Falcon F25/90 User manual

Bladsy/ Page 2
Gemagtigde Handelaar/ Authorised Dealer:
Verkoopsdatum/ Date of Sale:
Implement:
Model Nr./ Model No.:
Reeks Nr./ Serial No.:
Inhoud / Contents
Bladsy / Page
3
4
5
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
46
47
Falcon Slashers
Company Prole
Installation and Safety
Routine Maintenance
Falcon Warranty Policy
Falcon F25/90 Slasher
Falcon F25/120 Slasher
Falcon F40/120 Slasher
Falcon F40/150 Slasher
Falcon F50/120 Slasher
Falcon F50/150 Slasher
Falcon F50/150/4 Slasher
Falcon F50/180 Slasher
Falcon F50/180/4 Slasher
Falcon F50/150RG Slasher
Falcon F50/180RG Slasher
Falcon F80/150 Slasher
Falcon F80/150/4 Slasher
Falcon F80/180 Slasher
Falcon F80/180/4 Slasher
Falcon F80/200 Slasher
Falcon F80/200/4 Slasher
Falcon F50 Gearbox
Falcon F80 Gearbox
Falcon Wentelsnyer
Maatskappyproel
Installering en Veiligheid
Roetine-instandhouding
Falcon se Waarborgbeleid
Falcon F25/90 Wentelsnyer
Falcon F25/120 Wentelsnyer
Falcon F40/120 Wentelsnyer
Falcon F40/150 Wentelsnyer
Falcon F50/120 Wentelsnyer
Falcon F50/150 Wentelsnyer
Falcon F50/150/4 Wentelsnyer
Falcon F50/180 Wentelsnyer
Falcon F50/180/4 Wentelsnyer
Falcon F50/150RG Wentelsnyer
Falcon F50/180RG Wentelsnyer
Falcon F80/150 Wentelsnyer
Falcon F80/150/4 Wentelsnyer
Falcon F80/180 Wentelsnyer
Falcon F80/180/4 Wentelsnyer
Falcon F80/200 Wentelsnyer
Falcon F80/200/4 Wentelsnyer
Falcon F50 Ratkas
Falcon F80 Ratkas

Bladsy/ Page 3
Falcon Wentelsnyers
Die Falcon Wentelsnyer is ‘n vinnige, doeltreffende en moeitevry implement. Verskillende
modelle met snywydtes van 0,9 m tot 3 m is beskikbaar om in die verskillende sny- en
bossiekapbehoeftes te voorsien en by verskillende trekkergroottes te pas. Die beproefde en
bewese snymeganisme verseker ‘n skoon snit in alle toestande. Bossiekappers moenie vir
hooimaak gebruik word nie.
Falcon Ligtediens Wentelsnyers word vir alle grassny- en ligte bossiekapwerk gebruik. Daar
is twee modelle, met snywydtes van 0,9 m en 1,2 m onderskeidelik. Albei implemente is lig,
maar stewig gebou, en is vir kleiner trekkers ontwerp. ‘n Falcon-bossiekapper maak grassny en
ligte bossiekapwerk in die tuin of op die kleinhoewe ‘n plesier eerder as sleurwerk.
Falcon Mediumdiens Wentelsnyers word saam met mediumgrootte trekkers vir algemene
grassny- en bossiekapwerk gebruik. Twee modelle is beskikbaar, met snywydtes van 1,2 m en
1,5 m onderskeidelik. ‘n Kontrahaak is standaard op albei modelle, wat dit moontlik maak om tot
teenaan heinings te sny.
Falcon Swaardiens Wentelsnyers word saam met trekkers tot en met 50 kW gebruik vir alle
grassny- en bossiekapwerk. Verskillende modelle is beskikbaar, met snywydtes van 1,2 m tot
4.5 m. Hulle is met plaaslikvervaardigde F50-reeks-ratkaste toegerus; die 3 m model het ook ‘n
aftakmodule (splitter box). ‘n Kontrahaak is standaard op alle modelle, behalwe die F50/300,
wat dit moontlik maak om tot teenaan heinings te sny.
Falcon Ekstra Swaardiens Wentelsnyers, vir gebruik saam met trekkers tot en met 80 kW, is
geskik vir alle grassny, bosopruiming en baie swaar bossiekapwerk. Falcon vervaardig ‘n ver-
skeidenheid modelle, met snywydtes van 1,5 m tot 2 m. Hulle is met plaaslikvervaardigde F80-
reeks-ratkaste toegerus. Hierdie wentelsnyers is gemaak om die strafste toestande te hanteer.
Falcon Slashers
The Falcon Slasher is a quick, efcient and trouble-free implement. Different models with cutting
widths from 0,9 m to 3 m are available to meet the varying cutting and slashing requirements
and match the appropriate tractors. The tried and tested cutting gear ensures a clean cut in all
conditions. Slashers should not be used for haymaking purposes.
Falcon Light Duty Slashers are used for all grass-cutting and light slashing operations. There
are two models, with cutting widths of 0,9 m and 1,2 m respectively. Both implements have a
light but strong construction and are designed for use on smaller tractors. The use of a Falcon
Slasher makes grass-cutting and light slashing in the garden or on the plot a pleasure rather
than a chore.
Falcon Medium Duty Slashers are used on medium-sized tractors for all general grass-cutting
and slashing work. Two models are available, with cutting widths of 1,2 m and 1,5 m respec-
tively. An offset hitch is standard on both models, which permits cutting close up to boundary
fences.
Falcon Heavy Duty Slashers are for use on tractors up to 50 kW for all grass-cutting and slash-
ing operations. Different models are available, with cutting widths from 1,2 m to 4.5 m. They are
tted with a locally manufactured F50 series gearbox; in addition the 3 m model has a splitter
box. The off-set hitch, which permits cutting up to a boundary fence, is standard on all models
except the F50/300.
Falcon Extra Heavy Duty Slashers, for use with tractors up to 80 kW, are suitable for all
grass-cutting, bush-clearing and very heavy slashing operations. Falcon manufactures a range
of models, with cutting widths from 1,5 m to 2 m. They are tted with an F80 series, locally
manufactured gearbox. These slashers are engineered to tackle the toughest terrain.

Bladsy/ Page 4
Maatskappyproel
Falcon Agricultural Equipment (Edms.) Bpk. is ’n eienaar-bestuurde besigheid en die grootste
vervaardiger van wentelsnyers in Afrika. Die maatskappy het sy deure in 1985 by sy huidige perseel
in Howick, KwaZulu-Natal, Suid-Afrika, geopen en is ideaal geleë – in ’n boerderygebied, met ’n
vooraanstaande landboukollege naby. Falcon is ‘n erkende Breedgebaseerde Swart Ekonomiese
Bemagtiging-bydraer en ons geskoolde arbeidsmag is ’n toegewyde span op wie ons baie trots is.
Ons primêre mark is die landbousektor, met nisverkope in die nywerheids- en turmplement-markte.
Ons versprei ons produkte deur meer as 350 gemagtigde handelaars landswyd, asook buite ons
grense in ander Afrika-lande.
Ons vervaardig die Falcon- en Locust-implementreekse en ons voortgesette vernuwing- en verbeter-
ingsprogram verseker dat ons konsekwent implemente loods om in ons kliënte se veranderende
vereistes te voorsien.
Die Falcon-reeks sluit wentelsnyers, Hooimakers®, materiaalhanteringsimplemente, mulchers, grass-
nyers, strooiers, kapploeë en ploeë in. Almal is ontwerp om eenvoudig, veilig en diensbaar te wees
en uitstekende waarde vir geld te bied. Hulle is gebou om te hou en ons strawwe Suid-Afrikaanse
toestande die hoof te bied.
In baie dele van Suid-Afrika is “Falcon” die generiese term vir grassny-implemente, wat ons die
onbetwiste leier op ons gebied maak. Die nakom van ’n bemarkingsbelofte vorm die grondslag van
enige suksesvolle bemarkingsveldtog, en almal wat die Falcon-handelsmerk koop, koop meer as net
’n produk – hulle koop die erfenis en deskundigheid van ’n maatskappy wat al lank in die land is!
Die Locust-reeks is veral geskik vir kleinhoeweboere, meer prysgevoelige kopers en ontluikende
boere. Hierdie reeks implemente, wat wentelsnyers en ‘n rollersnyer insluit, werk goed saam met ouer
of minder kragtige trekkers.
Ons voer ook ‘n reeks implemente in wat die plaaslik-vervaardigdes komplementeer. Dit sluit die
Amazone-strooiers, -spuite, -grassnyers en -grondbewerkingsimplemente in (uit Duitsland), asook die
Votex-stokkiekappers en –grassnyers, insluitend reiksnyers (uit Nederland).
Falcon Agricultural Equipment (Edms.) Bpk. is daartoe verbind om ons plaaslike gemeenskappe op
baie verskillende maniere te ondersteun. Ons hooffokus is die welsyn van kinders, en ons voorsien ‘n
veilige en geskikte skoolomgewing vir hulle, sowel as skoolverwante benodigdhede.
Ons span is trots op sy professionele benadering tot besigheid. Ons het langdurige verhoudings met
ons handelaars en hul klante opgebou, gebaseer op eerlikheid, vertroue, respek en integriteit. Voor-
treike klantediens is ’n belangrike deel van die Falcon-belofte.
Company Prole
Falcon Agricultural Equipment (Pty) Ltd is an owner-managed business and the largest manufacturer
of rotary cutters in Africa. The company opened its doors in 1985, at its current premises in Howick,
KwaZulu-Natal, South Africa. This is the ideal location, as it is in an agricultural area with a leading
agricultural college nearby. Falcon is a recognised Broad-Based Black Economic Empowerment
contributor and our skilled labour force is a dedicated team of whom we are proud.
Our primary market is the agricultural sector, with niche efforts into the industrial and turf implement
markets. We distribute our products through more than 350 authorised dealers countrywide, as well
as across our borders into other African countries.
We manufacture the Falcon and Locust ranges of implements and our ongoing programme of
innovation and improvement ensures that we consistently launch implements to satisfy our customers’
ever-changing requirements.
The Falcon range includes slashers, Haymakers®, material handling implements, mulchers, mowers,
spreaders, rotavators and ploughs. Each one is designed to be simple, safe and serviceable, offering
excellent value for money. They are built to last and are capable of coping with the tough South
African conditions.
In many parts of South Africa, “Falcon” is the generic term for grass-cutting implements, making us
the undisputed leader in our eld. Delivery on a marketing promise is the foundation of any successful
marketing drive and farmers buying the Falcon brand buy more than just a product - they buy the
heritage and expertise of a company that has been around for a long time!
The Locust range of implements is particularly suited to smallholders, more price-sensitive buyers and
emerging farmers. These implements, which include slashers and a rollermower, work well with older
or lower-powered tractors.
We also import a range of implements that complement the locally manufactured ones. These include
the Amazone spreaders, sprayers, mowers and soil tillage implements (from Germany), the Votex
shredders and mowers, including reach mowers (from the Netherlands).
Falcon Agricultural Equipment (Pty) Ltd is committed to supporting our local communities in many
different ways. Our main focus is the well-being of children, and we provide a safe and suitable school
environment for them, as well as school-related necessities.
Our team prides itself on its professional approach to business. We have built long-standing
relationships with our dealers and their customers based on honesty, trust, respect and integrity.
Excellent customer service is an important part of the Falcon promise.

Bladsy/ Page 5
Lees die volgende instruksies vir installering, veiligheid en roetine-instandhouding asseblief baie
noukeurig. As u enigsins oor die korrekte gebruik- of instandhoudingsprosedure twyfel, kontak
asseblief u handelaar, of ons, en ons sal u met graagte help.
Installering en Veiligheid
Dit is noodsaaklik om die stappe hier onder streng te volg. Om hulle te ignoreer sal die lewensduur
van u Falcon-implement verkort en tot onnodige onkoste lei.
1. VUL DIE RATKAS MET OLIE TOT DIE KORREKTE VLAK
Vul die ratkas tot die korrekte vlak met hoëgehalte-ratkasolie. Ons beveel Fuchs Renep 1000
aan, maar EP90 kan vir byvulling gebruik word. Die Falcon F50- en F80-reeks ratkaste het ’n
peilstokkie en moet tot by die merkie daarop gevul word. Verseker dat die F50- en F80- rat-
kaste se asemgaatjies skoon gehou word om blokkasies te voorkom. Dié gaatjies is bo in die
peilstokkies geleë.
Die F25- en F40-reeks gegote-yster-ratkaste aan die ligte- en mediumdiens-implemente het
’n vulprop en ’n vlakprop. Maak albei proppe oop en vul totdat die olie by die vlakprop uitloop.
MOET NIE oorvul nie, want dit kan oorverhitting en skade aan seëls
veroorsaak.
VERSEKER DAT DIE KRAGAFTAKKERAS KORREK IS VIR U TREKKER
Die kragaftakkeras sal dalk tot die regte lengte gesny moet word om u trekker/Falcon-kombinasie
te pas. ’n Te lang as kan tot ernstige skade aan u trekker, die wentelsnyer of die kragaftakkeras
lei wanneer die implement gelig of laat sak word. As u die as egter te kort afsny, kan dit
veroorsaak dat u dit nie kan gebruik nie, of dat die as onder aandrywing kan begin vibreer, breek
of oopskeur indien die oorvleueling te kort is, kan dit die implement en trekker beskadig en die
drywer beseer. Hoe om die regte as-lengte te bereken en die as te sny word duidelik in die
kragaftakkeras-handleiding beskryf. Verwys dus asseblief na daardie handleiding (veral bladsye
39 en 97–100) voordat u die as sny.
Voordat u u trekker/Falcon-kombinasie gebruik, verseker dat die trekker
se hidrouliese 3-punt-koppelbeheer-hefboom op die regte hoogte
ingestel is, sodat die Falcon-implement nie te hoog opgelig word
nie, aangesien dit die kragaftakkeras sal beskadig. Verseker dat die
kragaftakker-omhulsel te alle tye in ‘n goeie toestand is.
Please read the following installation, safety and routine maintenance instructions very carefully.
Should you be in any doubt as to the correct operating or maintenance procedure, please contact
your dealer, or us, and we will gladly assist you.
Installation and Safety
It is essential that you adhere to the steps listed below. To ignore them will shorten the life of your
Falcon implement and result in unnecessary expense.
1. FILL THE GEARBOX WITH OIL TO THE CORRECT LEVEL
Fill the gearbox to the correct level with good-quality gearbox oil. We recommend Fuchs Renep
1000, but EP90 can be used for topping up. The Falcon F50 and F80 series gearboxes are tted
with a dipstick and should be lled to the mark on the dipstick. Ensure that the breather holes on
the F50 and F80 gearboxes are kept clean to avoid blockages. The breather hole is located on
top of the dipstick.
The F25 and F40 series cast-iron gearboxes used on the light- and medium-duty implements
have a ller plug and a level plug. Open both plugs and ll until the oil runs out of the level plug.
DO NOT overll, as this can cause overheating and damage to seals.
CHECK THAT THE PTO SHAFT IS CORRECTLY SUITED TO YOUR
TRACTOR
The PTO shaft may have to be cut to the correct length to suit your tractor/Falcon combination.
Too long a shaft can result in serious damage to your tractor, the slasher, or the PTO shaft when
the implement is either raised or lowered. Cutting the shaft too short may result in you not being
able to use it or, if the overlap is too short, the shaft will, when under power, start to vibrate,
break or tear open, causing damage to the implement and tractor and injury to the operator.
The process of cutting the PTO and the calculation to establish the correct length are clearly
described in the PTO manual, so please refer to this handbook, especially pages 39 and 97-100,
before cutting the PTO shaft.
Before using your tractor/Falcon combination ensure that the tractor’s
hydraulic 3-point linkage control lever is set to the correct height so that
it does not pick up the Falcon implement too high as this will result in
damage to the PTO shaft. Ensure that the PTO guard is in good order at
all times.
2. 2.
