ΣyG-S7G2 Modular Development Kit (MDK) Overview
1.1 Introduction
The Future Designs, Inc. ΣyG
TM
Family provides a complete and qualified Graphical User
Interface (GUI) / Human Machine Interface (HMI) platform for the rapid release of customer
products. The core of ΣyG (pronounced, “sig”) is Renesas Synergy
TM
– a comprehensive and
integrated software-based microcontroller platform. FDI adds the Synergy platform to its GUI
hardware, systems and production expertise. The end result is a sum of high-quality products that
provide a robust and proven source for GUI and HMI solutions:
ΣyG = Renesas Synergy+ GUI
The ΣyG-S7G2 Modular Development Kit for the System on Module is the gateway for beginning
Renesas Synergy
TM
projects. The ΣyG-S7G2 Modular Development Kit is compatible with FDI’s
ΣyG Modular Development LCD Kits but can be used independently as a lower cost option for those
embedded applications without the need for a touch screen display. FDI offers low cost customization
services for customer specific hardware, software or packaging applications at volumes of 500 units
or more.
1.2 ESD Warning
The ΣYG-S7G2-43C-MDK is shipped in a protective anti-static package. Do not subject the
module to high electrostatic potentials. Exposure to high electrostatic potentials may cause damage
to the boards that will not be covered under warranty. General practice for working with static
sensitive devices should be followed when working with the kit.

ΣYG-S7G2-43C-MDK User’s Manual


11/18/2015
Copyright ©2015,
Future Designs, Inc Page 6of 28

1.3 Renesas Synergy S7G2 Microcontoller Block Diagram
Figure 1: S7G2 System Block Diagram

ΣYG-S7G2-43C-MDK User’s Manual


11/18/2015
Copyright ©2015,
Future Designs, Inc Page 7of 28

1.4 ΣyG-S7G2-43C-MDK System Block Diagram
Figure 2: ΣYG-S7G2 Kit Block Diagram (4.3” display shown)

ΣYG-S7G2-43C-MDK User’s Manual


11/18/2015
Copyright ©2015,
Future Designs, Inc Page 8of 28

1.5 Requirements
The ΣYG-S7G2-43C -MDK requires a carrier board with a 200-pin SO-DIMM socket. The
socket should have the key at the 1.8V location. The CARRIER Board from Future Designs
provides this socket and should be utilized to develop your application for initial verification.
Each yG development kit includes:
•ΣyG-S7G2 System on Module (SOM)
•Renesas Synergy Software Platform
•Carrier Board
•5 VDC, 2.3A North American Power Supply
•USB and Ethernet Cables
•Segger ARM Cortex-M Mini-JTAG debugger and cables
•Optional LCD Carrier Board
•Optional 4.3” or 7.0″PCAP Touch Screen LCD
1.6 ΣyG-S7G2 SOM Power Requirements
The power requirement for the ΣYG-S7G2-43C-MDK is 5V DC Center Positive 2A Power
Supply.
Getting Started
2.1 Setting up the Hardware
The SOMDIMM should be inserted into the DIMM Socket as shown below and then
locked into place by pushing down to the Carrier Board. Ensure the SOMDIMM is inserted
completely into the socket prior to locking. The socket utilized on the CARRIER Board is
rated for a minimum of 25 insertions.

ΣYG-S7G2-43C-MDK User’s Manual


11/18/2015
Copyright ©2015,
Future Designs, Inc Page 9of 28

Figure 3: SOMDIMM Insertion
The following are step by step instructions for setting up the hardware.
1) Make sure you have a SOMDIMM board plugged into the CARRIER board at J1.
2) Verify the LCD Interface ribbon cable connects the LCD CARRIER board to the CARRIER (J7)
board.
3) With the power off, plug the 5V center-positive Power Supply into 5V (P5) of the CARRIER
board.
4) Connect an RJ-45 Ethernet cable to the ETHERNET (J5) interface of the CARRIER board.
5) Plug in a female-to-female DB9 serial cable between PC and RS232 (P4) on the CARRIER board.
6) Insert the microSD card with the demonstration files (included) into microSD connector on the
SOMDIMM.


ΣYG-S7G2-43C-MDK User’s Manual


11/18/2015
Copyright ©2015,
Future Designs, Inc Page 10 of 28

2.2 Demonstration Software
Once the device is powered on, the demonstration software start menu will appear on the LCD
screen. The software consists of the brewing demonstration and temperature demonstration.


2.2.1 Brewing Demonstration
To launch the Brewing Demonstration tap the “Brewing Demo” button on the
demonstration software start menu. The purpose of the Brewing Demonstration is to
showcase Renesas SSP’s sprite animation capability. Bottles appear to move down the
production line, fill with a liquid, and the man drinks the liquid.
2.2.2 Temperature Demo
To launch the Temperature Demonstration, tap the “Temperature” button on the
demonstration software start menu. This interactive demonstration displays the temperature
of the processor and the temperature measured by an optional external sensor. Clicking on
the “Deg. C” or “Deg. F” button will change the degree scale in which the temperatures are

ΣYG-S7G2-43C-MDK User’s Manual


11/18/2015
Copyright ©2015,
Future Designs, Inc Page 11 of 28

displayed. If you have a can of air duster, apply it over the external sensor located
Component U11 on the Carrier Board and watch the temperature drop!
2.3 uEZ Doxygen Online HTML Documentation
μEZ® has built-in comment documentation that follows the Doxygen comment standard.
This standard allows for code comments and annotations to be written in a certain manner, and then
compiled along with source code into HTML documentation.
FDI provides the pre-compiled HTML documentation at this link: http://www.teamfdi.com/uez/docs/
In the uEZ source code, “uEZ/uEZDoxyfile” is the main project file for the Doxygen generator. When
Doxygen is recompiled, the new Doxygen files will be found here: uEZ\Docs\
Doxygen_Documentation.html
FDI will update the documentation roughly with each new μEZ® release or as new drivers are added to
the system.
For more information, see the Doxygen website: http://www.doxygen.org/

ΣYG-S7G2-43C-MDK User’s Manual


11/18/2015
Copyright ©2015,
Future Designs, Inc Page 12 of 28

2.4 Software
PC with Windows 7 or Windows 8
e
2
studio Integrated Solution Development Environment (ISDE) from Renesas
Renesas Synergy
TM
Software Package (SSP)
GNU tool chain for ARM® Cortex®-M MCUs
You can download the latest versions of the SSP and e
2
studio ISDE from
https://synergybeta.renesas.com/
The GNU tool chain and installation instructions for the tool chain are included in the e2 studio
ISDE download.
NOTE: Access to this site is restricted to authorized Renesas Synergy beta program participants. If
you require access to this site, please contact your Renesas representative.
ΣyG-S7G2 SOM System on Module Board Components
3.1 ARM Mini-JTAG J2
The ΣyG-S7G2 SOM uses a JTAG connector based on a 2mm header. This smaller
connector provides 100% of the functionality of the standard 20-pin JTAG connector, but
utilizes 70% less board space.
Pin Number Description Pin Number Description
1 VCC 6 TDO
2 TMS 7 X
3 GND 8 TDI
4 TCK 9 GND
5 GND 10 JST#
Figure 4: ARM Mini JTAG

ΣYG-S7G2-43C-MDK User’s Manual


11/18/2015
Copyright ©2015,
Future Designs, Inc Page 13 of 28

3.2 Tag Connect J7
Use the Tag Connect 10-pin cable to program and JTAG the ΣyG-S7G2 SOM using a
Segger J-Link device.
Cable: http://www.tag-connect.com/tc2050-arm2010
Cable: http://www.tag-connect.com/TC2050-IDC-NL
Figure 5: Tag-Connect JTAG

ΣYG-S7G2-43C-MDK User’s Manual


11/18/2015
Copyright ©2015,
Future Designs, Inc Page 14 of 28

3.3 MicroSD Socket J1
The ΣyG-S7G2 SOM utilizes a microSD for flexible mass storage. MicroSD flash cards are
common, cost effective, and provides a large amount of user-changeable memory.
Pin Number Description
1 DAT2/RSV
2 CD_DAT3/CS#
3 CMD/SDI
4 VDD
5 CLK/SCLK
6 VSS
7 DAT0/SDO
8 DAT1/RSV
9 CD
The microSD card must be removed using the spring loaded “push-pull” mechanism on the
microSD socket. Forceful removal of a microSD card will result in permanent damage to the
socket that is not covered under warranty. To insert the card, push it into the socket until a
“click” sound is heard. Similarly, to remove the card, push the card into the socket. The push-
pull mechanism will “click” again and eject the card from the socket. The card is now
available for safe removal.

ΣYG-S7G2-43C-MDK User’s Manual


11/18/2015
Copyright ©2015,
Future Designs, Inc Page 15 of 28

3.3.1 Inserting the microSD card into the microSD socket
First, prepare to insert the microSD card into the
socket by positioning it with its text facing up.
Position the ridge, or “lip”, of the card furthest
from the socket.
Next, partially insert the card into the socket.
Then, use your figure to gently push the card
into the socket. When the card “clicks” into
place it is in its final, locked position. The card
is now ready for use.
Note: Once the microSD card is fully inserted it
should not fall out, even if the unit is shaken
vigorously.

ΣYG-S7G2-43C-MDK User’s Manual


11/18/2015
Copyright ©2015,
Future Designs, Inc Page 16 of 28

3.3.2 Removing the microSD card from the microSD socket
Begin to remove the microSD card by gently
pushing the card into the socket. The socket
will “click” and eject the card.
Once the microSD card is ejected, it will
partially extend out from the socket.
Carefully grab the ridged edge or sides of the
microSD card to gently pull it out.
The microSD card is now fully removed from
the socket.
3.4 Ethernet PHY U5
The ΣyG-S7G2 SOM provides an Ethernet PHY from SMSC, LAN8720. The LAN8720 is
a single chip solution for a 100BASE-TX/10BASE-T physical layer transceiver. It has support for
reduced MII (RMII), and HP MDI-X auto crossover allowing for any standard Ethernet cable to be
used, even a crossover cable. The LAN8720 is fully compliant to IEEE 802.3u with support for
auto-negotiation and manual selection of 10/100Mbps speed as well as full and half-duplex modes.

ΣYG-S7G2-43C-MDK User’s Manual


11/18/2015
Copyright ©2015,
Future Designs, Inc Page 17 of 28

3.5 200-pin SOMDIMM Connector Details J4
Pin SOMDIMM Signal Name Application Details I/O SOMDIMM Connection Details
1 ETH_TXP Ethernet Transmit Positive O Output from KSZ8041 Ethernet PHY
2 ETH_RXP Ethernet Receive Positive I Output from KSZ8041 Ethernet PHY
3 ETH_TXN Ethernet Transmit Negative O Input to KSZ8041 Ethernet PHY
4 ETH_RXN Ethernet Receive Negative I Input to KSZ8041 Ethernet PHY
5 3V3A 3.3V Analog P Analog 3.3V Output from PHY Circuit
6 GND Ground P
7 ETH_LED0 Ethernet LED0 O Ethernet LED0 output from KSZ8041
8 ETH_LED1 Ethernet LED1 O Ethernet LED1 output from KSZ8041
9 VBAT_IN Vdd Battery Input P Vdd for battery backup of internal RTC
10 NC Not Connected U
11 RSTIN# Reset Input I Reset input to POR IC TPS3801
12 RST# O Reset output from POR circuit
13 GPIO13_USB_ID
14 NC Not connected U
15 NC Not connected U
16 NC Not connected U
17 NC Not connected U
18 NC Not connected U
19 NC Not connected U
20 NC Not connected U
21 AVCC
22 AVCC
23 AVSS
24 GND Ground P
25 GPIO25_LCDPWR LCD Power Enable O Connected to S7G2 Port 2 bit 0
26 GPIO26_LCDLE LCD Latch Enable O Connected to S7G2 Port 2 bit 1
27 GPIO27_LCDCLK LCD Clock O Connected to S7G2 Port 2 bit 2
28 GPIO28_LCDFP O Connected to S7G2 Port 2 bit 3
29 GPIO29_LCDEN O Connected to S7G2 Port 2 bit 4
30 GPIO30_LCDLP O Connected to S7G2 Port 2 bit 5
31 GPIO31_LCDVDR4 LCD Data Bit 4 O Connected to S7G2 Port 2 bit 6
32 GPIO32_LCDVDR5 LCD Data Bit 5 O Connected to S7G2 Port 2 bit 7
33 GPIO33_LCDVDR6 LCD Data Bit 6 O Connected to S7G2 Port 2 bit 8
34 GPIO34_LCDVDR7 LCD Data Bit 7 O Connected to S7G2 Port 2 bit 9
35 GPIO35_SSLB2 GPIO U Connected to S7G2 Port 2 bit 10
36 GPIO36 GPIO U Connected to S7G2 Port 2 bit 11
37 3.3V 3.3V Power P
38 GND Ground P
39 3.3V 3.3V Power P
40 GND Ground P
41 USBH_DP USB Host Data Positive B Connected to S7G2 USB Port A D+
42 USBD_DP USB Device Data Postive B Connected to S7G2 USB Port B D+
43 USBH_DM USB Host Data Negative B Connected to S7G2 USB Port A D-
44 USBD_DM USB Device Data Negative B Connected to S7G2 USB Port B D-
45 GPIO45_LCD_B2
46 GPIO46_LCD_B3
47 GPIO47_RD GPIO / CAN Receive Data I Connected to S7G2 Port 0 bit 0
48 GPIO48_TD GPIO / CAN Transmit Data O Connected to S7G2 Port 0 bit 1
49 GPIO49 GPIO B Connected to S7G2 Port 0 bit 2
50 NC Not connected U
51 GPIO51_SPCK
52 GPIO52
53 GPIO53_MISO

ΣYG-S7G2-43C-MDK User’s Manual


11/18/2015
Copyright ©2015,
Future Designs, Inc Page 18 of 28

Pin SOMDIMM Signal Name Application Details I/O SOMDIMM Connection Details
54 GPIO51_SPCK
55 GPIO55
56 GPIO56_MOSI
57 GPIO57_TXD GPIO / Serial Transmit Data – For
RS232
O Connected to S7G2 Port 0 bit 10
58 GPIO58_RXD GPIO / Serial Receive Data – For
RS232
I Connected to S7G2 Port 0 bit 11
59 NC Not connected U DO NOT USE!
60 GPIO60_USBD_UPLED GPIO / USB Device Up LED O Connected to S7G2 Port 0 bit 13
61 GPIO61_USBD_CON GPIO / USB Device Connect O Connected to S7G2 Port 0 bit 14
62 GPIO62_RSCK GPIO / SPI Clock O Connected to S7G2 Port 0 bit 15
63 GPIO63 GPIO O Connected to S7G2 Port 0 bit 16 (used for
EEPROM CS)
64 GPIO64_MISO GPIO / SPI MISO I Connected to S7G2 Port 0 bit 17
65 GPIO65_MOSI GPIO / SPI MOSI O Connected to S7G2 Port 0 bit 18
66 GPIO66
67 GPIO67
68 GPIO68_USBH_OVC GPIO / USB Host Over Current I Connected to S7G2 Port 0 bit 21
69 GPIO69_TPIRQ GPIO / Touch IC IRQ Input I Connected to S7G2 Port 0 bit 22
70 GPIO70_AD0.0 GPIO / AD0 Bit 0 I Connected to S7G2 Port 0 bit 23
71 GPIO71_AD0.1 GPIO / AD0 Bit 1 I Connected to S7G2 Port 0 bit 24
72 GPIO72_AD0.2 GPIO / AD0 Bit 2 I Connected to S7G2 Port 0 bit 25
73 GPIO73_AD0.5_DA1 GPIO / AD0 Bit 3 I Connected to S7G2 Port 0 bit 26
74 GPIO74_SDA GPIO / User IO I2C Bus SDA B Connected to S7G2 Port 0 bit 27
75 GPIO75_SCL GPIO / User IO I2C Bus SCL O Connected to S7G2 Port 0 bit 28
76 GND Ground P
77 GND Ground P
78 GPIO78_ACC_IRQ GPIO / Accelerometer IRQ I Connected to S7G2 Port 1 bit 2
79 NC
80 GPIO80_RTC_IRQ GPIO / RTC IRQ Input I Connected to S7G2 Port 1 bit 5
81 NC Not connected U
82 NC Not connected U
83 NC Not connected U
84 NC Not connected U
85 NC Not connected U
86 GPIO86_LED_BR
87 GPIO87_USBH_PPWR GPIO / USB Host Power Ctl O Connected to S7G2 Port 1 bit 19
88 GPIO88_LCD_G2 LCD Data Bit 10 O Connected to S7G2 Port 1 bit 20
89 GPIO89_LCD_G3 LCD Data Bit 11 O Connected to S7G2 Port 1 bit 21
90 GPIO90_LCD_G4 LCD Data Bit 12 O Connected to S7G2 Port 1 bit 22
91 GPIO91_LCD_G5 LCD Data Bit 13 O Connected to S7G2 Port 1 bit 23
92 GPIO92_LCD_G6 LCD Data Bit 14 O Connected to S7G2 Port 1 bit 24
93 GPIO93_LCD_G7 LCD Data Bit 15 O Connected to S7G2 Port 1 bit 25
94 GPIO94_LCD_B4 LCD Data Bit 16 O Connected to S7G2 Port 1 bit 26
95 GPIO95_LCD_B5 LCD Data Bit 17 O Connected to S7G2 Port 1 bit 27
96 GPIO96_LCD_B6 LCD Data Bit 22 O Connected to S7G2 Port 1 bit 28
97 GPIO97_LCD_B& LCD Data Bit 23 O Connected to S7G2 Port 1 bit 29
98 GPIO98_USBD_VBUS USB Device VBus Sense Input I Connected to S7G2 Port 1 bit 30
99 GPIO99_AD0
100 NC Not connected B Unused
101 GND Ground P
102 GND Ground P
103 NC Not connected U Unused
104 NC Not connected U Unused
105 NC Not connected U Unused

ΣYG-S7G2-43C-MDK User’s Manual


11/18/2015
Copyright ©2015,
Future Designs, Inc Page 19 of 28

Pin SOMDIMM Signal Name Application Details I/O SOMDIMM Connection Details
106 NC Not connected U Unused
107 NC Not connected U Unused
108 NC Not connected U Unused
109 NC Not connected U Unused
110 NC Not connected U Unused
111 NC Not connected U Unused
112 NC Not connected U Unused
113 5V0 5.0V Power P
114 5V0 5.0V Power P
115 NC Not connected U Unused
116 GPIO116 GPIO B Connected to S7G2 Port 2 bit 14 / VOL_UD
117 GPIO117 GPIO B Connected to S7G2 Port 2 bit 15 / AMP_MODE
118 GPIO118 GPIO B Connected to S7G2 Port 2 bit 19 / RS485 Ren
119 GPIO119 GPIO B Connected to S7G2 Port 2 bit 21 / RS485 DE
120 GPIO120 GPIO B Connected to S7G2 Port 2 bit 22
121 GPIO121 GPIO B Connected to S7G2 Port 2 bit 23
122 GPIO122 GPIO B Connected to S7G2 Port 2 bit 25
123 GPIO123_SPKR_DA0 GPIO O Connected to S7G2 Port 2 bit 26 / SPEAKER
OUTPUT
124 GPIO124 GPIO B Connected to S7G2 Port 2 bit 27
125 GPIO125
126 GPIO126
127 GPIO127_LCD_R2
128 GPIO128_LCD_R3
129 GND Ground P
130 GND Ground P
131 GPIO131_LCD18B
132 GPIO132_LCD19B
133 GPIO133_LCD20B
134 GPIO134_LCD21B
135 GPIO135_LCD22B
136 GPIO136_LCD23B
137 NC Not connected U Unused
138 GPIO138
139 GPIO139
140 NC Not connected U Unused
141 GPIO141
142 GPIO142
143 GPIO143
144 GPIO144
145 GPIO145
146 GPIO146
147 GPIO147
148 GPIO148
149 GPIO149_RX RS485
150 GPIO150_TX RS485
151 GPIO151
152 GPIO152
153 GPIO153
154 NC Not connected U Unused
155 NC Not connected U Unused
156 NC Not connected U Unused
157 NC Not connected U Unused
158 NC Not connected U Unused
159 NC Not connected U Unused

ΣYG-S7G2-43C-MDK User’s Manual


11/18/2015
Copyright ©2015,
Future Designs, Inc Page 20 of 28

Pin SOMDIMM Signal Name Application Details I/O SOMDIMM Connection Details
160 GPIO160_MD
161 NC Not connected U Unused
162 GPIO162_NMI Not connected U Unused
163 GND Ground P
164 GND Ground P
165 3.3V 3.3V Power P
166 GND Ground P
167 NC Not connected U Unused
168 NC Not connected U Unused
169 NC Not connected U Unused
170 NC Not connected U Unused
171 NC Not connected U Unused
172 NC Not connected U Unused
173 NC Not connected U Unused
174 NC Not connected U Unused
175 NC Not connected U Unused
176 NC Not connected U Unused
177 NC Not connected U Unused
178 NC Not connected U Unused
179 NC Not connected U Unused
180 NC Not connected U Unused
181 NC Not connected U Unused
182 NC Not connected U Unused
183 NC Not connected U Unused
184 NC Not connected U Unused
185 NC Not connected U Unused
186 NC Not connected U Unused
187 NC Not connected U Unused
188 NC Not connected U Unused
189 NC Not connected U Unused
190 NC Not connected U Unused
191 NC Not connected U Unused
192 NC Not connected U Unused
193 NC Not connected U Unused
194 TMS
195 TCK
196 TDO
197 TDI
198 NC Not connected U Unused
199 3.3V 3.3V Power P
200 GND Ground P
