source or resolution Pos. Resolution Pos. Resolution
0 User recorded EDID 6 1366x768 C 2048x2160
1 Selected via RS-232 7 1440x900 D 2560x1600
2 Display on Rx output 8 1680x1050 E* 3840x2160
3 Display on Tx loop-through 9 1920x1080 F N/A
4 1280x720 A 1920x1200
5 1280x800 B 2048x1536
* 30 Hz

4
68-2540-50 Rev. C
