Feurst Turnkey Series User manual

TURNKEY® pins Installation and Removal,
TURNKEY® Range.
Assembly instructions
Equipment : The use of the TK13OD tool is
recommended for turnkey teeth assembly/
disassembly.
Always work safely and wear your safety
equipment (hard hat, steel-toed shoes,
gloves, safety glasses).
Keep bystanders away.
Cleaning : Tilt the bucket 30° upwards.
Before inserting turnkey sleeve in its hou-
sing, we recommend to clean the adapter
sleeve housing as well as the adapter nose
to make sure the sleeve will be correctly
positioned into the sleeve housing.
Sleeve insertion : Manually insert the
sleeve. You will notice on the sleeve & the
adapters some notches to make sure to
respect the sleeve insertion direction.
We now advise you to grab TK13OD® tool to
proceed for installation.
6
Sleeve insertion (2): We advise to use the
TK13OD® to fully push the sleeve into its
housing.
Tooth assembly : Firstly install Turnkey®
wear cap on top of the adapter, then install
the tooth on the adapter.
Pin insertion : Once the teeth is correctly
installed on the adapter, insert TK13CL® pin
into the key hole while respecting the inser-
tion direction (pin head down), then push it
to the end.
The pin as well as the sleeve have mechani-
cal codings to avoid any incorrect insertion.
Pin clamping : Once the pin has been
correctly installed, take TK13 OD® tool
to screw the pin. Make sure to push the
pin into the sleeve with the tool before
screwing and then make a 180°
counterclockwise pin turn.
Correct positioning : Pin is correctly
installed when you hear a “clac” sound
informing of correct pin lockings.
Correct locking : After the “clac” sound,
the pin will be locked as shown.
The pin rotation is fully completed, the pin
cannot be turned any further.
FEURST
Boulevard de la Boissonnette - 42110 - FEURS
Tel : [phone]
Fax : [phone]
Clac !!
30°
Protective caps installation : On both teeth
sides, insert the protective caps to avoid
nes to ll up the pin hole. (Left cap is
TK13CPL and right cap is TK13CPR). These
protective caps will allow you to decrease
teeth replacement time.
Pin insertion (2): Before pin clamping, the
pin should be in “head down” position.
Correct locking (2): Once the pin has been
correctly installed and locked, the pin
should be in “head on top” position.
1 2 3
754
8 9 10 11

TURNKEY® pins Installation and Removal,
TURNKEY® Range. ®
Disassembly instructions
Equipment : The use of TK13OD® tool is re-
commended for turnkey teeth disassembly.
Always work safely and wear your safety
equipment (hard hat, steel-toed shoes,
gloves, safety glasses).
Keep bystanders away.
Protective caps removal : Remove both
Left/right protective caps thanks to TK13
OD® tool.
If there is no cap, remove nes from pin
head hole to make sure the TK13 OD® tool
will correctly t into the pin head hole.
Pin unlocking : Once TK13OD® tool is
inserted into the pin, unlock the pin with a
180° clockwise turn.
You will hear a “clac” sound conrming
the pin was successfully unlocked.
Pin removal : Using TK13OD® tool, remove
the pin from the teeth/sleeve. You can also
remove the pin manually.
Teeth removal : Once the pin is removed,
you can easily remove teeth & adapter
wear cap.
Sleeve removal : To remove the sleeve, use
TK13OD® at side and manually push the
sleeve from adapter left side.
Sleeve removal (2) : Once the plug is par-
tially removed, you can complete removal
manually.
FEURST
Boulevard de la Boissonnette - 42110 - FEURS
Tel : [phone]
Fax : [phone]
Cleaning : Clean up the adapter nose,
sleeve housing and wear cap dovetail
guidance.
We advise to use a new pin and a new
sleeve for next teeth installation.
