SERVICE
Toolserviceandmaintenancemustbeperformedonlybyqualified
repairpersonnel.
When servicing a tool, only use identical replacement parts available
from FEIN.
Repairs on FEIN Power Tools required the use of special tools (pulling devices
and bearing press). Authorized repair centers have trained repair technicians
andequipmentnecessaryto per-formthese repairs.Service orrepairs performed
by unqualified persons could result in operator injury.
For the location of the repair center near you, please call 1-800-441-9878.
Monday thru Friday, 9AM to 5PM EST. Or, look on our web site at
www.feinus.com and follow the link to “Authorized Warranty Repair Centers”
Phone: [phone] Fax: [phone] Toll Free: 1-800-441-9878
FEIN Power Tools
1030 Alcon Street
Pittsburgh, PA 15220
November 24, 2003
Tapper
ASge 636

FEIN Power Tools
Asge 636 Parts List
Item Item Numbe
r
Descriptio
n
Reqd
10 3-19-01-117-01-5 MOTOR HOUSING 1
20 3-07-01-234-01-1 SWITCH (ASGE 110V) 1
50 3-07-12-043-00-1 BRUSH HOLDER 2
80 3-07-11-059-00-7 CARBON BRUSH 2
90 3-07-13-010-00-9 COVER FOR BRUSH HOLDER 2
100 4-30-02-014-99-8 SCREW 4
101 4-24-43-002-99-2 SECURING DISC 4
120 5-1-203-002-11-3 FIELD COIL 110V 1
130 4-30-02-025-99-1 SCREW 2
140 3-14-28-004-00-0 AIR RING 1
160 3-07-07-101-01-2 CABLE 1
170 3-14-13-142-00-9 STRAIN RELEASE 1
180 3-24-31-021-00-7 CABLE CLAMP 1
190 4-30-46-002-00-5 SCREW 2
200 3-12-01-066-00-5 COVER 1
220 3-28-05-119-00-8 SWITCH TRIGGER 1
230 4-30-60-017-03-8 SCREW 1
240 4-30-46-024-00-5 SCREW 1
250 4-30-66-002-99-2 SCREW 1
300 3-37-57-040-00-0 GEAR WHEEL (6T) 1
300-301 5-3-203-001-11-2 ARMATURE (110V) 1
310 4-30-64-001-99-3 SCREW 3
330 4-17-01-001-17-2 BALL BEARING 2
340-370 3-15-06-142-01-1 INTERMEDIATE BEARING 1
360 3-16-04-003-00-4 BEARING 2
370 4-30-64-014-99-7 SCREW 1
380 3-15-08-100-00-2 OUTER BEARING 1
410 3-24-08-028-00-1 DRIVING PLATE 1
420 3-34-01-057-00-0 DRILL SHAFT 1
430 3-01-01-024-00-4 CLUTCH SLEEVE 1
440 4-02-38-017-00-4 CLAMPING SLEEVE 1
450 3-38-01-037-00-8 GEAR 1
460 3-38-01-036-00-4 GEAR WHEEL (46T) 1
470 3-09-01-009-00-1 COMPRESSION SPRING 1
480 3-24-07-025-00-9 DISC 1
490 3-34-16-004-00-1 COUNTERSHAFT 1
500 3-36-57-015-00-2 GEAR WHEEL (31T) 1
510 3-36-57-014-00-8 GEAR WHEEL (41T) 1
520 4-17-01-202-01-8 BALL BEARING 2
530 4-17-05-005-00-3 NEEDLE BUSHING 1
540 3-24-08-153-00-0 DISC 1
550 3-38-11-001-00-4 COUNTERSHAFT PINION (9T) 1
560 3-36-57-013-00-0 COUNTERSHAFT GEAR WHEEL (30T) 1
570 3-26-12-055-00-8 SEALING RING 1
580 4-30-02-029-99-0 SCREW 2
590 4-30-02-024-99-7 SCREW 2
591 4-24-43-002-99-2 SECURING DISC 4
