Falcon M Series User manual

M Series Service Manual
Extra Heavy Duty, Grade 1 Mortise Lever and Knob Locks

i
M-Series Service Manual
Introduction ................................................ 1-2
Functions ................................................... 3-5
Replacement Parts for Early LM Series Lever
Trim ................................................................ 6
Trim Assemblies ....................................... 7-11
Falcon LM Series Mortise Trim ..................... 7
Falcon L-900 Series Mortise Trim ................. 8
Falcon MM Series Mortise Trim .................... 9
M Series Lever Trim Springs ....................... 10
LM12 Single Dummy Trim ........................... 11
Lock Case Assemblies .......................... 12-28
M101 Passage Latchset .............................. 12
M161 Connecting Room/Exit Latch ............. 13
M301 Privacy Lock ...................................... 14
M311 Privacy Lock ...................................... 15
M321 Privacy Lock ...................................... 16
M371/M541
Store Door Lock/Entry/Office Lock .............. 17
M381/M441/M561 Entry/Restroom Lock/
Classroom Security/Classroom Lock .......... 18
M411 Asylum Lock ...................................... 19
M431/M571 Classroom Security and Deadbolt/
Dormitory Lock ............................................ 20
M451/M641/M711
Hotel/Motel Lock/Dormitory Lock/Privacy Lock
w/ Cylinder ................................................... 21
M521 Entry/Office Lock ............................... 22
M531 Apartment Lock ................................. 23
M581 Storeroom/Exit Lock .......................... 24
M621 Front Door Lock ................................. 25
M851 ........................................................... 26
M881 ........................................................... 27
M911/921/931/941 Deadbolt ....................... 28
Lock Functions and Accessories ......... 29-34
Mortise Locking Units .................................. 29
Electrified Mortise Chassis - Maxim w/
030173-004 Screws .................................... 30
Levers ......................................................... 31
Roses .......................................................... 31
Escutcheons ............................................... 32
Strikes ......................................................... 33
Armored Fronts/Faceplates/Sclops ............. 34
Mortise Cylinders .................................. 35-39
Mortise, Rim and Cam Lock ....................... 35
Cams ..................................................... 36-37
Cylinder Collars ..................................... 38-39
Instructions ............................................ 40-42
Reversing Hand of Locks ............................ 40
Re-Handing Instructions for Lock Trim ........ 41
Lock Re-Handing Guide ............................. 42
Table of Contents

M-Series Service Manual
1
Introduction
Introduction
This manual contains a complete listing of parts and assemblies for M-Series mortise locks manufactured by Falcon
Lock Company. This edition lists components of M-Series locks manufactured after June, 2001. All lock case covers
are labeled with dates to identify year of manufacture. Example: 12507 = the 125th day of 2007.
Exploded views of each lock function and trim assembly are provided with accompanying charts to identify parts for
replacement purposes. Exploded views of trim are shown with parts for standard size doors. In addition, this manual
provides lock trim ordering procedures, cylinder length charts by door range, and all auxiliary components of the M-
Series mortise locks.
Standard Features*
Certifications ANSI A156 .13, Series 1000, Grade 1 Operation, Grade 2 security, UL Listed for 3-hour fire door.
Latch 2-piece brass mechanical anti-friction bolt, ³⁄₄” projection.
Strike 1¹⁄₄” x 4⁷⁄₈”, ANSI, Square corner, no box.
Cylinder 6-Pin solid brass, keyed 5-pin, Falcon G keyway, keyed different (KD)
Door Range 1³⁄₄” – 2¹⁄₄” standard
Keys Two, nickel silver cut keys per lock, Falcon G keyway
* Locks are furnished with standard features unless otherwise specified.
Lock Assembly Drawing Index
The Lock Assembly Drawing Index provides visual representations and textual descriptions of available functions.
Page numbers for full trim and chassis drawings are referenced.
Emergency Key
Key Key
Lever
T-Turn
K n obK n ob
Blank Plate
Knob
Rigid Knob
T- Tu r n

M-Series Service Manual
2
Introduction
Strike
C
L
6"
(10) 56M"
(6)
C
L
4"
(102)
4"
(102)
6"
(10) C
L
Height
Line
156O"
(38)
256"
(54)
2(6QE"
(62)
3(6:O"
(21)
3(6:O"
(21)
C
L
Lock
Front
2(6"
(73)
2(6"
(73)
46" (111)
26M" (70)
Backset
(6:O"
(6)
6M"
(19)
6"
(10)
4(6"
(124)
Cylinder
cut-out
Mounting
Holes (2)
Knob or Lever
Cut-out
Turn Piece
and
Occupancy
Indicator
1. Dimensions are maximum for the product
2. Templates are not to scale
3. Standard strike is shown on each template
for dimensions only
4. Dimensions do not provide allowances for door
silencers, weather stripping, sound proofing
or other additions to door or door frames
ANSI Standards: M-Series locks meet all requirements for installations in doors and frames prepared in accordance with
ANSI specifications A156.13, 2005
Metal Doors: Suitable reinforcement is required to support lock case in center of door and to prevent door from compressing
when trim is tightened. (See ANSI A115.1)
Thick Doors: Locks for non-standard door thickness may require special instructions
Lead Lining: When M-Series locks are ordered with lead lining, add 56" (3) to the width of the mortise cut-out on the lock case cover side of
installation
Electrified Locks: Provisions must be made to route low voltage wire to the lock. Attach wires to the 6" (152) pigtail of the solenoid.
Power transfer unit and low voltage wiring are not furnished
NOTE:
Bevel 56" in 2" (3 in 51)
156M"
(32)
156M"
(32)
C
L
156"
(29)
6"
(16)
36"
(86)
6QE"
(30)
36:O"
(18)
(6QE"
(37)
56QE"
(21)
56QE"
(24)

M-Series Service Manual
3
Function ANSI A156.13, 2005 Page
SCHLAGE ANSI DESCRIPTION OUTSIDE FUNCTION INSIDE FUNCTION
M101 F01-1
F01-2
Passage/Closet
Latchset
Latch bolt by levers at all
times.
Latch bolt by levers at all
times. 11
M161 -
Connecting
Room/Exit
Latch
Non-removable blank plate. Deadlocking latch bolt by
inside knob/lever. 12
M301 F02-1
F02-2 Privacy Lock
Latch bolt by knobs/levers,
emergency key (012727-
000-30).
Latch bolt by knobs/levers.
Deadbolt by turn. 13
M311 F19-1
F19-2
Privacy,
Bedroom or
Bath Lock
Latch bolt by knobs/levers.
Deadbolt by emergency key
(012727-000-30).
Latch bolt by knobs/levers.
Deadbolt by turn. Rotating
inside knob/lever retracts
both bolts.
14
M321 F22-1
F22-2 Privacy Lock
Latch bolt operated by knob/
lever from either side except
when outside knob/lever
is locked by inside T-turn.
Emergency key (012727-
000-30) furnished with lock.
Operating inside knob/lever,
closing door or operating
outside emergency release
unlocks outside knob/lever.
15
M371 F14-1
F14-2
Store Door
Lock
Latch bolt by knobs/levers.
Deadbolt by key from either
side.
Latch bolt by knobs/levers.
Deadbolt by key from either
side.
16
M381 F09-1
F09-2
Entry/Restroom
Lock
Deadlocking latch bolt by
knobs/levers except when
outside knob/lever is locked
by key inside, then by key
outside.
-17
M411 - Asylum Lock
Deadlocking latch bolt by
key from either side. Both
knobs/levers rigid.
Deadlocking latch bolt by
key from either side. Both
knobs/levers rigid.
18
M431 -
Classroom
Security Lock
with Deadbolt
Retracted by knob/lever from
either side, except when
outside lever is locked; latch
bolt then retracted by key
outside.
Retracted by knob/lever
from either side, except
when outside lever is
locked; latch bolt then
retracted by rotating lever
inside. Deadbolt thrown or
retracted by key only.
19
Functions
To order Falcon M Series locksets, please consult page 19 for ordering information and assistance.
Indicates interchangeable core available.
Catalog Number Prefixes: Add the following prefix for the appropriate trim style.
MM (example: MM521) = Knob Trim
LM (example: LM521) = Lever Trim
Note: If a special function is required and not listed here, please contact the factory for assistance.

M-Series Service Manual
4
Function ANSI A156.13, 2005 Page
SCHLAGE ANSI DESCRIPTION OUTSIDE FUNCTION INSIDE FUNCTION
M441 - Classroom
Security Lock
Deadlocking latch bolt by
levers from either side
except when outer lever
is locked by key from
either side. Outer lever
is unlocked by key from
either side.
Deadlocking latch bolt by
levers from either side
except when outer lever
is locked by key from
either side. Inside lever
is always free.
17
M451 F15-1
F15-2 Hotel/Guest Lock
Deadlocking latch bolt
by key. Outside knob/
lever rigid. Deadbolt by
emergency key outside.
Projecting deadbolt
displays occupancy
indicator and shuts out all
keys except emergency.
Deadlocking latch
bolt by inside knob/
lever. Deadbolt by turn.
Rotating inside knob/
lever retracts both bolts.
Must use button to
unlock outside.
20
M521 F04-1
F04-2 Entry/Office Lock
Deadlocking latch bolt by
knobs/levers except when
outside knob/lever is
locked by buttons in face,
then by key outside.
Deadlocking latch bolt
by knobs/levers except
when outside knob/lever
is locked by buttons in
face, then by key outside.
Must use button to
unlock outside.
21
M531
F10-1
F10-2
F12-1
F12-2
F20-1
Apartment
Latch bolt by knobs/levers
except when outside
knob/lever is made
inoperative by buttons in
face. Deadbolt by key
outside. Deadlocking
latch.
Deadbolt by turn.
Rotating inside knob/
lever retracts both bolts.
22
M541 F21-1
F21-2 Entry/Office Lock Latch bolt by knobs/ levers. Deadbolt by key.
Latch bolt by knobs/
levers. Deadbolt by turn. 16
M561 F05-1
F05-2 Classroom Lock
Deadlocking latch bolt
by knobs/levers. Outside
knob/lever locked by key
outside.
Deadlocking latch bolt
by knobs/levers. Inside
knob/lever always free.
17
M571 F13-1
F13-2 Dormitory Lock
Latch bolt by knobs/levers
except when knob/lever
is locked by projecting
deadbolt. Key retracts
deadbolt and unlcoks
knob/lever.
Latch bolt by knobs/
levers except when
knob/lever is locked
by projecting deadbolt.
Rotating knob/lever
retracts both bolts.
19
M581 F07-1 Storeroom Lock
Deadlocking latch bolt by
key. Outside knob/lever
always rigid.
Deadlocking latch bolt by
knob/lever. 23
M621 F08 Entry Lock
Latch bolt is operated by
knob/lever from either
side except when outside
knob/lever is made
inoperative by a stop or
mechanical means other
than key. Key outside
operates both bolts.
Deadbolt is operated by
turn. Must use button to
unlock outside.
24
Functions

M-Series Service Manual
5
Function ANSI A156.13, 2005 Page
SCHLAGE ANSI DESCRIPTION OUTSIDE FUNCTION INSIDE FUNCTION
M641 - Dormitory Lock
Latch bolt by key. Outside
knob/lever rigid. Deadbolt
by key. Deadlocking latch.
Latch bolt by knob/
lever. Inside knob/
lever free. Deadbolt by
T-turn. Rotating knob/
lever retracts both bolts.
Deadlocking latch.
20
M711 - Privacy Lock
(Special)
Latch bolt operated by
key. Outside knob/lever
is always in operative.
Deadbolt operated by
emergency release. Key
outside does not operate
deadbolt. Deadlocking
latch.
Latch bolt operated by
operating knob/lever.
Deadbolt operated by
T-turn. Operating inside
knob/lever retracts both
bolts.
20
M851 - Storeroom - Fail
Safe EL
Latch bolt operated by
knob/lever from either
side except when outer
knob/lever is electrically
locked. When outer
knob/lever is locked
latch bolt retracted by
key in cylinder outside.
Deadlocking latch.
Auxiliary latch deadlocks
latchbolt when door is
closed. Inside knob/
lever is always free for
immediate exit.
25
M881 - Storeroom - Fail
Secure EU
When locked, key in
cylinder outside retracts
latch bolt.
Latch bolt operated by
knob/lever from inside
except when outer
knob/lever is electrically
unlocked, then latch bolt
from either side.
26
M911 - Classroom Safety
Deadlock
Deadbolt retracted by key.
Deadbolt projected by key.
Deadbolt retracted by
turn. 27
M921 F18-1
F18-2 Deadlock Deadbolt by key. - 27
M931 F16-1
F16-2 Deadlock Deadbolt by key. Deadbolt by key. 27
M941 F17-1
F17-2 Deadlock Deadbolt by key. Deadbolt by turn. 27
M12/M18 - Dummy Trim Single or double available. -
Functions

M-Series Service Manual
6
Replacement Parts for Early LM Series Lever Trim
Call Out
Number Description Part Number
Call Out
Number Description Part Number
1 Bushing 030067-000-50 22 Lever Return Spring, Green 030057-002-30
6 Hex Nut 030282-000-30 23 Lever Stop 030054-001-30
7 Inner Insert 030051-001-55 24 Lock Washer 030284-000-60
8 Inner Insert Assy, All Other
Levers
A30073-003-00 44 Spindle & Spring Assembly A21245-000-00
15 Inner Trim Shank 030053-001-30
Trim and Accessories
44 6
24
23
22
71
15
8
Inside

M-Series Service Manual
7
Falcon LM Series Mortise Trim
Trim Assemblies
44 6
24
23
22
71
15
10
Inside
44
6
24
23
32
30 or 31
33
2
36 1
26 22
38
17
13
36
42
2
2
4
40 46
39
2
3
25 45
5
Call Out
Number Description Part Number
Call Out
Number Description Part Number
1 Bushing 030067-000-50 25 Mortise Cylinder w/9894-1 Cam 985 w/9894-1
2 Collar 030059-000 * 26 Outer Insert, Tapped 030051-000-55
3 Collar Assy, Sectional A08794-000 * 30 Outer Lever Assy, Dane Gala A30068-00D *
4 Escutcheon w/T-Turn, Napa A30203-000 * 31 Outer Lever Assy, Dane Napa A30072-05D *
5 Escutcheon, Napa 030066-005 * 32 Outer Lever, Dane 021280-000 *
6 Hex Nut 030282-000-30 33 Outer Washer 030205-002-50
7 Inner Insert 030051-001-55 36 Rose 030052-000 *
10 Inner Insert Assy A30073-001-00 38 Screw, 10-32 x 2 FHMS 030069-032-30
13 Inner Lever Assy, Dane (shown)** A30202-00D * 39 Screw, 6 x 1/2 FHSMS 002073-000 *
15 Inner Trim Shank 030053-001-30 40 Screw, 6 x 3/4 OHSMS 002074-012 *
17 Inner Washer 030205-001-50 42 Set Screw, 1/4-28 x 1/4 030283-004-30
22 Lever Return Spring 030057-002-30 44 Spindle & Spring Assembly A21245-000-00
23 Lever Stop 030054-001-30 45 Spring Washer, Cylinder 008789-001-60
24 Lock Washer 030284-000-60 46 T-Turn Assy, Sectional A20336-000 *
*= Finish or Specify Finish on All **For other lever options, see page

M-Series Service Manual
8
Falcon L-900 Series Mortise Trim
Call Out
Number Description Part Number
25 Mortise Cylinder w/9894-1
Cam
985 w/9894-1
39 Screw, 6 x 1/2 FHSMS 002073-000 *
45 Spring Washer, Cylinder 008789-001-60
46 T-Turn Assy, Sectional A20336-000 *
49 M911 Classroom Thumbturn 973 (RH) 974 (LH)
Inside
46
39
25 45
Inside
49
25 45
Inside
Inside
25 45
25
25 45
941
921 931
911
45
*= Finish or Specify Finish on All

M-Series Service Manual
9
Falcon MM Series Mortise Trim
Call Out
Number Description Part Number
Call Out
Number Description Part Number
1 Bushing 030067-000-50 29 Outer Knob Assy, Hana Napa A30074-05H *
2 Collar 030059-000 * 33 Outer Washer 030205-002-50
3 Collar Assy, Sectional A08794-000 * 35 Retainer Ring 002939-000-30
4 Escutcheon w/T-Turn, Napa A30203-000 * 36 Rose 030052-000 *
5 Escutcheon, Napa 030066-005 38 Screw, 10-32 x 2 FHMS 030069-032-30
7 Inner Insert 030051-001-55 39 Screw, 6 x 1/2 FHSMS 002073-000 *
11 Inner Insert Assy, Knob A30078-000-00 40 Screw, 6 x 3/4 OHSMS 002074-012 *
12 Inner Knob Assy, Hana A30065-00H * 42 Set Screw, 1/4-28 x 1/4 030283-004-30
14 Inner Trim Shank 030053-000-30 43 Spacer 030063-000-30
17 Inner Washer 030205-001-50 44 Spindle & Spring Assembly A21245-000-00
25 Mortise Cylinder w/9894-1 Cam 985 w/9894-1 45 Spring Washer, Cylinder 008789-001-60
26 Outer Insert, Tapped 030051-000-55 46 T-Turn Assy, Sectional A20336-000 *
27 Outer Knob Assy, Hana A30138-00H * 47 Washer 030163-000-60
28 Outer Knob Assy, Hana Gala A30077-00H * *= Finish or Specify Finish on All
Trim Assemblies
2
4
40 46
39
2
3
25
45
5
44
38
35
47
43
17
12
36
42
71
14
11
2
44
35
47
27
28 or 29
33
2
36 1
26 43

M-Series Service Manual
10
M-Series Lever Trim Springs
030057-002-30 Yellow Color (.052 Thick Wire)
Replacement for Green Springs
Used on: Avalon All Materials
Dane All Materials
Quantum All Materials
Sutro All Materials First used in July 1995
Trim Accessories

M-Series Service Manual
11
Parts List - LM12 AG
LM12 Single Dummy Trim
Lock Functions and Accessories
20
2
36
37
15
1
19
34
24
6
18 42
Call Out
Number Description Part Number
Call Out
Number Description Part Number
1 Bushing 030067-000-50 20 Lever Assembly, Avalon** A30202-00A *
2 Collar 030059-000 * 24 Lock Washer 030284-000-60
6 Hex Nut 030282-000-30 34 Plate, Dummy 030054-002-30
15 Inner Trim Shank 030053-001-30 36 Rose 030052-000 *
18 Insert Assembly A30257-04L-00 37 Screw, 10 x 1 FHSM (2) 030220-016-30
19 Insert, Dummy 030051-004-55 42 Set Screw, 1/4-28 x 1/4 030283-004-30
*= Finish or Specify Finish on All
** For other lever options, see page 25

Lock Case Assemblies
M-Series Service Manual
12
Parts List - A20800-30F * Locking Unit M101
M101 Passage Latchset
A20800-000-626
Call Out
Number Description Part Number
Call Out
Number Description Part Number
50 Arm, Lower Retract 020645-000-30 114 Latch Bolt Assy
A20639-004-626
59 Case Assy A20580-001-00 129 Screw 8-32 x 1/4 K110-020
77 Coupling 020646-000-30 130 Screw 8-32 x 3/8 (4) 002801-006-30
80 Cover Assy, Not Tapped A30875-000-00 131 Screw 8-32 x 3/8 (2) 002932-000-30
90 Faceplate 020100-000 * 137 Spacer Hub 020674-000-30
102 Front Plate 1-1/4” Wide 021349-000-30 153 Spring, Retract Arm 020666-000-60
105 Hub, Non-Locking (2) 020642-000-30 159 Washer, Flat 002900-000-30
*= Finish or Specify Finish on All
129
90
102
130
80
59
131
105
137
105
114
50
77
153
159
RIGHT HAND OR LEFT HAND REVERSE SHOWN

Lock Case Assemblies M-Series Service Manual
13
Parts List - A30842-30F* Locking Unit M161
M161 Connecting Room/Exit Latch
A30842-000-626
Call Out
Number Description Part Number
Call Out
Number Description Part Number
50 Arm, Lower Retract 020645-000-30 114 Latch Bolt Assy A20639-004-626
52 Arm, Upper Retract 020633-000-30 115 Lever 020575-000-30
54 Bar, Deadlocking 020579-000-630 128 Ring, Truarc 005347-000-30
55 Blocker Assy A20957-000-00 129 Screw 8-32 x 1/4 (2) K110-020
68 Case Assy A30877-00-00 130 Screw 8-32 x 3/8 (4) 002801-006-30
77 Coupling
020646-000-30 131 Screw 8-32 x 3/8 (2) 002932-000-30
80 Cover Assy, Not Tapped A30875-000-00 137 Spacer Hub 020674-000-30
89 Faceplate 020099-01U * 142 Spring, Blocker 020492-000-60
102 Front Plate 1-1/4” Wide 021349-000-30 147 Spring, DL 020595-001-60
105 Hub, Non-Locking (2) 020642-000-30 153 Spring, Retract Arm 020666-000-60
*= Finish or Specify Finish on All
130
80
129
89
102
RIGHT HAND OR LEFT HAND REVERSE SHOWN
68
131
105
137
105
114
147
115
54
55
142
128
52
50
77
153

Lock Case Assemblies
M-Series Service Manual
14
Parts List - A20806-000-626 Locking Unit M301
M301 Privacy Lock
A20806-000-XXX
Call Out
Number Description Part Number
Call Out
Number Description Part Number
50 Arm, Lower Retract 020645-000-30 129 Screw 8-32 x 1/4 (2) K110-020
64 Case Assy A20588-001-00 130 Screw 8-32 x 3/8 (4) 002801-006-30
77 Coupling 020646-000-30 131 Screw 8-32 x 3/8 (2) 002932-000-30
79 Blocker Assy A23204-000-00 134 Slide, Locking Hub 020572-000-30
84 Deadbolt 1”
030147-000-626 137 Spacer Hub 020674-000-30
91 Faceplate UL 020109-000 * 144 Spring, Deadbolt 020641-000-30
102 Front Plate 1-1/4” Wide 021349-000-30 153 Spring, Retract Arm 020666-000-60
104 Hub, Locking 020643-000-30 158 Torsion Spring 021111-001-60
109 Hub, T-Turn 020652-001-30 159 Washer, Flat 002900-000-30
114 Latch Bolt Assy
A20639-004-626
*= Finish or Specify Finish on All
130
79
129
91
102
RIGHT HAND OR LEFT HAND REVERSE SHOWN
64
131
104
144
104
137
158
134
84
109
159
50 114
77
153

Lock Case Assemblies M-Series Service Manual
15
Parts List - A21863-30F * Locking Unit M311
M311 Privacy Lock
A21841-000-626
Call Out
Number Description Part Number
Call Out
Number Description Part Number
50 Arm, Lower Retract 020645-000-30 109 Hub, T-Turn 020652-001-30
52 Arm, Upper Retract 020633-000-30 114 Latch Bolt Assy
A20639-004-626
64 Case Assy, Not Tapped A20588-001-00 129 Screw 8-32 x 1/4 (2) K110-020
77 Coupling 020646-000-30 130 Screw 8-32 x 3/8 (4) 002801-006-30
79 Cover Assy, Threaded A23204-000-00 131 Screw 8-32 x 3/8 (2) 002932-000-30
84 Deadbolt 1”
030147-000-626 134 Slide, Locking Hub 020572-000-30
91 Faceplate UL 020109-000 * 137 Spacer Hub 020674-000-30
102 Front Plate 1-1/4” Wide 021349-000-30 144 Spring, Deadbolt 020641-000-30
104 Hub, Locking 020643-000-30 153 Spring, Retract Arm 020666-000-60
105 Hub, Non-Locking 020642-000-30 158 Torsion Spring 021111-001-60
*= Finish or Specify Finish on All
130
79
129
91
102
RIGHT HAND SHOWN
64
131
104
144
105137
158
134
84
109
50
114
77
52
153

Lock Case Assemblies
M-Series Service Manual
16
Parts List - A30539-30F * Locking Unit M321
M321 Privacy Lock
A30539-000-626
Call Out
Number Description Part Number
Call Out
Number Description Part Number
50 Arm, Lower Retract 020645-000-30 129 Screw 8-32 x 1/4 (2) K110-020
72 Case Assy, Not Tapped A30544-000-00 130 Screw 8-32 x 3/8 (4) 002801-006-30
77 Coupling 020646-000-30 131 Screw 8-32 x 3/8 (2) 002932-000-30
79 Cover Assy, Not Tapped A23204-000-00 133 Slide, Locking 030535-000-55
90 Faceplate 020100-000 * 134 Slide, Locking Hub 020572-000-30
102 Front Plate 1-1/4” Wide 021349-000-30 137 Spacer Hub 020674-000-30
103 Hub & Pin Assy A30534-000-00 151 Spring, Locking Slide 030382-000-30
104 Hub, Locking 020643-000-30 153 Spring, Retract Arm 020666-000-60
105 Hub, Non-Locking 020642-000-30 158 Torsion Spring 021111-001-60
114 Latch Bolt Assy
A20639-004-626 159 Washer, Flat 002900-000-30
*= Finish or Specify Finish on All
130
79
RIGHT HAND SHOWN
72
131
104
151
105
137
158
134
159
50 114
133
103
77
153
129
90
102

Lock Case Assemblies M-Series Service Manual
17
Parts List - A20809-000-626 Locking Unit M371/541
M371 Store Door Lock
M541 Entry/Office Lock
A20809-000-626
Call Out
Number Description Part Number
Call Out
Number Description Part Number
50 Arm, Lower Retract 020645-000-30 121 Retainer Assy, Cyl A21209-000-00
64 Case Assy A20588-001-00 129 Screw 8-32 x 1/4 (2) K110-020
77 Coupling 020646-000-30 130 Screw 8-32 x 3/8 (4) 002801-006-30
79 Cover Assy A23204-000-00 131 Screw 8-32 x 3/8 (2) 002932-000-30
84 Deadbolt 1”
030147-000-626 134 Slide, Locking Hub 020572-000-30
91 Faceplate 020109-000 * 137 Spacer Hub 020674-000-30
102 Front Plate 1-1/4” Wide 021349-000-30 144 Spring, Deadbolt 020641-000-30
104 Hub, Locking (2) 020643-000-30 153 Spring, Retract Arm 020666-000-60
109 Hub, T-Turn 020652-001-30 158 Torsion Spring 021111-001-60
114 Latch Bolt Assy
A20639-004-626 159 Washer, Flat 002900-000-30
*= Finish or Specify Finish on All
129
91
102
50 114
158
134
104
137
104
144
109
84
121
77
159
153
64
131
RIGHT HAND OR LEFT HAND REVERSE SHOWN
130
79
