Festo CP-E16-M8 User manual

Compact Performance
CP Modules
Electronics
Only valid in agreement with the printed documentation
accompanying the product! Compare this edition code.

Author: S. Breuer
Translation: Douglas Smith
Editors: H.-J. Drung, M. Holder
Layout: Festo KG, Dept. PV-IDM
Type setting: PV-IDM
Edition: 9611A
1996 Festo KG, 73726 Esslingen
Federal Republic of Germany
All rights, including translation rights, are reserved. No
part of this publication may be reproduced or trans-
mitted in any form or by any means, (electronic, mech-
anical, photocopying or otherwise) without the prior
written permission of Festo KG.
CP..EA 9611A I

Part no. 165 225
Title: Manual
Designation: P.BE-CPEA-GB
II CP..EA 9611A

Content
Designated use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IV
Target group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . V
Important user instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . V
Information on this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . VII
Input module type CP-E16...-M...
1.1 Mode of operation of input modules CP-E16...-M... . . . . . . . . . . 1-3
1.1.1 Display and connecting elements . . . . . . . . . . . . . . . . . . . . . . . . 1-4
1.2 Fitting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
1.3 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
1.3.1 Connecting sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
1.3.2 Connecting the input module to the node . . . . . . . . . . . . . . . . . 1-19
1.4 Instructions on commissioning. . . . . . . . . . . . . . . . . . . . . . . . . . 1-21
1.5 Technical specifications CP-E16...-M... . . . . . . . . . . . . . . . . . . . 1-25
Output module type CP-A08...-M12
2.1 Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2.2 Fitting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
2.3 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
2.3.1 Connecting the actuators. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
2.3.2 Connecting the output module to the node . . . . . . . . . . . . . . . . 2-12
2.3.3 Connecting the load voltage. . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
2.4 Instructions on commissioning. . . . . . . . . . . . . . . . . . . . . . . . . . 2-15
2.5 Technical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17
Index
CP..EA 9611A III

Designated use
The CP modules described in this manual are desig-
nated exclusively for use in conjunction with the Festo
CP field bus node. The CP modules and CP cables
may only be used as follows:
- as intended for use
- in original condition
- without unauthorized modifications
- in faultless technical condition
If used in conjunction with commercially-available com-
ponents such as sensors and actuators, the specified
limit values for pressures, temperatures, electrical data,
torques etc. must be observed. Please comply also with
national and local safety laws and regulations.
All CP modules comply with protection class III.
WARNING
An isolating transformer as per EN 60742 (IEC 742,
DIN/VDE 0551) with at least 4 kV isolation resist-
ance is required for reliable electrical isolation of the
operating voltages.
IV CP..EA 9611A

Target group
This manual is directed exclusively at technicians who
are trained in control and automation technology.
Important user instructions
This manual contains instructions on the possible
dangers which may occur if the CP modules are not
used correctly. These instructions are always printed in
italics, are framed and also signalled by pictograms.
Danger
categories
A distinction is made between the following:
WARNING
This means that personal injury or damage to
property may occur if these instructions are not
observed.
CAUTION
This means that damage to property may occur if
these instructions are not observed.
PLEASE NOTE
This means that this instruction must also be ob-
served.
CP..EA 9611A V

Pictograms and symbols complement the danger warn-
ings and draw attention to the nature and conse-
quences of dangers.
Pictograms
The following pictograms are used:
Uncontrolled movements of loose tubing.
Unintentional movements of the connected actuators.
High voltages or undefined switching states of the elec-
tronic components which may influence connected cir-
cuits.
Electrostatically vulnerable components.
These will be damaged if you touch the contact sur-
faces.
•• This mark indicates activities which can be carried
out in any order.
Text
markings
1. Figures indicate activites which must be carried out
in the numerical order of the figures.
– Hyphens indicate general, non-compulsory activities.
VI CP..EA 9611A

Information on this manual
CP I/O modules are available both as PNP (positive
switching) and NPN (negative switching).
This manual contains specific information on the
method of operation, fitting, installation and com-
missioning of the following CP modules:
This manual refers to:
Input modules:
PNP
- CP-E16-M8
- CP-E16-M12x2
NPN
- CP-E16N-M8
- CP-E16N-M12x2
Output modules:
PNP
- CP-A08-M12
NPN
- CP-A08N-M12
Information on further CP modules as well as basic in-
formation on CP systems can be found in the manuals
described overleaf.
CP..EA 9611A VII

Manuals for the CP system Peripherals
Manual "CP system, Installation and commissioning"
Contents General, basic information on operating, fitting, installing
and commissioning CP systems.
Manual "CP field bus node,
programming and
diagnosing"
"CP valve
terminal,
pneumatics"
"CP modules,
electronics"
Contents Special information
on commissioning,
programming and
diagnosing related to
the node used.
Information on
fitting, installing
and commission-
ing CP valve
terminals
Information on
fitting,
installing and
commissioning
CP I/O modules
Fig. 0/1: CP system manuals
VIII CP..EA 9611A

Chapter 1
Input module type CP-E16...-M...
1. Input module type CP-E16...-M...
CP-E16...-M... 9611A 1-1

Contents
Input module type CP-E16...-M...
1.1 Mode of operation of input modules CP-E16...-M.... . . . . . . . . . 1-3
1.1.1 Display and connecting elements. . . . . . . . . . . . . . . . . . . . . . . . 1-4
1.2 Fitting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
1.3 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
1.3.1 Connecting sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
1.3.2 Connecting the input module to the node . . . . . . . . . . . . . . . . 1-19
1.4 Instructions on commissioning . . . . . . . . . . . . . . . . . . . . . . . . . 1-21
1.5 Technical specifications CP-E16...-M... . . . . . . . . . . . . . . . . . . 1-25
1. Input module type CP-E16...-M...
1-2 CP-E16...-M... 9611A

1.1 Mode of operation of input modules CP-E16...-M...
The CP input modules contain digital inputs for con-
necting sensors, thereby enabling e.g. cylinder positions
to be interrogated. A distinction is made between the
following types:
Type Explanation
CP-E16-M12X2
CP-E16N-M12X2
Provides 16 PNP inputs;
sensor connections via 8 sockets with
M12 thread
Provides 16 NPN inputs;
sensor connections via 8 sockets with
M12 thread
CP-E16-M8
CP-E16N-M8
Provides 16 PNP inputs;
sensor connections via 16 sockets with
M8 thread
Provides 16 NPN inputs;
sensor connections via 16 sockets with
M8 thread
1. Input module type CP-E16...-M...
CP-E16...-M... 9611A 1-3

1.1.1 Display and connecting elements
The diagram below shows the display and connecting
elements using the example of input module
CP-E16-M12x2.
1
2
3
Designation for input type:
- INPUT-P for PNP inputs
- INPUT-N for NPN inputs
Sensor connections
Green LED for status display
(one LED per input)
4
5
6
7
8
9
Status LED (green)
CP connection
Protective cap
Groove for inscription signs (ISB 6x10)
Functional earthing
Type plate
Fig. 1/1: Display and connecting elements
2
6
4
3
5
7
9
1
8
1. Input module type CP-E16...-M...
1-4 CP-E16...-M... 9611A

1.2 Fitting
Input modules are intended for fitting onto walls or hat
rails. For fitting them onto walls you will require the fol-
lowing surface areas:
Type Surface area
CP-E16-M8 approx. 150 x 66 mm2
CP-E16-M12x2 approx. 141 x 78 mm2
The diagram below shows the dimensions of the four
threaded holes of screw size M4.
Fitting on
a wall
1
2
Input module, type CP-E16...-M12x2
Input module, type CP-E16...-M8
Fig. 1/2: Fitting dimensions CP-E16...-M...
139.9 mm
63 mm
40 mm
131.9 mm
2
1
1. Input module type CP-E16...-M...
CP-E16...-M... 9611A 1-5

PLEASE NOTE
For fitting the modules onto a hat rail you will require
fastening kit CP-TS-HS35. This kit contains 2 fasten-
ings, 2 M4x12 screws and 2 washers.
In order to fit the modules onto a hat rail, proceed as
follows:
Fitting onto a
hat rail
1. Make sure that the fastening surface can support
the weight of the module.
2. Fit a hat rail (support rail EN 50022 - 35x15; width
35 mm, height 15 mm).
3. Fasten the hat rail at least every 100 mm to the sup-
port surface.
4. Let both fastenings on the hat rail snap into the
module (see Fig. 1/3).
5. Screw the housing on to the fastening with the
screws supplied as shown in the diagram below.
6. Tighten the screws. The fastening and the housing
will then be clamped tight on the hat rail.
1. Input module type CP-E16...-M...
1-6 CP-E16...-M... 9611A

1
2
3
4
5
Fastening
Hat rail
Housing
M4x12 screw
Washer
Fig. 1/3: Fitting on a hat rail
In order to remove the module from a hat rail, proceed
as follows:
1. Loosen the screws.
2. Remove the housing.
3. Use a screwdriver to prize open the hat rail and
remove the module.
1
2
Fastening
Screwdriver
Fig. 1/4: Removing the module
1
2
12
3
5
4
1. Input module type CP-E16...-M...
CP-E16...-M... 9611A 1-7

1.3 Installation
WARNING
Before undertaking installation work, switch off
the following:
- the power supply to the CP field bus node
- the power supply to all the output modules.
You thereby avoid:
– unintentional movements of the connected
actuators.
– undefined switching states of the
electronic components.
WARNING
Connect a protective earth cable to the functional ear-
thing contact (see Fig. 1/1).
You thereby avoid:
– interference caused by electromagnetic sources.
1. Input module type CP-E16...-M...
1-8 CP-E16...-M... 9611A

1.3.1 Connecting sensors
Use the following cable and plugs for connecting the
sensors.
Type Plug Cable
CP-E16-M12x2 PG7 KM12-DUO-...
CP-E16-M8 Use the plug with
union nut with
thread M8x1.
KM8-M8-GSGD-...
Fasten the plugs with the aid of the union nuts in order
to avoid unintentional loosening e.g. due to vibration.
Seal the unused sensor connections with the protective
caps supplied. Only then is compliance with class of
protection IP65 ensured.
1. Input module type CP-E16...-M...
CP-E16...-M... 9611A 1-9

Pin assignment
The diagram below shows the pin assignment of the
sensor connections as an example.
1
2
Input module type CP-E16...-M12x2
Input module type CP-E16...-M8 E = Input
Fig. 1/5: Pin assignment of input module
Ex+3
Ex
Ex+2
Pin 3: 0V
Pin 4: Ex
Pin 1: 24V
Pin 1: 24V
Pin 4: Ex+2
Pin 3: 0V
Pin 2: Ex+3
Ex+1
Pin 1: 24V
Pin 3: 0V
Pin 2: Ex+1
Pin 2: Ex
Pin 3: 0V
Pin 1: 24V
Ex+1
Ex
Pin 2: Ex+1
2
1
1. Input module type CP-E16...-M...
1-10 CP-E16...-M... 9611A

Internal layout of CP-E16-M8 (PNP inputs)
1
2
3
PLC/I-PC Ex (e.g. via field bus)
Logic recognition Ex
Green LED Ex
Fig. 1/6: Internal layout of input module CP-E16-M8
24 V +10/-15%
2
Pin 1
Pin 2
Pin 3
3
1
0V
1. Input module type CP-E16...-M...
CP-E16...-M... 9611A 1-11
