FMT41
45 mm Masking Paper Dispenser
Product Instrucon Manual
FMT4100_Product Instructions 20/11/2013 16:17 Page 1

FMT41
Instrucon Manual
Fast Mover Tools
T: 1582 661993 F: 1582 6671 E: [e-mail]
W: www.fastmovertoolsuk.com
Part Description Qty Part Description Qty
1 Seat Board 15Cutting Blade 1
1A M6 x40 Set Screw 86Tape heel Assembly 2
1B M6 Nut 10 6A M6 x 120 Bolt 2
1C M6 asher 10 6B ing Nut 4
2 Frame 2 6C Tape heel Hub 2
3 Connection Bar 1 6D M6 x 17 asher 4
4 Paper Roller Assembly 1
4A Paper Roller Fixer 4
4B M29 asher 4
4C Spring 2
4D M10 x 40 Bolt 1
4E M10 Knob 1
4F Spring 1
Introduction
The FMT4100 is designed to take an 18”/450mm Roll of Masking Paper. It also features a built in light duty hop
up platform.
General Safety Instructions
1 Use this tool on a smooth, level, non-slip surface and always keep your working environment clean
and tidy.
2 Do not use this tool whilst under the influence of drugs, alcohol and intoxicating medication.
3 Do not use this tool for any other purpose other than that for which it is intended. This tool is not
intended as a tethering point.
4 Do not allow children and other unauthorised persons to use this equipment.
5 This tool has sharp edges. It is strongly recommended that hand protection is worn when using this
tool.
6 Always be aware of those around you and keep in mind that your actions have a direct effect on your
colleagues and visitors.
7 The built in hop up is intended for short term use only, if the job you are carrying out requires long
periods of working at height a purpose built platform will be required.
Parts Diagram
