Fired Up Corporation BEF0001 User guide

UNI0003_V8_261022
SAFETY MANUAL
BIO-ETHANOL FIRE
SAFETY MANUAL FOR:
INSET FIRES FREE STANDING
STOVES FIREBOXES

02
SECTION 01
CONTENTS
SECTION 01 - INTRODUCTION
Introduction 03
Cautions 03-06
Important safety information 05-07
Safety symbols 07
SECTION 02 - IMPORTANT SAFETY INFORMATION
WARNING! 08
Installation and location 08
Adding fuel 09
Lighting 10
During use 10
Extinguishing 10-11
Caring for your product 11
SECTION 03 - INSTALLATION & GUARANTEE
Installation 12-15
Guarantee 16
Contacts 16
Read ALL the instructions before use.
These instructions are for your safety. Please read through
them thoroughly before use and retain for future reference.
Failure to follow them could cause injury and/or property
damage.
Note: This manual applies for a number of different
products. Please make sure you follow the appropriate
product guide lines.

03
SECTION 01
INTRODUCTION
The contents of this manual are intended to provide simple and informative instructions
on how to safely install and use your bio-ethanol fire. Before assembling the product,
please take the time to read this manual thoroughly.
Please bear in mind that bio-ethanol firesuse a real, uncovered flame which by nature
requires extra care and attention during use.
PLEASE KEEP THIS MANUAL FOR FUTURE REFERENCE
WARNING: FAILURE TO FOLLOW INSTRUCTIONS
MAY RESULT IN FIRE, PROPERTY DAMAGE,
SERIOUS INJURY OR DEATH.
General Information
Before using your bio-ethanol fire you will need to determine whether the space is
suitable for the product to be used safely. Using your bio-ethanol fire in a room smaller
than that stipulated below and without sufficient ventilation may result in headaches
or sickness. If this occurs, extinguish the fire immediately and open all doors and
windows. To calculate the Volume of the room:
Room size = H x W x D = m³
H
WD
If this value is less than the
Minimum Room Volume
stated for the fire DO NOT USE
IMPORTANT: Remove all packaging before use, but retain
the safety instructions. DO NOT remove the warning labels
from the unit.

04
SECTION 01
BIO ETHANOL FIRES
Burner
Size (L)
Min Room
Vol.(m3)
Model No. * Weight (kg)
*Model numbers can be located on the label attached to the product
BEF0001 10 1.5 63 3.5
BEF0007 2.5 1.5 63 3.5
BEF0008 4.2 3L 80 9.5
BEF0010 2.8 0.5 50 2.5
BEF0011 5.4 1.5 63 3.5
BEF0012 21.6 1.5 63 3.5
BEF0013 6.7 1.5 63 3.5
BEF0014 3.5 1.5 63 3.5
BEF0015 0.9 0.5 50 2.5
DO NOT put any objects
onto the fire.
DO NOT put fireplace in a
draft.
DO NOT fan the fire. DO NOT touch the flames. DO NOT position the fire
near combustible items.
IMPORTANT SAFETY INFORMATION
Please take the time to familarise yourself with ALL the information contained within this
section of the manual.
DO NOT pour fuel into the open
flame. Do not pour fuel into the
burner whilst it is still hot.
Approx.
Burn time (hrs

WARNING!
• Never leave children unsupervised in a room where the fire is ON and unguarded.
• Never obstruct or cover or force items into fire openings.
• Never install or use the fire anywhere where water is in use, i.e. Bathrooms, Kitchens,
Shower Rooms, and Swimming Pools etc.
• Never use aerosols or steam cleaners on or around the fire.
• Never use the fire to dry clothes etc.
• Never sit or stand on the fire.
• Never lean or put weight on the fire.
• Do not use outdoors.
• Do not sit the fire on deep pile carpets or rugs.
• This product is NOT for permanent use.
• This product is NOT for continuous operation.
• This product is ONLY intended for domestic use.
• This product must NOT be hired out for contract purposes.
• This product is NOT intended for cooking or heating food.
• This product must NOT be used a room with a minimum volume less than that
recommended the model specific information section of this instruction manual
and without sufficient ventilation. Failure to comply may result in headaches or
sickness.
05
SECTION 01
Keep suitable
extinguishing agent
ready.
Adhere to ALL instructions about
bio-ethanol fuel.
Fire danger / oxidising /
combustible
Do not smoke when
handling / filling
bio-ethanol fuel.
Harmful.
IMPORTANT SAFETY INFORMATION
Please take the time to familarise yourself with ALL the information contained within this
section of the manual.

06
SECTION 01
• If anyone in the vicinity of the fire experiences sickness or headaches,
extinguish the fire immediately and open all doors and windows.
• Once lit, DO NOT pour bio-ethanol liquid into the fire.
• DO NOT leave a lit fire unattended at any time.
• DO NOT use the bio-ethanol fire as a main source of heating.
• FIRE HAZARD – Hot liquid.
• DO ensure all safety precautions in this manual are followed.
• DO familiarise yourself with the procedure for extinguishing the fire BEFORE
lighting.
BEFORE YOU START
We recommend the following equipment is available at all times and clearly visible
before lighting the fire:
• The metal extinguishing tool supplied with the fire.
• An alcohol resistant foam, BC powder or carbon dioxide fire extinguisher (not
supplied).
• A protective mat placed beneath the fire in instances where the fire
is to be positioned on a wooden, plastic or glass table.
• A protective mat may be made of slate or marble, be a cast iron or stainless
steel trivet, or a heat resistant fabric mat, which can be purchased from
cookware retailers.
• A carbon monoxide detector in the room in which you intend to use your
bio-ethanol fireplace.
• A long stem lighter
We also recommend a set of heat resistant gloves when preparing and lighting the
fire.
INSTALLATION AND LOCATION
NOTE: These instructions are to be used in conjunction with building regulations. Please
observe local legislation in relation to installation and use of bio-ethanol fires.
• Please ensure thewall/table/floor you are placing this appliance can bear its
weight.
• You MUST use this product in a well ventilated area.
• DO NOT use this bio-ethanol fire in any small enclosed unventilated spaces
such as lofts or basements.
• You MUST locate this product in a location where it will NOT be subject to a
strong draught or wind.
• DO NOT place the fire in front of a window.
• You MUST only use this fire in rooms according to this manual.
• You MUST locate the fire at least 1m away from curtains and any other
flammable materials.
• DO NOT place it on or near any highly combustible/flammable surfaces or
materials.
• DO NOT use this bio-ethanol fire under any outdoor awnings, parasols, sun
umbrellas, gazebos or in a tent.
• A protective mat MUST be placed beneath the fire in instances where the
fire is to be positioned on a wooden, plastic or glass table (protective mat
not supplied)
• A protective mat may be made of slate or marble, be a cast iron or stainless
steel trivet, or a heat resistant fabric mat, which can be purchased from

07
SECTION 01
cookware retailers.
• DO NOT locate the fire in a location where it could be knocked or tipped
over.
• DO NOT use this bio-ethanol fire on anything other than a suitably strong,
stable, flat, level, permanent, heat and scratch resistant, low surface in a well
ventilated area.
• DO NOT reposition the fire when in use, only move the fire when it has
cooled completely.
• DO NOT position the fire below a wall-hung television, or beneath
overhanging lights.
• DO NOT locate the fire within 1m of a television.
• DO NOT locate the fire in an area where children and/or animals play.
• See minimum requirements for combustible distances on page 10.
• If enclosures dont allow for the distances stated on page 10, you MUST use
non- combustible materials.
ADDING FUEL
• This product is ONLY suitable for use with bio-ethanol liquid fuel.
• ALWAYS follow the fuel safety guidelines on the back of the bio-ethanol fuel
bottle.
• DO NOT use petrol, white spirit, lighter fluid, alcohol, gel fuel, citronella oil or
similar chemicals to light the fire as this will damage the product and may cause
property damage, serious injury or death.
• ALWAYS inspect the unit prior to adding fuel for fatigue and damage and replace
as and when necessary.
• ALWAYS use the funnel provided to fill the fuel tray.
• ALWAYS ensure that the whole unit and fuel container is fully extinguished and
cool prior to fueling.
• DO NOT re-fill the fuel tray with bio-ethanol liquid when the bio-ethanol fire
is in use or still hot.
• DO NOT OVERFILL THE FUEL TRAY WITH FUEL
• There is a maximum level mark on the inside of the fuel tray. DO NOT fill the fuel
tray with bio-ethanol liquid above the maximum mark.
• If any spillages have occurred when filling the fuel tray, ensure you clear up the
spilled fuel before use. Any fuel spilled can be removed by wiping the fuel up
with a dry cloth then removing any remaining residue with a damp cloth
• DO NOT use any chemicals to clean up spillages or to clean the bio-ethanol
fireplace.
• Only use luke warm water and a soft cloth to clean the bio-ethanol fire.
• Only add more bio-ethanol liquid when the flame has been properly
extinguished and the fire is COMPLETELY COOL.
• DO NOT POUR FUEL DIRECTLY ONTO A LIT FLAME, OR INTO A WARM FUEL
CONTAINER.
LIGHTING
NOTE: Before lighting we highly recommend familiarising yourself with the procedure(s)
for extinguishing the fire.
• Ensure there are no flammable materials within 1m of the bio-ethanol fire.
• DO NOT ignite the device if it is still warm.
• DO NOT smoke when lighting the fire.

08
• DO NOT light the fire in a room which already contains a burning fire.
• To light the bio-ethanol liquid fuel use a long stem lighter at arms length at a
minimum distance of 140mm from the handle of the lighter to the opening of
the bio-ethanol burner.
• It is recommended that you use heat resistant gloves (not supplied) when
preparing
this unit for use and lighting the bio-ethanol liquid.
• The extinguishing plate must remain completely open once the bio-ethanol
liquid fuel has been lit. When you want to extinguish the flame and when NOT in
use, the extinguishing plate must remain firmly closed.
DURING USE
• After approximately 5 minutes the flame will change from a small blue flame to
a larger yellow flame and will burn hotter than when first lit.
• Once alight DO NOT move or handle the bio-ethanol fire as it will be hot.
• The metal extinguishing tool should be kept close to the fire at all times,
especially when alight.
• DO NOT leave unattended.
• Beware of hot surfaces.
• DO NOT touch the flame.
• DO NOT put anything on top of the fire or cover the fire and/or the
fire glass.
• DO NOT smoke in the vicinity of the fire.
• DO NOT close all windows and doors whilst the fire is in use.
• DO NOT use this product in a strong draught or wind.
• DO NOT light the fire in a room which already contains a burning fire.
• DO NOT use this bio-ethanol fire in the rain.
• DO NOT move the bio-ethanol fire whilst alight as it will be hot.
• ALL of the bio-ethanol fire surfaces will become hot during use: HANDLE
WITH CAUTION.
• Keep children and pets at a safe distance from the bio-ethanol fire when
in use, whilst still hot or with hot fuel.
• DO NOT leave children unattended with the fire whilst in use, still hot or with
hot fuel.
• DO NOT reposition the fire when in use, only move the fire when it has
cooled completely.
EXTINGUISHING
• It is recommended that heat resistant gloves (not supplied) are used when
handling any part of the fire.
• Keep the extinguishing tool with the fire at all times.
• DO NOT douse the bio-ethanol fire with water even in an emergency.
• DO NOT attempt to blow out the flame, as the additional airflow will increase
the flame size and strength and not extinguish the flame.
• To extinguish the bio-ethanol fire allow all bio-ethanol liquid to burn completely
so there is no residue remaining in the fuel tray.
• If the fire is burning, using the extinguishing tool provided close the extinguishing
plate
covering the fuel tray completely, this will starve the flame of oxygen preventing
it from burning.
• Keep the stainless steel extinguishing plate firmly closed until the whole product
is cool and the flame is extinguished.
SECTION 02

06
• The fuel tray MUST be completely covered by the extinguishing plate.
• DO NOT handle or return to the product until the flame has been completely
extinguished.
• Once the fire is completely cool you may return to the product.
IN AN EMERGENCY:
• Using the metal extinguishing tool provided, firmly close the stainless steel
extinguishing plate across the fuel tray.
• Use an alcohol resistant foam, BC powder, or carbon dioxide fire extinguisher.
• Ensure the stainless steel extinguishing plate is completely closed covering the
fuel tray entirely.
• DO NOT douse the bio-ethanol fire with water even in an emergency.
• DO NOT attempt to blow out the flame, as the additional airflow will increase the
flame size and strength and not extinguish the flame.
Once cool:
• Ensure there is no fuel remaining in the fuel tray.
• Keep the extinguishing plate firmly closed.
CARING FOR YOUR PRODUCT
• DO NOT alter the design or construction of this fire in any way.
• DO NOT use any replacement parts from any other manufacturer.
• When not in use, ensure there is no fuel remaining in the fuel tray.
• To clean the fuel tray use lukewarm water and a soft cloth. It is also
recommended that you use a good quality stainless steel cleaner on the fuel
tray.
• ONLY use a damp soft cloth on the fireplace base unit.
• When not in use, store the unit indoors in a dry, cool place, out of reach of
children.
• Take special care when storing the bio-ethanol liquid fuel.
• For suitable fuel storage, please follow the directions for use and storage on the
bio-ethanol liquid packaging.
• Prior to next use, check all components of the product for fatigue, ensuring that
the secondary fuel container does not contain any fuel. Any residual fuel must
be removed, drained and cleaned before use.
• The stainless steel fuel tray will tarnish from first use and if placed outside, this is
normal and to be expected.
• Reposition the fireplace regularly to prevent the surface underneath the
fireplace from fading.
SECTION 02
09

10
SECTION 02
MINIMUM DISTANCES TO COMBUSTIBLE MATERIALS
32mm
Inset Fires
Free Standing
Stoves
Fireboxes
32mm
69mm
800mm
200mm
200mm200mm
100mm
300mm
200mm
200mm
200mm
100mm
100mm
200mm

11
SECTION 02
1 x Free stand-
ing Box*
1 x Bio-Ethanol
Burner
1 x Bio-Ethanol
Burner
1 x Fire Body1 x Trim
1 x Flame
Control Tool
1 x Flame
Control Tool
A crosshead screwdriver
A 6mm diameter masonry bit
A 2mm diameter drill bit
A pencil
An electric drill
PARTS SUPPLIED
Free standing
Inset Fire
Stove
Firebox
1 x Stove 1 x Flame
Control Tool
1 x Filler
Funnel
1 x Filler
Funnel
1 x Cable
Tie
1 x Hook
Screwhead
1 x Bio-Ethanol
Burner
1 x Firebox 1 x Flame
Control Tool
1 x Bio-Ethanol
Burner
4 x Neoprene
strips
TOOLS REQUIRED FOR INSTALLATION
or

12
SECTION 03
INSTALLATION (For Inset Fires Only)
This fire is suitable to fit into surrounds with a minimum opening (A & B)
A420mm
B570mm
C Trim styles & spacer options vary the depths typically between 55 -
105mm
A
B
IMPORTANT: ON ALL MODELS PLEASE ENSURE THE BURNER RESERVIOR
IS FACING THE FRONT OF THE FIREPLACE
WARNING:
PLACE BURNER
INTO THE INSET FIRE
BODY WITH THE
RESERVOIR FACING
TOWARDS THE FRONT
FRONT
REAR
. . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . .
.........
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. . . . . . . . .
........
........
.
.
..
..
..
..
. .
..
C

13
SECTION 03
FITTING AN INSET FIRE
Installing the fire where a stone or marble back panel is used
1. For solid walls, drill
the 2 holes approxi-
mately 35mm deep
using a 6mm
diameter drill bit.
Note if fitting the fire
to plaster board with
a cavity behind then
propriety wall fixings
(not supplied) will be
required.
3. Pass cable tie
through the larger
hole on the fire
body trim,
ensruing that
the head of
the cable tie
does not pass
through this
hole.
4. Pass cable tie
through the
hook of
the threaded
insert,
in a clockwise
direction.
5. Threading the
cable tie through
the second hole in
the fire body, and
attach through the
main head of the
tie, pulling to the
left to tighten the
fire into postition.
6. Once the
cable tie has has
sufficent tension
applied, the
excess cable can
be pushed neatly
through the
larger hole to be
concealed out of
view.
570mm
2. Insert wall plug
into wall, then
tighten the hook
screwthread into
the wall plug.

14
SECTION 03
A420mm
B570mm
C XXX
FITTING A FIREBOX
This fire is suitable to fit into surrounds with a minimum opening (A & B)
A
B
C
Fit the neoprene strips behind the trim to adhere
to the back panel
CONFORMITY WITH DIRECTIVES
Conforms with relevant European Directives

15
SECTION 03

DISCLAIMER
We will not accept responsibility for any loss, damage or injury caused by installations
of bio-ethanol fires other than those directly attributable to faulty workmanship or
materials used by ourselves during the guarantee period. The instructions in this
manual are designed to supplement those defined by building regulation, local
conventions and any other applicable safety steps required by law in relation to fire
safety and should not be used in isolation.
Over time the appearance of the product will tarnish though use and if kept
outdoors, this is natural and unavoidable and we are under no obligation to provide
repair or replacements under guarantee for cosmetic damage sustained in this
manner.
GUARANTEE
For your convenience, you are not required to complete a form and return it to us in
order to validate your guarantee. However, please ensure that you retain your
receipt which will act as both proof of purchase and a guarantee validation
document. We recommend that you attach your receipt to this documentation.
Your product carries a 12 month guarantee from the date that the original purchaser
receives it. If your product fails to operate to its specification, due to faulty
workmanship or materials during the guarantee period, we will either repair or
replace the product. We will use our discretion to determine whether to offer a
repair or provide a replacement. The product will not be covered by the guarantee
if it has been misused, transformed, modified or altered in any way. Over time the
appearance of the product will tarnish though use and if kept outdoors, this is natural
and unavoidable and we are under no obligation to provide repair or replacements
under guarantee for cosmetic damage sustained in this manner.
If your product fails within the guarantee period please ensure that you have all
necessary documentation available including proof or purchase (receipt or invoice
with serial number, location and date of purchase) in addition to all original
undamaged packaging and leaflets etc. It is strongly recommended that you
inspect your product carefully before it is used or installed. For full details of your
product you should refer to the instruction manual which accompanies the product.
You are strongly advised to read this manual carefully in its entirety and to retain it for
future reference.
This product guarantee does not affect your statutory rights.
CUSTOMER HELPLINE
[phone]
[email protected]
AFFIX RECEIPT OR PROOF
OF PURCHASE HERE
16
SECTION 03
www.firedupcorporation.com
Fired Up Corporation Ltd
Fired Up Buildings
HD1 3LF, UK
Fired Up Corporation
(Ireland) Ltd
71, D02 P593, Dublin
