Firex KF10 User manual

SMOKE ALARM DESCRIPTION
Model KF10, KF10LL Ionisation 230V AC smoke alarm with 9V
battery back-up an Hush Button
Model KF10 Ionisation 230V AC smoke alarm with recharge-
able battery backup an Hush Button
Model KF20,KF20LL Optical 230V AC smoke alarm with 9V
battery back-up with Hush Buttonl
Model KF20 Optical 230V AC smoke alarm with rechargeable
battery back-up an Hush Button
SMOKE ALA M FEATU ES
•Interconnects with up to 23 other mo els, KF1, KF1R, KF2, KF2R, KF3, KF3R,
KF10, KF10LL, KF10R, KF20, KF20LL, KF20R, KF30, KF30LL, KF30R, 4870,
4881, 4973, 4985, 4892, 4899, 1SFW, 1SFWR, 2SFW, 2SFWR, 3SFW, 3SFWR,
an 4MCO an 4MDCO Mains CO alarms. Unique power connector prevents
interconnection with incompatible smoke alarms or security systems.
•Tamper-resist bracket quickly snaps into place an serves as a safeguar
against tampering.
•Multi-purpose green an re LEDs in icate that the smoke alarm is receiving
AC power, working un er normal operation, in alarm, or un er Hush Button.
•Lou alarm horn—85 ecibels at 3 metres (10 feet)—soun s to alert you of
an emergency.
• Test button checks smoke alarm operation.
• All mo els feature Hush Button, which, when activate , quiets unwante alarms
for up to 9 minutes.
•Mo els KF10, KF10LL, KF20 an KF20LL will not attach to the mounting
bracket if a battery is not in the battery pocket. These mo els will also soun
a short beep about once a minute if the battery is weak or improperly con-
necte .
•Mo els KF10R , KF20R , KF10LL an KF20LL have lithium batteries that will
last the life of the alarm an a tamper-proof locking screw option.
•Mo els KF10R an KF20R inclu e permanent rechargeable lithium
batteries.
•Operating temperature: 0°C to 40°C
•Operates up to 93% humi ity (non-con ensing)
IMPO TANT SAFETY INFO MATION
PLEASE EAD AND SAVE THESE
INST UCTIONS
W A R N I N G
•DO NOT paint or cover the smoke alarm with tape.
•This smoke alarm should be out of the reach of children.
•AC smoke alarms require constant 230V AC, 50Hz power to operate
properly. Mains-powere smoke alarms WILL NOT work if AC power is not
connecte or has faile or been interrupte for any reason. Mo els KF10,
KF10LL an KF20, KF20LL require a working 9-volt battery to operate prop-
erly in the event of a power failure. Mo els KF10R an KF20R require a
minimum of 2 full ays un er mains power to reach full backup capacity. DO
NOT use any other kin of battery except as specifie in this user gui e. DO
NOT connect this smoke alarm to any other type of smoke alarm or auxiliary
evice, except those liste in this user gui e.
•DO NOT remove or disconnect battery or turn off AC power to quiet
unwanted alarms. This will remove your protection. Open win ows or fan the air
aroun smoke alarm to silence it. KF10, KF10LL, KF10R, KF20, KF20LL an
KF20R smoke alarms feature a Hush Button which, when activate , will quiet
unwante alarms for up to 9 minutes.
1
User Guide
PLEASE READ AND SAVE
INSTALLER: Please leave this user gui e with the pro uct.
KF10
KF10LL
KF10R
Ionisation
KF20
KF20LL
KF20R
Optical
EN14604:2005
LICENSE NO. KM 524754
0086-CPD-535595
14
EN 14604:2005
!
1374-7205-00(KF10_KF20_KF10R_KF20R)_EN_V4:_ 2014.11.20 10:16 AM Page 1

•The Push-to-Test button accurately tests all smoke alarm func-
tions. DO NOT use any other test metho . Test smoke alarm week-
ly to ensure proper operation.
•This smoke alarm should be installed only by a qualified
electrician.
•This smoke alarm is designed to be used inside a single family
household only. In multi-family buil ings, each in ivi ual living unit
shoul have its own smoke alarms. Do not install in non-resi ential
buil ings or places which house many people like hotels, motels,
ormitories, hospitals, nursing homes, or group homes of any kin .
This smoke alarm is not a substitute for a complete alarm system.
•Install a smoke alarm in every room and on every level of the home.
Smoke may not reach the smoke alarm for many reasons. For example,
if a fire starts in a remote part of the home, on another level, in a chim-
ney, wall, roof, or on the other si e of a close oor, smoke may not
reach the smoke alarm in time to alert househol members. A smoke
alarm will not promptly etect a fire EXCEPT in the area or room in
which it is installe .
•Interconnected smoke alarms installed in every room and on every
level of the household offers maximum protection. We recommen
interconnecting smoke alarms so that when one smoke alarm senses
smoke an soun s its alarm, all others will soun as well. Do not
interconnect smoke alarms from one in ivi ual family living unit to
another. Do not connect this smoke alarm to any other type of alarm or
auxiliary evice.
•Smoke alarms may not alert every household member every time.
The alarm horn is lou in or er to alert in ivi uals of a potential
anger. However, there may be limiting circumstances where a
househol member may not hear the alarm (i.e. out oor or in oor
noise, soun sleepers, rug or alcohol usage, the hearing impaire ,
etc.). If you suspect that this smoke alarm may not alert a househol
member, install an maintain specialty smoke alarms. Househol
members must hear the alarm’s warning soun an quickly respon to
it to re uce the risk of amage, injury, or eath that may result from
fire. If a househol member is hearing impaire , install special smoke
alarms with lights or vibrating evices to alert occupants.
•Smoke alarms can only sound their alarms when they detect
smoke. Smoke alarms etect combustion particles in the air. They o
not sense heat, flame, or gas. This smoke alarm is esigne to give
au ible warning of a eveloping fire. However, many fires are
fast-burning, explosive, or intentional. Others are cause by
carelessness or safety hazar s. Smoke may not reach the smoke
alarm QUICKLY ENOUGH to ensure safe escape.
•Smoke alarms have limitations. This smoke alarm is not fool-proof
an is not warrante to protect lives or property from fire. Smoke
alarms are not a substitute for insurance. Homeowners an renters
shoul insure their lives an property. In a ition, it is possible for the
smoke alarm to fail at any time. For this reason, you must test the
smoke alarm weekly and replace every 10 years.
SSMMOOKKEE AALLAARRMM PPLLAACCEEMMEENNTT
It is recommended to achieve complete coverage protection by installing
a smoke alarm in every room of your home.
At a minimum, smoke alarms shall be
installe outsi e or insi e all be rooms
an on each a itional storey of the family
living unit inclu ing basements, an con-
verte loft spaces. Any home requires a
minimum of two smoke alarms.
Typical Single Storey Home
•Install a smoke alarm on the ceiling or
wall insi e each be room an in the
hallway outsi e each separate sleeping
area. If a be room area hallway is more
than 9 m long, install a smoke alarm at
each en .
Typical Two-Storey Home
•Install a smoke alarm on the ceiling
insi e each be room an in the hall-
way outsi e each separate sleeping area.
If a be room area hallway is more than 9 m long, install a smoke
alarm at each en .
•Install a smoke alarm at the top an bottom of a first-to-secon floor
stairwell.
2
KITCHEN
FAMILY ROOM BEDROOM
BEDROOM
BEDROOM
FIREPLACE
DINING
ROOM
ATTIC OFFICE
BEDROOM BEDROOM
KITCHEN
LIVING ROOM
GARAGE
DINING ROOM KITCHEN
LIVING ROOM
BEDROOM
BEDROOM BEDROOM
Key
Ionisation Alarm
Heat Alarm
Optical Alarms
1374-7205-00(KF10_KF20_KF10R_KF20R)_EN_V4:_ 2014.11.20 10:16 AM Page 2

I
IM MP PO OR RT TA AN NT T S SM MO OK KE E A AL LA AR RM M P PL LA AC CE EM ME EN NT T A AN ND D
EEXXCCEEPPTTIIOONN IINNFFOORRMMAATTIIOONN::
•Install a smoke alarm as close to the centre
of the ceiling as possible. If this is not
practical, mount no closer than 30cm (12
inches) from a wall or corner. Also, if local
co es allow, install smoke alarms on walls,
30 cm (12 inches) from ceiling/wall intersec-
tions.
•Install a minimum of two smoke alarms in
every home, no matter how small the
home. Any size home requires fitting a
minimum of two smoke alarms.
•Install a smoke alarm in each room that is
ivi e by a partial wall (either coming
own from the ceiling at least 20 cm (8
inches), or coming up from the floor).
•Install smoke alarms on peake , cathe ral,
or gable ceilings 1 m from the highest
point (measure horizontally).
•Install a smoke alarm in live -in attics or
attics which house electrical equipment like
furnaces, air con itioners, or heaters.
Locations to be Avoided (Smoke Alarms)
•Do not site within 3m of a steam source e.g. kitchen/bath room or
garage.
•Do not site within 1m of immer control cabling or cable alarm into
any such cobling.
•Do not site a jacent to any heat source.
•Do not site within 300m (12”) of any lights fixure an 300mm from
any wall.
•Do not site near fluorescent lights; electronic noise may cause
nuisance alarms.
•In locations where temperature may fall below 0°C (40°F), or above
40°C (104°F).
In areas with relative humi ity (RH) above 93% (non-con ensing).
•In very usty/ irty/insect la en areas.
•Any location where the free flow of smoke to the alarm coul be
interrupte (e.g. next/above a oor/air vent/heater/air-con unit).
•Areas where routine maintenance or operating hush/test button is
ifficult (e.g. top of stairwells).
•Siting shoul be in accor ance with the current Buil ing Regulations
an /or BS5839 Pt6/current I.E.E. Regulations.
CAUTION: Alarm should not be exposed to dripping or splashing.
HOW TO INSTALL
THIS SMOKE ALA M
DANGER: ELECTRICAL SHOCK HAZARD. Turn off
power at the main consumer unit or cir-
cuit breaker by removing the fuse or
switching the circuit breaker to the OFF
position and securing it.
WARNING: Mains operated smoke alarms should be
installed by a qualified electrician in
accordance with the Regulations for
Electrical Installations published by the
Institution of Electrical Engineers (BS).
Failure to install this smoke alarm cor-
rectly may expose the user to shock or
fire hazards.
WARNING: The smoke alarm, its associated supply
and interconnect wiring must be installed
in accordance with BS 7671 published by
the Institution of Electrical Engineers.
WARNING: If a Firex Rechargeable alarm is replacing
an earlier non rechargeable model, the
new cable harness with 4 strands must
be used. sing the old 3 strand harness
will not allow new rechargeable alarm to
charge it's batteries.
•Install smoke alarm on ceiling, stan ar electrical box, or surface
mounting pattress.
1. Align mounting plate with mounting holes of stan ar electrical box
or surface mounting pattress. For siting on ceiling, use mounting
plate as template to mark holes. Drill holes an insert supplie
screw plugs into holes until flush with ceiling.Ceiling mounting is
always preferable over wall mounting.
2. Secure mounting plate to electrical box, pattress or ceiling.
(Diagram illustrates fixing mounting plate to electrical box.)
3. Connect blue cable from connector plug of smoke alarm to neutral
3
20cm
STUB WALL
SOFFIT
30cm
30cm
CEILING
SIDE
WALL
ACCEPTABLE HERE
NEVER HERE
TOP OF DETECTOR
ACCEPTABLE HERE
1M
PEAKED CEILING
!
!
!
!
!
1374-7205-00(KF10_KF20_KF10R_KF20R)_EN_V4:_ 2014.11.20 10:16 AM Page 3

replace with (N) mains power cable.
4. Connect brown cable from connector plug of smoke alarm to live (L)
mains power cable.
5. If interconnection is esire , connect orange or white cable from con-
nector to interconnect stran on the 3 core & earth cable. See section,
“Interconnecting Smoke Alarms.”
NOTE: If this will be a single-station smoke alarm, cover orange or white
cable with electrical tape and tuck into pattress.
Steps 6-9 for Models KF10, KF10LL, KF20, KF20LL ONLY:
6. Lift open battery pocket oor.
7. Connect new 9-volt battery to battery connector insi e battery pocket. BE
SURE BATTERY IS SECURELY CONNECTED. Smoke alarm may beep
briefly when battery is installe .
8. Close battery pocket oor, snapping it into place.
9. KF10LL an KF20LL inclu e a tamper-proofing locking option, using
the screw provi e
10. Push button an hol button on front cover of smoke alarm for three
(3) secon s. Smoke alarm shoul soun its alarm horn if battery is fit-
te correctly.
11. Attach connector plug to pins on back of smoke alarm. Plug will only
fit one way an will snap into place.
12. Gently tug connector to be sure it is attache securely.
13. Position smoke alarm to mounting plate so that keyslot on si e of
smoke alarm is to left of tab on mounting plate. Turn clockwise to lock
into place.
NOTE: (For Models KF10, KF10LL, KF20 and KF20LL only):
Smoke alarm will not mount to plate if battery is not installe .
14. Turn on power at main fuse box or circuit breaker. The green LED on the
cover shoul be illuminate .
15. Test smoke alarm. See “TESTING THE SMOKE ALARM”.
INTE CONNECTING
SMOKE ALA MS
•Use 1.5mm2minimum soli or stran e cable with a rating of 230V.
When interconnecting, maximum cable length between any two is 450
m for 1.5mm2or 1200 m for 2.5mm2(20 OHMS loop resistance).
•NOTE: Maximum length un er BS7671 17th E ition wiring regs
amen ment 1 for CB/RCBO type B is 72 metres for TN-S or TN-C-S
systems (source "On-Site Gui e" page 59)
•This smoke alarm may be interconnecte with as many as 23other
Mo els smoke alarms, as liste on page 1. DO NOT connect to any
other type or mo el smoke alarm.
•Connect smoke alarms to a single circuit. Wiring must conform to IEE
Regulations for electrical installation.
ED AND G EEN LED
INDICATO S
This smoke alarm features re an green LED in icators that can be seen
through the Push-to-Test button or the LED lens above the test button.
The LEDs in icate the following:
G EEN LED
ON — AC power is present.
OFF — AC power is not present.
ED LED
Blinks once every 5 minutes AND 20 ECOND — indicating normal
operation.
4
BLUE
ORANGE OR WHITE
BROWN LIVE
LIVE
INTERLINK
NEUTRAL
CEILING
DRY LINING BOX DRY LINING BOXOR PATTRESS
BLUE
BLUE
ORANGE OR WHITE
BROWN
NEUTRAL
INTERLINK
CEILING
OR PATTRESS
MODELS KF10, KF10LL,
KF20, KF20LL
MODELS KF10 , KF20 ( echargeable)
ORANGE OR WHITE ORANGE OR WHITE
FOR INTERCONNECT: USE STANDARD 3 core & earth cable 1.5mm2 cable
NEUTRAL
LINE
1374-7205-00(KF10_KF20_KF10R_KF20R)_EN_V4:_ 2014.11.20 10:16 AM Page 4

Blinks once a second — smoke alarm senses smoke and
simultaneously sounds an audible alarm.
Blinks once every 10 seconds — smoke alarm is in hush mode.
(Interconnected system only):
3 rapid flashes at 40 second intervals — indicates which alarm previously
detected an alarm condition.
OFF — another smoke alarm in the network has sensed
smoke and is signalling this alarm.
H SH B TTON
Mo els KF10, KF10LL, KF10R, KF20, KF20LL an KF20R feature Hush Button
that, when activate , quiets unwante alarms for up to 9 minutes.
To use the Hush Button:
Press an release the test button uring an unwante alarm. The alarm
shoul stop within ten secon s. This means the smoke alarm is in Hush
Button. If the smoke alarm oes not go into Hush an continues to soun
its lou alarm horn, or if it initially goes into Hush then resoun s the alarm,
the smoke is too heavy an coul be a angerous situation – take
emergency action.
TESTING THE SMOKE ALA M
W A N I N G
•Test each smoke alarm to be sure it is installe correctly an operating
properly.
•Test all smoke alarms in an interconnecte system after installation.
•The Push-to-Test button accurately tests all functions. DO NOT use an
open flame to test this smoke alarm. You may ignite an amage the
smoke alarm or your home.
•Test smoke alarms weekly an upon returning from holi ay or when no
one has been in the househol for several ays.
•Stan at arm’s length from the smoke alarm when testing. The alarm
horn is lou to alert you to an emergency an can be harmful to hearing.
Test all smoke alarms weekly by doing the following:
1. Check Push-to-Test button. A constant green light in icates the smoke
alarm is receiving 230V AC, 50Hz power. A re flashing LED about once
every 5 minutes verifies operation. For mo els KF10, KF10LL, KF10R,
KF20, KF20LL an KF20R the re flashing LED also verifies that a
working battery is present.
2. Firmly epress an hol the Push-to-Test button for at least five (5) sec-
on s. The smoke alarm will soun a lou beep about three (3) times a
secon . The alarm may soun for up to 10 secon s after releasing the
Push-to-Test button.
NOTE: If smoke alarms are interconnecte , all smoke alarms shoul
soun an alarm within three secon s after any test button is
pushe an the teste smoke alarm soun s.
3. If smoke alarm oes not soun , turn off power at main fuse box or
circuit breaker an check wiring. Retest smoke alarm.
DANGER: If alarm horn sounds, and smoke alarm is
not being tested, the smoke alarm is sensing
smoke. THE SO ND OF THE ALARM HORN
REQ IRES YO R IMMEDIATE ATTENTION
AND ACTION.
MAINTENANCE AND CLEANING
In a ition to weekly testing, Mo els KF10 an KF20 also require perio ic bat-
tery replacement. Regularly clean smoke alarm to remove ust, irt, an
ebris.
WARNING: Alarm comes equipped with a dust cover,
which prevents dust and debris from
damaging the unit during construction or
remodeling. Remove dust cover before oper-
ation. Alarm will not operate properly while
covered.
DANGER: ELECTRICAL SHOCK HAZARD. Turn off main
power at fuse box or consumer unit by
removing fuse or switching appropriate circuit
breaker to OFF position before replacing
battery or cleaning smoke alarm.
BBAATTTTEERRYY RREEPPLLAACCEEMMEENNTT
((For Models KF10 and KF20 only))::
CAUTION: Danger of explosion if battery is incorrectly
replaced.
Always turn off power to smoke alarm before replacing battery. Replace
battery at least once a year or immediately when the low battery signal
sounds once every 40 seconds, even though the smoke alarm is receiving
AC power. Use only the following 9V/(6F22) batteries as replacements in this
smoke alarm: Energizer 522; Duracell MN1604 or MX 1604; or
FDK CP-V9Ju; Ultralife U9VL-J-P
Replace only with the same or equivalent battery type recommended
5
MODELS KF10 , KF20 ( echargeable)
!
!
!
!
!
1374-7205-00(KF10_KF20_KF10R_KF20R)_EN_V4:_ 2014.11.20 10:16 AM Page 5

by the manufacturer. Discard used batteries safely according to
manufacturer's instructions.
WHENEVE THE BATTE Y IS EPLACED,
TEST THE ALA M FO CO ECT OPE ATION
PUSHING THE TEST BUTTON.
WA NING: DO NOT USE ANY OTHE TYPE OF
BATTE Y, EXCEPT AS SPECIFIED IN THIS
USE GUIDE. DO NOT USE ECHA GEABLE
BATTE IES.
1. Turn off power to smoke alarm at main consumer panel.
2. Insert a small screw river into the slot in the mounting plate. Depress
locking tab with the screw river an turn smoke alarm counter-clock-
wise to etach from mounting plate.
3. Gently pull own smoke alarm. Be careful not to separate cable
connections.
4. Pull out power plug from back of smoke alarm.
5. From back of smoke alarm, lift tab to open battery pocket oor.
6. Remove battery from pocket. Disconnect an iscar raine battery
from battery connector.
7. Connect a fresh, 9-volt battery to connector. The battery will fit only
one way. Be sure battery connector is securely attache to battery
terminals. Smoke alarm may soun a short beep when battery is
installe . This is normal an means the battery is installe correctly.
8. Place battery into battery pocket.
9. Close battery pocket oor. Push down until it snaps into place.
10. Press an hol test button. The alarm will soun if the battery is
properly connecte an working.
11. Replace connector plug. Connector will snap into place. Gently tug
connector to be sure it is attache properly.
12. Reattach smoke alarm to mounting plate by turning smoke alarm
clockwise until it snaps into place.
13. Turn on power an test smoke alarm using test button.
(For Models KF10 and KF20 only):
NNOOTTEE::Rechargeable lithium batteries are permanently mounted and
sealed in the tamper-proof housing. These cells are designed to
last the useful life of the smoke alarm.
CCLLEEAANNIINNGG
Clean the smoke alarm at least once a month to remove ust, irt, or
ebris. Always turn off power to smoke alarm before cleaning.
•Using the soft brush or wan attachment to a vacuum cleaner, vacuum all
si es an cover of smoke alarm. Be sure all the vents are free of ebris.
•If necessary, turn off power an use a amp cloth to clean smoke
alarm cover.
IMPO TANT: Do not attempt to remove the cover or clean insi e the smoke
alarm. THIS WILL VOID YOUR GUARANTEE.
RREEPPAAIIRR
CAUTION: Do not attempt to repair this smoke alarm.
Doing so will void your guarantee.
If smoke alarm is not operating properly, see “Troubleshooting”. If
necessary and if still under guarantee, return smoke alarm to Kidde.
Pack it in a well-padded carton and send, postage prepaid to Kidde
address at the end of this user guide.
If the smoke alarm is no longer un er guarantee, have a qualifie
electrician replace the smoke alarm imme iately with a comparable
Firex smoke alarm.
P ACTICE FI E SAFETY
If the smoke alarm soun s its alarm horn, an you have not
pushe the test button, it is warning of a angerous situation.
Your imme iate response is necessary. To prepare for such
occurrences, evelop family escape plans, iscuss them with
ALL househol members, an practice them regularly.
•Expose everyone to the soun of a smoke alarm an explain
what the soun means.
•Deci e on TWO exits from each room an an escape route
to the outsi e from each exit.
•Teach all househol members to touch the oor an use an
alternate exit if the oor is hot. INSTRUCT THEM NOT TO OPEN
THE DOOR IF THE DOOR IS HOT.
•Teach househol members to crawl along the floor to stay below
angerous smoke, fumes, an gases.
•Deci e on a safe meeting place for all members to meet outsi e the
buil ing.
6
!
!
1374-7205-00(KF10_KF20_KF10R_KF20R)_EN_V4:_ 2014.11.20 10:16 AM Page 6

WHAT TO DO IN CASE OF A FIRE
1. Don’t panic; stay calm.
2. Leave the building as quickly as possible. Touch doors to feel
if they are hot before opening them. Use an alternate exit if
necessary. Crawl along the floor, and DO NOT stop to collect
anything.
3. Meet at a pre-arranged meeting place outside the building.
4. Call the fire brigade (Dial 999) from OUTSIDE the building.
5. DO NOT GO BACK INSIDE A BU NING BUILDING. Wait for
the fire brigade to arrive.
These gui elines will assist you in the event of a fire. However, to
re uce the chance that fires will start, practice fire safety rules an
prevent hazar ous situations
TRO BLESHOOTING
DANGE : Always turn off power at main fuse box or
consumer unit before taking trouble-shooting
action.
WA NING: DO NOT disconnect battery or mains power
to quiet an unwanted alarm. This will remove
your protection. Fan the air or open a win-
dow to remove smoke or dust. For Models
KF10, KF10LL, KF10 , KF20, KF20LL and
KF20 you may also use the Hush Button
feature to quiet unwanted alarms.
7
!
!
PROBLEM SOLUTION
Smoke alarm oes not
soun when teste .
NOTE: Push an hol
test button for at least
five (5) secon s while
testing!
1. Check that AC power is
turne on. Green LED
shoul be illuminate .
2. Turn off power. Remove
smoke alarm from mount-
ing plate an :
a. check that connector plug
is securely attache .
b. check that battery is
properly attache to con-
nector.
3. Clean smoke alarm.
Smoke alarm beeps
once every 40 secon s
(KF10 an KF20 only)
(KF10R an KF20R )
item #3
1. Turn off power an replace
battery. See in the MAINTE-
NANCE AND CLEANING
section.
2. Clean smoke alarm.
3. Verify that unit has been
un er mains operation for a
minimum of 2 full ays. If
the beeping persists after
require charging perio ,
return the unit for service.
Smoke alarm soun s
unwante alarms when
resi ents are cook-
ing,taking showers, etc.
Interconnecte smoke
alarms o not soun
when system is teste .
1. Hire an electrician to move
smoke alarm to a new
location. See "SMOKE
ALARM PLACEMENT".
1. Press an hol test button
for at least three secon s
after the first unit soun s.
2. Hire an electrician to
ensure smoke alarms are
properly connecte .
3 chirps every 40
secon s
Ten (10) year en of life warn-
ing. Alarm must be replace
(REPLACE IMMEDIATELY! )
1374-7205-00(KF10_KF20_KF10R_KF20R)_EN_V4:_ 2014.11.20 10:16 AM Page 7

G ARANTEE
The manufacturer warrants to the original consumer purchaser each
new smoke alarm to be free from efects in material an workman-
ship un er normal use an service for a perio of six (6) years in the
Unite King om an Republic of Irelan from ate of
purchase. We agree to repair or replace, at its option, any efec-
tive smoke alarm, provi e that it is returne with postage prepai
an with proof of purchase ate to the manufacturer. This warranty
oes not cover amage resulting from acci ent, misuse or abuse or
lack of reasonable care of the pro uct. This warranty is in lieu of all
other express warranties, obligations or liabilities. THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE ARE LIMITED TO A PERIOD OF SIX (6)
YEARS FROM PURCHASE DATE. IN NO CASE SHALL THE
MANUFACTURER BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES FOR BREACH OF THIS OR ANY
OTHER WARRANTY, EXPRESS OR IMPLIED, WHATSOEVER, EVEN
IF THE LOSS OR DAMAGE IS CAUSED BY ITS NEGLIGENCE OR
FAULT.
Return units freight prepai to your local reseller. For information on
your local reseller in the U.K. an Republic of Irelan , contact:
FIREX PRODUCTS
KIDDE SAFETY EUROPE LIMITED
Mathisen Way
Colnbrook, Berkshire SL3 0HB
Unite King om
Tel.: [phone]
www.smoke-alarms.co.uk
8
Lea ing authorities recommen that both Ionisation an photoelec-
tric smoke alarms be installe to insure maximum etection of the
various types of fires that can occur within the home. Ionisation
sensing alarms may etect invisible fire particles (associate with
fast flaming fires) sooner than photoelectric alarms. Photoelectric
sensing alarms may etect visible fire particles (associate with
slow smoul ering fires) sooner than Ionisation alarms.
1374-7205-00
SOLUTION
1. Check that AC power is
turne on. Green LED
shoul be illuminate .
2. Turn off power. Remove
smoke alarm from mount-
ing plate an :
a. check that connector plug
is securely attache .
b. check that battery is
properly attache to con-
nector.
3. Clean smoke alarm.
1. Turn off power an replace
battery. See in the MAINTE-
NANCE AND CLEANING
section.
2. Clean smoke alarm.
3. Verify that unit has been
un er mains operation for a
minimum of 2 full ays. If
the beeping persists after
require charging perio ,
return the unit for service.
1. Hire an electrician to move
smoke alarm to a new
location. See "SMOKE
ALARM PLACEMENT".
1. Press an hol test button
for at least three secon s
after the first unit soun s.
2. Hire an electrician to
ensure smoke alarms are
properly connecte .
Ten (10) year en of life warn-
ing. Alarm must be replace
(REPLACE IMMEDIATELY! )
1374-7205-00(KF10_KF20_KF10R_KF20R)_EN_V4:_ 2014.11.20 10:16 AM Page 8
