The Kubix™
FP4420 Series
SPECIFICATION SHEET
Product Specifications Subject To Change

Copyright 2008 Fanimation, Inc. 2008/06
The Kubix™Fan Assembly – FP4420**
10983 Bennett Parkway
Zionsville, IN 46077
Toll Free [phone]
FAX [phone]
Outside U.S. call [phone]
Visit Our Website www.fanimation.com
Available Finishes
OB Oil-Rubbed Bronze with
Opal/Frosted Glass
SN Satin Nickel with
Opal/Frosted Glass
7´ min
Floor
Ceiling
Blade Sweep = 54˝dia
Net Hanging Weight: 19½ lbs
6˝Sq
14° Blade Pitch
13˝14½˝
Dimensions shown in inches
Distance from Ceiling
to Bottom of Fan A
Fan w/6˝downrod 19¼˝
Fan w/12˝downrod 25¼˝
Fan w/18˝downrod 31¼˝
Fan w/24˝downrod 37¼˝
Fan w/36˝downrod 49¼˝
Fan w/48˝downrod 61¼˝
Fan w/60˝downrod 73¼˝
Fan w/72˝downrod 85¼˝
A
INSTALLATION REQUIREMENTS:
Ceiling fan attaches to electrical junction box securely anchored and capable of withstanding a load of at least 50 lbs.
ELECTRICAL REQUIREMENTS:
Ceiling fan requires a grounded electrical supply line of 120 volts AC, 60 Hz, 15 amp circuit.
MOTOR SPECS:
153 x 18 motor is designed for optimal performance with this fan.
FAN SPEEDS:
3 fan speeds with reversing switch (on top of the motor). High – 150 rpm; Med – 110 rpm; Low – 60 rpm
CONTROL OPTIONS:
The hand-held remote control (C24) and canopy receiver (RECFP4420) are included. Push button remote control will
consist of 3 separate fan speeds, infinite light levels, and off position. Reversing switch located on fan housing. Installation
and operating instructions provided with fan. Optional wall control (C25) is available (to be used in conjunction with fan
receiver).
LIGHTING OPTION:
The 2-bulb downlight fixture (2-60 watt candelabra bulbs - not included) is included with this fan assembly with a maximum
of 120 watts. Maximum downlight wattage not to exceed 120 watts.
DOWNROD OPTIONS:
The Kubix™fan comes with a standard 6” downrod with square sleeve included. Optional downrods are available in 12”,
18”, 24”, 36”, 48”, 60”, and 72”. For installations requiring a longer downrod, a downrod coupler is available. The Kubix™
fan can be mounted on a sloped ceiling up to 30°. Most sloped ceiling installations require a downrod longer than the
standard 6˝downrod. Optional sloped ceiling ball kits (SCB1-52) are available for up to 52°. Call tech support for more
information.
BLADE SETS:
A set of three 26˝reversible (cherry/walnut) wood blades are included. Optional set of three 20˝reversible (cherry/
walnut–B4442CWR) and satin nickel (B4442SN) blades are available and sold separately. Not recommended for Damp
Location.
DAMP LOCATION:
Fan not rated for Damp Location usage.
