FDS FD102CMT User manual

Document Number:
MAN –FD102CMT
Rev:
H
Revision Date:
05/15/2017
Page 1 of 14
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
Installation and Operation Manual
FD102CMT
10.2” Widescreen LCD Ceiling Mount

Document Number:
MAN –FD102CMT
Rev:
H
Revision Date:
05/15/2017
Page 2 of 14
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
Table of Contents
General Information..........................................................................................................3
Front View.........................................................................................................................3
Additional Information..................................................................................................3
Specifications ...................................................................................................................4
Installation Instructions .................................................................................................4
Power..................................................................................................................................5
Wiring Suggestions .........................................................................................................5
S-Video/Comp and Audio Wiring................................................................................5
VGA Wiring......................................................................................................................6
Power and Ground Wiring ............................................................................................7
Power/Video .....................................................................................................................7
Pinout DB-15.....................................................................................................................8
Technical Drawing ..........................................................................................................9
Operation Instructions..................................................................................................10
Button Controls..............................................................................................................10
Remote Control ..............................................................................................................11
Technical Support..........................................................................................................12
Instructions for Continued Airworthiness ...............................................................12
Warranty ..........................................................................................................................13
Log of Revisions.............................................................................................................14

Document Number:
MAN –FD102CMT
Rev:
H
Revision Date:
05/15/2017
Page 3 of 14
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
General Information
The FD102CMT is a 10.2" Widescreen LCD Ceiling Mount, used to deploy our popular
10.2” Widescreen LCD. The FDS Avionics Corp. high resolution 10.2” Widescreen LCD
is perfect for cabin video and graphical entertainment.
Front View
Additional Information
The FD102CMT is very rugged with the mounting structure and the internal pivot parts
manufactured from milled aluminium. The ceiling mounting frame is mounted in the
aircraft where it will provide optimum viewing enjoyment by the passengers, resulting in a
smooth shape that houses the LCD and blends into the cabin headliner. The display can
deploy 180° so that it may be pushed away from the latching point in case of emergency
egress.
Deployment is via a mechanical latch at the font of the unit. Depressing the latch releases
the display and the display is normally placed at a 90 degree angle for viewing. To stow
the display the operator would push the display up to the ceiling position where a positive
latch occurs.

Document Number:
MAN –FD102CMT
Rev:
H
Revision Date:
05/15/2017
Page 4 of 14
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
Specifications
Display Type
10.2” Widescreen TFT Color LCD
Screen Resolution
800x480 / 640x480 ~ 1024x768
Display Brightness
500 cd/m2
Contrast Ratio
300:1
Display Dimension
9.80”(W) x 6.3”(H) x 1.1”(D)
Mount Dimension
9.80”(W) x 7.74”(H) x 1.27”(D)
LCD Dimension
8.7”(W) x 5.2”(H)
Weight
4 lbs.13.8 oz.
Viewing Angle
120°/90° (H/V)
Power
12VDC @ 2 Amps
28VDC @ .5 Amp
PC Video Input
SVGA (Analog RGB 15 pin D-sub)
Standard Video Input
2 Composite Video
Video Type Supported
NTSC, PAL
Screen Control
On-Screen Display Menu
Remote Control
IR, included
Materials
Aluminium
DO-160 Testing
Section 21, Category B
Installation Instructions
All cabin entertainment equipment, such as the FD102CMT, should be installed on a non-
essential bus and have a dedicated circuit breaker. It is a requirement that a switch be
installed in the cockpit so that the pilot can de-energize the entertainment system should it
become necessary.
The order in which you proceed is up to the installation center. We suggest that you first
look at the mounting plate prior to installing the LCD to make sure you have the proper
room and conditions in the aircraft to mount the display to the ceiling. Most aircraft have a
significant curvature in the headliner and it will probably be necessary to modify the
headliner to mount to a structure that will hold this mount.
Once it has been determined that you have sufficient room and mounting locations for the
FD102CMT, then it would be appropriate to start mounting the base to the frame. The
FD102CMT is attached to the aircraft with four #10 screws. There are four attach points
on the top plate.
There are two connectors on 14” cables coming from the LCD. The DB-9 is used for
12VDC Power. The DB-15 is used for VGA and two composite inputs..

Document Number:
MAN –FD102CMT
Rev:
H
Revision Date:
05/15/2017
Page 5 of 14
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
Power
This is a 12VDC monitor that requires 2 Amps of power to operate. This is also available
as FD102CMT (28V) which is a 28VDC monitor that requires .5 Amp of power to operate.
Wiring Suggestions
All shields should be grounded to the connector at the source, and floating at the display.
Avoid routing video wiring parallel to:
AC wiring
Strobe wiring
DC motor supply cables
Inverter cabling
Or any other potential noise source
S-Video/Composite and Audio Wiring
Recommended cable for s-video/composite and audio purposes is PIC 75 Ohm Coax,
P/N V76261. This is a lightweight, flexible, and low signal loss cable which meets FAA
flammability requirements of FAR 23.1359(d), FAR 25.853(a) and FAR 25.869(a)(4).
Similar aviation coaxial cable can be used from other vendors, as well.
Some aircraft are prone to AC noise - we recommend adding to the composite source a
75 Ohm video isolation transformer such as Deerfield Laboratory, Inc. Part No. 162-1
(www.deerfieldlab.com, [phone]). In most cases this should be added to the video
output of the source.

Document Number:
MAN –FD102CMT
Rev:
H
Revision Date:
05/15/2017
Page 6 of 14
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
VGA Wiring
Recommended cable for VGA purpose is ECS P/N 453005. This is a single shielded
cable containing 5 separate coaxial cables, color-coded to match the functions of the
wires.
The individual wires should be extended with 6” 22awg wires using an environmental
splice for the red & green wires, and Raychem caps for the blue, white, and black wires.

Document Number:
MAN –FD102CMT
Rev:
H
Revision Date:
05/15/2017
Page 7 of 14
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
Power and Ground Wiring
22 AWG wire is recommended for Power and Ground applications.
Power/Video
Pin out for High Density DB-15 Receptacle
Part Numbers for DB-15 connectors, manufactured by Tyco or Amp.
High density, D-sub, 15 contact receptacle (female) P/N 748565-1
HD15F pins P/N M39029/57-354
Pin
Number
Description
1
N/C
2
N/C
3
N/C
4
Composite Video #1 –Signal
5
Composite Video #1 –Shield
6
N/C
7
Composite Video #2 –Signal
8
Composite Video #2 –Shield
9
Red Video (Pin 1 on Standard VGA)
10
Green Video (Pin 2 on Standard VGA)
11
Blue Video (Pin 3 on Standard VGA)
12
Red Ground (Pin 6 on Standard VGA)
13
Green Ground (Pin 7 on Standard VGA)
14
Horizontal Sync (Pin 13 on Standard VGA)
15
Vertical Sync (Pin 14 on Standard VGA)

Document Number:
MAN –FD102CMT
Rev:
H
Revision Date:
05/15/2017
Page 8 of 14
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
Pin out for High Density DB-9 Receptacle
Part Numbers for DB-9 connectors, manufactured by Tyco or Amp.
D-sub, 9 contact receptacle (female) P/N 205203-1
DB9F pins P/N M39029/63-368
Pin
Number
Description
1
12VDC Power (28VDC for FD102CMT (28V))
2
12VDC Ground (28VDC for FD102CMT (28V))
3
N/C
4
N/C
5
N/C
6
N/C
7
N/C
8
N/C
9
N/C

Document Number:
MAN –FD102CMT
Rev:
H
Revision Date:
05/15/2017
Page 9 of 14
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
Technical Drawing

Document Number:
MAN –FD102CMT
Rev:
H
Revision Date:
05/15/2017
Page 10 of 14
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
Operation Instructions
The FD102CMT is continuously on but can be de-energized by removing power from the
entertainment system. No pilot or aircrew action is necessary during flight or ground
operation. Passengers can change the video output from the FD102CMT using the video
source select switch on the LCD monitor, or remotely throughout the cabin with the
included IR remote.
Button Controls
BUTTON
FUNCTION
DESCRIPTION
1
POWER
Press to turn the monitor on if currently off. Hold to turn the
monitor off.
2
SOURCE
Press to switch between sources.
3
UP
Press to increase the value of a menu item.
4
DOWN
Press to decrease the value of a menu item.
5
MENU
Press to activate Menu.

Document Number:
MAN –FD102CMT
Rev:
H
Revision Date:
05/15/2017
Page 11 of 14
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
Remote Control
The remote control included with the FD102CV contains the same functionality available
on the display buttons, to include power, source, menu, and directional arrows.

Document Number:
MAN –FD102CMT
Rev:
H
Revision Date:
05/15/2017
Page 12 of 14
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
Technical Support
Should you have any questions concerning this product or other FDS Avionics Corp.
products, please contact our Product Support representatives at [phone].
FDS Avionics Corp.
6435 Shiloh Road
Alpharetta, GA 30005
Phone: [phone]
Fax: [phone]
Email: [email protected]
For further product information, technical data and sample wiring diagrams, please click on
the Dealers section of our web site at www.FDSAvionics.com
Instructions for Continued Airworthiness
The FD102CMT is designed not to require regular general maintenance.

Document Number:
MAN –FD102CMT
Rev:
H
Revision Date:
05/15/2017
Page 13 of 14
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
Limited Warranty
All FDS Avionics Corp. products are warranted to be free from material or manufacturing defects for a period of 24
months from the date of shipment for General Aviation customers or 12 months from the date of shipment for
Government/Special Mission customers. Any material or repair workmanship for in warranty repair service will be
specifically warranted for 90 days or the remainder of the original warranty period, whichever is longer. If the
original warranty period has expired, the 90 day repair warranty is limited to the material and workmanship specific
to the repair activity completed.
The following conditions are exclusions to warranty coverage:
1. Labor costs associated with installation, removal or reinstallation of any product.
2. Damage to or malfunction caused by any unauthorized alteration made to the product.
3. Resolving signal quality issues caused by externally generated noise introduced by aircraft electrical
systems or other components connected to any FDS product.
4. Any malfunction caused by improper installation or connection to aircraft wiring, industry standard cabin
management/inflight entertainment systems, or third party commercial equipment not specifically identified
as compatible with FDS products.
5. Any malfunction caused by installation that does not conform to precautions associated with operating
environments listed in the operating manual or consistent with industry best practices such as high
temperature, adequate ventilation, high humidity, high dust, or power surges.
6. Cosmetic damage or damage to internal components caused by installation or removal, failure to follow
installation or operating instructions, or any neglect or misuse of the product.
7. Any product that is returned for service with a broken tamper evident seal, indicating tampering or improper
handling of the product by an unauthorized person. Violation of product tamper evident seals or
modification of factory installed serial and PMA labels voids any warranty, either expressed or implied.
The FDS Technical Support team is available to provide distance troubleshooting support during business hours
(8:00am to 5:00pm EST) Monday through Friday at [phone].
Many repair requests can be resolved through distance support and may not require return of merchandise to the
factory. If a product must be returned to the factory for repair, an RMA number will be issued as directed by the
Technical Support team and communicated by the Repair Coordinator.
Upon request by the customer, FDS may send a Service Technician onsite to repair any non-PMA products. The
travel expenses incurred to include transportation, lodging and meals along with the technician’s hourly rate shall
be payable by the customer in accordance with FDS’ applicable rates and procedures.
FDS Avionics Corp. will, upon receipt of returned merchandise, remanufacture or replace the unit at our discretion
and return the product by Ground Return Shipping. Express return shipment will be the responsibility of the
sender.
This warranty is not transferable.
Any implied warranties expire at the express limited warranty expiration date. FDS shall not be held liable for any
indirect, special, punitive, incidental or consequential damages.
Some states do not allow limitation on the length of an implied warranty. In such states, the exclusions or
limitations of this limited warranty may not apply.

Document Number:
MAN –FD102CMT
Rev:
H
Revision Date:
05/15/2017
Page 14 of 14
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
Log of Revisions
Rev
Date
Page
Description
A
01/29/2007
---
---
B
03/28/2007
2,3,6
Added info regarding FD102CMT (28V)
C
04/11/2007
6
Changed required amperage to 2 Amps.
D
10/05/2007
1
Changed image, removed color information.
E
02/11/2009
2,11
Updated specs, warranty info
F
12/10/2009
1,7,8
Revised photo, button control, remote control
G
08/02/2012
Updated format and warranty info, revised specs, added non-
PMA product box to cover
H
5/15/2017
All
New Format, New Corporate name, New Branding, Warranty,
