Firegear FPB-24LTFS-N User manual

Outdoor Thermocouple Flame Sense (TFS)
Linear Fire Pits
Installation and Operating Instructions
IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS
DO NOT ATTEMPT TO INSTALL OR OPERATE THIS APPLIANCE
Warning: For Outdoor Use Only
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE
INSTALLATION PRECAUTION:
This re pit requires a minimum 18-square inches (per side) of cross ventilation.
Failure to provide proper ventilation can void the warranty.
MODELS
Natural Gas Description Propane
FPB-24LTFS-N 24” Linear Pan & Burner FPB-24LTFS-P
FPB-30LTFS-N 30” Linear Pan & Burner FPB-30LTFS-P
FPB-36LTFS-N 36” Linear Pan & Burner FPB-36LTFS-P
MH# 60069

REV. 4-13-16 Page 1
TFS Linear Fire Pits
DANGER
CARBON MONOXIDE HAZZARD
This appliance can produce carbon monoxide
which has no odor.
Using it in an enclosed area can kill you.
Never use this appliance in an enclosed space
such as a camper, tent, car or home.
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open ame.
3. If odor continues, keep away from
the appliance and immediately call
your gas supplier or re department.
WARNING
Do not store our use gasoline or other
ammable vapors and liquids in the
vicinity of this or other appliances.
Any LP cylinder not connected for use
shall not be stored in the vicinity of this
or other appliances.
WARNING
Do not leave unattended during use.
Do not use for cooking.
Follow all gas leak procedures in this
manual prior to operation.
WARNING
Improper installation, adjustment,
alteration, service or maintenance
can cause injury of property damage.
Read the installation, operating and
maintenance instructions thoroughly
before installing or servicing this
equipment.
WARNING
If the information in these instructions is not followed exactly, a re or explosion
may result causing property damage, personal injury or death.
FOR YOUR SAFETY
Do not store or use gasoline or other ammable vapors and liquids in the vicinity
of this or other appliance.

REV. 4-13-16 Page 2
Specications 3
Part Identication & Install Details 4
Preparation for Non-Combustible Structure 5
Hard Piping to Fire Pit 5
Cross Ventilation Requirements 5
High Elevation 5
Installation into an Approved Enclosure 6
Requirements 6
Typical Installation Drawings 6
Installing Battery Pack 7
Learning Remote Control to Module (Receiver) 8
Installing Pilot Shield & Burner Screen 9
Installation of Media 9
Operation 10
Lighting Instructions 10
Replacement Parts 11
Replacement Parts List 12
Fire Pit Maintenance/ Trouble Shooting 13-14
Optional Accessories 15
TABLE OF CONTENTS
TFS Linear Fire Pits
Fuels used in gas red appliances, and the products of combustion such as fuels, contain
chemicals known to cause cancer, birth defects and/or other reproductive harm.
This warning is issued pursuant to the California Health & Safety Code Sec. 25249.1
Media such as (i.e. lava rock, lava stones, lava boulders) has the potential of thermal
spalling. This is a process that may occur when media is wet and moisture gets trapped
inside of the material due to rapid temperature differences. When this happens the
media has the potential to crack or “pop” outside the fire feature.
WE HIGHLY RECOMMEND COVERING ALL FIRE FEATURES WHEN NOT IN USE
The use of a cover can lessen the impact of thermal spalling; however, heavy rains, high
humidity and the presence of moisture may still cause the media to pop.
ALWAYS USE CAUTION WHEN USING THE FIRE FEATURE
Extra caution should be taken when lighting a fire feature when heavy rains, high humidity
and moisture are present. Light the fire feature; leave the area allowing any moisture in
the media to dissipate. We strongly recommend that during this drying out time that you
monitor the fire feature from a distance. This drying out period should be no less than 30
minutes. Continue monitoring the flame from distance to ensure that all popping has
ceased before fully enjoying the fire.
CAUTION

TFS SPECIFICATIONS
Table1. Fire Pit Dimensions
Fig. 2 Clearance to Combustibles (Not
to be used in an enclosed space)
REV. 4-13-16 Page 3
Model:
Factory
Orice
NG Btu’s
High
NG Btu’s
Low
Low Rate
Screw # Model:
Factory
Orice
LP Btu’s
High
LP Btu’s
Low
Low Rate
Screw #
FPB-24LTFS-N #38 35,000 20,000 #35 FPB-24LTFS-P #50 35,000 22,000 #49
FPB-30LTFS-N #35 42,000 23,000 #0 FPB-30LTFS-P #47 42,000 30,000 #49
FPB-36LTFS-N 0.125” 55,000 37,000 #0 FPB-36LTFS-P #43 55,000 37,000 #40
Table 2. Btu Specications
Disclaimer: BTU listings are based on 7.0”WC for Natural
Gas and 11.0”WC for Liquid Propane (LP) at the inlet side of
gas valve. Flex line size and proper gas pipe sizing will also
affect BTU. As a result your BTU may vary slightly from Table
2 specications.
Fig. 1 Fire Pit dimensions; refer to Table 1.
Pressure NG LP
Min. Inlet 5.0” WC 10.5” WC
Max. Inlet 10.5” WC 13.0” WC
Normal Inlet 7.0” WC 11.0” WC
Table 3. Gas Pressures
Model:
Natural Gas
(NG)
Model:
Propane Gas
(LP)
A
Pan
Depth
B
Min.Install
Length
C
Burner
Tube
D
Floor
Level
E
Side
Wall
F
Combustible
Ceiling
G
Framing
Width
FPB-24LTFS-N FPB-24LTFS-P 4” 28.250” 24” 15” 17” 44” 7”
FPB-30LTFS-N FPB-30LTFS-P 4” 34.250” 30” 15” 17” 44” 7”
FPB-36LTFS-N FPB-36LTFS-P 4” 40.250” 36” 15” 17” 44” 7”
B
C
G
TOP VIEW
F
E
NOTE: These re pits come shipped as Natural Gas or Propane Gas models only. There is no conversion kit
available. Ensure you order the specic model for your needs.
C
B
A
Level Ground (Earth) or Combustible Floor
D
Valve Box
TFS Linear Fire Pits

REV. 4-13-16 Page 4
Cradle
Burner Trim
Cradle Bracket
Cradle Bracket
Burner Tube
(Under Screen Gard)
Extension Bracket
Pilot Cover
Pilot Cover Gas Inlet Centered
Underneath Cradle
When in stalling into an opening its important to note some installation dimensions.
1) Cradle - is the assembly (outer shell) that all other parts sit inside. It is also the box where all rough framing takes
place. See page 3 and 4 for details.
2) Cradle Bracket - These brackets are 23” long with 2” anges. Each Linear model comes with two (2) cradle brackets
that mount on both sides of the re pit. The 7” frame clearance allows for the screws securing the cradle brackets. Each
cradle bracket can be adjusted 1/2” from the top edge of the cradle or lowered to a total of 2 3/4” from the top edge of the
cradle. There are 1/4” increments to adjust the depth of the re pit to t most nishing materials (See Fig. 4.).
3) Pilot Covers - are decorative spacers that provide equal spacing for all models. One side is used as a pilot shield for
the pilot system in the Thermocouple Flame Sense (TFS) models.
4) Burner Trim (Optional) - is 5/8” deep and sits inside the cradle. It has a 3/4” lip around that overlaps the entire perim-
eter of the of the cradle for its nished look.
PART IDENTIFICATION & INSTALL DETAILS
Fig. 3 Part identication
Fig. 4 Cradle bracket depth alignment
2 ¾”
1/2”
Cradle
End View
¾”
1”
1 ¼”
2”
2 ¼”
2 ½”
2 ¾”
Valve Box
Only one screw
required at each end of
cradle brackets
TFS Linear Fire Pits

REV. 4-13-16 Page 5
WARNING: Proper clearances from combustible, construction materials must be maintained from all sides, top and
bottom of this appliance. Use the specications listed on page 3 for proper clearance to combustibles.
PREPARING A NON-COMBUSTIBLE STRUCTURE
The re pit can be installed on a at, stable surface, away from any combustible materials. Install re pit on any level,
outdoor non-combustible, at, stable surface or a combustible oor according to the clearances specied in this manual.
NOTE: Do not place re pit directly on grass, dirt, or rocks this may prevent proper ventilation (Fig. 3, pg. 4).
Ensure proper water drainage is also incorporated into the re pit enclosure.
HARD PIPING TO FIRE PIT WITHOUT GAS PROXIMITY
NOTE: We recommend using ¾” black iron pipe; however please refer to the NFPA54 (National Fuel Gas Code) for
proper pipe sizing when exceeding 20-feet in length for re pits rated above 100,000 BTU.
1. Turn OFF gas supply system. NOTE: All gas connections (except for brass to brass) require the following. Clean pipe
threads using either a wire brush or steel wool. Apply pipe sealant to the ttings before making any connection.
BE CAREFUL! Ensure all gas connections are snug, but do not over tighten!
2. Extend the gas supply using minimum of ¾” black iron pipe or an approved exible gas line from existing house
supply. This can be accomplished by teeing off or tapping into a gas line connection. Install necessary pipe for the
distance required and then install a manual shut-off valve at the exterior house wall. If pipe is to pass through a foundation
or house wall, make sure to re-seal the area around the pipe with weather sealant.
3. The primary gas shut-off (not supplied) will require a ½” male ared tting to enable connection of the stainless steel
ex gas line supplied with the re pit (see gure 4).
IMPORTANT
Installation of Natural or LP gas should be done by a qualied installer, service agency or gas supplier.
This appliance must be isolated from the gas supply piping system by closing its manual shutoff valve during any
pressure testing of the gas supply piping system at test pressures equal to or less than ½ “psi. (3.5kPa)
VENTILATION FOR NON-COMBUSTIBLE ENCLOSURE
Fire pits are subjected to many outdoor elements such as rain,
snow, wind, heat or cold. A minimum of 18 square inches of
cross ventilation (2 sides) is required to keep the
components in good working order. Use gure 5 as a guide.
Fig 5. Cross Ventilation Example
HIGH ELEVATION INSTALLATION
This appliance is listed for elevations from 0- 4500 feet in Canada
and the U.S. If elevation exceeds 4500 feet it may be necessary
to decrease the input rating by changing the existing burner orice
to a smaller size. Input should be reduced 4% for each 1000 feet
beyond the 4500 feet above sea level. Check with your local gas
utility for assistance in determining the proper orice in your loca-
tion. In some cases the heating value may already be reduced
and downsizing the orice may not be necessary.
(2) 6”x12”
Examples of Cross Ventilation
3 - 2”x3” Slots Per Side or
2 - 1” x 9” Slots Per Side or
2- Firegear 6 x12 vents
Cross Flow Ventilation
(Min. 18 Sq. In. Per Side)
Fire Pit
Enclosure
Fire Pit
TFS Linear Fire Pits

REV. 4-13-16 Page 6
REQUIREMENTS
1. Only non-combustible materials should come in direct contact with any part of the re pit. Underneath area should be non-
combustible or a at level combustible surface according to the clearances specied in this manual.
2. We recommend using ¾” black iron pipe; however please refer to the NFPA54 (National Fuel Gas Code) for proper
pipe sizing when exceeding 20-feet in length for re pits rated above 100,000 BTU.
3. Determine the size linear re pit you are preparing to install (Refer to page 4).
4. You must provide a rectangular cut out to place the re pit into the non-combustible enclosure.
5. Follow the local code requirements for the gas type being used. This re pit should be installed in accordance with
local codes and ordinances or in the absence of local codes, with the latest National Fuel Gas Code, ANSI Z223.1
NFPA54 or CSA B149.1, Natural and Propane Installation Code in Canada.
6. Fire pits create high temperatures, it is very important to have any combustibles at a safe distance.
7. Normal operation of the re pit is with a battery pack that is supplied with your system (Fig 7). The battery pack has
12-feet of black sleeved wire that is to be passed through the junction box provided. This wire should not be cut or
spliced and the junction box can be placed in the facing of the vertical nish of the re pit, if you place the wire under
ground you should install those wires into an approved protective conduit/sleeve material.
8. Fire pit should never be left unattended while in operation. It should always be a safe distance from all trees and
combustible landscape materials.
10. Construction of the nished re pit should be stable and solid. From the bottom of the burner housing (cradle) that holds
the burner assembly it requires a minimum if of 15-inches to the ground level. See page 3. Drainage is critical to ensure
that water does not damage gas valve and components. Never install the re pit system below grade.
11. CAUTION: The re pit enclosure MUST have a minimum ventilation of 18 square inches on each side of the
nished enclosure.
12. Never ll the cavity under and around the valve box with any material, this is a provided air space necessary for
ventilation.
13. These products are designed for outdoor use only. They are not approved for any indoor use.
14. This re pit is designed for use with the following Firegear Outdoors media: FG-Lava Rock (min. 1” diameter), FG-Lava
Stones, Firegear Liquid Glass Beads or Firegear Large Broken Glass. Cover the burner completely, so that the burner is
not highly visible. Do not cover more than 1” above the top of the burner screen.
15. Gas lines and ttings must be installed into the non-combustible structure. All gas connections must be leak tested
following installation of the re pit. Soapy water leak detection is required before regular use of the re pit.
16. Do not use burner media (rocks/glass) that will absorb moisture over time and will not release this moisture quickly.
Moisture can boil in this material and can rapidly break apart and cause damage or personal injury.
17. Never leave any other combustible material on top of the re pit. This could cause unsafe operation of this system
and damage to the component that will not be covered under our warranty.
INSTALLATION OF FIRE PIT INTO AN APPROVED ENCLOSURE
Gas Supply
Fire Pit Pan
Non-Combustible
Fire Pit Enclousure
Valve Box
Steel
Studs
NOTE: Gas valve, exible gas lines and TFS
components are supplied. A gas shut-off
before the appliance is recommended but
not supplied
Fig. 6 Typical installation.
TFS Linear Fire Pits

REV. 4-13-16 Page 7
INSTALLATION OF BATTERY PACK
1. During installation the location of the battery pack should be installed in the location that is easy to service.
The best location is in the vertical enclosure of the Fire pit. The plastic junction box is provided for the installation
of the battery pack.
Requires 4-AA 1.5V
alkaline batteries
Battery cover slides on/off
Latching Solenoid DC Motor Drive
Slide Switch
to Latching
Solenoid
2. The wiring extending from the valve box is a 12-foot special 4-pin connector that connects to the battery pack and
(2) two additional wires with ¼” female connectors. A complete wiring diagram (Fig.13) is located on page 13.
3. Feed all wires into the plastic junction box and connect special 4-pin plug into back of the battery pack. Connect
¼” female spade connectors to solenoid wires matching color, red-to-red and black-to-black.
4. Install the (4) AA batteries in to the battery compartment shown in Fig 7. Double check to ensure the slide
switch is in the Latching Solenoid position on the battery pack. Then snap cover plate in place as shown in Fig.8.
Fig. 7. Slide switch on latching solenoid
5. Reinstall the battery pack into the plastic junction box, line up the two holes in the cover and install white screws
provided. Batteries can be changed or installed by removing the two screws that hold the cover plate battery pack
in place. Remove assembly, slide cover away from the cover plate and install the (4) four AA batteries.
6. Be sure the batteries are installed positive-to-positive and negative-to-negative. If one battery is installed wrong
the system will not operate.
7. Once the re pit is installed into the enclosure, the burner and control system should be tested before the media
(rocks/glass) is installed.
INSTALLATION OF BATTERY INTO TRANSMITTER
You have one handheld transmitter and you will need to install the included (12-volt battery) into the transmitter. On the
backside of the transmitter, push the cover away from the case. Place the battery into the compartment matching positive-
to-positive and negative-to-negative. To ensure the battery is properly installed push any button on the transmitter and
you will see a red LED light at the top of the transmitter glow. The red LED light will only be lit when a button is pushed.
Fig. 8 Cover plate installation
PILOT ALIGNMENT
The pilot assembly is mounted underneath the
pilot cover. Ensure the pilot ame is passing
through the ignition hole in the burner pan. Use
the Fig. 9 as a guide.
Fig. 9 Proper pilot assembly alignment.
Battery Pack
Cover Plate
(Rear View)
Burner Tube
(under screen)
Thermocouple
Media
Pilot Hood
Pilot Assembly
Ignition Hole
TFS Linear Fire Pits

REV. 4-13-16 Page 8
Fig. 10 Removing the cover from metal box.
LEARNING THE REMOTE CONTROL TO THE MODULE
The Firegear Outdoors re pit comes standard with one
remote controlled transmitter. The handheld remote is
shipped with this system are already learned (programmed)
to the module inside the control box.
Additional transmitters can be learned to this electronic
module; up to a total of three Firegear Outdoors transmitters
are available. Contact Firegear Outdoors to discuss
additional transmitter options or see the accessory page of
this instruction manual.
Learning the new transmitters is simple, but will require
pressing the learn button on the module. You should learn
any new transmitters before the nal installation of the re pit.
Follow the steps below:
1. Remove the two screws securing the cover on the
control box (See Fig. 10). The cover will slide
down exposing the gas valve and control module.
2. Find the black module attached to the inside of the
control box. Locate the “Learn Button” on the bottom
of the module.
3. Once the Learn button is located, press and release
the button once. You will hear a beep indicating that
the module is ready to receive a transmitter code
(See Fig. 11)
4. Take the transmitter and press the OFF button. You
will hear a series of rapid beeps indicating the module
has accepted the new code.
NOTE: A maximum of three (3) codes can be programmed to
the module. After a total of three (3) codes have been
programmed the memory is full and will not accept any
additional codes. To clear all codes, press and hold the learn
button for 10 seconds. The module will beep three (3) times
indicating the memory is clear of all codes. After codes have
been cleared see Step #3 above to re-learn transmitter.
Learn Button
AUX
POWER
PEN
MODULE
INSIDE FIRE PIT
METAL BOX
Fire Pit Valve Box
Fig. 11 Learn button location
TFS Linear Fire Pits

INSTALLING MEDIA
Install media into the burner pan. Ensure the media is lava rock, large broken glass or lava stones for proper operation.
Be sure media is free of any excessive dust. This prevents the burner pan weep holes from being plugged and holding
water. Loose tting media is important to ensure robust ames.
Completely cover the burner with media but do not make the depth greater than 1-inch overtop of the burner port holes.
IMPORTANT: Do not place media under the screen cover. It must be free of any debris to operate properly.
P
IL
O
T
C
O
V
ER
P
I
L
OT
S
HI
EL
D
SCREEN COVER - 2 PIECES
INSTALLING PILOT COVER AND PILOT SHIELD
Final preparations will require you to install the pilot cover and pilot shield. They are wrapped in a protective material to
prevent scratches and are inside the carton of the re pit.
After you re tested the re pit unwrap the pilot cover and pilot shield. The pilot cover will sit into place inside each
end of the cradle. The pilot shield then slides into the slots of the pilot cover and becomes a heat shield when the pilot
is burning for TFS models. NOTE: If you do not have a TFS system the pilot cover and pilot shield are required to be
installed on a MT model for a nished look.
Fig. 12 Installation of pilot cover and pilot shield.
Ensure the stainless steel screen is covering the burner as shown.
TFS Linear Fire Pits REV. 4-13-16 Page 9

REV. 4-13-16 Page 10
CAUTION: Children and adults should be alerted to the hazards on high surface temperatures and should stay away to
avoid burns or clothing ignition. Young children should be carefully supervised when they are in the area of the appliance.
WARNING: Do not use this appliance if any part has been under water. Immediately call a qualied service technician
to inspect the appliance and to replace any part of control system and any gas control, which has been under water.
OPERATION
SAFETY WARNINGS
1. Never leave the Fire pit unattended during operation.
2. Clothing or other ammable materials should not be placed on or near the appliance.
3. Any guard or other protective device removed for servicing the appliance must be replaced prior to operating the
appliance.
4. Installation and repair should be done by a qualied service person. The appliance should be inspected before
use and at least annually by a qualied service person. More frequent cleaning may be required as necessary. It
is imperative the control compartment, burners and circulating air passageways of the appliance be kept clean.
5. Inspect the fuel supply connection before each use of the appliance.
6. Temporary storage of this appliance indoors is permissible only if it has been disconnected from its fuel supply
(Natural or L.P. gas line).
WARNING
1. This appliance is hot when operated and can cause severe burns if contacted.
2. Do not burn any solid fuels in this appliance.
LIGHTING INSTRUCTIONS
NOTE: It may take several cycles of ON/OFF to purge the airow from the gas lines. The direct spark ignition
will turn OFF after 20 seconds if the burner does not light after which you will need to press transmitter OFF button then
back ON to initiate ignition again.
Flame height can be adjusted HI and LO. After the re pit is operating press the handheld transmitter HI or LO. The
transmitter defaults to the HI setting when initially lighting the re pit each time or if attempting to re-light but will
remember the last setting used and change back to that last setting in approximately 5 seconds after lighting.
READ ALL WARNING AND SAFETY INFORMATION ABOVE BEFORE ATTEMPTING TO LIGHT FIRE PIT
L
O
W
H
I
O
F
F
O
N
TURNING OFF FIRE PIT
1. To turn OFF the re pit press the OFF button on the transmitter. Fire pit will turn OFF.
2. After re pit has completely cooled off install cover.
Fig. 12 Transmitter
TURNING ON FIRE PIT
1. Ensure you have leak tested the re pit before operating. Turn main gas supply ON.
2. Ensure batteries are installed in battery pack and switch is on Latching Solenoid.
3. Press the ON button on the transmitter. You will hear the ignitor probe will begin sparking
for up to 20 seconds and the re pit will turn ON.
4. If the re pit does not light the module will “beep” one time every second indicating an
ignition error. This is a hard lockout. If this occurs press the OFF button on the remote
control and repeat step 1-3.
5. If re pit does not light after second try turn main gas OFF, wait 5 minutes and repeat
steps 1-3.
TFS Linear Fire Pits

REV. 4-13-16 Page 11
TFS REPLACEMENT PARTS
1
2
6
89
Drawings Are Not to Scale
Remote/Off
SI
ADJ.
IPI
POWER
Learn AUX
13
14
AA Batteries
AA Batteries
AA Batteries
AA Batteries
17
19
Latching Solenoid DC Moror Driv
e
Requires 4-AA 1.5V
alkaline batteries
Control Box
Battery cover slides on/off
Slide
Switch
ON
OFF
20
57
L
O
W
H
I
O
FF
O
N
21
10
OUT
PILOT ADJ
IN
MAIN
PILOT
3
4
11
12
15 16 18
TFS Linear Fire Pits

REV. 4-13-16 Page 12
1 24” Linear Burner Cradle 1 CRADLE-L24
1 30” Linear Burner Cradle 1 CRADLE-L30
1 36” Linear Burner Cradle 1 CRADLE-L36
2 24” Linear Burner Pan 1 PAN-L24
2 30” Linear Burner Pan 1 PAN-L30
2 36” Linear Burner Pan 1 PAN-L36
3 24” Linear Burner Tube 1 B-L24
3 30” Linear Burner Tube 1 B-L30
3 36” Linear Burner Tube 1 B-L36
4 24” Linear Burner Guard 1 GUARD-L24
4 30” Linear Burner Guard 1 GUARD -L30
4 36” Linear Burner Guard 1 GUARD-L36
5½” NPS Brass Mounting Nut 1 105-8
6 7/8” Flat Washer/Spacer 4 ST3-113-1026
71/2” Flex Gas Line (46-inch Length) 2 T-200-9898-46
8 Air Shutter Orice NG (for 24” Natural Gas Models) 1 OAS-NG38
8 Air Shutter Orice NG (for 30” Natural Gas Models) 1 OAS-NG35
8 Air Shutter Orice NG (for 36” Natural Gas Models) 1 OAS-NG125
9 Air Shutter Orice LP (for 24” Propane Gas Models) 1 OAS-LP50
9 Air Shutter Orice LP (for 30” Propane Gas Models) 1 OAS-LP47
9 Air Shutter Orice LP (for 36” Propane Gas Models) 1 OAS-LP43
10 Electronic IPI Gas Valve with Solenoid 1 AF-4025DSILSS36
11 Pilot Assembly 1 PILOTO23300-206
12 Linear Burner Cradle Bracket 2 CRADLEBRACKET-L
13 Linear Burner Ext Bracket 1 EXTBRACKET-L
14 Ignition Module 1 VCS-5000MODTC
15 Linear Burner Pilot Shield 2 PILOTSHIELD-L
16 Linear Burner Pilot Cover 2 PILOTCOVER-L
17 AA Batteries 1.5 Volt (used in battery pack) 4 BATTAA
18 Valve Box Stainless Steel Lid 1 FIREPITMETALBOXCO
19 Valve Box Stainless Steel 1 FIREPITMETALBOX
20 Battery Pack (with 12-foot 4-Pin, 4-wire harness, cover plate and 12-
foot red & black 2-wire harness for solenoid)
1 AF-4000BP12
21 ON/OFF HI/LO Transmitter 1 RCAF-3TX
22 Transmitter Battery (not shown) 1 BATT12VOLT
23 Stainless Thread Cutting Screws #10-24x ½” (not shown) 14 ST3-113-1028
24 ½” Cast Iron Coupler (not shown) 1 ST3-093-1029
25 Gas Valve 8-Pin Wiring Harness (not shown) 1 AF-40008PIN12WH/2
26 Plastic Electrical Gang Box with Tabs (not shown) 1 JUNCTIONBOX
27 12-inch, 8-Pin Wire Harness (not shown) 1 AF-40008PIN12WH2
28 ½” NPT Male to Male Close Nipple (not shown) 1 ST3-093-1025
29 ½” NPT Male to ½” Male Flare Fitting (not shown) 1 U1-8D-S
30 Red Silicone “O” Ring (not shown) 1 ORING
Item Description Qty. Part Number
TFS REPLACEMENT PARTS
TFS Linear Fire Pits

REV. 4-13-16 Page 13
FIRE PIT MAINTENANCE
1. The re pit should be inspected and cleaned before initial use at least annually by a qualied eld service person.
2. Any component that is found faulty must be replaced with an approved component.
3. Any tampering or modifying with the re pit is dangerous and voids all warranties.
4. During winter months in cold climates and various seasons operation the re pit may be affected by weather
conditions. It is recommended to use a ventilated cover overtop of your re pit to protect it from humid/rainy weather
conditions when not in use. Heavy rains/downpours could affect the re pit operation if not covered; if this
occurs ensure you allow the re pit time to dry out before attempting to operate. NOTE: If a combustible type cover is
used over the re pit when not in use be sure to remove it before operation to prevent a severe safety hazard.
5. Carbon (soot) may build up on the surface of logs (if installed) during heavy use. Sooting may also occur periodically
under the pilot cover. To clean, brush off with a dry bristle brush or cloth. Keep soot away from clothing or
furniture.
6. Over time stainless steel parts can discolor when heated, usually a golden or brown hue. This discoloration is normal
and does not affect the performance of the appliance.
TROUBLE SHOOTING
TROUBLE SHOOTING
FAULT CODES
The VCS-5000MODTC control module has built-in error detection for several common operating fault conditions. When
the control module detects an error, it will emit a series of beeps. The beeping pattern will help to determine the cause of
the operating fault.
Ignition Safety (Protection for Ignition system):
Error Code: One beep every one second.
Description of Fault: Warn users if the pilot is not successfully ignited in 20 seconds.
How to Clear: Press OFF then ON buttons to re-attempt ignition.
What to Check:
1. Ensure gas supply is turned ON.
2. Ensure that the gas line is purged of air. Air is common in the gas line if the appliance has just been installed, has
been disconnected then re-connected to the gas line, or if the appliance has been unused for an extended period
of time.
3. Ensure there is no blockage in the gas line.
4. Make sure that the ame is properly contacting the thermocouple on the pilot assembly and check for soot build-
up. Clean soot if present.
5. Ensure orange/white leads from module are plugged into the “PILOT” connection on the valve body.
6. Ensure green/white leads from module are plugged into the “MAIN” connection on the valve body.
7. Verify lead from pilot assembly is connected to the “I” terminal on the module.
8. Verify lead from ame sensor on electrode assembly is connected to the “S” terminal on the module and ground
terminal is connected to ground.
9. Verify that the black ground lead from the module is connected to a proper ground on the appliance and check for
frayed or pinched wires on the sensor wire lead.
Sensor Safety (Protection for Flame sensor):
Error Code: 4 Beeps every one second (Constant beeping)
Description of Fault: Warn users the ame sensor detects a ame already present when ignition sequence is initiated.
Also if thermocouple is not given enough time to cool off (30 seconds or more) before re-lighting appliance.
How to Clear: Press OFF then ON buttons to re-attempt normal ignition.
What to Check:
1. Allow thermocouple to cool off minimum of 30 seconds.
2. Check if ame is actually present when valve is turned OFF (if so, replace valve).
3. Check to ensure ground wire from thermocouple and module are connected to gas valve.
4. If 3-probe ignitor is exposed to excessive moisture/water it will need 24-48 hours to dry out.
6.
TFS Linear Fire Pits

REV. 4-13-16 Page 14
Thermal Safety (Overheat Protection):
Error Code: 4 Beeps every 2 seconds.
Description of Fault: Warn users that the modules internal temperature exceeds 170°F.
How to Clear: Module’s internal temperature must cool to below 160°F and then press ON button.
What to Check:
1. Ensure that there is proper ventilation to the control module.
2. Is module (inside valve box) located in unapproved location, too close to burner?
3. Move to cooler location.
Wireless Remote Transmitter Will Not Operate Appliance
1. Make sure that the transmitter is within the 25-foot operational range of the control module.
2. Ensure batteries in transmitter are fully charged and properly installed.
3. If using the battery pack, ensure batteries are fully charged and properly installed. Also, make sure the battery
pack’s 4-pin connector is securely connected to the battery pack and control module.
4. If using optional AC adapter, ensure that the AC adapter leads are securely attached to “POWER” connection on
the control module. Also, ensure that the AC adapter is connected to a live 120VAC power source.
5. Ensure “Remote/Off” switch on control module is set to “Remote”.
6. Ensure the control module has learned the transmitter’s security code (learning section pg. 8).
7. Make sure that the remote transmitter is not placed/mounted to a metal surface, which will reduce the operating
range.
8. Make sure that there is not a large metal obstruction between the remote transmitter and the control module.
Ignitor Sparks at Pilot Hood Frequently During Operation
1. The control module will generate a spark at the ignitor electrode to the pilot hood if the system is in the ON
position, but does not does not light; thermocouple may not be hot enough or generating enough millivolts.
2. Make sure that the tip of the thermocouple is clean. Soot buildup will insulate the thermocouple and will not allow
for proper ame sensing.
3. Make sure that wind does not blow the pilot ame out. The pilot hood and the media (rocks, glass, etc.) provides
shielding from the wind. Ensure that the pilot hood and media are properly positioned per the instructions. If wind
is too strong, and the pilot ame can not maintain contact the thermocouple properly, the appliance should not be
operated.
Flame Modulation Will Not Work or Works Backwards
1. Ensure that the black and red leads from the battery pack are securely connected to the red and black leads from
the Hi/Lo latching solenoid located on the valve body (red to red and black to black).
2. Verify that the selector switch on the battery pack is set to LATCHING SOLENOID only.
3. Check functionality with all transmitters to determine if there is an issue with the main control system or an
individual transmitter. If the issue is with an individual transmitter, make sure that the batteries in both the transmit
ter and battery pack are installed properly and fully charged.
Fig. 13 Wiring Diagram
OUT
PILOT ADJ
IN
MAIN
PILOT
Battery
Pack
Black (Ground)
Orange
Green
White
2-Brown
White
Black (-)
Red (+)
Black (4-Pin Connector)
Red
Red
Black
Black
Learn AUX
Remote/OFF
AF-5000MOD-1
Module
I
S
Ignitor
Sensor
Thermocouple Ground Wire
Pilot Assembly
TFS Linear Fire Pits

FOR TECHNICAL SERVICE, CALL:
Firegear Outdoors
9230 Conservation Way
Fort Wayne, IN 46809
For Sales: [phone]
WEB SITE: www.regearoutdoors.com
[phone]
OPTIONAL ACCESSORIES
The following accessories are available from your local Firegear dealer/distributor.
Each accessory comes with a separate installation manual. Read each instruction thoroughly before installing.
Firegear Outdoors Media
Lava Rock - 1” to 2” size
Lava Stones - 1” to 2” size
Glass Beads - Assorted Colors
Large Crushed Glass - Assorted
Colors
Model: AF-4000ADP24 (80) optional
7.5VDC transformer (24” leads)
eliminates the use of battery power.
LP CONVERSION KIT
THERE IS NO LP CONVERSION
KIT AVAILABLE THESE MODELS.
YOU MUST ORDER THE FIRE PIT
DIRECT FROM THE FACTORY AS
PROPANE.
MODEL: 1322-WT
Wireless wall switch with
ON/OFF/HI/LO
MODEL: 1001D-A
Wireless wall switch with
ON/OFF ONLY
MODEL: TMR-AF1
4-Button Timer with
30/60/120/OFF Minutes
Windshields
Models:
GSW-3812:
38” long x 12 7/8” wide x 7 1/2” tall
GSW4312:
43 1/2” long x 12 7/8” wide x 7 1/2” tall
Stainless Steel Trim
Models:
FPB-24LMT-N TRIM - L24
FPB-30LMT-N TRIM - L30
FPB-36LMT-N TRIM - L36
Home Automation System
Model: AF-4000HAT
Enables the re pit to operate with a
home automation device.
Vent Kits
Model: VENT-KIT-8x12 (provides
18-sq.in. per side of enclosure)
ON
OFF
HI
LO
30 MIN
60 MIN
120 MIN
OFF
REV. 4-13-16 Page 15
TFS Linear Fire Pits

Skytech Products Group (Firegear Outdoors) hereby
warrants to the end user that products will be free from
material and workmanship defects that prevent safe and
correct operation of the product. The warranty
commences from date of sale to the end user for the
following period:
Stainless Steel Components 5-Years
Gas Valve, Spark Ignitor &
Electronic Parts
2-Years
G90 Galvanized Pans 3-Years
Gas Logs 5-Years
Glass Windshield 1-Year
Glass Media 5-Years
Controls 5-Years
RTF Enclosure 5-Years
Lava Rock & Lava Stones No Warranty
Consumer/Non-Commercial Applications
Stainless Steel Components 1-Year
Gas Valve, Spark Ignitor &
Electronic Parts
1-Year
G90 Galvanized Pans 1-Year
Gas Logs 1-Year
Glass Windshield 1-Year
Glass Media 1-Year
Controls 1-Year
RTF Enclosure 1-Year
Lava Rock & Lava Stones No Warranty
Commercial Applications
End User must provide a bill of sale, canceled check, or
payment record from the end user to verify
purchase date and to establish warranty period. This
Limited Warranty shall be valid and limited to the
original purchaser only.
WARNING: Any modication to the product will void the
warranty.
This Limited Warranty shall be limited to the repair and/
or replacement of parts that have proven to be defective
under normal use and service. Before
returning any parts, contact our Technical Service
Department for a Return Materials Authorization (RMA)
number. All warranty claims must be made by the OEM
/ Distributor / Dealer account on behalf of the end user.
You may contact Technical Service at [phone].
All approved returned defects must be conrmed by our
Technical Service Department. If the defect is conrmed
and we approve the claim, we will replace such parts
without charge. This warranty gives you specic legal
rights, and you may also have other rights, which vary
from state to state.
Travel, diagnostic cost, service labor to repair the
defect and freight charges on warranty parts to and from
the factory will be responsibility of the owner. We will not
be responsible for labor charges and/or
damage incurred in installation, repair, and
replacement.
This Limited Warranty is voided if not assembled,
installed and operated as intended. This Limited
Warranty does not cover any defects due to accident,
abuse, misuse, alteration, misapplication, vandalism,
improper installation or improper maintenance or
service, removal from the original location or
re-installation into another location, or failure to
perform normal and routine maintenance.
Damage due to severe weather conditions such as hail,
hurricanes, earthquakes, tornadoes, discoloration due
to over-heating, exposure to chemicals (including salt),
either directly or in the atmosphere, or very high
humidity, is not covered by this Limited Warranty.
There are no other express warranties except as set
forth herein. For consumer applications, any
applicable implied warranties of merchantability and
tness are limited in duration to the period of coverage
of this Limited Warranty. Some states do not allow
limitation on how long an implied warranty lasts, so this
limitation may not apply to you.
For Commercial applications, the liability of
Firegear Outdoors is limited to the express terms of this
warranty. We expressly disclaim any and all implied
warranties, including any warranties of tness for a
particular purpose or merchantability.
We are not liable for any special, indirect or
consequential damages. Our maximum liability is
limited to the purchase price of the purchased products.
Some states do not allow the exclusion or limitation of
incidental or consequential damages, so this limitation or
exclusions may not apply to you.
We do not authorize any person or company to
assume for it any other obligation or liability in
connection with the sale, installation, use, removal,
return, or replacement of its equipment; and no such
representations are binding. REV. 3-2-16
LIMITED WARRANTY

Having problems getting the re pit to operate? Don’t leave the job site!
We want to help! Call 855.498.8324 for Technical Support
between the hours of 8:00AM to 5:00PM EST.
Text photos to 260.255.5750 or e-mail photos to [email protected].
BEFORE YOU CALL WE WILL NEED THIS INFORMATION
1. Model Number: ___________________________
2. Serial Number: ___________________________
3. How long is the gas line run? Nat Gas ____ LP Gas ____
4. What size is gas line? _____
5. Inlet Gas Pressure: _____WC
Manifold Gas Pressure: _____ WC
6. What type of media are you using? __________________
7. Review the troubleshooting section in the installation manual.
8. What are the symptoms? Please be prepared to explain.
9. Be prepared to send photos to us when on the phone.
10. Found missing or damaged parts? Let us know ASAP or send photos.
FPSS 3-30-16
Fire Pits
