Pre-Aligning Your Product
IMPORTANT!
• It is important that all four corners of the appliance is supported firmly onto the floor to eliminate
any movement.
• Installing the appliance on a soft, uneven, or not level floor may result in twisting of the product
and poor door sealing.
• Raise the appliance using an 7/16" (11 mm) hex socket or 3/16" (4mm) hex Allen key. One turn
of height adjusting nuts is equivalent to 1/16" (1 mm) height travel
Note: Maximum level travel is 13/16" (20 mm).
1. Using the front and rear adjustment nuts (A), level
the appliance back to front until all tabs located on
the installation aiders are in contact with adjacent
cabinetry.
https://producthelp.fisherpaykel.com/us/Cool/Integrated_Refrigeration/French_Door/With_Ice_and_Water/80_%2F%2F_84_in…
Updated: Wed, 12 Apr 2023 10:42:19 GMT
Powered by
1

IMPORTANT!
Ensure the appliance
makes light contact with all
tabs on installation aiders.
Difficulties in
achieving final alignment
can be caused by:
• Failure to make contact
with the installation aiders
• Too much pressure on the
installation aiders causing
tabs to bend
2. Gently push the front of the appliance to check the
stability, and ensure side gaps are even with enclosure.
