Fantasea FP-5000 User manual

Manual for the FP-5000 Housing
For Nikon Coolpix P5000 & P5100 Digital Cameras

2
TABLE OF CONTENTS
TABLE OF CONTENTS .................................................................................................................................2
GENERAL INFORMATION..........................................................................................................................3
THE FANTASEA FP-5000 HOUSING ..................................................................................................................3
FANTASEA FP-5000 USES................................................................................................................................3
GENERAL CAMERA DESCRIPTION..................................................................................................................11
USING THE FANTASEA FP-5000 HOUSING...........................................................................................13
OPENING THE HOUSING................................................................................................................................13
INSERTING CAMERA.......................................................................................................................................13
CHECKING THE O-RING .................................................................................................................................14
CLOSING THE HOUSING..................................................................................................................................14
VIEWING THE SUBJECT...........................................................................................................................16
TAKING THE PICTURE ....................................................................................................................................16
CHOOSING IMAGE FILES ................................................................................................................................16
BATTERY LIFE.............................................................................................................................................17
USING THE FLASH......................................................................................................................................18
ACCESSORY SLAVE FLASH.............................................................................................................................18
LENS ACCESSORIES .......................................................................................................................................19
FANTASEA COOLPIX ACCESSORY SYSTEMS AND SETS ..................................................................................19
SHOOTING TECHNIQUES.........................................................................................................................20
EXPOSURE MODES (PRE-SET BEFORE CAMERA INSERTION) ...........................................................................20
ZOOM CONTROL ............................................................................................................................................20
MACRO FOCUS...............................................................................................................................................20
QUICK REVIEW ..............................................................................................................................................20
CAMERA STANDBY MODE .............................................................................................................................21
CARE & MAINTENANCE...........................................................................................................................22

3
GENERAL INFORMATION
THE FANTASEA FP-5000 HOUSING
Fantasea has specially designed the FP-5000 housing for the Nikon Coolpix P5000 and P5100
cameras. This housing is ideal for outdoor and underwater photographers, who enjoy the
camera’s automatic exposure features for capturing fast action pictures easily, and manual
exposure features for capturing the widest variety of creative superior underwater images. The
FP-5000 housing insures easy handling and accurate access to camera functions through the
critical placement of push-button controls and a compact design.
The FP-5000 housing provides all control functions: On/Off, Shutter Release, Zoom In/Out,
Mode Dial, Command Dial, Function, Monitor, Playback, Menu, Delete, Timer, Macro, Flash,
Exposure Compensation, OK control, ISO, White Balance and has a built in Flash Diffuser and
an anti-glare hood over the LCD screen.
FANTASEA FP-5000 USES
The Fantasea FP-5000 housing is designed as an underwater/outdoor camera housing. It features
double O-ring on all controls, and has a working depth of 200 feet/60 meters. Underwater
photographers can dive or snorkel and capture all the excitement of this fascinating world, while
outdoor photographers also have the option of capturing the action of such activities as white
water and paddle sports, swimming, sailing and boating, surfing, fishing and hunting,
backpacking and camping. The Fantasea FP-5000 will protect the Coolpix P5000 and P5100
cameras from water, sand, dust, and other damaging elements.

4
Front Side of Housing
Numbered description below refers to corresponding numbers on above graphic.
1. Removable Flash Diffuser:
The Flash Diffuser is used to diffuse the internal flash's intensity. See the section on "Accessory Slave
Flash" for additional information.
2.Lens Port:
Refer to the section "Inserting Camera" for useful information.
3. Buckles to Secure Housing:
Refer to the section "Using the Fantasea FP-5000 Housing" on how to open and close the camera
housing.
3. Stainless Steel
Buckles
1. Removable
Flash Diffuser
2. Lens Port with
46mm thread ring

5
Top Side of Housing
Numbered description below refers to corresponding numbers on above graphic.
4. Mode Dial:
To select a mode, align the mode icon with the mark next to the mode dial. The P5000 and P5100
cameras offer the following modes:
Auto - A simple ―point-and-shoot‖ mode recommended for first time users of digital cameras.
Anti Shake - Prevent or reduce blur using vibration reduction and the Best Shot Selector (BSS).
High Sensitivity - Choose this mode to reduce blur when subject is poorly lit.
P, S, A, M - Choose this mode for greater control over shutter speed and aperture.
Setup - Display the setup menu, where you can perform such tasks as setting the camera clock and
adjusting monitor brightness.
Scene - Make voice recordings or choose from 16 ―scenes‖ suited to different subjects or shooting
conditions and let the camera do the rest.
6. Power On/Off
4. Mode Dial
5. Zoom In/Out and
Shutter Release

6
5. Zoom In/Out and Shutter Release:
Push this button to activate the shutter release control, and swivel it to the sides in order to activate
the zoom control.
Zoom In/Out
Use the Zoom button to activate optical zoom. Swivel to "W" (Wide) to zoom out, increasing the
area visible in the frame, or to "T" (Tele) to zoom in, so that the subject fills a larger area of the
frame. When the camera is zoomed to the maximum magnification (3.5x), holding "T" triggers
digital zoom. The subject is magnified up to x4, for a total magnification of x14. A monitor
indicator shows the current zoom ratio.
Swivel to "W" in full-frame playback to display pictures in "contact sheets" of four or nine
thumbnail images.
Swivel to "T" to zoom-in on still images displayed in full-frame playback.
When entering a menu, swivel to "T" to view a description of the currently selected menu option.
To return to the original menu, swivel the zoom control to ―T‖ again.
Shutter Release
This is a two-stage shutter-release button. First lightly press the shutter-release button halfway,
stopping when you feel minimal resistance. Once the camera has focused, press the shutter-
release button the rest of the way down to release the shutter and take the picture. Please note that
moving the camera while pressing the shutter-release button may result in blurred pictures.
6.Power On/Off button:
To turn on the camera, press the power switch. The power-on lamp (green) will turn on for a moment,
the monitor will turn on, and the lens will extend.
To turn off the camera, press the power switch again.

7
Back Side of Housing Buttons
Numbered description below refers to corresponding numbers on above graphic.
7. Command Dial:
In full-frame playback, rotate command dial right to view pictures in order recorded. Rotate
command dial left to view pictures in reverse order.
In scene mode, press the function button and rotate command dial until desired scene is displayed in
monitor.
In thumbnail playback, rotate command dial to page through pictures.
In playback zoom, rotate command dial to zoom pictures in or out.
In movie mode, press the function button and rotate command dial until desired setting is displayed in
monitor.
In movie playback, rotate the command dial to fast forward or rewind.
7. Command Dial
13. Function
8. Flash Mode
9. Exposure
Compensation
11. Self-Timer
10. Focus
14. Monitor
12. OK button
Multi-
Selector
Buttons
15. Playback
16. Menu
17. Delete

8
Choose the function performed by function button in P, A, S and M modes. In these modes, press
down the function button to display the chosen function options, rotate command dial to highlight
desired option and release function button.
In S mode, rotate command dial to choose the desired shutter speed.
In A mode, rotate command dial to choose the desired aperture.
In P mode, rotate command dial to choose different combinations of shutter speed and aperture.
In M mode, select aperture or shutter speed by pressing the multi selector to right. Rotate command
dial to choose the desired aperture or shutter speed.
Multi-Selector buttons (8-12)
8. Flash Mode:
In order to select a flash mode:
Press the Flash Mode button.
Use the multi-selector up/down arrows to choose the desired flash mode (Auto, Auto with Red-Eye
Reduction, Off, Fill Flash, Rear-Curtain Sync and Slow Sync), and press "OK".
9. Exposure Compensation:
In modes other than M, exposure compensation is used to alter exposure from the value suggested by the
camera to make pictures brighter or darker.
Press the Exposure Compensation button.
Press the multi-selector up/down arrows to adjust exposure, and press "OK".
10. Focus:
Choose a focus mode according to the subject and composition (Auto focus, Infinity, Focusing limit and
Macro close-up).
Press the Focus button.
Press the multi-selector up/down arrows to highlight mode, and press ―OK‖.

9
11. Self-Timer:
The camera is equipped with a ten second timer and a three second timer for self-portraits and to reduce
blur. When using the self-timer, mount the camera on a tripod or rest it on a flat and stable surface.
Press the Self-Timer button.
Press the multi-selector up/down arrows to choose mode, and press "OK".
Press the shutter-release button halfway to focus, and then all the way down.
12. OK Button:
Push this button to confirm a selection.
13. Function:
Choose the function performed by function button in P, A, S and M modes (ISO, Image quality,
Image size, white balance and vibration reduction) through the camera's menu.
In these manual modes, press down the function button to display the chosen function options, rotate
command dial to highlight desired option and release function button.
14. Monitor:
Press the Monitor button to hide or display indicators in the monitor.
15. Playback:
Press the Playback button to enter full-frame playback. Multi-selector buttons may be used to view
pictures.
Press Playback button again or press the shutter-release button to return to shooting mode.
16. Menu:
When Menu button is pressed, the following menus are displayed according to the mode that has been
selected:
Scene mode - displays the scene menu.
Movie mode - displays the movie menu.
P, S, A, M modes - displays the shooting menu.
Playback mode - displays the playback menu.

10
17. Delete:
Press Delete to delete the picture currently displayed in the monitor in full-frame playback. Press the
multi-selector up/down arrows to choose "Yes", and press "OK".
In Shooting Mode, press this button to delete the last picture taken. When the confirmation dialog
shown at right is displayed, press the multi-selector up/down arrows to choose "Yes", and press
"OK".
Press Delete to delete the movie currently displayed in the monitor in full-frame playback. Press the
multi-selector up/down arrows to choose "Yes", and press "OK".
Note!
It is strongly recommended that you familiarize yourself with all the
controls topside before using these controls while diving.

11
GENERAL CAMERA DESCRIPTION
With the release of the COOLPIX P5000 and P5100, Nikon offers a camera with a
range of features that enable the user to explore creativity behind photography.
The latest addition to their COOLPIX line of cameras is a lightweight solid model
with an impressive imaging performance of 10.0 megapixels on the P5000 and
12.1 megapixels on the P5100, which enables the photographer to capture images
with incredible detail, even after enlargement. Picture quality is further guaranteed
by Vibration Reduction (VR). This system compensates for the blurring that can be
caused by camera shake or lower light, which are common factors underwater. A
light sensitivity range up to ISO 3200 also enables the COOLPIX P5000 and P5100
to capture quality images of fast moving subjects or poorly lit scenes, another
significant advantage for underwater photographers. The new Mode dial provides
quick access to a selection of 16 different scene-optimized modes, seven movie
modes, Anti-Shake mode and High-Sensitivity mode. Images can be composed
carefully, and the results appreciated immediately, on the high-quality 2.5 inch
LCD screen. The COOLPIX P5000 and P5100 come equipped with a Zoom-Nikkor
lens, which delivers excellent results when shooting anything from portrait to
panorama.

12
NIKON COOLPIX P5000 and P5100 FEATURE HIGHLIGHTS
Superb Image Quality
Excellent imaging quality is a priority for the COOLPIX P5000 and P5100,
from the 10.0 effective megapixels on the P5000 and 12.1 effective
megapixels on the P5100, of outstanding resolution produced by their
1/1.8-inch RGB CCD and improved high-performance image-processing
engine, to its powerful 3.5x Zoom-Nikkor lens and lens shift VR.
VR Image Stabilization
Proven optical lens shift VR (Vibration Reduction) technology originally
developed for interchangeable lenses used in Nikon SLR camera systems.
Nikon’s exclusive VR system provides the ability to shoot at shutter
speeds as much as three steps slower without blurring the image, while
also providing a smoother image on the LCD monitor.
Anti Shake Mode
A turn of the Mode dial activates High ISO and BSS (Best Shot Selector)
in addition to VR (Vibration Reduction), automatically sets the optimal
ISO for steady results, and selects the sharpest image from up to ten
sequential shots.
Diverse Selection of Practical Shooting Modes
The new Mode dial gives access to four exposure modes (A, S, M and P)
that appeal to photographers at all levels for greater control over camera
operation.
Three Image Innovations
Face-priority AF can automatically detect then achieve accurate focus
on people’s faces, no matter where they are in the frame. In-Camera
Red-Eye Fix can automatically detect the annoying red-eye effect
sometimes caused by flash and compensate for it in-camera. The D-
Lighting function can rescue underexposed images or shots with too
much backlight by creating a copy of the image but with light and detail
added where necessary and well-exposed areas left exactly as they were.

13
USING THE FANTASEA FP-5000 HOUSING
OPENING THE HOUSING
1. Release all four latches at the same time, and lift off back half to open housing.
INSERTING CAMERA
Since the Fantasea FP-5000 is specifically designed for the Coolpix P5000 and P5100 digital cameras,
inserting the camera into the housing is quite simple.
1. Mount the camera on the removable tray, using the tripod screw. Please note that the two small
plastic supports face up and go to the front of the camera. The camera needs to be resting up
against these supports to avoid any rotation once inside the housing.
2. Slide the tray and camera into the housing tray slot. Make sure it is completely inserted.
3. Make sure the camera lens is centered in the rounded port area and that the lens does not distort the
round black rubber seat. The housing is designed to have the camera fit in place perfectly, but if you
are not careful, it is possible to put it in at an improper angle and hence it will be impossible to get a
good seal or easy closure of the housing.
4. After camera insertion, be sure that the extended camera lens does not catch or bend the
black rubber seat on the inside of the lens port. It is vital that the lens does not disturb this
rubber seat.
Notes:
1. It is recommended to make some camera settings prior to
inserting camera into the housing. Please refer to the Coolpix
Owner's Manual for menu options and personal preferences.
2. Take a few test shots: it is recommended to turn the camera "on"
and program to ―Flash Always‖ mode before inserting into
housing and then take test shots to make sure all systems are
working.
Underwater photographers will probably want to set the flash mode to the flash always setting to insure they
always have a flash with every exposure. It is also wise to set the focus mode to allow the lens to focus in the
macro range for capturing great images of the tiny and exotic subjects that you can find underwater.

14
CHECKING THE O-RING
Prior to each closure of the housing the O-ring should be visually inspected. If there is any debris present,
including dirt, sand, dust, hair, grease or other matter, it must be cleaned to insure a proper watertight seal.
Cleaning the O-ring is a simple matter of wiping it with a damp, soft cloth to remove the foreign matter. Be
careful the cloth you use does not leave any of its own material behind as this can also affect the
effectiveness of the seal. When replacing the O-ring, place it back into the groove starting at the same corner
and gently put it in by pressing it into the groove all around the housing until it is all sitting in the groove and
no part of it is sticking up or out of the groove. You can then apply a slight layer of silicone if you have not
done this yet. Be sure it is completely seated in the channel for a proper seal.
Note
Lubrication of an O-ring does not improve the seal. It only reduces the
amount of friction on the O-ring when it is being moved into sealing
position. The amount of lubrication required on the O-ring is only enough
to allow it to slip into place without friction, so it does not twist or
become dislodged. More grease is not better, and could in some cases
have a negative affect if it is applied in large amounts to form a build-up
that could trap any debris or foreign matter.
CLOSING THE HOUSING
1. Place housing back over front and align the complete mating surface of the housing and the O-
ring, forming a proper seal.
2. Position all four latches over latch hooks in ready position.
3. Close all four latches at one time. If it is not possible to close all four latches at the same time,
close the bottom latches first, maintaining pressure on the other side. Then close the two top
latches simultaneously. Test all latches carefully to make sure that they are completely locked into
place and not just pushed down. Try to open them to make sure that they cannot open
accidentally.

15
4. Inspect the O-ring for proper closure. A complete seal can be visually confirmed by the O-ring
around the complete circumference of the housing.
5. Always take the first dive without your camera in the housing just to make sure there is no leakage
from damage to the housing. During the dive—especially at the beginning of descent—take special
care to look at the housing to make sure no bubbles are escaping from it and that no water is entering.
Generally, if there is a problem with the seal, you will discover it in the first seconds of the dive.

16
VIEWING THE SUBJECT
The P5000 and P5100 cameras feature a large 2.5 inch LCD viewing monitor for composing photographs.
The LCD monitor will allow you to see your subject in sharp focus and framed properly. Hold the camera
housing in your outstretched arm at a position that is both comfortable and also allows you to easily see the
LCD monitor, for best compositional options.
TAKING THE PICTURE
Once you have composed your scene or subject in the LCD monitor, depress the shutter release button to take
the picture. A half depress will activate the live viewing ability of the LCD and allow the camera to focus,
once in focus and ready to shoot a green light will appear on the LCD monitor and the camera is ready to
take the picture. Press down the shutter all the way to complete image capture. You may notice a pre-flash
and slight delay in the shutter release. This is to allow the camera to make its final focus and exposure
calculations before taking the picture. With a little practice, you will become used to this and taking pictures
of moving subjects will become easier and natural.
CHOOSING IMAGE FILES
There are several image file options to choose from that offer different resolution and file sizes. This
determination must be made prior to camera insertion from Menu options. Please refer to the Coolpix
instruction manual for details on setting these preferences.

17
BATTERY LIFE
Rechargeable Lithium-ion battery EN-EL5
The P5000 and P5100 cameras make use of a Rechargeable Lithium-ion battery EN-EL5, which is capable of
shooting approximately 250 shots on a single charge.
There are certain things that users can control to help extend battery life. It is recommended to set the camera
to turn the LCD off after 30 sec of non use. This helps to conserve battery power as well as helps to prevent
condensation inside the housing. It can then be automatically turned back on if you depress the shutter
release control half way. Please refer to the Coolpix instruction manual for details on how to make this
adjustment setting. It is always wise to have backup batteries in case you do run out of power. The supplied
battery can be recharged many times and offers an economical and environmentally friendly power source.

18
USING THE FLASH
The Coolpix has a built-in flash, which will illuminate nearby underwater subjects. For subjects that are
farther away, an accessory slave flash is recommended (See Below). A built-in flash diffuser is supplied
which will help achieve a wider and softer light source thereby providing more coverage and less likelihood
of backscatter (the unattractive snowstorm affect of the flash reflecting off the suspended particles in the
water). Further reduction of backscatter can be achieved by using an accessory off-camera slave flash. This
will be discussed in more detail.
The need for artificial light to maximize color reproduction is necessary in nearly all pictures. Therefore it is
strongly recommended that you set the flash mode to Flash Always. This will insure the flash fires on every
exposure regardless of the ambient light conditions (Please refer to the camera's instruction manual for more
details).
Outdoor photographers do not have this same concern. There is no backscatter to be concerned with, and due
to the ability of the flash to travel farther and more effectively in air as compared to water, there is normally
not a need for an accessory flash to provide proper illumination for most subjects.
ACCESSORY SLAVE FLASH
If you use the Coolpix built-in flash as the master, you can trigger a second slave flash to provide more
artificial light when needed. To do this, you must use an accessory flash that has a slave feature built in. The
flash from the Coolpix must be aimed or bounced toward the accessory flash's slave sensor, or other fiber
optic sensor. This will trigger the slave to fire in sync with the master flash.
When using an accessory slave flash with fiber optic cable, it is recommended to black out the internal
camera flash. The internal flash is located near the camera lens and can contribute to backscatter by
illuminating floating particles close to the lens port.
If the sensor of the fiber optic cable is attached to the outside of the housing directly above the internal flash
and taped over with black tape–it will block out the light from the internal flash but transmit the light pulse to
the external slave flash
Note
Be sure to use a slave flash that has the ability to ignore the built-in pre-flash in
digital cameras, and synchronizes with the shutter release.

19
LENS ACCESSORIES
The Fantasea FP-5000 features a 46mm threaded lens port. This thread port is designed to work with some of
the wide-angle and macro adapters that are currently on the market. Fantasea Line offers the following lens
accessories:
FWAL-01 Wide Angle Lens: an accessory Wide Angle Lens which fits over the housing port and can
be installed and removed during the course of the dive.
Red Filter 46 - fits over the housing port and can be installed and removed during the course of the
dive. The filter is mounted on the housing lens port and held in place by screw thread.
For more information on these items, see your local photo dealer or visit our website at www.fantasea.com
FANTASEA COOLPIX ACCESSORY SYSTEMS AND SETS
Fantasea offers a variety of Coolpix (and other housings) sets made up of quality accessory products, which
serve to enhance and improve your underwater images. Products like external flash systems, flexible arms,
trays, filters, wide angle and macro lenses, fiber optic cables and more. Below you can see one sample
system. For more information please refer to our website or to the Fantasea Dealer where you purchased your
housing.
FANTASEA HOUSING
NANO FLASH
LENS CADDY FOR
HOLDING ACCESSORY
LENS PRODUCTS
FLEX ARM
NANO FOCUS LIGHT
FIBER OPTIC
CABLE
XLSTAY SLOT TRAY
MACRO /WIDE ANGLE
ACCESSORY LENS

20
SHOOTING TECHNIQUES
EXPOSURE MODES (PRE-SET BEFORE CAMERA INSERTION)
There are several exposure modes [16 different Scene modes] for photographers to choose from, depending
on the situation. Underwater it is recommended that you shoot in the Manual mode on the camera in which
you can manually control ambient light and artificial light according to the lighting conditions. You can also
select different light meters to use, based on the situation and your personal preferences. Additionally, you
can choose the Manual White Balance setting for color temperature control, or experiment with some of the
other modes to see which will work best underwater. These settings do not have to be made ahead of any
dive, as they can be accessed through the housing controls while underwater.
Please reference the Coolpix instruction manual for details on how to set these camera options, and under
what conditions the different choices would be used.
ZOOM CONTROL
Zoom in for telephoto photos and larger subject size. Zoom out for wide-angle scenes. It is generally not
recommended to use the zoom underwater as it is preferable to get physically closer to your subject. The
digital zoom has no value at all.
MACRO FOCUS
For capturing the tiny and exotic subjects that require close focus. Macro focus is possible when the lens is in
the wide-angle position.
QUICK REVIEW
Immediate review of most recent image is available that will confirm that you captured the shot you want.
However, if you want to scroll through your images, or delete images from the memory card, this should be
done when you are topside and the camera is out of the housing.
