3
en
en
For your safety.
Read all safety warnings and
all instructions. Failure to fol-
low the warnings and instructions may result
in electric shock, fire and/or serious injury.
Save all warnings and instructions for future-
reference.
Do not use this power tool before you
have thoroughly read and completely
understood this Instruction Manual, including
the figures, specifications, safety regulations
and the signs indicating DANGER, WARN-
ING and CAUTION.
Only carry out such operations with this
power tool as intended for by FEIN. Only use
application tools and accessories that have
been released by FEIN.
Please also observe the relevant national
industrial safety regulations.
Non-observance of the safety instructions in
the said documentation can lead to an electric
shock, burns and/or severe injuries.
This Instruction Manual should be kept for
later use and enclosed with the power tool,
should it be passed on or sold.
SAVE THESE INSTRUCTIONS.
The term “power tool” in the warnings refers
to your mains-operated (corded) power tool
or battery operated (cordless) power tool.
General safety rules.
1) Work area safety
a)Keep work area clean and well lit. Clut-
tered or dark areas invite accidents.
b)Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power
tools create sparks which may ignite the
dust or fumes.
c) Keep children and bystanders away
while operating a power tool. Distrac-
tion can cause you to lose control.
2) Electrical safety
a)Power tool plugs must match the outlet.
Never modify the plug in any way. Do not
use any adapter plugs with earthed
(grounded) power tools. Unmodified
plugs and matching outlets will reduce
risk of electric shock.
b)Avoid body contact with earthed or
grounded surfaces such as pipes, radia-
tors, ranges and refrigerators. There is
an increased risk of electric shock if
your body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power
tool will increase the risk of electric
shock.
d)Do not abuse the cord. Never use the
cord for carrying, pulling or unplugging
the power tool. Keep cord away from
heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase
the risk of electric shock.
e) When operating a power tool outdoors,
use an extension cord suitable for out-
door use. Use of a cord suitable for out-
door use reduces the risk of electric
shock.
f) If operating a power tool in a damp loca-
tion is unavoidable, use a ground fault
circuit interrupter (GFCI) protected sup-
ply. Use of an GFCI reduces the risk of
electric shock.
3) Personal safety
a)Stay alert, watch what you are doing
and use common sense when operating
a power tool. Do not use a power tool
while you are tired or under the influ-
ence of drugs, alcohol or medication. A
moment of inattention while operating
power tools may result in serious per-
sonal injury.
b)Use personal protective equipment.
Always wear eye protection. Protective
equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing pro-
tection used for appropriate conditions
will reduce personal injuries.
WARNING
OBJ_BUCH-0000000271-001.book Page 3 Wednesday, December 21, 2016 1:15 PM

4en
c) Prevent unintentional starting. Ensure
the switch is in the off-position before
connecting to power source and/or bat-
tery pack, picking up or carrying the
tool. Carrying power tools with your
finger on the switch or energising
power tools that have the switch on
invites accidents.
d)Remove any adjusting key or wrench
before turning the power tool on. A
wrench or a key left attached to a rotat-
ing part of the power tool may result in
personal injury.
e) Do not overreach. Keep proper footing
and balance at all times. This enables
better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose cloth-
ing or jewelery. Keep your hair, clothing
and gloves away from moving parts.
Loose clothes, jewelry or long hair can
be caught in moving parts.
g)If devices are provided for the connec-
tion of dust extraction and collection
facilities, ensure these are connected
and properly used. Use of dust collec-
tion can reduce dust-related hazards.
4) Power tool use and care
a)Do not force the power tool. Use the cor-
rect power tool for your application. The
correct power tool will do the job bet-
ter and safer at the rate for which it was
designed.
b)Do not use the power tool if the switch
does not turn it on and off. Any power
tool that cannot be controlled with the
switch is dangerous and must be
repaired.
c) Disconnect the plug from the power
source and/or the battery pack from the
power tool before making any adjust-
ments, changing accessories, or storing
power tools. Such preventive safety
measures reduce the risk of starting the
power tool accidentally.
d)Store idle power tools out of the reach of
children and do not allow persons unfa-
miliar with the power tool or these
instructions to operate the power tool.
Power tools are dangerous in the hands
of untrained users.
e) Maintain power tools. Check for mis-
alignment or binding of moving parts,
breakage of parts and any other condi-
tion that may affect the power tool’s
operation. If damaged, have the power
tool repaired before use. Many accidents
are caused by poorly maintained power
tools.
f) Keep cutting tools sharp and clean.
Properly maintained cutting tools with
sharp cutting edges are less likely to
bind and are easier to control.
g)Use the power tool, accessories and tool
bits etc. in accordance with these
instructions, taking into account the
working conditions and the work to be
performed. Use of the power tool for
operations different from those
intended could result in a hazardous sit-
uation.
5) Battery tool use and care
a)Recharge only with the charger speci-
fied by the manufacturer. A charger that
is suitable for one type of battery pack
may create a risk of fire when used with
another battery pack.
b)Use power tools only with specifically
designated battery packs. Use of any
other battery packs may create a risk of
injury and fire.
c) When battery pack is not in use, keep it
away from other metal objects, like
paper clips, coins, keys, nails, screws or
other small metal objects, that can
make a connection from one terminal to
another. Shorting the battery terminals
together may cause burns or a fire.
d)Under abusive conditions, liquid may be
ejected from the battery; avoid contact.
If contact accidentally occurs, flush
with water. If liquid contacts eyes, addi-
tionally seek medical help. Liquid
ejected from the battery may cause irri-
tation or burns.
6) Service
a)Have your power tool serviced by a qual-
ified repair person using only identical
replacement parts. This will ensure that
the safety of the power tool is main-
tained.
OBJ_BUCH-0000000271-001.book Page 4 Wednesday, December 21, 2016 1:15 PM

5
en
Special safety instructions.
Use auxiliary handles provided with the
machine. Loss of control can lead to injury.
Hold the power tool by the insulated gripping
surface when performing operations where
the application tool could contact hidden
wires. Contact with a “live” wire will also
make exposed metal parts of the power tool
“live” and shock the operator.
Beware of any concealed electric cables, gas
or water conduits. Check the working area
before commencing work, e. g. with a metal
detector.
Wear personal protective equipment. Depend-
ing on application, use face shield, safety
goggles or safety glasses. Where appropriate,
wear dust mask, hearing protectors, gloves
and workshop apron capable of stopping
small abrasive or workpiece fragments. The
safety glasses must be capable of protecting
against flying particles generated by the vari-
ous operations. Prolonged exposure to high
intensity noise may cause loss of hearing.
Secure the work piece firmly. A work piece
that is gripped tightly in a clamping device or
vice, is more secure than if held by hand.
Hold the power tool firmly. High reaction
torque can briefly occur.
Do not machine any material containing
asbestos. Asbestos is cancerogenic.
Do not rivet or screw any name-plates or
signs onto the power tool. If the insulation is
damaged, protection against an electric shock
will be ineffective. Adhesive labels are recom-
mended.
Do not use accessories which are not specifi-
cally designed and recommended by the
power tool manufacturer. Safe operation is
not ensured merely because an accessory fits
your power tool.
Clean the ventilation openings on the power
tool at regular intervals using non-metal
tools. The blower of the motor draws dust
into the housing. An excessive accumulation
of metallic dust can cause an electrical hazard.
Never look or stare into the light of the power
tool's lamp from a short distance. Never point
the light of the lamp into the eyes of other
persons in close vicinity. The radiation pro-
duced by the lamp can be harmful for the eye.
Do not direct the power tool against yourself,
other persons or animals. Danger of injury
from sharp or hot application tools.
Use and handling of the battery (bat-
tery pack)
To avoid hazardous situations such as burns,
fire, explosion, skin injuries, and other inju-
ries when handling the battery, observe the
following instructions:
Batteries must not be disassembled, opened
or reduced in size. Do not subject batteries to
mechanical impact or shock. Hazardous
vapours and fluid can escape in case of dam-
age and improper use of the battery. The
vapours can irritate the respiratory system.
Liquid ejected from the battery may cause
skin irritations or burns.
When battery fluid from a damaged battery
has come into contact with objects close by,
check the respective components, clean them
or replace them as required.
Keep the battery away from heat and fire. Do
not store the battery in direct sunlight.
Do not remove the battery from its original
packaging until it is going to be used.
Before any work on the machine itself,
remove the battery from the power tool. If the
power tool accidentally starts, there is danger
of injury.
Remove the battery only when the power tool
is switched off.
Keep the battery away from children.
Keep the battery clean and protect it against
moisture and water. Clean contaminated bat-
tery terminals and power tool connections
with a dry, clean cloth.
Use only intact original FEIN batteries that are
intended for your power tool. When working
with and charging incorrect, damaged,
repaired or reconditioned batteries, imita-
tions or other brands, there is danger of fire
and/or explosion.
Follow the safety warnings in the operating
instructions of the battery charger.
OBJ_BUCH-0000000271-001.book Page 5 Wednesday, December 21, 2016 1:15 PM

6en
Handling hazardous dusts.
When working with power
tools, such as when grinding,
sanding, polishing, sawing or for other work
procedures where material is removed, dusts
develop that are both hazardous to one’s
health and can spontaneously combust or be
explosive.
Contact with or inhaling some dust types can
trigger allergic reactions to the operator or
bystanders and/or lead to respiratory infec-
tions, cancer, birth defects or other reproduc-
tive harm.
Examples of such materials which contain
chemicals that can produce hazardous dusts,
are:
–Asbestos and materials containing asbes-
tos;
–Lead-containing coatings, some wood
types such as beech and oak;
–Minerals and metal;
–Silicate particles from bricks, concrete and
other materials containing stone;
–Solvent from solvent-containing paint/
varnish;
–Arsenic, chromium and other wood pre-
servatives;
–Materials for pesticide treatment on boat
and ship hulls;
–Stainless steel dust, metal dust and non-
ferrous metal dust;
To minimize the unwanted intake of these
materials:
–Use dust extraction matched appropriately
for the developing dust.
–Use personal protective equipment, such
as a P2 filter-class dust protection mask.
–Provide for good ventilation of the work-
place.
The risk from inhaling dusts depends on how
often these materials are worked. Materials
containing asbestos may only be worked on
by specialists.
Wood and light-metal dust
can cause spontaneous com-
bustion or explosions.
Hot mixtures of sanding dust and paint/var-
nish remainders or other chemical materials
in the filter bag or the vac filter can self-ignite
under unfavorable conditions, such as spark-
ing from sanding metal, continuous sunlight
or high ambient temperatures. To prevent
this:
–Avoid overheating the material being
sanded and the power tool.
–Empty the dust collector/container in time.
–Observe the material manufacturer’s
working instructions.
–Observe the relevant regulations in your
country for the materials being worked.
Hand/arm vibrations.
While working with this power
tool, hand/arm vibrations
occur. These can lead to health impairments.
The vibration emission value
during actual use of the power
tool can differ from the declared value
depending on the ways in which the tool is
used.
It is necessary to identify
safety measures to protect the
operator that are based on an estimation of
exposure in the actual conditions of use.
The vibration emission level given in this
information sheet has been measured in
accordance with a standardised test given in
EN 60745 and may be used to compare one
tool with another. It may be used for a pre-
liminary assessment of exposure.
The declared vibration emission level repre-
sents the main applications of the tool. How-
ever if the tool is used for different
applications, with different accessories or
poorly maintained, the vibration emission
may differ. This may significantly increase the
exposure level over the total working period.
WARNING
CAUTION
WARNING
WARNING
WARNING
OBJ_BUCH-0000000271-001.book Page 6 Wednesday, December 21, 2016 1:15 PM

7
en
An estimation of the level of exposure to
vibration should also take into account the
times when the tool is switched off or when
it is running but not actually doing the job.
This may significantly reduce the exposure
level over the total working period.
Identify additional safety measures to protect
the operator from the effects of vibration
such as: maintain the tool and the accessories,
keep the hands warm, organisation of work
patterns.
Emission values for sound and vibration (Two-figure – specifications as per ISO 4871)
Intended use of the power tool:
Hand-held cordless drill/driver for screwing
in and unscrewing screws and nuts, and for
drilling and screwdriving in metal, wood, plas-
tic, ceramics, in weather-protected environ-
ments without water supply using the
application tools and accessories recom-
mended by FEIN.
Sound emission ASCM18QM (**)
A-weighted emission pressure power level measured at the workplace
L
pA
(re 20 μPa), in decibels 73
Measuring uncertainty
K
pA
, in decibels 3
Measured A-weighted sound power level
L
wA
(re 1 pW), in decibels 84
Measuring uncertainty
K
wA
, in decibels 3
C-weighted peak sound pressure level measured at the workplace
L
pC-
peak
, in decibels 86
Measuring uncertainty
K
pCpeak
, in decibels 3
Vibrations
Mean vibrational value for drilling in metal
–m/s2
–ft/s21.5
4.5
Arithmetic mean value of the vibration total values
–m/s2
–ft/s2–
–
Measuring uncertainty
K , in
–m/s2
–ft/s21.5 4.5
REMARK: The sum of the measured emission value and respective measuring inaccuracy
represents the upper limit of the values that can occur during measuring.
Wear hearing protection!
Measured values determined in accordance with the corresponding product standard.
OBJ_BUCH-0000000271-001.book Page 7 Wednesday, December 21, 2016 1:15 PM

8en
Symbols.
Symbol, character Explanation
Do not touch the rotating parts of the power tool.
Make sure to read the enclosed documents such as the Instruction Man-
ual and the General Safety Instructions.
Observe the instructions in the text or graphic opposite!
Before commencing this working step, remove the battery from the
power tool. Otherwise there may be danger of injury caused by unin-
tentional starting of the power tool.
Use eye protection during operation.
Use ear protection during operation.
Use protective gloves during operation.
General prohibition sign. This action is prohibited.
Do not charge damaged batteries.
Keep the battery away from fire. Protect the battery against heat, e. g.
against continuous intense sunlight.
Observe the notes in the text aside!
Switching on
Switching off
This symbol confirms the certification of this product for the USA and
Canada.
Confirms the conformity of the power tool with the guidelines of the
European Community.
This sign warns of a directly imminent, dangerous situation. A false reac-
tion can cause a severe or fatal injury.
This sign indicates a possible dangerous situation that could cause severe
or fatal injury.
This sign warns of a possible dangerous situation that could cause injury.
Recycling code: identifies recyclable materials
DC voltage
Worn out power tools and other electrotechnical and electrical prod-
ucts should be sorted separately for environmentally-friendly recycling.
Battery type
DANGER
WARNING
CAUTION
OBJ_BUCH-0000000271-001.book Page 8 Wednesday, December 21, 2016 1:15 PM

9
en
Low speed
High speed
Reduce torque
Increase torque
(**) may contain numbers and letters
*** Partially in delivery scope
Symbol, character Explanation
Character Unit of measurement,
national Explanation
n
0
rpm; /min; min-1; r/min No-load speed (with fully charged battery)
P W Electrical power
°Anglewidth
UV Electric voltage
fHz Frequency
I A Electric current intensity
m kg, lbs Mass
lft, in Length, width, height, depth, diameter or thread
Ø ft, in Diameter of a round part
K... Uncertainty
m/s2Vibrational emission value according to EN 60745
(vector sum of three directions)
m, s, kg, A, mm, V, W,
Hz, N, °C, dB, min, m/s2Basic and derived units of measurement from the
international system of units SI.
OBJ_BUCH-0000000271-001.book Page 9 Wednesday, December 21, 2016 1:15 PM

10 en
Technical description and specifications.
Before mounting or replacing application tools or accessories, remove the bat-
tery. This preventive safety measure rules out the danger of injuries through
accidental starting of the power tool.
All accessories described or shown in this instruction manual will not be included with your-
power tool.
WARNING
Gripping surface
Gripping surface
Battery
Bit garage
Belt hook
Rotational direction switch
Gear selector
Torque setting
Drill chuck
Auxiliary handle
Battery-Unlocking button
Light
Tool holder
On/Off switch
Fig. 1
OBJ_BUCH-0000000271-001.book Page 10 Wednesday, December 21, 2016 1:15 PM

11
en
Type ASCM18QM (**)
Order number 7 116 ...
Rated voltage 18 V
No-load speed
1. Gear 0–400 /min
2. Gear 0–800 /min
3. Gear 0–1950 /min
4. Gear 0–3850 /min
Torque
(soft/hard screwdriving application) 407/797 in-lbs/ 46/90 Nm
Drilling capacity in steel 1/2 in
13 mm
Drilling capacity in wood 2 in
50 mm
Chuck clamping range 1/16–1/2 in
1.5–13 mm
Screw diameter 3/8 in
10 mm
Weight according to EPTA-Procedure 01
(power tool without battery and application tool) 2.64 lbs (1.2 kg)
Weight according to EPTA-Procedure 01
(drill chuck) 0.66 lbs
(0.3 kg)
Type B18A B18A
Battery type Lithium ion
(Li ion) Lithium ion (Li ion)
Rated voltage 18 V 18 V
Weight according to EPTA-Procedure 01 (Battery) 0.45 kg (0.99 lbs) 0.70 kg (1.54 lbs)
OBJ_BUCH-0000000271-001.book Page 11 Wednesday, December 21, 2016 1:15 PM

12 en
Assembly instructions.
Before mounting or replacing application tools or accessories, remove the bat-
tery. This preventive safety measure rules out the danger of injuries through
accidental starting of the power tool.
Mounting the auxiliary handle (figure 2).
To loosen the clamping strap of the auxiliary handle, turn the handle counterclockwise.
Slide the strap of the auxiliary handle in the desired working position onto the collar until the
teeth engage into the recesses, and then tighten.
WARNING
1.
2.
3. 1.
4.
3.
2.
5.
Fig. 2
Auxiliary handle
OBJ_BUCH-0000000271-001.book Page 12 Wednesday, December 21, 2016 1:15 PM

13
en
Removing and charging the battery
(figure 3).
Prior to the first charging procedure,
read the operating instructions of the
battery charger.
Charge the battery completely before
putting into operation for the first time.
Release the battery by pressing the battery
unlocking button and pull the battery out of
the handle. Do not exert any force when
doing this.
Connect the battery charger to a socket out-
let, slide the battery onto the battery charger
and charge the battery. After the charging
process is over, insert the battery into the
power tool and pull the plug of the battery
charger out of the socket outlet.
A new battery does not reach its full capacity
until after several charging and discharging
procedures.
Battery
LED indication on battery
Battery-Unlocking button
Fig. 3
1.
2.
OBJ_BUCH-0000000271-001.book Page 13 Wednesday, December 21, 2016 1:15 PM

14 en
Mounting the belt hook and the bit
garage (figure 4).
To mount the belt hook, fit the spacer as well
as the belt hook to the tool and fasten both
with the screw.
To mount the bit garage, fit the spacer as well
as the bit garage to the tool and fasten both
with the screw.
To mount the belt hook together with the bit
garage, fit the spacer, the belt hook and the bit
garage to the tool and fasten all parts with the
screw.
1.
3.
4.
2.
1.
3.
2.
1.
3.
2.
Spacer
Belt hook
Bit garage
Screw
Fig. 4
OBJ_BUCH-0000000271-001.book Page 14 Wednesday, December 21, 2016 1:15 PM

15
en
Mounting the drill chuck (figure 5).
When changing the drill chuck, avoid debris
from entering the drill chuck and the spindle!
Slide the ring toward the front.
Place the drill chuck onto the spindle.
Release the ring.
Turn the drill chuck to lock it.
Removing the drill chuck (figure 6).
When changing the drill chuck, avoid debris
from entering the drill chuck and the spindle!
Slide the ring frontwards and pull the drill
chuck off the spindle.
1.
2.
3.
4.
Drill chuck
Ring
Fig. 5
2.
1.
Drill chuck
Ring
Fig. 6
OBJ_BUCH-0000000271-001.book Page 15 Wednesday, December 21, 2016 1:15 PM

16 en
Changing the tool
Before mounting or replacing application tools or accessories, remove the bat-
tery. This preventive safety measure rules out the danger of injuries through
accidental starting of the power tool.
Mounting application tools (figure 7).
Open the keyless drill chuck.
Afterwards, insert the desired application
tool.
Tighten the keyless drill chuck.
Mounting application tools (figure 8).
Insert the application tool.
WARNING
1.
3.
2.
Drill chuck
Fig. 7
Fig. 8
OBJ_BUCH-0000000271-001.book Page 16 Wednesday, December 21, 2016 1:15 PM

17
en
Working instructions.
Before mounting or replacing application tools or accessories, remove the bat-
tery. This preventive safety measure rules out the danger of injuries through
accidental starting of the power tool.
Do not use accessories not specifically intended and recommended for this power tool by FEIN.
The use of non-original FEIN accessories can lead to overheating of the power tool and destroy
it.
For each job, use only the FEIN application tool released and intended for the
respective application.
Setting the operating mode (figure 9).
Adjust the rotational direction switch and the
gear switch only when the machine is at a
complete stop.
Always slide the gear selector to the stop.
Otherwise, the machine can become dam-
aged.
Set the desired operating mode.
–For drilling, set the operating mode selec-
tor switch to the “drilling” symbol.
Setting the torque (figure 10).
Adjust the torque only when the machine is at
a complete stop.
The torque setting is for the small to mid-size
screw range.
The tightening torque also depends on the
force with which the power tool is pressed
against the screw.
–Low torque: Small screws
–High torque: Large screws
Determine the torque setting with which the
screws are screwed flush into the material by
practical testing.
WARNING
CAUTION
Fig. 9
max
10
9
11
12
13
14
15
8
7
6
5
4
3
2
1
Fig. 10
Torque setting
OBJ_BUCH-0000000271-001.book Page 17 Wednesday, December 21, 2016 1:15 PM

18 en
Electronic torque shut-off (figure 11).
Adjust the torque only when the machine is at
a complete stop.
The motor switches off when reaching the set
torque and an audio signal sounds. After the
shut-off has taken place, release the on/off
switch and press it again for the next screw-
driving operation.
The audio signal can be switched on and off.
The electronic shut-off is deactivated when
working in the “ ” torque level.
To achieve good working results, press the
power tool with sufficient force against the
screw.
The maximum speed is reduced in the lower
torque levels.
5 sec.
3.
2.
1.
5.
4.
6.
6.
Fig. 11
On/Off switch
Battery
OBJ_BUCH-0000000271-001.book Page 18 Wednesday, December 21, 2016 1:15 PM

19
en
Selecting the rotation direction
(figure 12).
To avoid accidental starting, e. g., during
transport, set the rotation selector switch to
the centre position.
Set the rotation selector switch to right or left
rotation as required.
Adjust the rotation selector switch only
when the machine is at a complete stop.
Adjusting the gear setting (figure 13).
Adjust the rotational direction switch and the
gear switch only when the machine is at a
complete stop.
Always slide the gear selector to the stop.
Otherwise, the machine can become dam-
aged.
You can adjust 4 gear settings.
Set the lowest gear setting to work at low
speed with high torque. This gear setting is
suitable for screwing in large screw diameters.
Set the highest gear setting to work at high
speed with low torque. This gear setting is
suitable for drilling with small drill bit diame-
ters.
The material-dependent gear setting can be
determined by practical testing.
Adjust the rotation direction only when
the machine is at a complete stop.
Fig. 12
Rotational direction switch
Fig. 13
OBJ_BUCH-0000000271-001.book Page 19 Wednesday, December 21, 2016 1:15 PM

20 en
Switching on and off (figure 14).
Always hold the power tool
firmly. Otherwise, you could
lose control over the power tool.
In case of overload, the machine switches off.
Thermal overload of the power tool is indi-
cated through flashing of the LED in the han-
dle.
Switching on:
Press the On/Off switch. The speed increases
the more you press the On/Off switch.
Switching off:
To switch off the power tool, release the
On/Off switch.
Illumination (figure 15).
Never look or stare into the
light of the power tool's lamp
from a short distance. Never point the light of
the lamp into the eyes of other persons in
close vicinity. The radiation produced by the
lamp can be harmful for the eye.
When pressing the On/Off switch, the light is
switched on.
After releasing the On/Off switch, the light
briefly stays on and then switches off auto-
matically.
CAUTION
1. 2.
Fig. 14
On/Off switch
WARNING
=
=
Fig. 15
OBJ_BUCH-0000000271-001.book Page 20 Wednesday, December 21, 2016 1:15 PM
