Extron electronics TP Series User manual

Setup Guide — TP Transmitters
This guide provides quick start instructions for
an experienced installer to set up and operate
the TP Transmitter Series products. Refer to
www.extron.com for the complete user’s manual.
Pre-installation — Jumper settings
The TP T 15HD A, TP T 15HD AV, and the TP T BNC DA4 are factory
configured to transmit RGB video. You can reconfigure them to transmit
component, S-video, or composite video by using a jumper to connect the
following pins on the main board:
• TPT15HDAandTPT15HDAV — Use a jumper to connect pins 1
and 2 at locations J1 and J2 (see the illustration at upper right).
• TPTBNCDA4 — Use a jumper to connect pins 1 and 2 at locations J11
and J12 (see the illustration at lower right).
NIf using the TP T 15HD AV with a TPX 88X transmitter or with
an older, unmodified receiver, refer to the TP Transmitters User’s
Manual, “Audio jumpers”, for information on audio jumper
placement for compatibility.
Installation
Step 1 — Mount the unit
Turn off or disconnect power to all equipment, and mount the transmitter as desired.
Step 2 — Connect inputs
Attach input cables to the audio and video connectors as applicable for your TP T model.
• Compositevideo — Connect a composite video source device to the Video RCA jack
(TP T 15 HD AV), the G pin of the Computer Input HD connector (TP T 15HD A), or the
G BNC connector (TP T BNC DA4). For three separate genlocked video signals on the
TP T BNC DA4, connect the input device to the R, G, and B BNC connectors.
• S-video — Connect an S-video source device to pins R (chroma) and G (luma) of the
Computer Input HD connector (TP T 15 HD A and TP T 15 HD AV), or to the R (C-chroma)
and G (Y-luma) BNC connectors (TP T BNC DA4).
• Componentvideo — Connect a source device to pins R (R-Y), G (Y), and B (B-Y) of the
Computer Input HD connector (TP T 15 HD A and TP T 15 HD AV), or to the R (R-Y), G (Y)
and B (B-Y) BNC connectors (TP T BNC DA4).
• RGBHVcomputervideo — Connect an RGB source device to the female Computer Input
HD connector (TP T 15 HD A and TP T 15 HD AV) or to the R, G, B, H/HV, and V female
BNC connectors (TP T BNC DA4).
• RGBScomputervideo — Connect an RGB source device to the female Computer Input
HD connector (TP T 15 HD A and TP T 15 HD AV) or to the R, G, B, and H/HV female BNC
connectors (TP T BNC DA4).
• Audioinput — Connect PC audio to the 3.5 mm stereo jack (TP T 15HD A and
TP T 15HD AV).
• AudioinputLandRpair — Connect left and right stereo audio to the RCA connector pair
(TP T 15HD AV only).
N Input only analog line level audio signals on these connectors.
Component,
S-video,
Composite
1
1
1
1
1
1
RGB
TP T 15HD A
TP T 15HD AV
Component,
S-video,
Composite
1
1
1
1
RGB
1
1
1
1
TP T BNC DA4
(Continued on reverse side)

Setup Guide — TP Transmitters
Extron USA - West
Headquarters
+800.633.9876
Inside USA / Canada Only
+1.714.491.1500
+1.714.491.1517FAX
Extron USA - East
+800.633.9876
Inside USA / Canada Only
+1.919.863.1794
+1.919.863.1797FAX
Extron Europe
+800.3987.6673
Inside Europe Only
+31.33.453.4040
+31.33.453.4050 FAX
Extron Asia
+800.7339.8766
Inside Asia Only
+65.6383.4400
+65.6383.4664FAX
Extron Japan
+81.3.3511.7655
+81.3.3511.7656FAX
Extron China
+400.883.1568
Inside China Only
+86.21.3760.1568
+86.21.3760.1566 FAX
Extron Middle East
+971.4.2991800
+971.4.2991880 FAX
© 2009 Extron Electronics. All rights reserved.
Step 3 — Connect outputs
• Connect the RJ-45 cable from a TP receiver to an RJ-45 port on the TP transmitter. Terminate
the cable’s ends according to the TIA/EIA T 568A wiring standard (see the table below).
• If desired, connect a local monitor video cable to the Buffered Local Monitor port
(TP T 15HD A and TP T 15HD AV only).
Step 4 — Connect power
Plug the included external 15 VDC power
supply into the 3-pole captive screw connector.
Wire the connector as shown at right.
NThe TP T 15HD A and TP T 15HD AV
can be powered via the attached receiver
(except the TP R 15HD A) for cable runs
of 300 feet (91.4 m) or less.
Step 5 — Set DIP switches (TP T 15HD A and TP T 15HD AV only)
• IDPin4andIDPin11 (front panel)—Set these switches to Off
(down) if a local monitor is connected, or to On (up) if not.
• DDSP (back panel) — Set this switch to On (up), if needed, to turn
on Digital Display Sync Processing. Set the switch to Off (down) for
displays that cannot handle processed sync.
Step 6 — Adjust horizontal shift (TP T 15HD A and TP T 15HD AV)
While viewing the display, use a small screwdriver to turn the H. Shift potentiometer on the
front panel to adjust the side-to-side image placement.
ID PIN 4 ID PIN 11
DDSP SPARE
SECTION A–A
Power Supply
Output Cord
Ridges
Smooth
A A
3/16” (5 mm)
Max.
N/C N/C
Pin Wire color
RGB video and audio AV video and audio
Signal Level Signal Level
1White-green Red/V. sync+ ±0.35V Video+ +0.35V
2Green Red/V. sync– ±0.35V Video– –0.35V
3 White-orange Audio and power +15V with ±0.5 V +15V
4Blue Green+ +0.35V Reserved None
5White-blue Green– –0.35V Reserved None
6 Orange Audio and power
Audio+* & power+
Audio–* & power–
±0.5 V0V
7White-brown Blue/H. sync+ ±0.35V Reserved None
8Brown
*Audio can be connected to wire pair 7 and 8 with a jumper.
Blue/H. sync– ±0.35V Reserved None
12345678
RJ-45 Connector
Insert Twisted
Pair Wires
Pins:
68-546-50
Rev. A
02 09
TP T 15HD A
H-SHIFT
BUFFEREDCOMPUTER
INPUT
AUDIO
IDPIN 4
IDPIN 11
LOCALMONITOR
Extron
TP R BNC A
