Fanmaster CAB200 User manual

FA NM A ST E R
cooling heating ventilation extraction
INSTRUCTION MANUAL
TO PREVENT SERIOUS INJURY, READ & UNDERSTAND ALL WARNINGS &
INSTRUCTIONS BEFORE USE. PLEASE KEEP THIS DOCUMENT FOR YOUR RECORDS
MODEL: CAB200, CAB300, CAB450
COMPACT AIR BLASTERS
PORTABLE VENTILATORS
1 year warranty

FOR YOUR INFORMATION
Thank you for purchasing a Fanmaster Compact Air Blaster Fan. Please read this
instruction manual carefully before using this appliance.
Disclaimer:
Fanmaster reserves the right to make alterations to specications, quantities,
dimensions, for production or other reasons, subsequent to publication.
While we believe the information is accurate and complete, we make no warranty
or representation for any particular purposes. The information is offered in good faith
and with the understanding that any use of the units or accessories in breach of the
directions and warnings in this document is at the sole discretion and risk of the user
Disposal Guidelines:
Do not dispose of this product with general household waste. This product must be
disposed according to the laws governing Waste Electrical and Electronic Equipment.
If required, contact your local authorities for information regarding the available
disposal facilities.

1. GENERAL SAFETY RULES & WARNINGS
• PLEASE READ INSTRUCTIONS CAREFULLY.
• PLACE INSTRUCTION MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE. DO NOT ALLOW
ANYONE WHO HAS NOT READ THESE INSTRUCTIONS TO ASSEMBLE, ADJUST OR OPERATE THIS
APPLIANCE.
• IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLOSION
MAY RESULT IN CAUSING PROPERTY DAMAGE, SERIOUS INJURY OR LOSS OF LIFE.
• FAILURE TO COMPLY WITH THE PRECAUTIONS AND INSTRUCTIONS PROVIDED WITH THIS
APPLIANCE, CAN RESULT IN DEATH, SERIOUS INJURY AND PROPERTY LOSS OR DAMAGE FROM
HAZARDS OF FIRE, EXPLOSION, BURN, AND/OR ELECTRICAL SHOCK.
• ONLY PERSONS WHO CAN UNDERSTAND AND FOLLOW THE INSTRUCTIONS SHOULD USE OR
SERVICE THIS APPLIANCE. IF YOU NEED ASSISTANCE OR REQUIRE INFORMATION SUCH AS AN
INSTRUCTION MANUAL, LABELS, ETC. CONTACT FANMASTER.
• DO NOT STORE OR USE GASOLINE, PETROL OR ANY OTHER FLAMMABLE OR COMBUSTIBLE
VAPORS AND LIQUIDS IN THE VICINITY OF THIS APPLIANCE.
• FIRE, BURN, INHALATION, AND EXPLOSION HAZARD. KEEP SOLID COMBUSTIBLES, SUCH
AS BUILDING MATERIALS, PAPER OR CARDBOARD, A SAFE DISTANCE AWAY FROM THE
APPLIANCE. NEVER USE THE APPLIANCE IN SPACES WHICH DO OR MAY CONTAIN VOLATILE
OR AIRBORNE COMBUSTIBLES, OR PRODUCTS SUCH AS GASOLINE, SOLVENTS, PAINT THINNER,
DUST PARTICLES OR UNKNOWN CHEMICALS.
• THE ELECTRICAL SYSTEM TO WHICH THE APPLIANCE IS CONNECTED MUST COMPLY WITH
LOCAL REGULATIONS. A RESIDUAL-CURRENT DEVICE (RCD) MUST BE INSTALLED.
• UNPLUG THE APPLIANCE BEFORE PERFORMING ANY MAINTENANCE OPERATIONS.
• ALWAYS CHECK THE POWER CABLE BEFORE USING THE APPLIANCE. IT MUST NOT BE BENT,
TAUT, STRETCHED, CRUSHED OR ANY WAY DAMAGED.
• IF THE POWER CORD AND/OR PLUG IS DAMAGED, IT MUST BE REPLACED BY FANMASTER, A
SERVICE AGENT OR A QUALIFIED PERSONS.
• DO NOT COVER THE FAN GUARD OR MOTOR.
• DO NOT LEAVE THE APPLIANCE UNATTENDED WHEN IN USE.
• NEVER USE THE APPLIANCE WHEN EITHER THE APPLIANCE OR THE POWER CABLE IS WET.
• CHILDREN SHOULD BE SUPERVISED TO ENSURE THAT THEY DO NOT PLAY WITH THE APPLIANCE.
• THE APPLIANCE IS NOT INTENDED FOR USE BY PERSONS (INCLUDING CHILDREN) WITH
REDUCED PHYSICAL, SENSORY OR MENTAL CAPABILITIES, OR LOCK OF EXPERIENCE &
KNOWLEDGE.
• DO NOT PUT OBJECTS INTO THE FAN GUARD & BLADE.
• DO NOT CLIMB OR STACK THINGS ON THE APPLIANCE.
FOR YOUR INFORMATION

2. PRODUCT DESCRIPTION & SPECIFICATIONS
PRODUCT DESCRIPTION
The Fanmaster Compact Air Blasters are an innovative multi-purpose ventilator
excellent for dust and fume extraction, or can be used to supply fresh air to conned
spaces. The Compact Air Blaster is economical, affordable and is the perfect air
extractor and blower without the large cost. The Compact Air Blaster is both compact
and portable. Flexible Ducting is also available and sold separately
SPECIFICATIONS
MODEL CAB200 CAB300 CAB450
Air Flow (L/s) 416 1000 2083
Diameter (mm) 200 300 450
dBa 70 83 96
Motor (K/W) 0.18 0.52 1.7
Voltage/Hz 240 / 50-60 240 / 50-60 240/50
RPM 2800/3300 2800/3300 2800
Pressure (PA) 240 345 972
Plug Connection 3 Pin 10a 3 Pin 10a 3 Pin 10a HD
Fan Speed 1 1 1
IP Rating IP24 IP24 IP24
Net Weight (kg) 8.8 14 29
1. Place the ventilator fan on an even surface.
2. Connect the plug to the relevant power source.
3. The ventilator fan is not suitable in environments that is too moist or corrosive.
4. The ventilator fan has 1 speed.
Operating Instructions
Remove the appliance from the carton. If the appliance is damaged, please
contact Fanmaster or where you purchased the appliance from.
Environment of Use
1. The max relative humidity is 90% (when in 25°C).
2. Below 1000 metres altitude.
Maintenance
1. To ensure prolonged safe use ensure you have this unit inspected,
cleaned & moving parts lubricated by a qualied person after every 1000
hours of use.
2. Regularly inspect the cord & plug & do not use if damaged. A license
electrician is required to repair or replace the cord & plug.
3. Any other repairs or maintenance must be performed by a qualied
person.
3. OPERATING INSTRUCTIONS

4. DIMENSIONS2. PRODUCT DESCRIPTION & SPECIFICATIONS
3. OPERATING INSTRUCTIONS
MODEL A B C D E
CAB200 310 245 210 250 310
CAB300 380 245 300 340 410
CAB450 460 / 457 515 555
DIMENSIONS (MM)
PEFORMANCE CURVE
CAB200 CAB300
CAB450

6. WARRANTY
Any claim under this warranty must be made within 12 months of the date of
purchase of the product. To make a claim under the warranty, take the product
(with proof of purchase) to the store where you purchased the product or go to
https://www.fanmaster.com.au/support.
This warranty is given by Fanmaster Pty Ltd
ABN: 45 353 934 457
Unit 1/6-8 Yalgar Rd, KIRRAWEE NSW 2232
P: 1300 900 345
E: [email protected]
This warranty is provided in addition to other rights and remedies you have under law:
Our goods come with guarantees which cannot be excluded under the Australian
Consumer Law. You are entitled to replacement or refund for a major failure and
to compensation for other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major failure.
Exclusions: This warranty does not cover:
• Any defects caused by an accident, misuse, abuse, improper installation or
operation, lack of reasonable care, unauthorized modication, loss of parts,
tampering or attempted repair by a person not authorized by the distributor.
• Any product that has not been installed, operated or maintained to a
satisfactory level.
• Any damage caused by improper power input or improper cable connection.
7. WARRANTY VALIDATION

6. WARRANTY
Register Your Product
REGISTER
www.fanmaster.com.au/warranty-registration
7. WARRANTY VALIDATION
> Warranty Management
Validate your warranty, and receive notication 14 days prior to expiration.
> Warranty Extension Available
Add extended warranty to give you peace of mind.
> Product Updates
Latest news and updates on Fanmaster products.

N11664
MADE IN CHINA
Fanmaster Pty Ltd | 1/6-8 Yalgar Road, KIRRAWEE NSW 2232
1300 900 345 | [email protected] | www.fanmaster.com.au
