Eyevision EV-D298F Series User manual

EV-D298F Series User Manual
EV-D298F-D
EV-D298F
Model: EV-D298F(-D)

-2-

CONTENTS
1.Parts and Functions............................................................................................. 1
2.Terminal Descriptions .......................................................................................... 1
3.Specications ...................................................................................................... 2
4.Mounting.............................................................................................................. 2
4.1 Mounting ....................................................................................................... 2
4.2 Placing Name Label ...................................................................................... 3
5.System Wiring and Connections ......................................................................... 3
5.1 Basic Connection........................................................................................... 3
5.2 Electric Lock Connection............................................................................... 4
5.2.1 Door Lock Controlled with Internal Power ............................................. 4
5.2.2 Door Lock Controlled with Dry Contact ................................................. 4
5.2.3 Unlock parameter setting(set on monitor) ............................................. 5
5.3 Multi Doorstations Connection....................................................................... 5
5.4 Multi Monitors Connection............................................................................. 6
5.4.1 Basic IN-OUT Wiring Mode ................................................................. 6
5.4.2 With DBC-4S Wiring Mode.................................................................. 7
6.Setup ................................................................................................................... 8
6.1 ID of Doorstation Settings ......................................................................... 8
6.2 Unlock Time Settings ................................................................................. 9
6.3 Ringtone Modes Settings .......................................................................... 10
7.Cables Requirements.......................................................................................... 11

-1-
1.Parts and Functions
110 mm
188 mm
Camera Lens
Speaker
Nameplate
Call Button
Microphone
Night Light
Side View Mounting box
2.Terminal Descriptions
1 2 3
JP/LK
PL
S+ S-
Main Connect Port
BUS

-2-
•JP/LK: Lock control jumper, to select the lock type(see 5.2.1 , 5.2.2).
•Main Connect Port: To connect the bus line and the electronic locks.
•BUS: Connect to the bus line, no polarity.
•PL: External lock power input, connect to the power positive(power +).
•S+: Lock power(+) output.
•S-: Lock power(-) output, connect to the power(-) input of locks(only when using the camera to
power the locks, if using the external power supply for the locks, the S- will not be connected).
3.Specications
•Power Supply : DC 24V;
•Lock Power supply: 12Vdc, 300mA(Internal Power);
•Power Consumtion: Standby 33mA; Working status 110mA;
•Camera: Color ARS; 650 TV Lines;
•Unlocking time: 1~30s(Default 1s);
•Working temperature: -15ºC ~ 55ºC;
•Dimension: 188(H)×110(W)×39(D)mm.
4.Mounting
4.1 Mounting
1 2
54
Drill a hole in the wall to match the size of the
mounting box and attach to the wall.
Attach the panel to the mounting box and
use screws supplied to fix the panel
3
Connect the cable correctly

-3-
4.2 Placing Name Label
Move the plastic cover away to open the transparent name label cover, insert a
name paper, then put the plastic cover back to the panel.
STEP 1
Unscrew the screws.
STEP 2
Replace name label.
Name label.
5.1 Basic Connection
5.System Wiring and Connections
-
+
AC~
monitor
EV-DPS PS4
L1 L2 PL S+ S-

-4-
5.2 Electric Lock Connection
5.2.1 Door Lock Controlled with Internal Power
Note:
1. Electronic lock of Power-on-to-unlock
type should be used.
2. The door lock is limited to 12V, and
holding current must be less than 250mA.
3. The door lock control is not timed from
Exit Button(EB).
4. The Unlock Mode Parameter of Monitor
must be set to 0 (by default).
5. When it connect Electronic lock, the
jumper position in 2-3.
6. When it connect E-magnetic lock, the
jumper position in 1-2.
EB
*
LOCK
PL S+S-
connect Electronic lock, the jumper position in 2-3.
1 2 3
BUS
connect E-magnetic lock, the jumper position in 1-2.
1 2 3
5.2.2 Door Lock Controlled with Dry Contact
Note:
1. The external power supply must be
used according to the lock.
2. The jumper must be taken off
before connecting.
3. Setup the Unlock Mode of Monitor
for different lock types.
•Power-on-to-unlock type:Unlock
Mode=0 (by default)
•Power-off-to-unlock type:Unlock
Mode=1
LOCK
Take off the Jumper
POWER
SUPPLY
BUS PL S+S-

-5-
5.2.3 Unlock parameter setting(set on monitor)
Note:
1.must connect EV-D298F/EV-D298F-D correctly before setting.
2.the parameter will be saved in EV-D298F/EV-D298F-D automatically,so you need only set on one
monitor.
5.3 Multi Doorstations Connection
monitors
100~240VAC
BUS(IM) BUS(DS)
PC6
AC~
EV-DBC4A
A B C D
OFF
ON
Impedance
switch
L1 L2 PL S+ S- L1 L2 PL S+ S- L1 L2 PL S+ S- L1 L2 PL S+ S-
1# Camera2# Camera3# Camera4# Camera
(Device Address:3) (Device Address:2) (Device Address:1) (Device Address:0)
1.Touch item on main
menu page.
2.Touch the screen anywhere
and hold for 2s.
3.Touch Installer setup item
4.A digital keypad and setting
instructions will be showed.
Manual
Monitor
Monitor
Memory
Playback
Album User Setup
09/30/2010 Thu.16:41
Close
Intercom Multimedia
About
?
H/W : --- a1.3
S/W: V17.11.418.00
Local addr: ---
Unlock timing: ---
Video standard: -
UI-CODE: ---
MCM-VER.: ---
Updated: ---
Home
Installer
setup
Caliber
TouchScreen
Code Number:[----]
[0010]#:Remove all remote control
[0011]#:Add remote control
[8000]#:Set as master unit 0
[8001]#:Set as slaver unit 1
[8002]#:Set as slaver unit 2
[8003]#:Set as slaver unit 3
[8004]#:Set as guard unit
[8005]#:Set as not guard unit
[8006]#:Panel on as slaver unit called
[8007]#:Panel off as slaver unit called
[8008]#:Date format:MM/DD/YYYY
[8009]#:Date format:DD/MM/YYYY
[8010]#:Set lock mode to 0
[8011]#:Set lock mode to 1
[8021]~[8029]
#Set the lock time of 1~9s
Multi language settings:
---
1
4
78
0
9
6
5
23
Cancel
Installation settings:

-6-
5.4.1 Basic IN-OUT Wiring Mode
5.4 Multi Monitors Connection
(Device Address:0)
BUS(IM) BUS(DS)
PC6
AC~
100~240VAC
Code=0, DIP-6=off
1 2 3 4 5 6
ON
Code=15, DIP-6=on
1 2 3 4 5 6
ON
Code=14, DIP-6=off
1 2 3 4 5 6
ON
monitor
Code=1, DIP-6=off
1 2 3 4 5 6
ON
monitor
monitormonitor

-7-
5.4.2 With EV-DBC4A Wiring Mode
(Device Address:0)
100~240VAC
BUS(IM) BUS(DS)
PC6
AC~
1 2 3 4 5 6
ON
1 2 3 4 5 6
Code=15, DIP-6=on
Code=13, DIP-6=on
1 2 3 4 5 6
ON
1 2 3 4 5 6
ON
Code=14, DIP-6=on
Code=12, DIP-6=on
1 2 3 4 5 6
ON
1 2 3 4 5 6
ON
Code=3, DIP-6=on
Code=1, DIP-6=on
1 2 3 4 5 6
ON
1 2 3 4 5 6
ON
Code=2, DIP-6=on
Code=0, DIP-6=on
OFF ON
OFF ON
monitor
monitor
monitor
monitor
monitor
monitor
monitor
monitor
EV-DBC4A
A B C D
EV-DBC4A
A B C D
Impedance
switch
Impedance
switch

-8-
A A
B
Holder
Holder
A
Note:Monitors response button A must set the user code from 0
to 15.and button B set the user code from 16 to 31.
The internal structure of the ONE button version and the TWO buttons are the same.
Both have the A, and B button.
The difference is for the TWO button version both buttons are located externally and the
procedures can be performed directly without removing the front fascia.
For the ONE button version the front fascia must be removed which is held in place by
the four holders on the rear (one in each corner).
Once removed from the front fascia the procedure will remain the same as below.
A
B
A
6. Setup

-9-
6.1 ID of Doorstation Settings
The ID of doorstation can be set to ID0/ID1/ID2/ID3.The default is ID0.
1)Power-on within 5 seconds;
2)Press and hold "B" button for 3
seconds, it will enter the setting
state of prepare.
background indicator Buzzer
beep+,beep
(ash)
Press and hold "A" and "B"
button for 3 seconds at the same
time, it will enter the state of ID
setting.
beep+,
(off)
background indicator Buzzer
Followed by pressing the "B"
button, each time you press "B"
button to replace the ID;
Note:The ID will cycle between
ID0 ID1 ID2 ID3.
beep one
(ash one)
ID0:
beep twice
ID1:
beep 3 times
ID2:
beep 4 times
ID3:
(ash twice)
(ash 3 times)
(ash 4 times)
background indicator Buzzer

-10-
6.2 Unlock Time Settings
Note:During timing, the background indicator ashes once per second, tone beeps once per second. Less
than one second by one second calculation.
The unlock time can be set to 1~30 seconds. The default is 1s.
1)Power-on within 5 seconds;
2)Press and hold "B" button for 3
seconds, it will enter the setting
state of prepare.
background indicator Buzzer
beep+,beep
Press and hold "A" button for 3
seconds, it will enter the state of
unlock time setting.
beep+,
(off)
(ash)
background indicator Buzzer
At this time press and hold "B"
button,timing starts; release "B"
button to end the timing. The
time of press and hold "B" button
equal to unlock time.(Timing Unit:
1s)
beep once
per second
(ash once per second)
background indicator Buzzer

-11-
6.3 Ringtone Modes Settings
The system supports three ringtone modes: [A]one ringtone, [B]continuous
ringtone, [C]forbid ringtone. The default is one ringtone.
Followed by pressing the "B"
button,each time you press "B" to
replace the ringtone mode;
Note:The ringtone mode will cycle
between [A] [B] [C].
beep one
[A]:
beep twice
[B]:
beep 3 times
[C]:
(ash one)
(ash twice)
(ash 3 times)
1)Power-on within 5 seconds;
2)Press and hold "B" button for 3
seconds, it will enter the setting
state of prepare.
background indicator Buzzer
beep+,beep
Press and hold "B" button for 3
seconds at the same time, it will
enter the state of ringtone modes
setting.
beep+,
(off)
(ash)
background indicator Buzzer
background indicator Buzzer

-12-
For service:
PH +03 9532 0804
53 Cochranes Road
Moorabbin Victoria 3189 Australia
7.Cables Requirements
The maximum distance of the wiring is limited in the DT system. Using different cables may also affect the
maximum distance which the system can reach.
When Monitor quantity < 20
Cable Usage A B C
Twisted cable 2x0.75 mm260 60 30
Twisted cable 2x1 mm280 80 40
When Monitor quantity > 20
Cable Usage A B C
Twisted cable 2x1 mm270 30 20
Twisted cable 2x1.5 mm270 50 30
The farest monitor
B
A
C
EV-DBC4A
monitor
monitor
monitor
with two or four monitors
100~240VAC
BUS(IM) BUS(DS)
PC6
AC~
Note:If the monitor has been specied the distance,refer to the
parameter.

For service:
PH +03 9532 0804
53 Cochranes Road
Moorabbin Victoria 3189 Australia
