Festo CDPX-X-E2-W-5-EX2 User manual

100442
Application Note
CDPX-X-E2-W-5-EX2
Manual
This Application Note describes the main features of the Festo operator
panels. The manual refers to the following model CDPX-X-E2-W-5-EX2.
This operational guidelines described below is information which re-
lates to the device, installation, transportation, storage, assembly, use
and maintenance.
CDPX-X-E2-W-5-EX2

Title ............................................................................................................................. CDPX-X-E2-W-5-EX2 Manual
Version ............................................................................................................................................................. 1.30
Document no. .............................................................................................................................................. 100442
Original ................................................................................................................................................................ EN
Author .............................................................................................................................................................Festo
Last saved ............................................................................................................................................ 09.03.2023
Copyright Notice
This documentation is the intellectual property of Festo SE & Co. KG, which also has the exclusive copyright. Any
modification of the content, duplication or reprinting of this documentation as well as distribution to third par-
ties can only be made with the express consent of Festo SE & Co. KG.
Festo SE & Co KG reserves the right to make modifications to this document in whole or in part. All brand and
product names are trademarks or registered trademarks of their respective owners.
Legal Notice
Hardware, software, operating systems and drivers may only be used for the applications described and only in
conjunction with components recommended by Festo SE & Co. KG.
Festo SE & Co. KG does not accept any liability for damages arising from the use of any incorrect or incomplete
information contained in this documentation or any information missing therefrom.
Defects resulting from the improper handling of devices and modules are excluded from the warranty.
The data and information specified in this document should not be used for the implementation of safety func-
tions relating to the protection of personnel and machinery.
No liability is accepted for claims for damages arising from a failure or functional defect. In other respects, the
regulations with regard to liability from the terms and conditions of delivery, payment and use of software of
Festo SE & Co. KG, which can be found at www.festo.com and can be supplied on request, shall apply.
All data contained in this document do not represent guaranteed specifications, particularly with regard to func-
tionality, condition or quality, in the legal sense.
The information in this document serves only as basic information for the implementation of a specific, hypo-
thetical application and is in no way intended as a substitute for the operating instructions of the respective
manufacturers and the design and testing of the respective application by the user.
The operating instructions for Festo products can be found at www.festo.com .
Users of this document (application note) must verify that all functions described here also work correctly in the
application. By reading this document and adhering to the specifications contained therein, users are also solely
responsible for their own application.
©(Festo SE & CO. KG, D-73726 Esslingen, 2023)
Internet: http://www.festo.com

Application Note –CDPX-X-E2-W-5-EX2 Page 3 of 24
Table of contents
1
1Components/Software used....................................................................................................................... 5
1.1Software Used ............................................................................................................................................. 5
1.2 Hardware Used............................................................................................................................................ 5
2APPLICATION NOTE DESCRIPTION ............................................................................................................. 6
3Product Overview........................................................................................................................................ 7
4Standards and Approvals ........................................................................................................................... 8
5Product Identification ................................................................................................................................. 9
6Technical Specifications........................................................................................................................... 10
7Technical Data .......................................................................................................................................... 13
7.1 Dimensions ............................................................................................................................................... 14
7.2 Installation Environment and Procedure ................................................................................................... 15
7.3 Safety instructions .................................................................................................................................... 16
8Connections .............................................................................................................................................. 17
9Power Supply, Grounding and Shielding ................................................................................................. 18
10 Battery ...................................................................................................................................................... 19
11 Special Instructions for Use ..................................................................................................................... 20
12 Getting Started ......................................................................................................................................... 21
13 System Settings........................................................................................................................................ 22
14 Unpacking and Packing instructions........................................................................................................ 24

Components/Software used
Application Note –CDPX-X-E2-W-5-EX2 Page 5 of 24
1Components/Software used
1.1 Software Used
Type/Name
Software Version
Festo Designer Studio
V4.5.0.224
Table 1.1: Software used
1.2 Hardware Used
Type/Name
Firmware Version
CDXP-X-E2-W-5-EX2
Config-OS 1.3.638
Main-OS 1.3.638
Bootloader 1.0.11
EtherNet Cables
NEBC-R3G8M22-K-3-N-S-R3G8
NEDU-L2R1-R3U1G12-5L1-1L2-K-
R3L1G12M22
Table 1.2: Hardware used

APPLICATION NOTE DESCRIPTION
Page 6 of 24 Application Note –CDPX-X-E2-W-5-EX2
2APPLICATION NOTE DESCRIPTION
The manual contains safety standards that must be respected for the personal safety and to
avoid damage. Indications of attention are divided into three levels of severity:
DANGER: indicates a failure to observe safety rules and such failure may cause death or seri-
ous injuries.
ATTENTION: indicates a failure to observe safety rules and that deficiency may cause damage.
CAUTION: indicates a failure to observe safety rules and that deficiency may cause defects to
the equipment or inconsistencies.

!
DANGER
!
ATTENTION
CAUTION

Product Overview
Application Note –CDPX-X-E2-W-5-EX2 Page 7 of 24
3Product Overview
Festo CDPX products are ideal for field installation in critical areas. High-resolution displays
and multitouch PCAP touchscreen with a robust glass front.
Power-over-Ethernet (PoE) for maximum simplicity of connection using standard
shielded CAT 5 wiring. Full IP protection with the use of dedicated connectors for the
maximum flexibility of installation, from mounting arm to a simple M22 hole. The prod-
uct includes environment and motion sensors to make this device a true IIoT edge de-
vice for Industry 4.0 applications.
The CDPX product family has been optimized for use as an embedded browser or as a Designer
Studio HMI device.
•Open platform for Linux applications
•Performing HTML5-compatible browser with graphic accelerator
•Designer Studio runtime with OPC UA Server and Client
•Optional CODESYS V3 PLC for integrated HMI and control applications
•Built-in sensors (temperature and acceleration)

Standards and Approvals
Page 8 of 24 Application Note –CDPX-X-E2-W-5-EX2
4Standards and Approvals
The products have been designed for use in an industrial environment in compliance
with the 2014/30/EU EMC Directive.
The products have been designed in compliance with:
EN 61000-6-4 CISPR 22 Class B
EN 61000-6-3 CISPR 16-2-3
EN 61000-6-2 EN 61000-4-2
EN 61000-6-1 EN 61000-4-3
EN 61000-4-4
EN 61000-4-5
EN 61000-4-6
EN 61000-4-8
The installation of these devices in residential, commercial and light industrial envi-
ronments may require special measures to ensure compliance with EN 61000-6-3.
The products are in compliance with the Restrictions on Certain Hazardous Sub-
stances (RoHS) Directive 2011/65/EU
In compliance with the above regulations the products are CE marked.

Product Identification
Application Note –CDPX-X-E2-W-5-EX2 Page 9 of 24
5Product Identification
The product may be identified by the indications in the back cover. You will have to know the
type of unit you are using for correct usage of the information contained in the guide.
An example of the information reported is shown below:
product name CDPX-X-E2-W-EX2
part number 8155219
year/week of production xx/yy
serial number AA00012P8000000561AA
approvals CE / UL / C-Tick / …

Technical Specifications
Page 10 of 24 Application Note –CDPX-X-E2-W-5-EX2
6Technical Specifications
Touchscreen technology Projected capacitive –Multitouch
Back-up battery 3V 7mAh Vanadium-Lithium, rechargeable,
not user replaceable, model VL1220.
Flash 4GB
RAM 1GB
Hardware clock Clock/Calendar with back-up battery
Accuracy RTC (at 25°C) <100ppm
Environmental conditions
Operating temperature (surround-
ing air temperature)
-20 - +55°C (vertical installation)
EN-60068-2-14
Storage temperature
-30 - +80°C
EN 60068-2-1
EN 60068-2-2
EN 60068-2-14
Operating and storage humidity
5 - 85 % RH not-condensing
EN 60068-2-30
Vibrations
9 –150 Hz, 1 g
5 - 9 Hz, 7 mm p-p
EN 60068-2-6
Shock
± 50 g, 11 ms, 3 pulses per axis
EN60068-2-27
Protection class
IP67 (requires appropriate connectors
and cables)
EN 60529
Electromagnetic Compatibility (EMC)
Radiated disturbance test
Class B
CISPR 22
CISPR 16-2-3
Electrostatic discharge immunity test
8 kV (air electrostatic discharge)
4 kV (contact electrostatic discharge)
EN 61000-4-2
Radiated, radio-frequency,
electromagnetic field immnity test
80 MHz ÷ 1 GHz, 10V/m
1,4 GHz ÷ 2 GHz, 3 V/m
2 GHz ÷ 2.7 GHz, 1 V/m
EN 61000-4-3
Burst immunity test
± 2 KV dc power port
± 1 KV signal line
EN 61000-4-4
Surge immunity test
± 0,5 KV dc power port (line to earth)
± 0,5 KV dc power port (line to line)
± 1 KV signal line (line to earth)
EN 61000-4-5
Immunity to conducted disturbances
inducted by radiofrequency field
0.15 –80 MHz, 10V
EN 61000-4-6
Power frequency magnetic field
immunity test
Enclosure, 50/60Hz, 30A/m
EN 61000-4-8

Technical Specifications
Application Note –CDPX-X-E2-W-5-EX2 Page 11 of 24
Durability information
Backlight service life 40000 Hrs. or more
(LED type) (Time of continuous operation until the brightness
of the backlight reaches 50% of the rated value when
the surrounding air temperature is 25°C) - see Note 1
Note 1: Extended use in environments where the surrounding air temperature is 40°C or higher may
degrade backlight quality/reliability/durability.
Viewing angles
For the viewing angles values (U,D,R,L) of the display types, see the technical data of the respective
device.
The viewing angles are specified for the horizontal (L,R) and vertical (U,D) axes in reference to the
vertical axis of the display.
The specified viewing angles above always refer to the standard mounting orientation.
Legend:
Display viewing angle
U
From top
D
From bottom
L
From left
R
From right

Technical Specifications
Page 12 of 24 Application Note –CDPX-X-E2-W-5-EX2
Surface resistance
Chemical resistance of the front glass for an exposure time of 24 hours without visible changes:
•Betadine (10% Povidone Solution)
•Cola
•Electrode Gel/Paste
•Hydrogen Peroxide (3% Solution)
•NaCl (0.9% Solution)
•Coffee
•Dextrose (5% Glucose Solution)
•Hydrogen chloride (0.5% Solution PH=1)
•Isopropyl Alcohol
•Sodium Hypochlorite
•Ethyl Alcohol (70%-90%)
•Quaternary ammonium compound
Properties multitouch PCAP touchscreen
Operation with gloves
Projected capacitive touch screens (PCAP) are suitable for operation with or without gloves.
A large number of gloves (rubber gloves, light/heavy leather gloves, disposable latex gloves, etc.) are
supported.
Due to the variety of commercially available gloves, however, FESTO cannot guarantee all types
Number of fingers
5
Glove operation
Yes
Passive stylus pens
Yes
Active stylus pens
No
Hardened front glass
Yes

Technical Data
Application Note –CDPX-X-E2-W-5-EX2 Page 13 of 24
7Technical Data
Model
CDPX-X-E2-W-EX2
Display / Backlight
TFT Colour / LED
Colours
16M
Resolution
800 x 480
Diagonal (inches)
5” widescreen
Viewing angles horizontal
Direction L / Direction R Typ. 70°
Viewing angles vertical
Direction U Typ. 50° / Direction D Typ. 70°
Dimming
yes to 0%
CPU
ARM Cortex-A9 dual core 800 MHz
Operating System
Linux RT
Flash
4GB
RAM
1GB
Ethernet port
10/100 PoE 802.3af/at
USB port
1 (Host V2.0, request special connector)
Battery
rechargeable
Real Time Clock
yes
Power supply
802.3af
Current consumption
6W
Weight
0.5 Kg

Technical Data
Page 14 of 24 Application Note –CDPX-X-E2-W-5-EX2
7.1 Dimensions
MODEL
A
B
C
D
CDPX-X-E2-W-EX2
105.1mm/4.13”
148.3mm/5.83”
16,5mm/0.64”
17mm/0.66”
Rear view

Technical Data
Application Note –CDPX-X-E2-W-5-EX2 Page 15 of 24
7.2 Installation Environment and Procedure
Avoid prolonged exposition to direct sunlight to avoid the risk of overheating the device.
The equipment is not intended for installation in contact with corrosive chemical compounds. Check
the resistance of the front panel to a specific compound before installation.
Do not use tools of any kind (screwdrivers, etc.) to operate the touch screen of the panel.
IP67 is guaranteed only if a NEBC-R3G8M22-K-3-N-S-R3G8 cable is used and if:
•max deviation from the plane surface to the cut-out: <=.5mm
•thickness of the case where is mounted the equipment: from 1,5mm to 3mm
•max surface roughness where the gasket is applied: O120 um
D
Usable cable
Max 3mm
NEBC-R3G8M22-K-3-N-S-R3G8
(IP67)
Max 10mm
Standard Ethernet

CAUTION
Tightening torque: 1000Ncm for nut, 130Ncm for screws

Technical Data
Page 16 of 24 Application Note –CDPX-X-E2-W-5-EX2
7.3 Safety instructions

Connections
Application Note –CDPX-X-E2-W-5-EX2 Page 17 of 24
8Connections
Ethernet Port
Reserved
The Ethernet port has two status indicators. Please see description in figure
RED GREEN
Pin
Description
1
TX+
2
TX-
3
RX+
4
n/c
5
n/c
6
RX-
7
n/c
8
n/c
Red
Green
OFF: Valid link has not been detected
ON: No activity
ON: Valid link has been detected
Blinking: Activity

Power Supply, Grounding and Shielding
Page 18 of 24 Application Note –CDPX-X-E2-W-5-EX2
9Power Supply, Grounding and Shielding
The power supply terminal block is shown in the figure below
Use a shielded CAT 5 cable or higher
Note: Ensure that the power supply has enough power capacity for the operation of the equipment
The unit must always be grounded to earth with shielded CAT 5 cable. Grounding helps limit the ef-
fects of noise due to electromagnetic interference on the control system.
The earth connection can also be made using the screws located near the connector.
A label helps identify the ground connection.
All the electronic devices in the control system must be properly grounded. Grounding must be per-
formed according to applicable regulations.

Battery
Application Note –CDPX-X-E2-W-5-EX2 Page 19 of 24
10 Battery
These devices are equipped with rechargeable Lithium battery, not user-replaceable.
The following information is maintained by the battery: hardware real-time clock (date and time)
Charge:
At first installation must be charged for 48 hours.
When the battery is fully charged, it ensures a period of 3 months of date and time back-up at 25°C.
Battery

Special Instructions for Use
Page 20 of 24 Application Note –CDPX-X-E2-W-5-EX2
11 Special Instructions for Use
•The equipment shall only be used in an area of not more than pollution degree 2, as defined in
IEC/EN 60664-1.
•The equipment shall be installed in an enclosure that provides a degree of protection not less
than IP 54 in accordance with IEC/EN 60079-15.
•Transient protection shall be provided that is set at a level not exceeding 140 % of the peak
rated voltage value at the supply terminals to the equipment.
•Install the HMI device according to the accompanying installation instructions.
•Ground the HMI device according to the accompanying installation instructions.
•Only qualified personnel may install the HMI device or repair it.
•Care shall be taken not to allow layers of dust to form on the graphic panel in a way that might
cause the accumulation of static charges. Keep the faceplate of the HMI device clean: the
equipment must be cleaned only with a soft cloth and neutral soap product. Do not use sol-
vents.
•This device should not be used for purposes and methods other than indicated in this docu-
ment and in the documentation accompanying the product.
