Fieldpiece SRS3 User manual

01 02 03 04 05
Specifications
Specifications good in ambient conditions of 73°F ±9°F
(23°C ±5°C), <75% relative humidity
Over range: "OL" is displayed
Maximum load: 252 lbs (114 kg)
Auto power off: 30 minutes of inactivity (no change in weight or
buttons pressed), (APO can be disabled)
Backlight: Blue, turns off in 60 seconds if no buttons are pressed
Accuracy:
±0.03%rdg + 0.25 oz (10 g), 0 to 66 lbs (0 to 30 kg)
±0.05%rdg + 0.25 oz (10 g), 66 to 252 lbs (30 to 114 kg)
Resolution and Units:
lb oz (0.25 oz), lb (0.1 lb), oz (0.1 oz),
kg g (10 g), kg (0.1 kg), g (10 g)
Temperature coefficient: 0.1 x (specified accuracy) per °F
Wireless Range: 100 feet (30 meters)
Radio Frequency: 2400 MHz
Battery Type:
Remote Display: 9V, NEDA 1604, JIS 006P, IEC 6F22
Platform: 6 x AA, NEDA 15A, JIS UM3, IEC LR6
Battery Life: is displayed when the battery voltage drops
below the operating level.
Remote Display: 80 hours typical alkaline (without backlight)
Platform: 200 hours typical alkaline
Operating environment: 32°F to 122°F (0°C to 50°C) at <75% RH
Storage temperature: -4°F to 140°F (-20°C to 60°C), 0 to 80% RH
(with battery removed)
Weight: 7.3 lbs (3.3 kg)
Quick Start
1 Install the 9V battery into the remote display
and 6 x AA batteries into the platform.
2 Press for 1 second to turn on the platform.
3 Press for 1 second to turn on the display.
4 Read weight directly on the display.
Certifications
EN300 220
Remote FCC ID: 2ALHR001
Platform FCC ID: 2ALHR002
RCM
WEEE
RoHS Compliant
Description
Your new SRS3 Wireless Refrigerant Scale
combines modern wireless electronics and
rugged materials to perform at the high level
you demand.
The platform is made of thick aluminum to
maintain accuracy over the life of the product.
Rubber bumpers and pad cushion both the tank
and the scale itself.
A new wireless protocol sends platform
measurements to both the included remote
display and the Fieldpiece Job LinkTM mobile
app.
Platform electronics are sealed to block
the occasional moisture seen from rain and
splashing.
Hang the remote display from a condenser or
anywhere metallic and easy to see.The magnetic
folding hat holds it right where you put it.
Maintenance
Clean the exterior with a dry cloth. Do not
use liquid.
The batteries of the remote or platform must
be replaced when its battery life indicator is
empty. Remove rear battery cover and replace.
Buttons
Press for 1 second to power the
platform on/off.
Press for 1 second to power the
remote on/off. Tap for backlight.
Press for 1 second to zero (tare).
Press for 1 second to cycle through
units.
Press for 1 second to search for
available platforms to connect to.
Display Icons
Auto Power Off Enabled on Platform
Remote Display Battery Life
Platform Battery Life
Wireless Signal Strength
Pounds
Kilograms
Ounces
Grams
Fieldpiece
Wireless
Refrigerant
Scale
OPERATOR'S
MANUAL
Model SRS3

06 07 08 09 10
Functions
Weight Measurement
Your SRS3 scale is designed to measure
refrigerant tanks weighing up to 252 lbs.
Placing items over 252 lbs on the scale may
damage the scale.
1 Remove the scale from the padded case and
place the platform on solid, level ground.
2 Press for 1 second to turn on the platform.
3 Press for 1 second to turn on the display.
4 Press UNITS for 1 second to cycle through
LB OZ, LB, OZ, KG G, KG, and G.
5 Press ZERO for 1 second to tare the scale.
6 Set your tank on the platform and zero again
to view only the change in refrigerant.
7 View the change in weight in real-time when
charging or recovering refrigerant.
Backlight
Tap to turn on the blue backlight on
the LCD. This is useful when the sun is going
down on late day jobs or any dark situation.
The backlight uses extra battery power than
standard use.
Auto Power Off (APO)
If the weight is unchanged for 30 minutes, the
platform will automatically power off.
To disable APO, while power is on tap twice
on the platform. The LED will briefly blink red
and APO will not be shown on the display.
To enable APO, while power is on tap twice
on the platform. The LED will briefly shine red
and APO will be shown on the display.
Syncing a Display to a Platform
The included remote display is setup to view
the platform at the factory. You shouldn't ever
need to re-sync them. You can sync two SRS3
remote displays to a single SRS3 platform if
desired.
1 Press SYNC for 1 second.
2 The ID# of a detected platform will show.
(This ID# is printed on the platform.)
3 TapSYNCtocyclethroughanyotherplatforms
detected.
4 Press SYNC for 1 second to select a platform.
Job LinkTM:If using the Job Link mobile app
as a display, add the SRS3 platform to the tool
manager in the app.
Tech Tips
Respect the Environment
Always use hoses with ball valves or low-loss
fittings to minimize harmful refrigerant gases
entering the atmosphere.
Account for Your Hose Weight
Connect the hoses to the system and tank
before zeroing the scale. After charge/recovery
is finished and the system is stable, note the
weight before removing hoses.
Use Your Appropriate G-Value
Acceleration due to gravity in m/s2(G-Value)
varies slightly depending on your altitude and
location. Here are few cities' examples:
Los Angeles (default) 9.796
New York City 9.802
Paris 9.809
Sydney 9.797
Denver 9.798
1 Hold UNITS while powering on display.
2 With the current G-Value showing, tap SYNC
toincreasevalue.TapUNITStodecreasevalue.
3 Tap ZERO to save and exit.
FCC Statement
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.These
limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if notinstalled and used in accordance withthe instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
. Reorient or relocate the receiving antenna.
. Increase the separation between the equipment and receiver.
. Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
. Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: To assure continued compliance, any changes or
modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
(Example - use only shielded interface cables when connecting to
computer or peripheral devices).
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Fieldpiece Instruments
1636 West Collins Avenue
Orange, CA 92867
Limited Warranty
This scale is warranted against defects in material or workmanship
for one year fromdate of purchase froman authorized Fieldpiece dealer.
Fieldpiece will replace or repair the defective unit, at its option, subject
to verification of the defect.
This warranty does not apply to defects resulting from abuse,
neglect, accident, unauthorized repair, alteration, or unreasonable
use of the instrument.
Any implied warranties arisingfrom the sale of a Fieldpiece product,
including but not limited to implied warranties of merchantability and
fitness for a particular purpose, are limited to the above. Fieldpiece
shall not be liable for loss of use of the instrument or other incidental
or consequential damages, expenses, or economic loss, or for any claim
of such damage, expenses, or economic loss.
State laws vary. The above limitations or exclusions may not apply
to you.
Obtaining Service
E-mailFieldpiecewarrantydepartmentatfpwarranty@fieldpiece.com
for current fixed price repair service. Send check or money order made
out to Fieldpiece Instruments for the amount quoted. If your meter is
under warranty there will be no cost for the repair/replacement. Send
your scale, freight prepaid, to Fieldpiece Instruments. Send proof of
date and location of purchase for in-warranty service. The meter will
be repaired or replaced, at the option of Fieldpiece, and returned via
least cost transportation.
For international customers, warranty for products purchased
outside of the U.S. should be handled through local distributors. Visit
our website to find your local distributor.
www.fieldpiece.com
© Fieldpiece Instruments, Inc 2017; v12
