FasTest FE001 Series Guide

REPLACMENT INSTRUCTIONS
Roseville, MN
Ph: 1-800-444-2373
Fax: [phone]
www.fastestinc.com
WP006 10/6/2010
Assembly View
Instructions Supplement FE001 Mini Connector
READ ALL INSTRUCTIONS AND WARNINGS PRIOR TO USE
WARNING: Do not operate FasTest connectors without reading and understanding
the complete installation and operating instructions. If instructions are not clear or
components are missing, contact factory before using connector.
Information on:
•Mounting of connector
•Attachment of pilot pressure and test media supply lines.
•Connector operation instructions
is described in the FE general instructions included with each connector.
FE001 Mini Connector Seal Sizes
MODEL SEAL SET SEALING RANGE
FE001 -0050 .030” - .050”
-001 .050” - .080”
-002 .080” - .130”
Buna-N o-ring seals are standard, other materials available per request.
PARTS LIST
PART NUMBER DESCRIPTION
FE001-0050 Complete External Connector
Sealing Range .030” - .050”
FE001-001 Complete External Connector
Sealing Range .050” - .080”
FE001-002 Complete External Connector
Sealing Range .080” - .130”
FES001-0050 Replacement Seal Set
Sealing Range .030” - .050”
Includes Buna-N O-Ring Seal and
Seal Casing.
PARTS LIST CONTINUED
PART NUMBER DESCRIPTION
FES001-001 Replacement Seal Set
Sealing Range .050” - .080”
Includes Buna-N O-Ring Seal and
Seal Casing.
FES001-002 Replacement Seal Set
Sealing Range .030” - .050”
Includes Buna-N O-Ring Seal and
Seal Casing.
FEB001-0050 Buna-N Replacement O-Ring Seals
Sealing Range .030” - .050”
Five seal changes per package.
FEB001-001 Buna-N Replacement O-Ring Seals
Sealing Range .050” - .080”
Five seal changes per package.
FEB001-002 Buna-N Replacement O-Ring Seals
Sealing Range .080” - .130”
Five seal changes per package.
30539-000 Internal Spring for FE001 Connector
Pilot Port
Test Port
Test Piece
Entrance Hole

REPLACMENT INSTRUCTIONS
Roseville, MN
Ph: 1-800-444-2373
Fax: [phone]
www.fastestinc.com
WP006 10/6/2010
INSTALLATION OF REPLACEMENT SEALS
To Replace Seal
1. Unscrew and remove Seal Casing. Wrench flats provided for easy removal.
NOTE: The internal Spring is set loose inside the Housing. Make sure that this Spring is not damaged or
lost.
2. O-Ring seals are held in the Seal Casing by friction fit. Remove old O-Ring and replace with new one.
3. Place Spring into Housing.
4. Thread Seal Casing into Housing, using a wrench to tighten will prevent loosening.
Changing Connector Seal Range
Changing the Seal Casing assembly allows the user to have one FE001 Body seal the entire .030” - .130”
sealing range. The FES Replacement Seal Sets are listed on the parts list. Installation is similar to the
replacement seal installation except that the entire seal casing assembly (Seal Casing and Buna-N O-Ring)
is replaced.
FASTEST FE001 MINI EXTERNAL CONNECTOR
PART SPECIFICATIONS & OVER ALL DIMENSIONS
Operating Pressure: Medium Vacuum to 500 PSI
FasTest, Inc. Product Warranty
FasTest, Inc. warrants its products against defects of workmanship and/or material for 12 months from
the date of the sale by FasTest, Inc. This warranty is void if the product is misused, tampered with or
used in a manner that is not in accordance with FasTest, Inc. recommendations and/or instructions.
FasTest, Inc. is not liable for consequential or other damages including, but not limited to, loss, damage,
personal injury, or any other expense directly or indirectly arising from the use of or inability to use its
products either separately or in combination with other products. ALL OTHER WARRANTIES
EXPRESSED OR IMPLIED, WHETHER ORAL OR WRITTEN, INCLUDING BUT NOT LIMITED TO
WARRANTIES OR MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ARE
EXPRESSLY EXCLUDED.
Remedy under this warranty is limited to replacement of the product or an account credit in the amount of the original
selling price, at the option on FasTest, Inc. All allegedly defective products must be returned prepaid transportation to
FasTest, Inc. along with information describing the products performance, unless disposition in the field is authorized
in writing by FasTest, Inc.
SEAL CASING
SPRING
PISTON
HOUSING
WRENCH FLATS
WASHER – ONLY USED ON FE001-0050
CONNECTOR (ID CHAMFER TOWARDS
SEAL CASING)
O-RING SEAL
Exploded View
