MICRO-EPSILON scanCONTROL 25 Series User manual

MICRO-EPSILON MESSTECHNIK GmbH & Co. KG
Koenigbacher Str. 15 · 94496 Ortenburg / Germany
Tel. [phone] / 168-0 · Fax [phone] / 168-90
[email protected] · www.micro-epsilon.com
Your local contact: www.micro-epsilon.com/contact/worldwide/
LLT2500-25
LLT2500-50
LLT2500-100
LLT2510-25
LLT2510-50
LLT2510-100
LLT2500-25/BL
LLT2500-50/BL
LLT2500-100/BL
LLT2510-25/BL
LLT2510-50/BL
LLT2510-100/BL
Operating Instructions
scanCONTROL 25xx

MICRO-EPSILON
MESSTECHNIK
GmbH & Co. KG
Koenigbacher Str. 15
94496 Ortenburg / Germany
Tel. [phone] / 168-0
Fax [phone] / 168-90
[email protected]
www.micro-epsilon.com
Laser scanner

scanCONTROL 25xx
Contents
1. Safety ........................................................................................................................................ 7
1.1 Symbols ........................................................................................................................................................... 7
1.2 Warnings.......................................................................................................................................................... 7
1.3 Notes on CE Marking ...................................................................................................................................... 8
1.4 Intended Use ................................................................................................................................................... 9
1.5 Proper Environment......................................................................................................................................... 9
2. Laser Safety............................................................................................................................ 10
2.1 General .......................................................................................................................................................... 10
2.2 Laser Class 2M .............................................................................................................................................. 11
2.3 Laser Class 3B............................................................................................................................................... 12
3. Functional Principle, Technical Data ..................................................................................... 14
3.1 Short Description........................................................................................................................................... 14
3.1.1 Measuring Principle ..................................................................................................................... 14
3.1.2 System Setup ............................................................................................................................... 14
3.1.3 Special Performance Features..................................................................................................... 15
3.1.4 Advantages................................................................................................................................... 15
3.2 Technical Data ............................................................................................................................................... 16
3.3 LED Displays.................................................................................................................................................. 18
4. Delivery ................................................................................................................................... 19
4.1 Unpacking...................................................................................................................................................... 19
4.2 Storage .......................................................................................................................................................... 19
5. Mounting and Installation ...................................................................................................... 20
5.1 Attachment and Mounting ............................................................................................................................ 20
5.2 Connections................................................................................................................................................... 25
5.2.1 General ......................................................................................................................................... 25
5.2.2 Power Supply .............................................................................................................................. 26
5.2.3 RS422, Synchronization............................................................................................................... 27
5.2.4 Switching Inputs ........................................................................................................................... 29
5.2.5 Ethernet Connection .................................................................................................................... 31
5.2.6 External Laser Switching (optional) ............................................................................................. 33
5.3 Installation Instructions.................................................................................................................................. 34
5.4 Getting Ready for Operation, Commissioning.............................................................................................. 34

scanCONTROL 25xx
6. Operation of the Measuring System with a PC..................................................................... 35
6.1 Displays ......................................................................................................................................................... 35
6.2 Operating and Demonstration Programs...................................................................................................... 35
6.3 Installation...................................................................................................................................................... 36
6.3.1 Requirements ............................................................................................................................... 36
6.3.2 Connecting scanCONTROL 25xx to the PC ............................................................................... 36
6.4 Instructions for Operation.............................................................................................................................. 37
6.4.1 Measuring Field Selection............................................................................................................ 37
6.4.2 Calibration .................................................................................................................................... 40
6.4.3 Automatic Exposure Time Regulation.......................................................................................... 41
6.5 Error Influences.............................................................................................................................................. 43
6.5.1 Reflection of the Target Surface ................................................................................................... 43
6.5.2 Color Differences.......................................................................................................................... 43
6.5.3 Temperature Influences................................................................................................................ 44
6.5.4 External Light................................................................................................................................ 44
6.5.5 Mechanical Vibrations .................................................................................................................. 44
6.5.6 Surface Roughness...................................................................................................................... 44
6.5.7 Shadowing Effects........................................................................................................................ 45
6.6 Cleaning......................................................................................................................................................... 46
7. 2D/3D Output Unit .................................................................................................................. 47
7.1 2D/3D Output Unit - Components ................................................................................................................. 48
7.2 Connect the Power Supply............................................................................................................................ 49
7.3 Commissioning 2D/3D Output Unit............................................................................................................... 50
7.4 Specification of the Components .................................................................................................................. 51
7.4.1 2D/3D Output Unit Basic ............................................................................................................. 51
7.4.2 Supported Modules...................................................................................................................... 52
7.4.3 OU-DigitalOut/8-Channel/DC24 V/0.5 A/High-side Switching/8 Actuators ................................. 53
7.4.4 OU-AnalogOut/4-Channel/0-10 V................................................................................................. 54
8. 2D/3D Gateway ....................................................................................................................... 55
9. Liability for Material Defects.................................................................................................. 56
10. Service, Repair ....................................................................................................................... 56
11. Decommissioning, Disposal .................................................................................................. 57
12. Error Codes ............................................................................................................................ 58

scanCONTROL 25xx
Appendix
A 1 Accessories ............................................................................................................................ 60
A 1.1 Recommended Accessories ......................................................................................................................... 60
A 1.2 Optional Accessories..................................................................................................................................... 61

Page 7
Safety
scanCONTROL 25xx
1. Safety
Sensor operation assumes knowledge of the operating instructions.
1.1 Symbols
The following symbols are used in these operating instructions.
Indicates a hazardous situation which, if not avoided, may result in minor or mode-
rate injury.
Indicates a situation that may result in property damage if not avoided.
Indicates a user action.
iIndicates a tip for users.
Measure Indicates hardware or a software button/menu.
1.2 Warnings
Avoid unnecessary laser radiation to be exposed to the human body.
Switch off the sensor for cleaning and maintenance.
Switch off the sensor for system maintenance and repair if the sensor is integrated into a system.
Caution - use of controls or adjustments or performance of procedures other than those specified may cause
harm.
Connect the power supply and the display-/output device according to the safety regulations for electrical
equipment
> Risk of injury
> Damage to or destruction of the sensor
Avoid shocks and impacts to the sensor.
> Damage to or destruction of the sensor

Page 8
Safety
scanCONTROL 25xx
The supply voltage must not exceed the specified limits.
> Damage to or destruction of the sensor
Avoid continuous exposure to dust and spray on the sensor by appropriate methods such as blowing or us-
ing a protective housing.
> Damage to or destruction of the sensor
Do not touch the protective windows of the optics with the fingers. Remove any fingerprints immediately us-
ing pure alcohol and a clean cotton cloth without leaving any streaks, see 6.6.
Protect the cable against damage.
> Failure of the measuring device
Do not plug or unplug devices during the operation.
1.3 Notes on CE Marking
The following apply to the scanCONTROL 25xx measuring system:
- EU Directive 2014/30/EU
- EU Directive 2011/65/EU
Products which carry the CE mark satisfy the requirements of the EU directives cited and the relevant appli-
cable harmonized European standards (EN). The measuring system is designed for use in industrial environ-
ments.
The EU Declaration of Conformity and the technical documentation are available to the responsible authori-
ties according to EU Directives.

Page 9
Safety
scanCONTROL 25xx
1.4 Intended Use
- The scanCONTROL 25xx sensor is designed for use in industrial and laboratory applications.
- It is used for
Profile measurement
Length measurement
Quality monitoring and inspection of dimensions
- The sensor must only be operated within the limits specified in the technical data, see 3.2.
- The sensor must be used in such a way that no persons are endangered or machines and other material
goods are damaged in the event of malfunction or total failure of the sensor.
- Take additional precautions for safety and damage prevention in case of safety-related applications.
1.5 Proper Environment
- Protection class for sensors: IP65 (applies only when connected output connectors or protective caps)
- Temperature range:
Operation: 0 ... +45 °C (+32 ... +113 °F) (with free air circulation)
Storage: -20 ... +70 °C (-4 ... +158 °F)
- Ambient pressure: Atmospheric pressure
- Humidity: 5 - 95 % (non-condensing)
The protection class does not apply for the optical sections during operation as their soiling / contamination
results in adversely affecting or failure of the function.
Only use shielded cables or original cables from the range of accessories for the connection to a power
supply and for the outputs.
Note also the assembly and installation instructions, see 5.
The IP65 protection class is a specification which is limited to the protection with respect to dust and water.
Oil, steam and emulsion penetration are not included in this protection class and must be tested separately.

Page 10
Laser Safety
scanCONTROL 25xx
2. Laser Safety
2.1 General
The scanCONTROL 25xx sensors operate with a semiconductor laser having a wavelength of 658 nm (visible/
red) resp. 405 nm (visible/blue).
The laser operation is indicated visually by the LED on the sensor.
When operating the scanCONTROL 25xx sensors, the relevant regulations according to IEC 60825, Part 1 of
05/2014 and the applicable accident prevention regulations must be followed.
The laser warning labels for Germany have already been attached. For other non German speaking coun-
tries, an IEC standard label is included in delivery and the versions valid for the user’s country must be at-
tached before the device is put into operation for the first time.
iIf both warning labels are covered over when the unit is installed, the user must ensure that supplemen- tary labels are applied.
Laser Operation is indicated by LED, see 3.3.
The housings of the scanCONTROL 25xx optical sensors must only be opened by manufacturer, see 9.
For repair and service purposes, the sensors must always be sent to the manufacturer.
LASER RADIATION
DO NOT STARE INTO BEAM
OR EXPOSE USERS OF
TELESCOPE OPTICS
CLASS 2M LASER PRODUCT
IEC 60825-1: 2014
P≤8mW, P ≤8mW; H ≤52W/m²;
0 P
λ = 658nm; F = 0...4kHz, t = 1µ s... ∞
scanCONTROL
COMPLIES WITH 21 CFR 1040.10
AND 1040.11 EXCEPT FOR
CONFORMANCE WITH IEC 60825-1
ED. 3., AS DESCRIBED IN LASER
NOTICE NO. 56, DATED MAY8, 2019.
Fig. 1 Sensor with laser labels

Page 11
Laser Safety
scanCONTROL 25xx
2.2 Laser Class 2M
The sensors fall within laser class 2M. The laser is operated in a pulsed mode, the maximum optical power is
≤8mW.Thepulsefrequencydependsontheadjustedmeasuringrate(0...4kHz).Thepulsedurationcan
be 1 µs up to infinite.
iObserve the laser protection regulations.
Accordingly, the following applies:
Laser equipment of the Class 2M can be employed without further protective measures, when deliberate
viewing into the laser beam or into a beam reflected by mirrors is not longer than 0.25 s. Directly looking into
the beam can be dangerous, if the eye-closure reflex is consciously suppressed, e.g., during adjusting. Di-
rectly looking into the beam with optical devices, such as magnifying glasses, is dangerous. Since generally
the presence of the eye-closure reflex should not be assumed, one should close the eyes or immediately turn
away if the laser radiation impinges on the eye.
Lasers of Class 2M are subject to notification and a laser protection officer is not required.
Attach the following warning labels to the cover (front and rear side) of the housing:
LASER RADIATION
DO NOT STARE INTO BEAM
OR EXPOSE USERS OF
TELESCOPE OPTICS
CLASS 2M LASER PRODUCT
IEC 60825-1: 2014
P≤8 mW , P ≤8 mW ; H≤52 W/m²;
0 P
λ= 658 nm; F = 0...4 kHz, t = 1 µs...∞
Fig. 2 Laser warning sign and laser label,
LLT 25xx-25, 25xx-50, 25xx-100
Fig. 3 Laser warning sign and laser label,
LLT 25xx-25/BL, 25xx-50/BL, 25xx-100/BL
COMPLIES WITH 21 CFR 1040.10 AND 1040.11
EXCEPT FOR CONFORMANCE WITH
IEC 60825-1 ED. 3., AS DESCRIBED IN
LASER NOTICE NO. 56, DATED MAY 8, 2019
Fig. 4 Only for USA
Mark the laser area recognizable and everlasting.
Laser radiation. Close
your eyes or immedi-
ately turn away if the
laser beam hits the eye.
Irritation or injury of the
eyes possible.

Page 12
Laser Safety
scanCONTROL 25xx
2.3 Laser Class 3B
The sensors within laser class 3B. The laser is operated on a pulsed mode, the maximum optical power is
≤50mW.Thepulsefrequencydependsontheadjustedmeasuringrate(0...4kHz).Thepulsedurationcan
be 1 µs up to infinite.
iObserve the laser protection regulations.
iSensors of laser class 3B require an external key switch to switch off the laser, see 5.2.6.
Accordingly, the following applies: The accessible laser radiation is harmful to the eyes, and often also for the
skin. Looking directly into the laser beam is harmful to the eyes. Reflections of shiny or mirroring surfaces are
also harmful to the eyes. The accessible laser radiation is harmful to the skin with laser class 3B devices if the
values of the maximum permissible exposure are exceeded.
Class 3B laser sensors are notifiable and a laser protection officer is required. Mark the laser area recogniz-
able and everlasting. During operation the laser area has to be restricted and marked.
Attach the following warning labels to the cover (front and rear side) of the sensor housing:
IEC 60825-1: 2014
P
≤ 50mW, P ≤ 50mW;
0 P
 = 658nm; F = 0...4kHz, t = 1µs...∞
WARNING - LASER RADIATION
AVOID EXPOSURE TO BEAM
CLASS 3B LASER PRODUCT
Fig. 5 Laser warning sign and laser label, LLT 25xx-25, 25xx-50, 25xx-100
COMPLIES WITH 21 CFR 1040.10 AND 1040.11
EXCEPT FOR CONFORMANCE WITH
IEC 60825-1 ED. 3., AS DESCRIBED IN
LASER NOTICE NO. 56, DATED MAY 8, 2019
Fig. 6 Only for USA
In addition, the following information label must be attached to the laser output on the sensor housing:
LASER
APERTURE
Laser radiation. Wear
suitable protective
glasses. Injury of the
eyes and the skin are
possible.

Page 13
Laser Safety
scanCONTROL 25xx
If the sensor is on the laser output can be reduced to 8 mW with the software. Reducing the laser output to
1 mW is not possible. Reducing the laser output from 20 mW to 8 mW with a software affects not the laser
class!
Beam attenuator
Fig. 7 Sensor with close beam attenuator Fig. 8 Sensor with open beam attenuator for mea-
surements
Laser products certified as Class 3B products (EN 60825-1) require a beam attenuator, see Fig. 7, see Fig. 8,
other then the key-operated control. The beam attenuator prevents access to all laser and collateral radiation.
To open or close the aperture please follow the steps below:
Loosen the knurled screw.
Change the attenuator position and tighten the knurled screw.
The laser aperture must be open during measurement. Please observe the notes on external laser switching,
see 5.2.6.

Page 14
Functional Principle, Technical Data
scanCONTROL 25xx
3. Functional Principle, Technical Data
3.1 Short Description
3.1.1 Measuring Principle
The scanCONTROL 25xx sensor operates accord-
ing to the principle of optical triangulation (light
intersection method):
- A laser line is projected onto the target surface
via a linear optical system.
- The diffusely reflected light from the laser line
is replicated on a sensor array by a high quality
optical system and evaluated in two dimensions.
The laser line triangulation corresponds in principle
to the triangulation of a laser point. In addition,
during the measurement a row of lines are simulta-
neously illuminated by the laser line. Apart from the
distance information (Z-axis), the exact position of
each point on the laser line (X-axis) is also acquired
and output by the system.
Measuring
range X-axis
(profile width)
Measuring
range Z-axis
(profile height)
3.1.2 System Setup
The scanCONTROL 25xx sensor is a compact sensor with an integrated controller. All necessary integral
parts are combined in one housing.

Page 15
Functional Principle, Technical Data
scanCONTROL 25xx
3.1.3 Special Performance Features
- scanCONTROL 25xx stands out due to its compact design. A special line-scanning optical system ensures uniform exposure of the
measuring field.
- The sensor array is arranged in the sensor head according to the Scheimpflug condition which facilitates uniform image focusing
over the whole depth of the measurement range (Z-axis).
- The scanCONTROL 2510 series with integrated profile analysis works even without a PC in conjunction with saved configurations.
The sensor runs the profile measurement internally and calculates default measured values such as angle or edge position.
Besides measurement value output via Ethernet (Modbus TCP protocol, UDP protocol) and RS422 (Modbus RTU protocol or ASCII
format), additional switching signals (results of the determination of limit values) and analog measurement values can be output.
This is done by an optional 2D/3D Output Unit, which transforms the determined measurement signals in switching and analog
signals for further processing in a PLC.
- 2D/3D Gateway allows for scanCONTROL SMART sensors to be integrated into various fieldbus systems (PROFINET, EtherNet/IP,
EtherCAT).
3.1.4 Advantages
- External synchronization and triggering
- Serial interface (RS422) for communication with PLC or PC
- Digital switching inputs, selectable TTL or HTL
- The automatic control of the exposure time enables consistent measurement results with changing surfaces. This function can be
switched off on request.
- Ethernet 100/1000 Mbit as fast standard connection to PC

Page 16
Functional Principle, Technical Data
scanCONTROL 25xx
3.2 Technical Data
Model LLT 25xx-25 LLT 25xx-50 LLT 25xx-100
Laser type Red Laser |
Blue Laser Red Laser | Blue Laser Red Laser | Blue Laser
Z-axis
Measuring range
Start of measuring range 53.5 mm 70 mm 190 mm
Mid of measuring range 66 mm 95 mm 240 mm
End of measuring range 78.5 mm 120 mm 290 mm
Height of measuring range 25 mm 50 mm 100 mm
Extended measuring
range
Start of measuring range 53 mm 65 mm 125 mm
End of measuring range 79 mm 125 mm 390 mm
Max. deviation of a single
point 1 (2sigma) ±0.10 % ±0.10 % ±0.10 %
Line linearity 1 2 2 µm 4 µm 12 µm
±0.008 % ±0.008 % ±0.012 %
X-axis
Measuring range
Start of measuring range 23.4 mm 42 mm 83.1 mm
Mid of measuring range 25 mm 50 mm 100 mm
End of measuring range 29.1 mm 58 mm 120.8 mm
Extended measuring
range
Start of measuring range 23.2 mm 40 mm 58.5 mm
End of measuring range 29.3 mm 60 mm 143.5 mm
Resolution 640 points/profile
Profile frequency up to 2000 Hz
Interfaces
Ethernet GigE Vison Output of measurement values / Sensor control /
Profile data transmission
Digital inputs Mode switching / Encoder (counter) / Trigger
RS422 (halb-duplex) 3 Output of measurement values / Sensor control / Trigger /
Synchronization

Page 17
Functional Principle, Technical Data
scanCONTROL 25xx
Model LLT 25xx-25 LLT 25xx-50 LLT 25xx-100
Laser type Red Laser |
Blue Laser Red Laser | Blue Laser Red Laser | Blue Laser
Output of measurement values Ethernet (UDP / Modbus TCP); RS422 (ASCII / Modbus RTU);
analog 4; switch signal 4; PROFINET 5; EtherCAT 5; EtherNet/IP 5
Control and display elements 3 x color LEDs for laser, data and error
Light source
Red Laser
≤8mW
Standard: laser class 2M, semiconductor laser 658 nm
≤20mW ≤20mW ≤20mW
Option: Laser class 3B, semiconductor laser 658 nm
Blue Laser ≤8mW
Standard: Laser class 2M, semiconductor laser 405 nm
Laser switch-off per software, hardware switch-off with option /SI
Aperture angle of laser line 20° 25° 25°
Permissible ambient light (fluorescent light) 1 10.000 lx
Protection class (DIN-EN 60529) IP65 (when connected)
Vibration (DIN EN 60068-2-27) 2g / 20 … 500 Hz
Shock (DIN EN 60068-2-6) 15g / 6 ms
Temperature range Storage: -20 … +70 °C; Operation: 0 … +45 °C
Weight 380 g (without cable)
Supply voltage 11 … 30 VDC, nominal value 24 V, 500 mA,
IEEE 802.3af class 2, Power over Ethernet (PoE)
1) Based on measuring range; measuring object: Micro-Epsilon standard object
2) According to an one-time averaging over the measuring field (640 points)
3) RS422 interface, programmable either as serial interface or as input for triggering / synchronization
4) Only with 2D/3D Output Unit
5) Only with 2D/3D Gateway

Page 18
Functional Principle, Technical Data
scanCONTROL 25xx
3.3 LED Displays
LED laser on Meaning
Green Laser on
LED state Meaning
Green Measurement is active
Green, flashes long Controller accesses
Green, flashes short Data transmission is active
Red, flashes Error code, see 12

Page 19
Delivery
scanCONTROL 25xx
4. Delivery
4.1 Unpacking
- 1 Sensor scanCONTROL 25xx
- 1 Assembly instructions
- 1 Calibration final inspection
- 2 Protective caps
- 1 PCR3000-5 Multifunction cable; 5 m long; for power supply, trigger and RS422; M12x1 screw connector
and free cable ends
Carefully remove the components of the measuring system from the packaging and ensure that the
goods are forwarded in such a way that no damage can occur.
Check the delivery for completeness and shipping damage immediately after unpacking.
If there is damage or parts are missing, immediately contact the manufacturer or supplier.
Recommended accessories and optional accessories are listed in the appendix, see A 1.1, see A 1.2.
4.2 Storage
Storage temperature: -20 ... +70 °C (-4 ... +158 °F)
Humidity: 5 - 95 % (non condensing)

Page 20
Mounting and Installation
scanCONTROL 25xx
5. Mounting and Installation
5.1 Attachment and Mounting
- using 2 or 3 screws M5, screwed directly
- using 2 or 3 screws M4, screwed pushed through
Depending on the installation position it is recommended to determine the position of the sensor for example
by adjusting screws on the specially marked attachment points.
The pin hole ø3H11 is provided for a position locking pin. The sensor can be mounted reproducible and
replaceable together with an attachment point, see Fig. 10.
The mounting dimensions refer to the dimensional drawings.
Pay attention to careful handling during mounting and operation.
> Damage to or destruction of the sensor
The laser beam should strike the target surface at right angles. Otherwise, inaccurate measurements cannot
be excluded.
Mount the sensor by means of screws type M5 or by means of through bores for M4 with the screws
from the accessories.
Bolt connection
Through length Screw Washer Torque
33 mm M4 x ISO 4762-A2 A 4,3 ISO 7089-A2 2 Nm (µ = 0,12)
Direct fastening
Screw depth Screw Torque
min 8 mm, max 10 mm M5 x ISO 4762-A2 3,5 Nm (µ = 0.12)
Fig. 9 Mounting conditions
The bearing surfaces surrounding the fastening holes (through-holes) are slightly raised.
Mount the sensor only to the existing holes on a flat surface. Clamps of any kind are not permitted. Do not
exceed torques.
> Inaccurate, erroneous measuring values
