glowPhone™Quickstart Guide
Refer to the label below during the activation of
your glowPhone.

Copyright @2007 Firey Mobile, Inc.
glowPhone™ is the exclusive trademark of Firey Mobile, Inc.
For more information visit www.reymobile.com
Screen images are simulated. Actual screen images may vary among service
providers.
Printed in USA
84-0001-037

i
Quick Start Guide
Table of Contents
MEET glowPhone ...........................................................1
GETTING STARTED ........................................................2
Battery and SIM Card .............................................2
Power On/Off .........................................................3
DISPLAY AREA / KEYPAD ................................................5
Display Area ..........................................................5
Keypad .................................................................5
MENUS ........................................................................6
SETTING UP glowPhone ..................................................8
Type Names and Numbers .......................................8
Setup the Call Keys ................................................8
Setup the Contact List .............................................9
USING THE PHONE ........................................................9
Make a Call Using the Call Keys ................................9
Make a Call Using the Contact List ............................9
Make an Emergency Call ....................................... 10
Answer a Call ....................................................... 10
Missed Calls ......................................................... 10
VOICE MAIL ................................................................11
TEXT MESSAGES ......................................................... 11
GAMES....................................................................... 12
RINGTONES ................................................................ 12
WALLPAPER ................................................................ 13
FLASHLIGHT ............................................................... 13
TERMS & CONDITIONS ................................................. 14
FIREFLY ONE-YEAR LIMITED WARRANTY ......................... 14
SPECIFIC ABSORPTION RATE DATA ................................ 17
RF ENERGY INTERFERENCE / COMPATIBILITY .................. 18

ii Quick Start Guide
Battery Safety/Disposal
glowPhone uses a rechargeable lithium-ion (Li-ion) battery. An AC charger is
provided.
Follow these battery safety guidelines:
Do not expose the battery to temperatures above 140 degrees F
(60 degrees C).
Do not take the battery apart.
Do not allow metal objects to touch the terminals.
Dispose of properly. Do not dispose of in re. Do not throw in the trash.
Customer Service
Do not return this product to the store. Contact Firey Customer Service or visit
our web site at reymobile.com for any of the following:
Troubleshooting
Activation questions
Coverage issues
About this Quick Start Guide
This Quick Start Guide provides basic information about using glowPhone. For
additional and more detailed information about the features and functions of
your glowPhone, go to reymobile.com to download the User’s Guide.
PIN Protection
The PIN-protected Parental Controls can be used to block certain phone
functions. See the User’s Guide for information on programming the call keys,
setting up the Contact List, setting Parental Controls, and changing the PIN.
•
•
•
•
•
•
•

1
Quick Start Guide
MEET glowPhone
1 Earpiece Hold to ear when using the
phone.
2Emergency Call button
3 Headset port For accessory headset.
4 Display area View glowPhone activities.
5Volume buttons Press to raise/lower the
sound.
6 Send key Press to answer or make a call.
7 End key Press to end a call. Press and hold
to turn glowPhone on/off.
8 Mom Call key Press to call a pre-
programmed number.
9Dad Call key Press to call a pre-
programmed number.
10 Navigation key Navigation arrows and
Select button.
11 Mouthpiece
12 Connect port Connect to battery charger.
13 Battery compartment Install battery and
SIM card.
14 Loud speaker
1
2
3
4
7
10
9
10
11
8
6
5
14
13
2
3
12

2Quick Start Guide
GETTING STARTED
Battery and SIM Card
Remove the Battery
1. Press lightly at the top of the
battery compartment (1) with
your thumb and slide the cover
until it stops. Lift up the cover.
2. Place the tip of your thumb in
the indent (2), push in the tab,
and lift the battery out of
the compartment.
Install a SIM Card
glowPhone requires a SIM card and
a charged battery for operation.
You must install a SIM card
(provided with your phone or
obtained through your network
service provider). The SIM card
contains the phone number for your
glowPhone and provides access to
network services.
Note: Do not touch the metal part
of the SIM card.
1. Remove the battery cover.
2. Remove the battery (if installed).
3. Push back the metal tab (1)
if needed.
4. Slide a SIM card (2) into the
SIM card holder and under the
plastic lip (3). Make sure the
SIM card lies at in the holder
and that the side with the metal
side is face down.
5. Slide the metal tab over the SIM
card to hold it in place.
6. Install the battery and replace
the cover.
121
2
3

3
Quick Start Guide
Install the Battery
1. Hold the battery so that the
words are facing down and the
tab (1) is at the bottom of
the compartment.
2. Lower the battery into place and
press gently on the tab end until
it clicks into place.
3. Place the cover (2) over the
battery and slide it gently
forward until it closes.
Charge the Battery
It will take about 3 hours for the
battery to charge the rst time.
Recharge the battery when the
battery icon is at 1 bar or less.
Important! Always use the charger
supplied with glowPhone or one
approved by the manufacturer.
Other chargers may damage
glowPhone and void the warranty.
1. Plug the charger cable into a
standard AC wall outlet.
2. Plug the charger cable (1) into
the glowPhone battery port (2).
A battery icon will display
on the screen.
Power On/Off
To turn on: press and hold
the End key (1) until the
display activates.
To turn off: press and hold
the End key (1) until the
lights go off.
•
•
12
1
1
2

4Quick Start Guide
Backpack Clip
The string loop on the backpack clip
attaches to your glowPhone.
To install the backpack clip:
1. Remove the battery
compartment cover.
2. Slip the string loop through the
hole next to the charger port
and hook the string loop over
the notch.
3. Pull gently on the string to make
sure it is on the notch. Replace
the cover.
Headphones
Plug your headphone cable (1) into
the headphone port (2) on the right
side of your glowPhone.
Parental Controls
See the Setting Up glowPhone
section of this guide for information
on how to program the special keys
and create a Contact List.
See the User’s Guide for information
on how to set permissions and use
the other options in the Parental
Controls menu.
1
2

5
Quick Start Guide
DISPLAY AREA / KEYPAD
Display Area
The Display Area provides
information about glowPhone.
Top Line
Middle Area
Bottom Line
Top line Icons for network
connection, voice mail, messages,
battery strength, etc. Check the top
line when you turn on glowPhone:
Middle area Viewing/activity area
for date/time, phone numbers,
names, wallpaper, menu lists,
games, etc.
Bottom line Menu options.
Note: When glowPhone is on, the
keypad and display area will
go dark when it isn’t being
used. Press any key to wake
up glowPhone.
Keypad
1 Send Press to place a call.
2 End Press to quit a call.
Press and hold to turn
glowPhone on and off.
3Navigation arrows
Press the Navigation
arrows to scroll to and
highlight items.
4 Select button
Press to select or open
an option.
5 Mom Call key
Press call a
pre-programmed number.
6 Dad Call key
Press to call a
pre-programmed number.
12
4
65
3

6Quick Start Guide
MENUS
There are 8 menus. Each menu has an icon that displays in the center of
the bottom line of the display area. When you highlight an icon, the menu
name appears above it in the display area.
Use the Navigation arrows to scroll to and highlight a menu.
Press the Select button to open a menu.
Press the Navigation arrows to highlight a menu option on a list.
Press the Select button to open the option.
Note: The default menu is Contacts. See the User’s Guide if you want to
change this default option.
•
•
•
•
