Fein ABH 18 Series User manual

© C. & E. Fein GmbH. Printed in Germany. Abbildungen unverbindlich. Technische Änderungen vorbehalten. 3 41 01 263 21 0 BY 2018.02 DE.
USA
FEIN Power Tools, Inc.
1000 Omega Drive
Suite 1180
Pittsburgh, PA 15205
Phone: [phone]
www.feinus.com
Canada
FEIN Canadian Power Tool
Company
323 Traders Boulevard East
Mississauga, Ontario L4Z 2E5
Telephone: [phone]
Phone: [phone]
www.fein.com
Headquarter
C. & E. Fein GmbH
Hans-Fein-Straße 81
D-73529 Schwäbisch Gmünd-Bargau
www.fein.com
FEIN Service
FEIN Power Tools, Inc.
2735 Hickory Grove Road
Davenport, IA 52804
Phone: [phone]
[e-mail]
 ABH 18 (**) 7 140 ...
OBJ_BUCH-0000000298-001.book Page 1 Thursday, February 8, 2018 9:01 AM

2
Instruction Manual
Mode d’emploi
Instrucciones de uso
en
3
fr
22
es
42
OBJ_BUCH-0000000298-001.book Page 2 Thursday, February 8, 2018 9:02 AM

3
en
en
For your safety.
Read all safety warnings and
all instructions. Failure to fol-
low the warnings and instructions may result
in electric shock, fire and/or serious injury.
Save all warnings and instructions for future-
reference.
Do not use this power tool before you
have thoroughly read and completely
understood this Instruction Manual, including
the figures, specifications, safety regulations
and the signs indicating DANGER, WARN-
ING and CAUTION.
Only carry out such operations with this
power tool as intended for by FEIN. Only use
application tools and accessories that have
been released by FEIN.
Please also observe the relevant national
industrial safety regulations.
Non-observance of the safety instructions in
the said documentation can lead to an electric
shock, burns and/or severe injuries.
This Instruction Manual should be kept for
later use and enclosed with the power tool,
should it be passed on or sold.
SAVE THESE INSTRUCTIONS.
The term “power tool” in the warnings refers
to your mains-operated (corded) power tool
or battery operated (cordless) power tool.
General safety rules.
1) Work area safety
a)Keep work area clean and well lit. Clut-
tered or dark areas invite accidents.
b)Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power
tools create sparks which may ignite the
dust or fumes.
c) Keep children and bystanders away
while operating a power tool. Distrac-
tion can cause you to lose control.
2) Electrical safety
a)Power tool plugs must match the outlet.
Never modify the plug in any way. Do not
use any adapter plugs with earthed
(grounded) power tools. Unmodified
plugs and matching outlets will reduce
risk of electric shock.
b)Avoid body contact with earthed or
grounded surfaces such as pipes, radia-
tors, ranges and refrigerators. There is
an increased risk of electric shock if
your body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power
tool will increase the risk of electric
shock.
d)Do not abuse the cord. Never use the
cord for carrying, pulling or unplugging
the power tool. Keep cord away from
heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase
the risk of electric shock.
e) When operating a power tool outdoors,
use an extension cord suitable for out-
door use. Use of a cord suitable for out-
door use reduces the risk of electric
shock.
f) If operating a power tool in a damp loca-
tion is unavoidable, use a ground fault
circuit interrupter (GFCI) protected sup-
ply. Use of an GFCI reduces the risk of
electric shock.
3) Personal safety
a)Stay alert, watch what you are doing
and use common sense when operating
a power tool. Do not use a power tool
while you are tired or under the influ-
ence of drugs, alcohol or medication. A
moment of inattention while operating
power tools may result in serious per-
sonal injury.
b)Use personal protective equipment.
Always wear eye protection. Protective
equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing pro-
tection used for appropriate conditions
will reduce personal injuries.
c) Prevent unintentional starting. Ensure
the switch is in the off-position before
connecting to power source and/or bat-
tery pack, picking up or carrying the
tool. Carrying power tools with your
finger on the switch or energising
power tools that have the switch on
invites accidents.
WARNING
OBJ_BUCH-0000000298-001.book Page 3 Thursday, February 8, 2018 9:02 AM

4en
d)Remove any adjusting key or wrench
before turning the power tool on. A
wrench or a key left attached to a rotat-
ing part of the power tool may result in
personal injury.
e) Do not overreach. Keep proper footing
and balance at all times. This enables
better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose cloth-
ing or jewelery. Keep your hair, clothing
and gloves away from moving parts.
Loose clothes, jewelry or long hair can
be caught in moving parts.
g)If devices are provided for the connec-
tion of dust extraction and collection
facilities, ensure these are connected
and properly used. Use of dust collec-
tion can reduce dust-related hazards.
4) Power tool use and care
a)Do not force the power tool. Use the cor-
rect power tool for your application. The
correct power tool will do the job bet-
ter and safer at the rate for which it was
designed.
b)Do not use the power tool if the switch
does not turn it on and off. Any power
tool that cannot be controlled with the
switch is dangerous and must be
repaired.
c) Disconnect the plug from the power
source and/or the battery pack from the
power tool before making any adjust-
ments, changing accessories, or storing
power tools. Such preventive safety
measures reduce the risk of starting the
power tool accidentally.
d)Store idle power tools out of the reach of
children and do not allow persons unfa-
miliar with the power tool or these
instructions to operate the power tool.
Power tools are dangerous in the hands
of untrained users.
e) Maintain power tools. Check for mis-
alignment or binding of moving parts,
breakage of parts and any other condi-
tion that may affect the power tool’s
operation. If damaged, have the power
tool repaired before use. Many accidents
are caused by poorly maintained power
tools.
f) Keep cutting tools sharp and clean.
Properly maintained cutting tools with
sharp cutting edges are less likely to
bind and are easier to control.
g)Use the power tool, accessories and tool
bits etc. in accordance with these
instructions, taking into account the
working conditions and the work to be
performed. Use of the power tool for
operations different from those
intended could result in a hazardous sit-
uation.
5) Battery tool use and care
a)Recharge only with the charger speci-
fied by the manufacturer. A charger that
is suitable for one type of battery pack
may create a risk of fire when used with
another battery pack.
b)Use power tools only with specifically
designated battery packs. Use of any
other battery packs may create a risk of
injury and fire.
c) When battery pack is not in use, keep it
away from other metal objects, like
paper clips, coins, keys, nails, screws or
other small metal objects, that can
make a connection from one terminal to
another. Shorting the battery terminals
together may cause burns or a fire.
d)Under abusive conditions, liquid may be
ejected from the battery; avoid contact.
If contact accidentally occurs, flush
with water. If liquid contacts eyes, addi-
tionally seek medical help. Liquid
ejected from the battery may cause irri-
tation or burns.
6) Service
a)Have your power tool serviced by a qual-
ified repair person using only identical
replacement parts. This will ensure that
the safety of the power tool is main-
tained.
OBJ_BUCH-0000000298-001.book Page 4 Thursday, February 8, 2018 9:02 AM

5
en
Special safety instructions.
Wear ear protectors. Exposure to noise can
cause hearing loss.
Use auxiliary handle(s), if supplied with the
tool. Loss of control can cause personal injury.
Hold power tool by insulated gripping sur-
faces, when performing an operation where
the cutting accessory may contact hidden
wiring. Cutting accessory contacting a “live”
wire may make exposed metal parts of the
power tool “live” and could give the operator
an electric shock.
Wear personal protective equipment. Depend-
ing on the application, wear face shield, eye
protection or safety goggles. Where appropri-
ate, wear dust mask, hearing protection, pro-
tective gloves or a special apron to protect
yourself against sanding- and material parti-
cles. The eyes are to be protected against
thrown about foreign objects that develop at
various applications. Dust masks or respira-
tors used must filter the dust developing at
the application. When subjected to loud
noise, loss of hearing can occur.
Beware of any concealed electric cables, gas
or water conduits. Check the working area
before commencing work, e. g. with a metal
detector.
Secure the work piece firmly. A work piece
that is gripped tightly in a clamping device or
vice, is more secure than if held by hand.
Hold the power tool firmly. High reaction
torque can briefly occur.
Do not direct the power tool against yourself,
other persons or animals. Danger of injury
from sharp or hot application tools.
Do not rivet or screw any name-plates or
signs onto the power tool. If the insulation is
damaged, protection against an electric shock
will be ineffective. Adhesive labels are recom-
mended.
Do not use accessories which are not specifi-
cally designed and recommended by the
power tool manufacturer. Safe operation is
not ensured merely because an accessory fits
your power tool.
Clean the ventilation openings on the power
tool at regular intervals using non-metal
tools. The blower of the motor draws dust
into the housing. An excessive accumulation
of metallic dust can cause an electrical hazard.
Use and handling of the battery
(battery pack)
To avoid hazardous situations such as burns,
fire, explosion, skin injuries, and other inju-
ries when handling the battery, observe the
following instructions:
Batteries must not be disassembled, opened
or reduced in size. Do not subject batteries to
mechanical impact or shock. Hazardous
vapours and fluid can escape in case of dam-
age and improper use of the battery. The
vapours can irritate the respiratory system.
Liquid ejected from the battery may cause
skin irritations or burns.
When battery fluid from a damaged battery
has come into contact with objects close by,
check the respective components, clean them
or replace them as required.
Keep the battery away from heat and fire. Do
not store the battery in direct sunlight.
Do not remove the battery from its original
packaging until it is going to be used.
Before any work on the machine itself,
remove the battery from the power tool. If the
power tool accidentally starts, there is danger
of injury.
Remove the battery only when the power tool
is switched off.
Keep the battery away from children.
Keep the battery clean and protect it against
moisture and water. Clean contaminated bat-
tery terminals and power tool connections
with a dry, clean cloth.
Charge the batteries only with battery char-
gers recommended by the manufacturer. A
charger that is suitable for one type of battery
may create a risk of fire when used with
another battery.
OBJ_DOKU-0000007903-001.fm Page 5 Thursday, February 8, 2018 1:52 PM

6en
Keep the battery not being used away from
paper clips, coins, keys, nails, screws or other
small metal objects, that can make a connec-
tion from one terminal to another. Shorting
the battery terminals together may cause
burns or a fire.
Remove the power tool's battery during trans-
port and storage.
Use only intact original FEIN batteries that are
intended for your power tool. When working
with and charging incorrect, damaged,
repaired or reconditioned batteries, imita-
tions or other brands, there is danger of fire
and/or explosion.
Follow the safety warnings in the operating
instructions of the battery charger.
Handling hazardous dusts.
When working with power
tools, such as when grinding,
sanding, polishing, or for other work proce-
dures where material is removed, dusts
develop that are both hazardous to one's
health and can spontaneously combust or be
explosive.
Contact with or inhaling some dust types can
trigger allergic reactions to the operator or
bystanders and/or lead to respiratory infec-
tions, cancer, birth defects or other reproduc-
tive harm.
Examples of such materials which contain
chemicals that can produce hazardous dusts,
are:
–Asbestos and materials containing asbes-
tos;
–Lead-containing coatings, some wood
types such as beech and oak;
–Minerals and metal;
–Silicate particles from bricks, concrete and
other materials containing stone;
–Solvent from solvent-containing paint/
varnish;
–Arsenic, chromium and other wood pre-
servatives;
–Materials for pesticide treatment on boat
and ship hulls;
–Stainless steel dust, metal dust and non-
ferrous metal dust;
To minimize the unwanted intake of these
materials:
–Use dust extraction matched appropriately
for the developing dust.
–Use personal protective equipment, such
as a P2 filter-class dust protection mask.
–Provide for good ventilation of the work-
place.
The risk from inhaling dusts depends on how
often these materials are worked. Materials
containing asbestos may only be worked on
by specialists.
Wood and light-metal dust can
cause spontaneous combus-
tion or explosions.
Hot mixtures of sanding dust and paint/var-
nish remainders or other chemical materials
in the filter bag or the vac filter can self-ignite
under unfavorable conditions, such as spark-
ing from sanding metal, continuous sunlight
or high ambient temperatures. To prevent
this:
–Avoid overheating the material being
sanded and the power tool.
–Empty the dust collector/container in time.
–Observe the material manufacturer’s
working instructions.
–Observe the relevant regulations in your
country for the materials being worked.
WARNING
CAUTION
OBJ_BUCH-0000000298-001.book Page 6 Thursday, February 8, 2018 9:02 AM

7
en
Hand/arm vibrations.
While working with this power
tool, hand/arm vibrations
occur. These can lead to health impairments.
The vibration emission value
during actual use of the power
tool can differ from the declared value
depending on the ways in which the tool is
used.
It is necessary to identify safety
measures to protect the oper-
ator that are based on an estimation of expo-
sure in the actual conditions of use.
The vibration emission level given in this
information sheet has been measured in
accordance with a standardized test given in
EN 60745 and may be used to compare one
tool with another. It may be used for a pre-
liminary assessment of the vibrational impact.
The declared vibration emission level repre-
sents the main applications of the power tool.
However, if the power tool is used for other
applications with different accessories or
poorly maintained, the vibration emission
may differ. This may significantly increase the
vibrational impact over the total working
period.
An estimation of the level of exposure to
vibration should also take into account the
times when the tool is switched off or when
it is running but not actually doing the job.
This may significantly reduce the exposure
level over the total working period.
Identify additional safety measures to protect
the operator from the effects of vibration
such as: Maintain the power tool and the
accessories, keep the hands warm, organiza-
tion of work patterns.
The vibrational emission values are given for
dry grinding of metal with grinding points.
Other applications, such as shaping with hard
metal cutters, can lead to other vibrational
emission values.
WARNING
WARNING
WARNING
OBJ_BUCH-0000000298-001.book Page 7 Thursday, February 8, 2018 9:02 AM

8en
Emission values for sound and vibration (Two-figure – specifications as per ISO 4871)
Sound emission ABH 18 (**)
A-weighted emission pressure power level measured at the work-
place
L
pA
(re 20 μPa), in decibels 88.4
Measuring uncertainty
K
pA
, in decibels 3
Measured A-weighted sound power level
L
wA
(re 1 pW), in deci-
bels 99.4
Measuring uncertainty
K
wA
, in decibels 3
C-weighted peak sound pressure level measured at the workplace
L
pCpeak
, in decibels 105.8
Measuring uncertainty
K
pCpeak
, in decibels 3
Vibrations
Mean vibrational value for drilling in metal
h,D
, in
–m/s2
–ft/s24.2 14.2
Mean vibrational value for hammer drilling in concrete h,ID , in
–m/s2
–ft/s211.8
39.9
Measuring uncertainty
K , in
–m/s2
–ft/s21.5
4.9
REMARK: The sum of the measured emission value and respective measuring inaccuracy rep-
resents the upper limit of the values that can occur during measuring.
Wear hearing protection!
Wear eye protection!
Measured values determined in accordance with the corresponding product standard.
OBJ_BUCH-0000000298-001.book Page 8 Thursday, February 8, 2018 9:02 AM

9
en
Intended use of the power tool:
Hand-guided rotary hammer for use with the
application tools and accessories recom-
mended by FEIN in weather-protected envi-
ronments for hammer drilling in concrete,
bricks and masonry as well as for chiselling
work, and with appropriate accessories for
drilling without impact in wood, metal,
ceramics and plastic.
Symbols.
Symbol, character Explanation
Do not touch the rotating parts of the power tool.
Observe the instructions in the text or graphic opposite!
Observe the notes in the text aside!
General prohibition sign. This action is prohibited.
Make sure to read the enclosed documents such as the Instruction Man-
ual and the General Safety Instructions.
Before commencing this working step, remove the battery from the
power tool. Otherwise there may be danger of injury caused by unin-
tentional starting of the power tool.
Use eye protection during operation.
Use ear protection during operation.
Use a dust mask during operation.
Do not charge damaged batteries.
Keep the battery away from fire. Protect the battery against heat, e. g.
against continuous intense sunlight.
Switching on
Switching off
Confirms the conformity of the power tool with the guidelines of the
European Community.
This symbol confirms the certification of this product for the USA and
Canada.
This sign warns of a directly imminent, dangerous situation. A false reac-
tion can cause a severe or fatal injury.
This sign indicates a possible dangerous situation that could cause severe
or fatal injury.
DANGER
WARNING
OBJ_BUCH-0000000298-001.book Page 9 Thursday, February 8, 2018 9:02 AM

10 en
This sign warns of a possible dangerous situation that could cause injury.
Worn out power tools and other electrotechnical and electrical prod-
ucts should be sorted separately for environmentally-friendly recycling.
Battery type
Product with double or reinforced insulation
Low speed
High speed
Caution: Do not look or stare into the switched-on lamp!
(**) may contain numbers and letters
*** Partially in delivery scope
Symbol, character Explanation
CAUTION
Character Unit of measurement,
national Explanation
n rpm; /min; min-1; r/min Rated speed
n
0
rpm; /min; min-1; r/min No-load speed
P W Electrical power
°Anglewidth
UV Electric voltage
fHz Frequency
I A Electric current intensity
m kg, lbs Mass
lft, in Length, width, height, depth, diameter or thread
Ø ft, in Diameter of a round part
K... Uncertainty
m/s2Vibrational emission value according to EN 60745
(vector sum of three directions)
m, s, kg, A, mm, V, W,
Hz, N, °C, dB, min, m/s2Basic and derived units of measurement from the
international system of units SI.
OBJ_BUCH-0000000298-001.book Page 10 Thursday, February 8, 2018 9:02 AM

11
en
Technical description and specifications.
Before mounting or replacing application tools or accessories, remove the bat-
tery. This preventive safety measure rules out the danger of injuries through
accidental starting of the power tool.
Not all accessories described or shown in this instruction manual will be included with your-
power tool.
WARNING
Auxiliary handle Depth stop
On/Off switch
Tool holder
Battery
Operating mode selector switch
Unlocking button for the
operating mode selector switch
Rotational direction switch
Light
Battery-unlocking button
Gripping surface
Fig. 1
LED indication on battery
SDS-Drill chuck
OBJ_BUCH-0000000298-001.book Page 11 Thursday, February 8, 2018 9:02 AM

12 en
Type ABH 18 (**)
Order number 7 140 ...
Rated voltage 18 V
Impact energy per stroke according to EPTA 05 2.0 J
Rated speed 0–1200 rpm
No-load speed 0–4400 rpm
Drilling capacity in concrete 3/4 in
20 mm
Drilling capacity in wood 7/8 in
22 mm
Drilling capacity in steel 1/2 in
13 mm
Drilling diameter (core bit) 2 3/4 in
68 mm
Weight according to EPTA-Procedure 01 5.07 lbs
(2.30 kg)
Type B18A B18A B18A
Battery type Lithium ion Lithium ion High Power
Lithium ion
Rated voltage 18 18 18
Weight according to EPTA-Procedure 01
(Battery) 0.45 0.70 0.75
OBJ_BUCH-0000000298-001.book Page 12 Thursday, February 8, 2018 9:02 AM

13
en
Assembly instructions.
Before mounting or replacing application tools or accessories, remove the bat-
tery. This preventive safety measure rules out the danger of injuries through
accidental starting of the power tool.
For all work or when changing application tools, always wear protective gloves.
Danger of injury from the sharp edges of the application tools. Application
tools can become very hot while working. Danger of burns!
Removing and charging the battery
(figure 2).
Prior to the first charging procedure,
read the operating instructions of the
battery charger.
Charge the battery completely before
putting into operation for the first time.
Release the battery by pressing the battery-
unlocking button and pull the battery out of
the handle. Do not exert any force when
doing this.
Connect the battery charger to a socket out-
let, slide the battery onto the battery charger
and charge the battery. After the charging
process is over, insert the battery into the
power tool and pull the plug of the battery
charger out of the socket outlet.
A new battery does not reach its full capacity
until after several charging and discharging
procedures.
WARNING
CAUTION
Fig. 2
Battery
Battery-unlocking
button
1.
2.
OBJ_BUCH-0000000298-001.book Page 13 Thursday, February 8, 2018 9:02 AM

14 en
Mounting the auxiliary handle
(figure 3).
To loosen the clamping strap of the auxiliary
handle, turn the handle counterclockwise.
Slide the clamping strap of the auxiliary han-
dle over the collar.
Turn the auxiliary handle to the desired
working position and retighten it.
1.
2.
3.
Auxiliary handle
Strap
Fig. 3
1.
2.
3.
OBJ_BUCH-0000000298-001.book Page 14 Thursday, February 8, 2018 9:02 AM

15
en
Mounting and adjusting the depth
stop (figure 4).
Actuate the unlocking button for the depth
stop and slide the depth stop in auxiliary han-
dle.
The notched grooves must face upward.
Adjust the desired drilling depth X (X = clear-
ance between the tips of the application tool
and the depth stop).
Fig. 4
Unlocking button for
the depth stop
X
1.
2.
X
2.
Depth stop
OBJ_BUCH-0000000298-001.book Page 15 Thursday, February 8, 2018 9:02 AM

16 en
Changing the tool (figure 5).
Before mounting or replacing application tools or accessories, remove the bat-
tery. This preventive safety measure rules out the danger of injuries through
accidental starting of the power tool.
Slide the application tool into the tool holder
rotating it clockwise until it locks.
Pull the locking sleeve back and remove the
application tool.
WARNING
Fig. 5
2.
2.
SDS-plus
SDS-plus
1.
1.
3.
OBJ_BUCH-0000000298-001.book Page 16 Thursday, February 8, 2018 9:02 AM

17
en
Working instructions.
Before mounting or replacing application tools or accessories, remove the bat-
tery. This preventive safety measure rules out the danger of injuries through
accidental starting of the power tool.
Do not use accessories not specifically intended and recommended for this power tool by FEIN.
The use of non-original FEIN accessories can lead to overheating of the power tool and destroy
it. For each job, use only the FEIN application tool released and intended for the respective
application.
Selecting the rotation direction
(figure 6).
To avoid accidental starting, e. g., during
transport, set the rotation selector switch to
the centre position.
Set the rotation selector switch to right or left
rotation as required.
Adjust the rotation selector switch only
when the machine is at a complete stop.
Setting the operating mode (figure 7).
Change the operating mode only when the
power tool is switched off! Otherwise, the
machine can become damaged.
Press the unlocking button and rotate the
operating mode selector switch to the desired
position until it can be heard to engage. Oth-
erwise, the power tool can become damaged.
Set the desired operating mode.
–For drilling without impact in wood, metal,
ceramics and plastic, or for screwdriving,
set the operating mode selector switch to
the “drilling” symbol.
–For hammer drilling in concrete or stone,
set the operating mode selector switch to
the “hammer drilling” symbol.
–For chiselling, set the operating mode
selector switch to the “chiselling” symbol.
WARNING
Fig. 6
Rotational
direction switch
Fig. 7
1.
2.
Operating mode selector switch
Unlocking button for the
operating mode selector switch
OBJ_BUCH-0000000298-001.book Page 17 Thursday, February 8, 2018 9:02 AM

18 en
Adjusting the chisel position
(figure 8).
In this position, the operating mode selector
switch will not engage. Rotate the chisel to
the desired working position. Then, turn the
operating mode selector switch back to the
chiselling position.
Switching on and off (figure 9).
Always hold the power tool
firmly. Otherwise, you could
lose control over the power tool.
In case of overload, the machine switches off.
Switching on:
Press the On/Off switch. The speed increases
the more you press the On/Off switch.
Switching off:
To switch off the power tool, release the
On/Off switch.
2.
2.
1.
3.
Fig. 8
CAUTION
2.
1.
Fig. 9
OBJ_BUCH-0000000298-001.book Page 18 Thursday, February 8, 2018 9:02 AM

19
en
Illumination (figure 10).
Never look or stare into the
light of the power tool's lamp
from a short distance. Never point the light of
the lamp into the eyes of other persons in
close vicinity. The radiation produced by the
lamp can be harmful for the eye.
When pressing the On/Off switch, the light is
switched on.
After releasing the On/Off switch, the light
briefly stays on and then switches off auto-
matically.
Handling the battery.
Operate and charge the battery only within
the battery operating-temperature range of
0°C – 45°C (32°F –113°F). At the beginning
of the charging procedure, the battery tem-
perature must be within the battery operat-
ing-temperature range.
Battery charge-control indicator
(figure 11).
Press the button to activate the LED indication.
The real percentage of the battery charge
condition is only indicated when the power
tool motor is stopped.
The electronics automatically switch off the
motor prior to the battery being deep dis-
charged.
WARNING
10 sec.
=
=
Fig. 10
LED indicator Meaning Activity
1–4green
LED Percent- age of
charge
condition
Operation
Continuous
red light Battery is almost
empty
Charge battery
Red flashing
light Battery is not ready
for opera-
tion
Bring the battery
into the battery
operating-tem-
perature range,
then charge
Fig. 11
LED indication on battery
100 %
75 %
50 %
25 %
0 %
≤
≤
≤
≤
=
OBJ_BUCH-0000000298-001.book Page 19 Thursday, February 8, 2018 9:02 AM

20 en
Repair and customer service.
Before mounting or replacing application tools or accessories, remove the bat-
tery. This preventive safety measure rules out the danger of injuries through
accidental starting of the power tool.
Service.
Have maintenance carried out
only through qualified person-
nel. Incorrectly mounted leads and compo-
nents can cause serious injuries. Have the
required service carried out only through a
FEIN customer service agent.
The current spare parts list for this power
tool can be found in the Internet at
www.fein.com.
Cleaning.
Remove the battery prior to
any maintenance and clean-
ing. This preventive safety measure rules out
the danger of injuries through accidental start-
ing of the power tool.
When using in environments
with conductive dust in the
air, such as when working metals, this dust
can settle in the interior of the power tool.
Therefore, regularly blow out the interior of
the power tool from outside via the ventilation
openings with dry, oil-free compressed air;
always wear eye protection when doing this.
Do not attempt to clean
clogged or dirty ventilation
openings of the power tool with pointed
metal objects; use nonmetal tools or objects
if necessary.
Do not use cleaning agents
and solvents that can cause
damage to plastic parts. These include: Gas-
oline, carbon-tetrachloride, chloric solvents,
ammonia and domestic cleaning agents that
contain ammonia.
When working gypsum-containing materials,
dust can settle within the power tool and
switch element, which can harden in connec-
tion with humidity. This can impair the
switching mechanism. Blow out the interior
of the power tool via the ventilation slots and
the switch element frequently with dry and
oil-free compressed air.
Warranty and liability.
The warranty for the product is valid in accordance with the legal regulations in the country
where it is marketed. In addition, FEIN also provides a guarantee in accordance with the FEIN
manufacturer’s warranty declaration.
Not all accessories described or shown in this instruction manual will be included with your-
power tool.
Environmental protection, disposal.
Packaging, worn out power tools and accessories should be sorted for environmental-friendly
recycling.
Dispose of batteries only when discharged.
For batteries that are not completely discharged, insulate the terminals with tape as a protective
measure against short-circuiting.
For further information, please contact your specialist shop.
WARNING
WARNING
WARNING
WARNING
CAUTION
CAUTION
OBJ_BUCH-0000000298-001.book Page 20 Thursday, February 8, 2018 9:02 AM
