FasTest CoreMax SCFTP0620 User guide

HEAD INSTALLATION AND OPERATING INSTRUCTION
Roseville, MN
Ph: 1-800-444-2373
Fax: [phone]
www.fastestinc.com
WP171 Rev A 03/28/2019
FasTest, Inc. Product Warranty
FasTest, Inc. warrants its products against defects of workmanship and/or material for 12 months from the date of the
sale by FasTest, Inc. This warranty is void if the product is misused, tampered with or used in a manner that is not in
accordance with FasTest, Inc. recommendations and/or instructions. FasTest, Inc. is not liable for conse uential or
other damages including, but not limited to, loss, damage, personal injury, or any other expense directly or indirectly
arising from the use of or inability to use its products either separately or in combination with other products. ALL
OTHER WARRANTIES EXPRESSED OR IMPLIED, WHETHER ORAL OR WRITTEN, INCLUDING BUT NOT
LIMITED TO
WARRANTIES OR MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ARE EXPRESSLY
EXCLUDED.
Remedy under this warranty is limited to replacement of the product or an account credit in the amount of the original
selling price, at the option on FasTest, Inc. All allegedly defective products must be returned prepaid transportation to
FasTest, Inc. along with information describing the products performance, unless disposition in the field is authorized
in writing by FasTest, Inc.
SCFTP0620 CoreMax Installation Torque
Tool.
Description: The CoreMax Installation Torque Tool
Installs the CoreMax Valve Into a CoreMax Seat,
Torqueing the Valve to 8 ft/lbs. at 200 RPM’s
(Maximum).
Please thoroughly read the instructions prior to operating the SCFTP0620
CoreMax torque tool. If you do not understand instructions, or if components
are missing, call FasTest before using connector.
The Torque Tool is designed to mate with a specific application
SCFTP0
20
Core
Max Installation
To
r
qu
ing
Tool

HEAD INSTALLATION AND OPERATING INSTRUCTION
Roseville, MN
Ph: 1-800-444-2373
Fax: [phone]
www.fastestinc.com
WP171 Rev A 03/28/2019
Torque tool
Head
CoreMax Valve
hex
KNURLED
B
ACK BODY
CoreMax Seat
hex
Torque tool
Fully engaged with valve
assembly
CoreMax Valve
hex
CoreMax Seat
Tool Trigger
Torque tool
Fully engaged with valve
assembly
SCFTP16
ASSEMBLY
SCFTP0
6
Place drive socket onto an-
gle wrench drive.
Hold Socket
(SCFTP
6212
)
Socket firmly attached to
the drive adapter
OPERATION:
1. With the seat (SCH07030xxx) Brazed in place, Place the CoreMax Core (SCCA07H
Into seat. Turn the valve to start the thread.
2. With the CoreMax valve started into the seat place the torque tool onto
The valve, being sure that the socket(s) of the torque tool are engaged with
The hex’s of the seat and the valve.
3. With the tool fully engaged with the CoreMax
Valve/Seat assembly, squeeze the
Trigger of the tool. The tool will spin the Core Valve
into the seat until 8 ft/lbs. of
Torque is achieved at a speed of 200 RPM’s (max).
Once the proper torque is achieved the
torque tool will shut off.
Installation of the tool head (SCFTP16), Onto the SCFTP06 angle
wrench.
1. Obtain the torque head assembly (SCFTP16) and the angle torque wrench
(QXN2PT18PS6-VP1-K40).
2. Securely place the 1/4” drive adapter (SCFTP61) Into the SCFTP06 tool. Attach the ½” dp
socket (5543A87) to the square end of the adapter.
3. Place the hold socket (SCFTP6212) and socket head on to
the torque wrench/head assembly. Thread on. NOTE: The threads are left hand.
