Installation (cont)...
2.5. Mount the base in the desired position using the fasteners supplied.
2.6. Replace the fan body in-between the spigots and tighten the two
retaining clamps.
Fan Maintenance
3.1. Inspect the fan at least once every 12 months to ensure that the motor
and fan blades are clean. Any build up of dust should be removed
using a non-abrasive cleaner.
3.2. All fastenings should be checked for tightness.
3.3. Bearings are of the ‘sealed for life’ type and will not need a detailed
inspection.
Wiring Diagram
Please note that the ProVent with run-on timer (models RIL-150T and RIL-200T is single speed only,
is not suitable for speed control and does not come with a plug and lead.
Part No: INST-RIL-T 11/12
RIL-150T
RIL-200T
INSTALLATION & MAINTENANCE
INSTRUCTIONS
In-Line
Duct Mounted Fan
Specification
Dimensions
Model A B C D E F G H J
Weight
kg
RIL-150T 112 60 100 80 295 147 200 225 236 2.7
RIL-200T 124 94 108.5 100 302 198 217 235 265 4.9
Electrical Data
Model
Speed
r/min FLC Amps Input W
RIL-150T 2500 0.22 50
RIL-200T 2500 0.50 120
General
1.1. It is important that these Installation and Maintenance Instructions
are fully adhered to.
1.2. All electrical installations must be carried out by suitably qualified
and competent personnel in accordance with all statutory
requirements.
1.3. The fan is designed for use in an ambient temperature of up to 40°C.
It is not suitable for corrosive or explosive atmospheres.
1.4. The installer should provide easy access to the fan to facilitate future
maintenance, and ensure that the fan is adequately supported.
1.5 This product is not intended for use by persons (including children)
with reduced physical sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the product by a person responsible
for their safety. Children should be supervised to ensure that they do
not play with the product.
1.6 Precautions must be taken to avoid back-flow of gases into the room
from the open flue of gas or other fuel burning appliances.
1.7 A minimum of one (1) metre of duct is to be fitted to the fan inlet and
discharge spigots.
1.8 Fan Run-on is from 1 to 30 minutes. Adjust via the trim-pot fitted in
the junction box.
Installation
Warning: The fan must be isolated from the power supply during
installation and maintenance.
2.1. Upon receipt, the fan should be inspected for any damage.
2.2. Check the details on the rating plate to ensure that the correct power
supply is available
2.3. Means for electrical disconnection must be incorporated in the wiring
installation in accordance with the relevant wiring regulations.
2.4. Remove the fan body from the spigots that are attached to the base by
releasing the two retaining clamps (RIL-150T, see diagram), or the
two clamp screws (RIL-200T).
Page 2 of 4 Page 3 of 4
