Fast Mover FMT4200 User manual

T: 44 (0)1582 661993 F: 44 (0)1582 667100 E: [e-mail]
FMT4200
450mm Twin Masking Paper Dispenser
Product Instrucon Manual
Scan here or go to
fastmovertoolsuk.com/FMT4200
FMT4200_Product Instructions 16/04/2014 11:56 Page 1

FMT4200
Instrucon Manual
Fast Mover Tools Ltd
T: 01582 661993 F: 01582 667100 E: sales fastmovertoolsuk.com
W: www.fastmovertoolsuk.com
Ref. Code Description
1 FMT4200/1 Frame
2 FMT4200/2 Tray
3 FMT4200/3 Bottom Paper Cutter
4 FMT4200/4 Top Papper Cutter
5 FMT4200/5 Paper Retainer
6 FMT4200/6 Paper Washer
7 FMT4200/7 Screw
8 FMT4200/8 Knob
9 FMT4200/9 Paper Bar
10 FMT4200/10 Star Lock Nut
11 FMT4200/11 Washer
12 FMT4200/12 Bolt
13 FMT4200/13 Axle
14 FMT4200/14 Wheel
16 FMT4200/16 Foot
17 FMT4200/17 Cutter Spring
20 FMT4200/20 Tape Reel
21 FMT4200/21 Hub
22 FMT4200/22 Bolt
23 FMT4200/23 Top Tray
24 FMT4200/24 Handle Grip
25 FMT4200/25 Hanger
27 FMT4200/27 Retaining Spring
28 FMT4200/28 Wing Nut
30 FMT4200/30 Bolt
31 FMT4200/31 Washer
Introduction
The FMT4200 is designed to take two 18”/450mm Rolls of Masking Paper. It also features a two tool shelves.
General Safety Instructions
1se this tool on a smooth, level, non-slip surface and always keep your working environment clean
and tidy.
2 Do not use this tool whilst under the influence of drugs, alcohol and intoxicating medication.
3 Do not use this tool for any other purpose other than that for which it is intended. This tool is not
intended as a tethering point.
4 Do not allow children and other unauthorised persons to use this equipment.
5 This tool has sharp edges. It is strongly recommended that hand protection is worn when using this
tool.
6 Always be aware of those around you and keep in mind that your actions have a direct effect on your
colleagues and visitors.
Parts Diagram
Assembly Detail 1 Assembly Detail 2
FMT4200_Product Instructions 16/04/2014 11:56 Page 2
