FireplaceXtrordinair ProBuilder 72 Linear MV User manual

ProBuilder
72 Linear (MV/GSB2)
Installation Manual
WARNING: FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Leave the building immediately
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
HOT GLASS WILL CAUSE
BURNS
DO NOT TOUCH GLASS
UNTIL COOLED
NEVER ALLOW CHILDREN
TO TOUCH GLASS
A barrier designed to reduce the risk of burns from
the hot viewing glass is provided with this appliance
and shall be installed for the protection of children
and other at-risk individuals.
Tested and Listed by
Report # 0028GF105S-001
Omni-Test Laboratories, Inc.
Portland, Oregon
ANSI Z21.88-2016
CSA 2.33-2016
 Built-In Direct Vent
Fireplace
 Natural Gas or Propane
 Residential or Mobile
Home
This appliance may be installed in an aftermarket, permanently located, manufactured home
(USA only) or mobile home, where not prohibited by local codes.
This appliance is only for use with the type of gas indicated on the rating plate. A conversion
kit is supplied with the appliance.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
French language manuals at travisindustries.com
Manuels de langue Française à travisindustries.com
Travis Industries, Inc. 12521 Harbour Reach Dr., Mukilteo, WA 98275 www.travisproducts.com
 Copyright 2018, T.I. $10.00 1/2/19 100-01458

2 Introduction
© Travis Industries 1/2/19 - 1458 PB 72 MV/GSB2 Install
Overview
This manual details the installation
requirements for the Pro Builder 72 Linear mV
fireplace. For operating and maintenance
instructions, refer to the Pro Builder 72 Linear
mV Owner's Manual.
Listing Details
This appliance was listed by Omni Test Labs to
ANSI Z21.88. The listing label is attached to
the appliance near the gas control valve. A
copy is shown to the right.
Massachusetts Approval
This manual has been submitted to the
Massachusetts Board of State Examiners of
Plumbers and Gas Fitters.
National Fireplace Institute

Table of Contents 3
© Travis Industries 1/2/19 - 1458 PB 72 MV/GSB2 Install
Overview ................................................................... 2
Listing Details ........................................................... 2
Installation Options .................................................. 6
Heating Specifications ............................................. 6
Dimensions ............................................................... 6
Packing List .............................................................. 7
Additional Items Required ....................................... 7
Recommended Installation Procedure ................... 7
Massachusetts Requirements ................................ 8
Requirements for the Commonwealth of
Massachusetts .................................................................8
MANUFACTURER REQUIREMENTS .............................8
Fireplace Placement Requirements ....................... 9
Clearances ......................................................................9
Raised Fireplaces ............................................................9
Televisions Placed Above the Fireplace ................ 10
Minimum Framing Dimensions ............................... 11
Standoff Assembly ................................................... 12
Nailing Brackets ....................................................... 13
Standard vs. Extended Position ............................. 14
Header and Pipe Shield Installation ....................... 15
Corner Installations .................................................. 19
Outdoor fireplace installations ............................... 20
Removing the Front Panel ....................................... 21
Gas Line Requirements ........................................... 22
Fuel .................................................................................22
Gas Line Connection .......................................................22
Gas Inlet Pressure ...........................................................22
Gas Line Location ............................................................23
*Relocating the Gas Line to the Base of Fireplace ......... 23
Electrical Connection ............................................... 24
Optional Wall Switch or Thermostat Installation .. 25
Parallel ConnectionSeries Connection ...................25
Vent Requirements ................................................... 26
Vent Clearances ..............................................................26
Vent Firestop or Thimble .................................................26
Altitude Considerations ....................................................26
Approved Vent .................................................................26
Vent Installation ...............................................................27
Approved Vent Configurations ............................... 27
Exhaust Restrictor Position..............................................27
Diffuser ............................................................................28
Minimum Vent Configuration .................................. 29
Vent Configuration: Vertical Termination .............. 30
Vent Configuration: Horizontal Termination
with Vertical Rise ...................................................... 31
Masonry Chimney Conversions ............................. 32
Class A Chimney Conversion ................................. 33
Termination Requirements ...................................... 34
Hearth Requirements ............................................... 35
Facing Requirements ............................................... 36
Standard vs. Extended Position ...................................... 37
Facing Thicker than 1-1/2”. ........................................... 38
Screen Assembly Mounts ................................................ 39
Do Not Drill or Screw Zone .............................................. 40
Mantel Requirements ............................................... 41
Mantel Column Clearances ........................................... 41
Use of a Non-Combustible Mantel Below Listed
Mantel Clearances .................................................... 42
Finalizing the Installation ........................................ 43
MV Units Only - Pilot Flame Inspection - (see
instructions on page 46) .................................................. 43
GSB2 Units Only - Pilot Flame Inspection - (see
instructions on page 46) .................................................. 43
Air Shutter Adjustment .................................................... 44
Location of Controls ........................................................ 45
MV Units Only - Starting the Pilot .................................... 46
Glass Frame Removal and Installation ............................ 47
Barrier Screen Visual Deflector Adjustment .................... 5 0 
Crushed Glass Installation ............................................... 51
LP Conversion Instructions .................................... 53 
Wall Mount Remote Thermostat installation
(optional) ................................................................... 58
Packing List ..................................................................... 58
Installation ....................................................................... 58
Wiring Diagram – MV Version ................................. 61
Optional Blower Wiring .................................................... 61
Wiring Diagram – GSB2 Version ............................. 62

4 Safety Precautions
© Travis Industries 1/2/19 - 1458 PB 72 MV/GSB2 Install
Safety Warnings
 Failure to follow all of the requirements may result in property damage, bodily injury, or even death.
Young children should be carefully supervised when they are in the same room
as the appliance. Toddlers, young children and others may be susceptible to
accidental contact burns. A physical barrier is recommended if there are at risk
individuals in the house. To restrict access to a fireplace or stove, install an
adjustable safety gate to keep toddlers, young children and other at risk
individuals out of the room and away from hot surfaces.
Children and adults should be alerted to the hazards of high surface temperature
and should stay away to avoid burns or clothing ignition. Do not touch the hot
surfaces of the heater. Educate all children of the danger of a high-temperature
heater.
Due to the high temperature, the heater should be located out of traffic and away
from furniture and draperies.
 This unit must be installed by a qualified installer to prevent the possibility of an explosion.
 This appliance must be installed in accordance with all local codes, if any; if not, in U.S.A. follow ANSI
Z223.1 and NFPA 54(88), in Canada follow CSA B149.1.
 A manufactured home (USA only) or mobile home OEM installation must conform with the
Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280, or, when such a
standard is not applicable, the Standard for Manufactured Home Installations, ANSI/NCSBCS
A225.1, or Standard for Gas Equipped Recreational Vehicles and Mobile Housing, CSA Z240.4. This
appliance may be installed in Manufactured Housing only after the home is site located.
 All exhaust gases must be vented outside the structure of the living-area. Combustion air is drawn
from outside the living-area structure. The venting must not be connected to a chimney flue serving a
separate solid-fuel burning appliance.
 Notify your insurance company before hooking up this fireplace.
 The instructions in this manual must be strictly adhered to. Do not use makeshift methods or
compromise in the installation. Improper installation will void the warranty and safety listing.
 This heater is approved for use with natural gas (NG) or propane (LP). Burning the incorrect fuel will
void the warranty and safety listing and may cause an extreme safety hazard. Direct questions about
the type of fuel used to your dealer.
 Contact your local building officials to obtain a permit and information on any installation restrictions
or inspection requirements in your area.
 If the flame becomes sooty, dark orange in color, or extremely tall, do not operate the heater. Call
your dealer and arrange for proper servicing.
 It is imperative that control compartments, screens, or circulating air passageways of the heater be
kept clean and free of obstructions. These areas provide the air necessary for safe operation.
 Do not operate the heater if it is not operating properly in any fashion or if you are uncertain. Call
your dealer for a full explanation of your heater and what to expect.
 Do not store or use gasoline or other flammable liquids in the vicinity of this heater.
 Do not operate if any portion of the heater was submerged in water or if any corrosion occurs.
Immediately call a qualified service technician to inspect the appliance and to replace any part of the
control system and any gas control which has been under water.

Safety Precautions 5
© Travis Industries 1/2/19 - 1458 PB 72 MV/GSB2 Install
Safety Warnings (continued)
 Because this heater can be controlled by a thermostat there is a possibility of the heater turning on
and igniting any items placed on or near the appliance.
 Light the heater using the built-in igniter. Do not use matches or any other external device to light
your heater.
 Never remove, replace, modify or substitute any part of the heater unless instructions are given in this
manual. All other work must be done by a trained technician. Don't modify or replace orifices.
 The viewing glass should be opened only for conducting service (or lighting the pilot on millivolt units).
 Allow the heater to cool before carrying out any maintenance or cleaning.
 Operate the heater according to the instructions included in this manual.
 If the main burners do not start correctly turn the gas off and call your dealer for service.
 This unit is not for use with solid fuel.
 Do not place anything inside the firebox (except the optional artwork).
 Warning: Do not operate appliance with the glass front removed, cracked or broken. Replacement
of the glass should be done by a licensed or qualified service person.
 Do not throw this manual away. This manual has important operating and maintenance instructions
that you will need at a later time. Always follow the instructions in this manual.
 Instruct everyone in the house how to shut gas off to the appliance and at the gas main shutoff valve.
The gas main shutoff valve is usually next to the gas meter or propane tank and requires a wrench to
shut off.
 A barrier designed to reduce the risk of burns from the hot viewing glass is provided with this
appliance and shall be installed for the protection of children and other at-risk individuals.
 If the barrier becomes damaged, the barrier shall be replaced with the manufacturer’s barrier for this
appliance.
 Clothing or other flammable material should not be placed on or near the appliance.
 Any safety screen, guard, or barrier removed for servicing an appliance must be replaced prior to
operating the appliance.
 Installation and repair should be done by a qualified service person. The appliance should be
inspected before use and at least annually by a professional service person. More frequent cleaning
might be required due to excessive lint from carpeting, bedding material, et cetera. It is imperative
that control compartments, burners, and circulating air passageways of the appliance be kept clean.
 Travis Industries, Inc. grants no warranty, implied or stated, for the installation or
maintenance of your heater, and assumes no responsibility of any consequential damage(s).
Proposition 65 Warning: Fuels used in gas, woodburning or oil fired appliances, and the products of combustion of such fuels,
contain chemicals known to the State of California to cause cancer, birth defects and other reproductive harm.
California Health & Safety Code Sec. 25249.6
Travis Gas Fireplaces. Stoves and Inserts are protected by one or more of the following patents; U.S. 8,469,021,
7,066,170, 6,602,068, 6,443,726, 6,953,037; Canada 2755517 as well as other U.S. and Foreign Patents pending.

6 Features and Specifications
© Travis Industries 1/2/19 - 1458 PB 72 MV/GSB2 Install
Installation Options
 Residential or Mobile Home
 Straight or Corner Placement
 Raised or Floor Placement
 Internal or External Chase
 Bedroom Approved
Heating Specifications
Natural Gas Propane
Approximate Heating Capacity (in square feet)* Up to 2,250 Up to 2,250
Maximum BTU Input Per Hour 45,000 45,000
* Heating capacity will vary with floor plan, insulation, and outside temperature.
Dimensions
4-7/8"
124mm
77-1/8" *
1959mm *
275 lbs.
125 Kg.
15-7/8" *
404mm *
43"
1092mm
Left
a' gauche
Front
avant
Right
droit
Rear
arrie're
* Includes the required 1/2" clearance to each side and rear of the fireplace.
20-1/2"
521mm
75-3/4" 1924mm
1-1/2"
38mm
3-3/4"
96mm
31"
788mm
9-3/4"
248mm
SIDE OF
FIREPLACE

Installation (for qualified installers only) 7
© Travis Industries 1/2/19 - 1458 PB 72 MV/GSB2 Install
Packing List
 LP (Propane) Conversion Kit - Burner Orifices (2)-(#54), Pilot Orifice (0.14 LP), LP Regulator
 Thimble (2-Piece Assembly)
 Pipe Shield, Header Shield (shipped attached to top of fireplace)
 Wall Switch, Cover Plate, and Wire
Additional Items Required
 Gas Line Equipment (shutoff valve, pipe, etc.)
 Electrical Equipment (min. 14 gauge, grounded line)
 This Fireplace Requires 8 lbs. (3.6 Kg) of 1/4” Crushed Glass
94500580 Platinum (10 lbs./4.55Kg)
94500581 Bronze (10 lbs./4.55Kg)
94500582 Cobalt (10 lbs./4.55Kg)
94500583 Black (10 lbs./4.55Kg)
Recommended Installation Procedure
 Frame the opening for the fireplace. Make sure to allow for vent installation.
 Install the vent, gas line and electrical hook-up.
 Install the drywall.
 Install the hearth (if applicable).
 Install the facing (if applicable).
 Install the mantel (if applicable).
 Finalize the installation (see page 41).

8 Installation (for qualified installers only)
© Travis Industries 1/2/19 - 1453 PB 72 MV/GSB2 Install
Massachusetts Requirements
NOTE: The following requirements reference various Massachusetts and national codes not contained in this document.
Requirements for the Commonwealth of Massachusetts
For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in
part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent
termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and
porches, the following requirements shall be satisfied:
Installation of Carbon Monoxide Detectors
At the time of installation of the side wall horizontal vented gas fueled equipment, the installing plumber or gasfitter shall
observe that a hard wired carbon monoxide detector with an alarm and battery back-up is installed on the floor level where the
gas equipment is to be installed. In addition, the installing plumber or gasfitter shall observe that a battery operated or hard
wired carbon monoxide detector with an alarm is installed on each additional level of the dwelling, building or structure served
by the side wall horizontal vented gas fueled equipment. It shall be the responsibility of the property owner to secure the
services of qualified licensed professionals for the installation of hard wired carbon monoxide detectors.
In the event that the side wall horizontally vented gas fueled equipment is installed in a crawl space or an attic, the hard wired
carbon monoxide detector with alarm and battery back-up may be installed on the next adjacent floor level.
In the event that the requirements of this subdivision cannot be met at the time of completion of installation, the owner shall
have a period of thirty (30) days to comply with the above requirements; provided, however, that during said thirty (30) day
period, a battery operated carbon monoxide detector with an alarm shall be installed.
Approved Carbon Monoxide Detectors
Each carbon monoxide detector as required in accordance with the above provisions shall comply with NFPA 720 and be
ANSI/UL 2034 listed and IAS certified.
Signage
A metal or plastic identification plate shall be permanently mounted to the exterior of the building at a minimum height of eight
(8) feet above grade directly in line with the exhaust vent terminal for the horizontally vented gas fueled heating appliance or
equipment. The sign shall read, in print size no less than one-half (1/2) inch in size, “GAS VENT DIRECTLY BELOW. KEEP
CLEAR OF ALL OBSTRUCTIONS”.
Inspection
The state or local gas inspector of the side wall horizontally vented gas fueled equipment shall not approve the installation
unless, upon inspection, the inspector observes carbon monoxide detectors and signage installed in accordance with the
provisions of 248 CMR 5.08(2)(a)1 through 4.
Exemptions
The following equipment is exempt from 248 CMR 5.08(2)(a)1 through 4:
• The equipment listed in Chapter 10 entitled “Equipment Not Required To Be Vented” in the most current edition of NFPA 54
as adopted by the Board; and
• Product Approved side wall horizontally vented gas fueled equipment installed in a room or structure separate from the
dwelling, building or structure used in whole or in part for residential purposes.
MANUFACTURER REQUIREMENTS
Gas Equipment Venting System Provided
When the manufacturer of Product Approved side wall horizontally vented gas equipment provides a venting system design or
venting system components with the equipment, the instructions provided by the manufacturer for installation of the equipment
and the venting system shall include:
• Detailed instructions for the installation of the venting system design or the venting system components; and
• A complete parts list for the venting system design or venting system.
Gas Equipment Venting System NOT Provided
When the manufacturer of a Product Approved side wall horizontally vented gas fueled equipment does not provide the parts for
venting the flue gases, but identifies “special venting systems”, the following requirements shall be satisfied by the manufacturer:
• The referenced “special venting system” instructions shall be included with the appliance or equipment installation
instructions; and
• The “special venting systems” shall be Product Approved by the Board, and the instructions for that system shall include a parts list
and detailed installation instructions.
A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipment, all venting
instructions, all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or
equipment at the completion of the installation.
See Gas Connection section for additional Commonwealth of Massachusetts requirements.

Installation (for qualified installers only) 9
© Travis Industries 1/2/19 - 1458 PB 72 MV/GSB2 Install
Fireplace Placement Requirements
 Fireplace must be installed on a level surface capable of supporting the fireplace and vent
 Fireplace must be placed directly on wood or non-combustible surface (not on linoleum or carpet)
 Fireplace should be located out of traffic and away from furniture and avoid burns.
 Fireplace must be placed so the gaps below and above the glass frame do not become blocked.
 Fireplace may be placed in a bedroom. Please be aware of the large amount of heat this appliance produces
when determining a location.
Clearances
(a) Clearance to Side of Fireplace 1/2” (13mm). Do not place insulation in this space.
NOTE: Drywall (or other combustible) may contact the first ½” of the sides of the fireplace.
(b) Clearance to Back of Fireplace 1/2” (13mm). Do not place insulation in this space.
(c) When installed, walls in front of the fireplace must be a minimum 0” (0mm) to the side of the fireplace
standoffs.
Raised Fireplaces
 The fireplace (and hearth, if desired) may be placed on a platform designed to support the fireplace and vent.
 The base of the fireplace must be a minimum 60” (1524mm) below the room ceiling.
The top of the control door (firebox opening) is approximately 8-3/4” (223mm) above the base of
the fireplace. For a typical raised fireplace of 36” (915mm), place the fireplace on a platform 27.25”
(693mm) tall.
a
c
b

10 Installation (for qualified installers only)
© Travis Industries 1/2/19 - 1453 PB 72 MV/GSB2 Install
Televisions Placed Above the Fireplace
The following section gives guidelines to place a television above the fireplace.
IMPORTANT NOTE REGARDING TELEVISIONS AND THIS FIREPLACE
Most television manufacturers instruct the homeowner not to place the television above a heat source like this fireplace. Doing
so may decrease the longevity of the television and negate the warranty. If you do place a television above the fireplace, you
should place a mantel (or build-out) between the fireplace and television (or use a CoolSmart TV Wall™ kit). Follow the
guidelines below to reduce the amount of heat reaching the television. Travis Industries does not take responsibility for any
negative impact to televisions placed near this fireplace.
Minimum Dimensions:
(a) Minimum Mantel Height above Base of Fireplace* 39” (991mm) with 4” (102mm) mantel depth
(b) Minimum Mantel Depth* 4” (102mm)*
(c) Optional Columns (or Build-Out) Must Meet Side Wall Clearances
(Measured to the side of fireplace ZC-can)
* Minimum mantel depth must be 4”(102mm) to allow heat to dissipate. If using a mantel larger than 4”(102mm),
make sure to adjust the mantel height (a) to meet the mantel clearancer (see mantel requirements on page Error!
Bookmark not defined. for details).
 The mantel must extend 2” in front of the television and 1” to both sides.
 If you have a television that is greater than 6” deep (including the 1” gap behind), you will need to alter the mantel depth
and height (see the example below).
 The television must have a 1” gap to the wall to allow for proper cooling. Any build-out near the television must
maintain a 3” gap to the top and sides to prevent heat from being trapped near the television.
NOTE: The mantel must extend 1”(26mm) in front of the TV and 1”(26mm) to both sides. If you have a TV that is greater than
3”(77mm) deep (including the 1”(26mm) gap behind), you will need to alter the mantel depth and height.
Fireplace
Min. 1" (26mm)
Min. 1" (152mm) Min. 2" (51mm)
a
b
c
Optional Column
or Build-Out

















Min. 1" (26mm) Air Gap Behind TV
Min. 3"
(77mm)
Television (TV)



















IDB01243
(b) Depth
(a)
Height
Above
Base of
Fireplace
0" (0mm)
1" (25mm)
2" (51mm)
8" (203mm)
7" (178mm)
6" (152mm)
5" (127mm)
4" (102mm)
3" (76mm)
9" (229mm)
10" (254mm)
11" (279mm)
12" (305mm)
45" (1143mm)
44" (1118mm)
43" (1093mm)
IDB01242
PB42,54,72
42" (1067mm)
41" (1042mm)
40" (1016mm)
39" (991mm)

Installation (for qualified installers only) 11
© Travis Industries 1/2/19 - 1458 PB 72 MV/GSB2 Install
Minimum Framing Dimensions
The fireplace enclosure must be a minimum 68” (1727mm) tall. Do not build into the fireplace
enclosure.
77-1/8"
1959mm
43"
1092mm
a
68"
1727mm
15-7/8"
404mm
a

12 Installation (for qualified installers only)
© Travis Industries 1/2/19 - 1453 PB 72 MV/GSB2 Install
Standoff Assembly
 The side and rear standoffs must be assembled prior to placing the fireplace into position.
 These standoffs, when properly constructed, provide a guide for the required 1/2" clearance.
NOTE: The rear standoffs are bent around the rear corners of the fireplace as shown below to the right.
Rear Standoffs

Installation (for qualified installers only) 13
© Travis Industries 1/2/19 - 1458 PB 72 MV/GSB2 Install
Nailing Brackets
The fireplace has nailing brackets on both sides. Secure the fireplace to the framing with the nailing brackets.
NOTE: Make sure the fireplace is square and plumb when placed in the framing. Measured corner-to-corner the
fireplace should be square. Use shims to insure the fireplace is square.
NOTE: The nailing brackets have two positions: standard and extended. See the section “Facing Requirements”
for details on which position is best for your installation.
Bend the two nailing
brackets out (each side)
a
b
Rotate the two nailing
brackets out (each side)
Secure the fireplace to
the framing using the
nailing brackets
c
Extended Position
(rotate nailing brackets as shown below)
Standard Position
(nailing brackets as shown below)
NOTE: 2 holes are provided on
each side of the fireplace if you
wish to secure the base of the
fireplace to the floor (platform).

14 Installation (for qualified installers only)
© Travis Industries 1/2/19 - 1453 PB 72 MV/GSB2 Install
Standard vs. Extended Position
There are two positions that the standoff/heat shield assembly can be installed. The standoffs are shipped in the
standard (forward) position.
 If the unit is installed in the standard position no modification is needed.
 If the unit is being installed in the extended position, the standoff/heat shield assembly must be
repositioned back ½” (see illustration below).
NOTE: see pages 13 & 37.for additional details about standard vs. extended installations.
Standard Position
Extended Position
This header standoff is in the
extended position.

Installation (for qualified installers only) 15
© Travis Industries 1/2/19 - 1458 PB 72 MV/GSB2 Install
Header and Pipe Shield Installation
The header and pipe shield must be installed as shown below.
NOTE: The header and pipe shields may be installed after the fireplace is in place and vent attached (this allows
for the fireplace to fit into the framing underneath the header and for the vent to be installed more easily).
1 Remove the pipe shield from its shipping location by removing the (4) - ¼” screws attaching it to the back
of the fireplace (Keep the screws for reinstallation).
2 At each of the perforations, bend the sides of the pipe shield backwards 90°asshownbelow.
NOTE: The bottom flanges should be facing outward
Bend at perforations
Tabs face out.
Remove the (4) screws
securing the shield
Remove shield

16 Installation (for qualified installers only)
© Travis Industries 1/2/19 - 1453 PB 72 MV/GSB2 Install
3 Line up the holes on the pipe shield tabs with the holes on the top of the fireplace. Use the screws that
secured the shield during shipping to attach the pipe shield to the top of the fireplace.

Installation (for qualified installers only) 17
© Travis Industries 1/2/19 - 1458 PB 72 MV/GSB2 Install
4 Remove the (4) screws from each of the (2) header shields (keep the screws for reinstallation). Turn
each of the shields over endwise and secure them back into place using the screws you just removed.
The bent edge of the shields should be facing upward and toward the back of the fireplace (see
illustration below).
5 The (2) header standoffs are screwed down flat to front edge of the top of the shields. On each standoff,
remove the screw that is closest to the outside edge of the fireplace (keep screw for reinstallation). Bend
the legs at the perforations as shown below and attach the foot of the standoff to the top of the fireplace
using the screw removed earlier in this step.
NOTE: Use the
forward hole for
standard position.
Attach the header shield to the
header standoff (both sides).
Bend the vertical standoff as
shown to the right (both sides).

18 Installation (for qualified installers only)
© Travis Industries 1/2/19 - 1453 PB 72 MV/GSB2 Install
6 When finished the fireplace should be configured like the picture below.

Installation (for qualified installers only) 19
© Travis Industries 1/2/19 - 1458 PB 72 MV/GSB2 Install
Corner Installations
A typical 45° installation uses the framing dimensions shown in the illustration below (NOTE: all clearances still
apply).
(a) Corner to Wall (minimum) 76-7/16” (1942mm)
(b) Corner to Center of Flue (typical) 31-1/4” (794mm)










































Minimum 1/2" (13mm) Clearance








a
b

20 Installation (for qualified installers only)
© Travis Industries 1/2/19 - 1453 PB 72 MV/GSB2 Install
Outdoor fireplace installations
Travis Industries Inc. gas-fired fireplaces are
suitable for installation into outdoor areas
protected from direct water impingement. In
addition to maintaining listed mantel and
combustibles clearances, a rain protection
overhang factor of 1/2 shall be constructed to
the front and to each side of installed
appliances (see the illustration to the right). All
wiring connections to line power shall be in
accordance with outdoor requirements of
NECA NFPA 70.



































A
B
Side of
Fireplace
The overhang (A) must extend at least 1/2 the roofline height
(B). Height is measured from the base of the fireplace.
For example: if the rooline (B) is 10' (3M) above the base of
the fireplace, the overhang (A) must be at least 5' (1.5M).










