Faithfull FPP SLLEDPOD User manual

IMPORTANT
It is essential that you read the instructions contained in this manual before using the
light for the first time. Failure to follow these instructions could result in damage to the light,
property damage or personal injury. This manual should be stored safely for future reference.
Instruction Manual
Rechargeable
LED Work Light
10Watt
FPP SLLEDPOD

The Faithfull LED Work Light
Your new cordless, rechargeable Work Light is perfect for use in and around the home and garage,
providing a safe and portable source of light for use just where and when you need it.
Great for use during power failures, while camping, shing or working on the car and
many other uses including roadside emergencies.
230v AC/DC Wall Charger*:
Model: YS 16-0841000
Input: 100-240V 50/60HZ
Output: 8.4V DC 1A
Specifications
LED power: 10 Watt
Brightness: 650 Lumens
LED lifetime: Up to 50,000 hours
Beam angle: 120o
Colour temp: 6500K
IP rating: IP44 Splash & dust proof
Type: COB
Battery: Lithium-ion 7.4V 4000mAh
Charge time: 3.5 hours
Run time: Minimum 3 hours
12v DC Car Charger*:
Input: 12-24V DC
Output: 8.4VDC 1A
Magnetic Base
The magnetic base allows the Work Light to be
attached to metal surfaces.
Work Light Operation
1. The Work Light may be used with the included
stand alone base.
2. To attach the base, remove the mounting bolt
and place the light on top, aligning the hole in
the mounting bracket to the hole in the base and
replace the bolt by nger tightening securely.
No tools are required.
4. Adjust the angle of the light by grasping the
padded handle and tilting the face of the Work
Light up and down or swivelling right to left.
Running Times
The operating times of this Work Light may vary
depending on the working conditions and the
amount of charge in the battery at the time of
use. The running time for this light when fully
charged is approximately 3 hours.
To achieve the best performance always switch
the light off when the battery power begins to run
low, and recharge immediately.

Charging the LED Work Light
The LED Work Light must be fully charged before being used for the rst time.
This will ensure that the battery gives its best performance now and on future re-charging cycles.
The AC and DC charging adapters are for re-charging the battery only.
Using the AC Charging Adapter
1) Plug the charging cables jack plug into the
recharge socket of the Work Light. located
under the Black rubber cover
2) Plug the adapter into a 240V socket and
switch the socket on (if applicable).
3) The charging indicator lamp on the back panel
of the lamp will glow RED while charging is in
progress and then GREEN when fully charged.
4) The battery will be fully charged after
approximately 3 hours, disconnect the jack
plug from the Work Light, remove the adapter
from the wall socket or switch off.
Using the DC Charging Adapter
1) Plug the charging cables jack plug into the
recharge socket of the Work Light.
2) Plug the adapter into the vehicles 12V DC
cigarette lighter or accessory power socket.
3) The charging indicator lamp will glow RED
while charging is in progress and then turn
green when fully charged.
4) Disconnect the jack plug from the light, and
remove the DC adapter from the outlet socket.
5) The battery will be fully charged after
approximately 3.5 hours, Disconnect the jack
plug from the Work Light, remove the DC
adapter from the outlet socket.
To prevent overheating do not charge
for more than 9 hours.
Safety Precautions
The DC charging adapter can be used in most
vehicles by plugging into the 12V DC cigarette
lighter or accessory power socket.
Consult your vehicle owner’s manual for further
information on operating 12V DC accessories.
Do not drive the vehicle while charging, as an
unsecured light may be a hazard during certain
driving manoeuvres.
Store in dry location and do not allow the charging
adapter to come in contact with water, rain or snow.
If the charging adapter comes into contact with
water, place in a dry location at room temperature,
on a soft absorbent towel and allow to dry
thoroughly.
Do not operate the unit until it is completely
free of moisture.
If the adaptor becomes submerged in water,
discontinue use immediately and contact your local
Faithfull retailer for a replacement charging adapter.
Do not store charging adapter where temperatures
may exceed 122°F (50°C).
Use only the DC charging adapter supplied with
the light. Do not attempt to charge the light with an
adapter that is not compatible as this could result in
a re, damage to the torch or personal injury.
Safety Precautions
Use 240V AC charging adapter indoors in a dry
location only. Exposure to damp or wet conditions
could cause electrocution or damage to adapter.
Do not use the charger in the vicinity of ammable
liquids or materials.
Do not use the charging adapter in combination with
any extension cord, electrical generators, or step-up
transformers.
Always plug the adapter directly into a 240V outlet in
a suitable location.
Store in dry location and do not allow the charging
adapter to come in contact with water, rain or snow.
If the charging adapter comes into contact with
water, place in a dry location at room temperature,
on a soft absorbent towel and allow to dry thoroughly.
Do not operate the unit until it is completely free of
moisture.
If the adaptor becomes submerged in water,
discontinue use immediately and contact your local
Faithfull retailer for a replacement charger unit.
Do not store charging adapter where temperatures
may exceed 122°F (50°C). Use only the AC
charging adapter supplied with the light.
Do not attempt to charge the light with an adapter that
is not compatible as this could result in a re, damage
to the light or personal injury.

Care and Maintenance
Storage
Store the Work Light and charging adaptors in
a clean and dry area. Be sure to keep the
charging adapters supplied with this product
stored separately from similar items as only
charging adapters included with this light are
compatible. Using a non-compatible charger
could cause damage to the Work Light.
or personal injury.
The Work Light may also be stored in a vehicle
for use in roadside emergencies. If kept in
a vehicle, it is recommended that battery be
re-charged periodically to ensure maximum
performance in an emergency. To prevent the
light and any of the accessories being damaged,
please ensure that it is properly secure and in a
safe place inside the vehicle.
Cleaning
All exterior surfaces of the Work Light can be
wiped clean with a soft cloth dampened with a
soap and water solution. Do not immerse or
submerge any part of the light in water or any
other solvent. Never use solvents or cleaning
agents containing petroleum (petrol, kerosene,
oil), paint thinner, turpentine, alcohol,
or ammonia. Harsh materials like these
can damage surfaces.
FAITHFULL TOOLS
Phoenix House,
3 White Lodge Business Estate,
Hall Road, Norwich, Norfolk,
NR4 6DG, United Kingdom.
E-mail: [email protected]
www.faithfulltools.com
Maintenance
All repairs should only be carried out by qualied
service personnel. Do not open exterior casing
of the Work Light, as there are no user
serviceable parts inside. Opening or visible
attempts to open or repair a Work Light may
void any guarantee and/or cause damage to
the product or personal injury.
Never attempt to open the battery
pack, under abusive conditions liquid
may be ejected from the battery, if
accidental contact occurs ush the
affected area with water. If the liquid
comes into contact with the eyes
ush with water and seek medical
help. Liquid ejected from batteries
may cause irritation or burns.
This product contains an internal
Li-ion battery pack formulated from
environmentally sensitive materials.
This product must be disposed of
properly with due care for the
environment. Please return this
product to your local dealer or to
your local recycling
station where batteries will be
recycled or disposed of properly.
Never attempt to incinerate
batteries as they may leak or ex-
plode.
*Chargers may differ in appearance to the
illustrations in this manual.
