SMA 800-SS40DX User manual

Page 1
Model: 800-SS40DX
(5301785)
(40 Gallon Lawn & Garden
Spot Sprayer)
Jonesboro, AR 72401
Phone: [phone] Fax: [phone]
5194926 (02/19)
OWNER’S MANUAL
Assembly Instructions
Your sprayer has been mostly assembled at the factory. One
requirement will be for you to hook up your battery leads to a
fully charged 12 Volt battery.
Remove the handgun clips from the parts bag and place them
onto the tank as shown.
CAUTION: When fully filled with water, this sprayer will
weight approximately 365 Lbs. Always check the vehicle
load rating before using this sprayer. Do not exceed the
recommended rating.
Technical Specifications
40 Gal. Corrosion-Resistant Polyethylene Tank
12 Volt Diaphragm Pump, 4.5 GPM - 60 PSI
25 Ft. Handgun Hose (3/8” I.D.)
26 Ft. max. vertical throw, 35 Ft. max. horizontal throw
General Information
Thank you for purchasing this product. The purpose of this
manual is to assist you in operating and maintaining your lawn
& garden Spot sprayer.
Retain a copy of your receipt for your
unit, as it will be required to validate
any warranty service.
Warranted against manufacturer or
workmanship defects from date of
purchase with copy of receipt:
Homeowner Usage: Sprayer-One Year and Pump-Two Years.
Commercial Usage: Sprayer and Pump-90 Days.
If you should have a question or experience a problem with
your SMA Product: call the Toll free number above.
Our technical support representatives will be happy to
help you. In most cases a customer service rep. can
resolve the problem over the phone.
To obtain prompt, efficient service, always remember to give
the following information....
• Correct Part Description and/or part number
• Model number and Serial Number
Part descriptions and numbers can be obtained from the
illustrated parts list section(s) of this manual.
BEFORE RETURNING THIS PRODUCT
FOR ANY REASON, PLEASE CALL
1-870-935-3291

Page 2
(Pistol-Grip) Handgun #5273959
28”
IMPORTANT: Remove tank lid and be sure the tank is
clean and free of any foreign material. Rinse tank out
of any tank residue before filling with water to test.
Testing the Sprayer
NOTE:
It is important that you test your sprayer for leakage and proper spray
patterns with plain water before chemical application is attempted.
This will also give you the opportunity to familiarize yourself with the
operation of the sprayer, without the possibility of losing any
expensive chemicals.
Fill the tank about 1/2 full of plain water for testing. Conditions of
weather and terrain must be considered when setting the sprayer. Do
not spray on windy days. Protective clothing must be worn in some
cases
Be sure to read the chemical label(s) before application!
Operation
The pumping system draws solution from the tank, through the
strainer and to the pump. The pump forces the solution under
pressure to the handgun or boom nozzles.
Connect the lead wire to a fully charged 12 volt battery. You may use
either a stand-alone battery or the battery on your towing vehicle.
Connect to the positive (red) terminal first, then connect to the
negative (black) terminal. Then connect the end of the lead wire to
the end of the pump. When disconnecting, disconnect the end of the
pump wire from the lead wire, then disconnect the negative (black)
connection and finally the positive (red) connection. The lead wire
has an On/Off switch to activate the pump. “-” is on and “O” is off.
Fill the tank part way with water and then add the desired amount of
chemical to be sprayed. Finish filling tank to proper level. Turn the
pump on and by depressing the “-” side of the rocker switch.
NOTE: The pump is equipped with a pressure switch that is pre-set
at the factory to shut the pump off when all discharges are closed.
The pump will turn back on when you activate the handgun by
squeezing the handle lever.
 Rotating the adjustable nozzle tip on the handgun will change
the tip pattern from a straight stream to a cone pattern (fine
mist)
Maintenance During/After Spraying
Periodically check the strainer and clean the screen on your intake
line.
Proper care and maintenance will prolong the life of your sprayer.
After use, drain the tank and store or dispose of chemical properly.
Fill the sprayer half way with clean water. Start the pump and allow
the water to pump through the entire plumbing system and nozzles.
Drain and then refill half full, add the recommended amount of a
good quality tank cleaner. (If no tank cleaner is available, you may
substitute dish soap for this step, about 1-2 oz. per gallon). Turn
pump on and circulate through system for 15 minutes and then spray
out through boom and handgun nozzles. Refill sprayer half way with
clean water and repeat. Follow the chemical manufacturer’s disposal
instructions of all wash or rinsing water.
If boom or handgun nozzles need cleaning, remove them from the
sprayer and soak in warm soapy water. Clean with a soft bristled
brush or toothpick if necessary. Never use a metal object. Even the
slightest damage can change the flow rate and spray distribution.
Water rinse and dry the tips before storing.
WARNING: Some chemicals will damage the pump valves if
allowed to soak untreated for a length of time! ALWAYS flush
the pump as instructed after each use. DO NOT allow chemicals
to sit in the pump for extended times of idleness. Follow the
chemical manufacturer’s instructions on disposal of all waste
water from the sprayer.
Winter Storage
Prepare the sprayer for end-of-season storage by running RV
antifreeze through the system. This will keep internal parts lubricated,
protect against corrosion and keep the unit from freezing. Note: RV
antifreeze is non-toxic and biodegradable and generally safer for the
environment than automotive antifreeze.
Before storing your sprayer for winter or long term storage,
thoroughly clean and drain it as much as possible. Then pour enough
pink RV antifreeze into the tank so that when the pump is turned on
you can pump the antifreeze throughout the entire plumbing system,
including the bypass, if equipped. Make sure to operate the handgun
until you see pink fluid spraying from the nozzle. Leave any
remaining antifreeze in the tank. Before your next usage, rinse the
antifreeze from the sprayer with clean water.
It is nearly impossible to drain all of the water from the sprayer and
any trapped water can freeze in cold weather and damage parts of
the sprayer. Pumping the antifreeze through the system will displace
the water and help prevent this damage.
Removing from storage: drain the antifreeze. Fill the tank with fresh
water and run through the system. Dispose of antifreeze and flush
water properly.

Page 3
DO
 Clean and rinse your pump after each use with a Tank
Neutralizer
 Winterize your pump or sprayer by rinsing, draining and
running RV Antifreeze through it before storing for the winter.
 Use clean water for your spray mixture
 Store inside a building when not in use.
DON’T
 Use to pump bleach.
 Use to pump petroleum products such as diesel fuel,
gasoline or kerosene
 Leave your pump sit with spray mixture in it for extended
periods
 Use dirty or unfiltered water for spraying
Troubleshooting the Pump:
Motor does not run:
 Check for loose wiring connection(s).
 Make sure the 'ON/OFF' switch in the lead wire assembly
is in the 'ON' position. "I" is the 'ON' position and 'O' is
the 'OFF' position.
 Check for defective pressure switch. Make sure you are
connected to a good 12 volt power source. Make sure
any on/off switches are in the 'on' position. Remove the
cap to the pressure switch. Pull both red wires off of their
terminals, and touch the two ends together. If your pump
runs when you do this, your pressure switch will need to
be replaced.
 Check the fuse.
 Check for low voltage at the power supply.
Pump does not prime:
 Check for air leaks in supply line.
 Check for debris in the check valve assembly.
 Check for defective check valve.
 Check for clogged strainer/filter.
 Check for cracks in the pump housing.
 Check for empty product supply.
Low Pressure/Low Flow:
 Check for leaks in the discharge line.
 Check for restriction in the discharge line.
 Check for debris in nozzle orifice.
 Check for clogged strainer.
 Check for proper voltage—try another 12-volt battery.
Pulsating flow (surging):
 Low flow may cause pump to surge.
 Spray wand is adjusted for a small or fine spray
pattern.
 Slightly open bypass (if applicable) to overcome.
 If needed, pressure switch may need to be adjusted—
adjust a quarter turn at a time clockwise until surging
stops.
 Check for defective pressure switch.
 Check for leaks in the discharge line.
 Check for restriction in the discharge line.
 Check for debris in nozzle orifice.
 Discharge hose may be too long.
 Check for clogged strainer.
Motor continues to run after discharge is shut off:
 Check for empty product supply.
 Check for open bypass valve. (if equipped)
 Check for low voltage.
 Check for leak in discharge line.
 Check for defective pressure switch.
 System has leaks.
Fuse blows:
 Excessive voltage.
 Improper adjustment of pressure switch.
 Damaged or defective wiring harness.
 Half-moon & counterweight are sticking.
 Defective pressure switch.
Replacement Pump: 5151088
Includes:
1/2” MNPT Port Kit Fitting #5168832
1/2” Hose Barb Port Kit Fitting #5168833
Pump Model: 5281372
4.5 GPM, 60 PSI
Available Replacement Parts

Page 4
Try another 12-Volt battery
Quarter turn at a time clockwise until surging stops
Defective pressure switch
Troubleshooting
Bypass is not completely closed
System has leaks
Check for worn or dirty check valve
Excessive voltage
Improper adjustment of pressure switch
Damaged or defective wiring harness
Check for proper voltage
Check for worn or dirty check valve
Low flow may cause pump to surge
Spray wand is adjusted for a small or fine spray pattern
Slightly open bypass (if applicable) to overcome
If needed, pressure switch may need to be adjusted
Pump will not run:
Low Pressure/Low Flow:
Pump surges:
Pump continues to run:
Fuse blows:
Check for loose wiring
Make sure the ON/OFF switch is on
Check the fuse
Check for defective pressure switch
Check for a clogged strainer
Cleaning the Check Valve:
If you’re experiencing little to no pressure or the pump is not priming and you’ve checked your filter
screen and it’s clean, and you’ve gone through the other trouble shooting tips, you may need to
clean the check valve.
 Remove the head of the pump, which is held on by 7 screws.
 The first piece inside the head of the pump is called a check valve, it’s the part responsible for building up pressure
and pumping water/solution through the lines.
 Clean the check valve under hot, soapy water (such as a good grade dish soap).
 Give it a very light scrubbing with something like an old toothbrush, something with soft bristles.
 Then let it soak for about an hour or so in the hot soapy solution and replace in the pump and reassemble the pump.
Most times this will restore most, if not all of the prime of a pump.
If you’re still having issues with pressure after this step, it would be recommended to replace this part.
Checking the Pressure Switch:
If your motor is not running and you’ve checked the following: for loose wiring connections, fuse, the switch on
the lead wire was “ON” and made sure you were connected to a fully charged battery and everything is fine, but
the motor won’t run, then it’s time to check to see if the pressure switch is bad.
 Remove the cover off the 1” square box (pressure switch) on the head of the pump, the cover is held on by
one phillips-head screw. This will expose the two red wires.
 With the pump connected to a good 12 volt power source and everything on.
 Slip the two red wires off the terminals and touch them together.
If the motor runs, it means the pressure switch is bad and needs to be replaced.
If it still doesn’t run, try bypassing the switch in the lead wire or using another lead wire. Even if a tester shows
power to the pressure switch, it still could be the switch in the wire that is causing the problem. If still not
responsive, use a voltmeter or electrical tester to make sure you are getting power to the head of the pump, as
it could possibly be something in one of the wires or even the lead wire assembly may need to be replaced.
Warning: It is NOT recommended to run the pump this way, as the pump will continue to run and
not shut off.
This could result in blown hoses when all discharges are closed.
Also, this could result in premature failure of the pump completely.

Page 5
Exploded View/Parts List:
800-SS40DX (5302150)
Manifold
Detail

Page 6
LIMITED WARRANTY FOR NEW FIMCO, IND. EQUIPMENT
WHO MAY USE THIS LIMITED WARRANTY. This limited warranty (the “Limited Warranty”) is provided by Fimco, Ind. to the original purchaser
(“you”) of the Equipment (as dened below) from Fimco, Ind. or one of Fimco, Ind.’s authorized dealers. This Limited Warranty does not apply to
any subsequent owner or other transferee of the Equipment. THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO
HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.
WHAT THIS LIMITED WARRANTY COVERS AND FOR HOW LONG. Fimco, Ind. warrants that any new Equipment will be free from defects in
material and workmanship for a period of one (1) year for sprayer and two (2) years for High-Flo High Performance pump (homeowner), 90 days
for sprayer and pump (commercial user), aer delivery of the Equipment to you (the “Warranty Period”). The Warranty Period is not extended if
Fimco, Ind. repairs or replaces the Equipment.
WHAT IS NOT COVERED BY THIS LIMITED WARRANTY. This Limited Warranty does not apply to: (1) used Equipment; (2) any Equipment that has
been altered, changed, repaired or treated since its delivery to you, other than by Fimco, Ind. or its authorized dealers; (3) damage or deprecia-
on due to normal wear and tear; (4) defects or damage due to failure to follow Fimco, Ind.’s operator’s manual, specicaons or other wrien
instrucons, or improper storage, operaon, maintenance, applicaon or installaon of parts; (5) defects or damage due to misuse, accident or
neglect, “acts of God” or other events beyond Fimco, Ind.’s reasonable control; (6) accessories, aachments, tools or parts that were not manu-
factured by Fimco, Ind., whether or not sold or operated with the Equipment; or (7) rubber parts, such as res, hoses and grommets.
HOW TO OBTAIN WARRANTY SERVICE. To obtain warranty service under this Limited Warranty, you must (1) provide wrien noce to Fimco,
Ind. of the defect during the Warranty Period and within thirty (30) days aer the defect becomes apparent or the repair becomes necessary, at
the following address: Fimco, Ind., 1000 Fimco Lane, North Sioux City, SD 57049; and (2) make the Equipment available to Fimco, Ind. or an
authorized dealer within a reasonable period of me. For more informaon about this Limited Warranty, please call: 800-831-0027.
WHAT REMEDIES ARE AVAILABLE UNDER THIS LIMITED WARRANTY. If the condions set forth above are fullled and the Equipment or any part
thereof is found to be defecve, Fimco, Ind. shall, at its own cost, and at its opon, either repair or replace the defecve Equipment or part.
Fimco, Ind. will pay for shipping and handling fees to return the repaired or replacement Equipment or part to you.
LIMITATION OF IMPLIED WARRANTIES AND OTHER REMEDIES. THE REMEDIES DESCRIBED ABOVE ARE YOUR SOLE AND EXCLUSIVE REMEDIES,
AND FIMCO, IND.’S SOLE LIABILITY, FOR ANY BREACH OF THIS LIMITED WARRANTY. TO THE EXTENT APPLICABLE, ANY IMPLIED WARRANTIES,
INCLUDING, WITHOUT LIMITATION, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIM-
ITED IN DURATION TO THE WARRANTY PERIOD, AND THE REMEDIES AVAILABLE FOR BREACH THEREOF SHALL BE LIMITED TO THE REMEDIES
AVAILABLE UNDER THIS EXPRESS LIMITED WARRANTY. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY
LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU. IN NO EVENT SHALL FIMCO, IND.’S LIABILITY UNDER THIS LIMITED WARRANTY EX-
CEED THE ACTUAL AMOUNT PAID BY YOU FOR THE DEFECTIVE EQUIPMENT, NOR SHALL FIMCO, IND. BE LIABLE, UNDER ANY CIRCUMSTANCES,
FOR ANY CONSEQUENTIAL, INCIDENTAL, SPECIAL OR PUNITIVE DAMAGES OR LOSSES, WHETHER DIRECT OR INDIRECT. SOME STATES DO NOT
ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT
APPLY TO YOU.
Warranty
