Fantasea EyeGrabber MPK Series User manual

EyeGrabber Sony MPK Series Instruction Manual
FantaseaEyeGrabberSonyMPKSeries
(Cat.No.4056)
InstructionManual

TheEyeGrabberSonyMPKSeriesallowsforsecurestorageofFantaseaaccessorylenses
andfilterswhennotinstalledonthehousing.

CompatiblewiththeFollowingLensAccessories:
BigEyeLensMPKSeries(Cat.No.5141)
EyeDaptorMPKSeries‐F67(Cat.No.4711)‐withanylensaccessorymountedonthe
adaptor
SharpEyeLensM67(Cat.No.5128)‐ONLYwhenmountedontopoftheEyeDaptor
MPKSeries‐F67(Cat.No.4711)

IncludedintheKit:












InstructionsforUse:
1.AssemblingtheEyeGrabberLensHolderonaFlexorBall&JointArm
a. Pleaseusetheutmostcareanddonotuseexcessiveforcewhenassemblingand
disassemblingthedifferentaccessories,inordertonotcauseanydamagetothe
products.
b. ItisadvisabletomounttheEyeGrabberonthearmpriortoinstallingthearmonthe
housingtrayorhandle.
c. RemovethescrewsfromtheT2ConnectorsothatthetwopartsoftheT2Connector
aredisconnected.Pleasenotethattherearetwosetsofscrewsincludedinthekit.The
typeofscrewscompatiblewithyourarmdependsonthemodelofthearm.Ingeneral,


EyeGrabberSonyMPKSeriesT2ConnectorSetof2shorterscrews

EyeGrabber Sony MPK Series Instruction Manual

longerscrewsarecompatiblewithwiderarms,suchasFantaseaFlexarms,while
shorterscrewsarecompatiblewithnarrowerarms,suchasBall&Jointarms.Choose
thepropersetofscrewsforyoursystemandleavethescrewsinstalledonlyinsidethe
frontpartoftheT2Connector(image#1).Keeptheothersetofscrewsinstoragefor
futureuse,incaseyoureplacethearmsusedinyoursystem.
d. IfassemblingtheEyeGrabberonaFlexarm,gentlyrotatethelinksofthearmsothat
twosequentialholespositionedontheupperhalfof
thearmarealignedinawaythatenablesinserting
screwsinside(image#2).IfassemblingtheEyeGrabber
onaBall&Jointarm,simplychoosetwoslotsonthe
upperhalfofthearmwhichtheEyeGrabberwillbe
assembledthrough.












e. HoldthefrontpartoftheT2connectorwiththetwoscrewsinstalledinsideinfrontof
thearm,sothatthescrewsarealignedwiththetwoholesorslotsinthearm.Insert
thescrewsthroughtheholesorslotsofthearm(image#3).Anyresistance
encounteredmightbeduetoimproperalignmentoftheholesontheFlexarm.Insuch
acase,pleaserepeatstep1c.
f. HoldtherearpartoftheT2Connectorontheothersideofthearm,sothenarrowside
ofitisfacingthearmandalignedwiththescrews(theflaredsidewithconicalholes
shouldbefacingoutward).Insertthescrewsintothispartoftheconnectoraswelland
tightenthemtillbothsidesoftheT2Connectorarestableonthearm(image#4).If
thescrewsaretooshorttoreachtheendoftherearconnector,replacethemwiththe
setoflongerscrews.Ifthescrewsaretoolongandstickoutfromthebackofthe
connector,replacethemwiththesetofshorterscrews.




Image#1Image#2

EyeGrabber Sony MPK Series Instruction Manual














g. HoldthelensholderagainstoneofthesidesoftheT2Connectorattachedtothearm,
sothatthelensholderisfacingoutofthearmandthelensholder’sconnectoris
alignedwiththeT2Connector.MakesurethatyouattachtheEyeGrabberontheT2
Connectorthatfacesoutwardfromthehousing,soyouwillhavemorespacetomount
thelensontheEyeGrabber.SlidethelensholderontheT2Connectorandtightenthe
screwonthelensholderinordertofixitsposition(image#5).Itisimportanttoensure
thatthelensholderconnectorandtheT2Connectorareperfectlyalignedpriorto
tighteningthescrew,orelsethelensholdercannotbestabilizedonthearm.
h. Installthesnapcordoftheaccessorylensonthearm.Ifyouhadthesnapcord
attachedtothehousingbefore,removeitandinstallitonthearminstead,sothe
accessorylenscanbesecuredwhenmountedbothonthehousinglensportandthe
EyeGrabber.
i. Mountthearm,withtheEyeGrabberinstalled,onyourhousingtrayorhandle.














Image#3Image#4
Image#5

EyeGrabber Sony MPK Series Instruction Manual


2. InstallingandRemovingLensAccessoriesfromtheEyeGrabber
a. InstallingandremovinglensaccessoriesfromtheEyeGrabberduringthediveisthe
sameaswheninstallingandremovingfromthehousinglensport(image#6).
HoldthelensaccessoryinfrontoftheEyeGrabbersothatthe“TOP”markingprinted
onthelensconfigurationispointedoppositetheEyeGrabberscrew.Thiswillmakeit
easiertoremovethelensaccessoryfromtheEyeGrabberlateron.Toinstallthe
accessorylens,pushitagainsttheEyeGrabberstartingfromthebottomand
proceedingwiththetop.Makesurethattheaccessorylensisproperlymountedon
theEyeGrabberbygentlytryingtopullitout.Ifproperlyinstalled,thelensshouldnot
easilycomeofftheEyeGrabber.
b. Itisrecommendednottodetachthesecurelinefromtheaccessorylensduringthe
dive,whetherifmountedonthearmoronthehousinglensport.
c. InordertoremovetheaccessorylensfromtheEyeGrabber,gentlypushitoff,starting
fromthetopandproceedingwiththebottom.
d. Afterthedive,detachthelensaccessoryfromtheEyeGrabberandrinseall
componentsinfreshwater.Drywithasoftcleanclothandstoresafely.

www.fantasea.com/contactForfurtherinformation,pleasecontactusat
comwww.fantasea.
orvisitourwebsite
Image#6
