FiberHome AN5506-04-A User manual

AN5506-04-A
GPON Optical Network Unit
User Manual
Version: A
Code: MN000000423
FiberHome Telecommunication Technologies Co., Ltd.
May 2010

Thank you for choosing our products.
We appreciate your business. Your satisfaction is our
goal. We will provide you with comprehensive technical
support and after-sales service. Please contact your
local sales representative, service representative or
distributor for any help needed at the contact information
shown below.
Fiberhome Telecommunication Technologies Co., Ltd.
Address: No. 5 Dongxin Rd., Hongshan Dist., Wuhan, China
Zip code: 430073
Tel: [phone]
Fax: [phone]
Website: http://www.fiberhomegroup.com

Legal Notice




are trademarks of FiberHome Telecommunication Technologies Co., Ltd.
(Hereinafter referred to as FiberHome)
All brand names and product names used in this document are used fo
r
identification purposes only and are trademarks or registered trademarks
of their respective holders.
All rights reserved
No part of this document (including the electronic version) may be
reproduced or transmitted in any form or by any means without prio
r
written permission from FiberHome.
Information in this document is subject to change without notice.


TM
TM
TM

I
Operation Safety Rules
High optical power can cause bodily harm, especially to eyes.
Never look directly into the end of the optical transmitter fiber
jumper or the end of its active connector.
Exercise care if you must bend fibers. If bends are necessary,
the fiber bending radius should never be less than 38mm.
Power socket overload, broken cables or broken plugs may
cause electric shock or fire. Regular check-ups on power
supply wires and cables are essential. If any appears
damaged, replace it at once.
Use the power supply adapter provided in the package only.
Using other adapters may cause equipment damages or
operation failures.
Install the equipment in ventilated environment without high
temperatures or direct sunlight to protect the equipment and
its components from overheating, which can result in
damages.

II
Avoid moisture, dampness and water damage. Equipment
exposed to water cannot work normally and can be extremely
hazardous due to shorting.
Do not lay this equipment on an unsteady base.

III
Packing List
After opening the packing case of the AN5506-04-A, please check
whether the accompanied articles are in the packing case according to
the packing list as below:
Item Quantity Remarks
AN5506-04-A 1 -
Certificate of quality 1 -
User manual 1 AN5506-04-A GPON Optical Network
Unit User Manual
DC power adapter with two
pins 1 DC power adapter with two pins for the AN5506-04-A
RJ45 connector 5 -

Contents
1Product Introduction .........................................................................1-1
1.1Product Functions....................................................................1-1
1.2 Product Types..........................................................................1-3
1.3 Technical Specifications...........................................................1-4
2 Appearance Description ...................................................................2-1
2.1 Top Panel and LED Indicators .................................................2-1
2.2 Rear Panel and Interfaces.......................................................2-3
3 Product Installation...........................................................................3-1
3.1 Preparation Before Installation ................................................3-1
3.1.1Unpacking Check....................................................... 3-1
3.1.2Installation Precautions.............................................. 3-1
3.2 Placing the Device...................................................................3-2
3.3 Cable Connection ....................................................................3-2
3.3.1 Connection of Network Cable .................................... 3-2
3.3.2 Connection of Optical Fiber........................................ 3-3
3.3.3 Connection of Power Cable ....................................... 3-4
3.4 Examination after Installation...................................................3-5
4FAQs...............................................................................................4-1

Figures
Figure 1-1 Networking application of the AN5506-04-A ...................1-2
Figure 2-1 Top panel of the AN5506-04-A ........................................2-2
Figure 2-2 Rear panel of the AN5506-04-A ......................................2-3

Tables
Table 1-1 Product types ...................................................................1-3
Table 1-2 Technical specifications of the AN5506-04-A....................1-4
Table 2-1 Description of the AN5506-04-A LED indicators ...............2-2
Table 2-2 Interfaces and buttons of the AN5506-04-A......................2-4

Version: A 1-1
1 Product Introduction
1.1 Product Functions
The AN5506-04-A is a desktop GPON ONU (optical network unit). The
AN5506-04-A is applicable for FTTH scenario. It provides 1 PON
interface for uplink, 4 FE interfaces (or 4 GE interfaces) for downlink, 12
V DC power supply and 20 km transmission distance. As one of the
GPON ONU of the AN5506 series, the AN5506-04-A should work with
the GPON OLT(optical line terminal) of the AN5116 series.

AN5506-04-A GPON Optical Network Unit User Manual
1-2 Version: A
The following figure shows the networking application of the
AN5506-04-A:
Figure 1-1 Networking application of the AN5506-04-A
As shown in Figure 1-1, the AN5506-04-A works with the AN5116-06B
(OLT) to build a gigabit GPON system, and they can provide triple-play
multi-service access of high capacity and reliability.
The AN5506-04-A supports the following features:
Adopts GPON interface for uplink, compliant with ITU-T G.984.
Supports the following configurations: Ethernet interface rate,
working mode, MDI/MDIX self-adaption and pause-frame-based
flow control.
Supports packet filtering and anti-illegal message attack protection,
so as to suppress unknown unicast, broadcast and multicast
messages.
Supports performance statistics of Ethernet lines.

1 Product Introduction
Version: A 1-3
Supports DHCP Option82 reporting the physical position
information of Ethernet interfaces.
Supports PPPoE+ function for accurate subscribers identification.
Supports IGMP Snooping and IGMP Proxy.
Supports STP / RSTP protocol.
Supports Layer2 /3 wire-speed forwarding.
Downstream data in GPON system adopts triple churning algorithm
for data encryption.
Supports powerful QoS function. Supports global configuration of
queue priority and flexible mapping of 802.1p value of messages.
Supports three scheduling modes: PQ, WRR or PQ+WRR. You can
configure the weight of scheduling queue to ensure QoS of key
services such as voice and video under multiple service conditions.
1.2 Product Types
The AN5506-04-A has two types according to different types of interface.
Table 1-1 lists the two types of the AN5506-04-A and the interface type
and quantity that each product supports.
Table 1-1 Product types
Product Type FE Interface of
Ethernet
GE Interface of
Ethernet
Power
Interface
AN5506-04-A1 4 - Power socket
with pin

AN5506-04-A GPON Optical Network Unit User Manual
1-4 Version: A
Product Type FE Interface of
Ethernet
GE Interface of
Ethernet
Power
Interface
AN5506-04-A1G - 4 Power socket
with pin
1.3 Technical Specifications
The AN5506-04-A has two types according to different types of interface.
Table 1-2 lists the technical specifications in detail.
Table 1-2 Technical specifications of the AN5506-04-A
Type Item Description
Service
parameter
VLAN
Supports IEEE 802.1Q VLAN.
Supports the join into 802.1Q VLAN in tag /
untag mode.
Supports 64 VLANs.
MAC address Supports 8k MAC addresses.
Multicast Supports IGMP Snooping and IGMP Proxy.
Supports IGMP V1/V2.
QoS
Supports 802.1P.
Supports QoS classification strategy based
on ports, MAC address and VLAN ID.
Supports priority re-tagging.
Wire speed layer
2/3 switch All interfaces support wire speed forwarding.
PON interface One SC/PC interface. The maximum
transmission distance is 20 km.
LAN interface
AN5506-04-A1: Four RJ-45 interfaces.
Supports full duplex and half duplex,
10/100Mbps self-adaption.
AN5506-04-A1G: Four RJ-45 interfaces.
Supports full duplex and half duplex,
10/100/1000Mbps self-adaption.
Mechanical
parameter
Dimension 27 mm x 63 mm x 117 mm (Height x Width x
Depth)
Shell color White
Weight About 300 g
Power supply
parameter
DC Input voltage: 12 V DC
Consumption AN5506-04-A1 < 6 W
