Fisher & Paykel ACTIVESMART RS32A72 User manual

ACTIVESMART™ INTEGRATED
FRENCH DOOR REFRIGERATOR FREEZER
RS2A72 and RS6A72 models
INSTALLATION GUIDE
US CA
862212C 08.19

1
@1 FIXING TO CABINETRY
@2 WATER FILTER INSTALLATION
@3 TOE KICK INSTALLATION
@4 COVERS AND TRIMS INSTALLATION
!9 DOOR PANEL INSTALLATION — STAINLESS STEEL @0 DOOR PANEL INSTALLATION — CUSTOM
OR
IMPORTANT!
SAVE THESE INSTRUCTIONS
The models shown in this installation guide may not be available in all markets and are subject to change at any time. For current details about model and specification availability in your country,
go to our website fisherpaykel.com or contact your local Fisher & Paykel dealer.
CONTENTS
1 SAFETY AND WARNINGS
2 COMPONENTS
3 TOOLS
4 APPLIANCE AND CAVITY DIMENSIONS
5 CABINETRY OPTIONS
6 DOOR PANEL DIMENSIONS
7 CUSTOM DOOR PANEL INSTALLATION DIMENSIONS — RS32A72
7 CUSTOM DOOR PANEL INSTALLATION DIMENSIONS — RS36A72
8 CUSTOM DOOR PANEL INSTALLATION TEMPLATE (RS32A72)
8 CUSTOM DOOR PANEL INSTALLATION TEMPLATE (RS36A72)
9 DOOR CLEARANCE
!0 ELECTRICAL AND PLUMBING
!1 BEFORE INSTALLATION
!2 CAVITY PREPARATION
!3 WATER SUPPLY CONNECTION
!4 POWER SUPPLY CONNECTION
!5 INSTALLATION PREPARATION
!6 TOP TRIM INSTALLATION
!7 POSITIONING INTO CABINETRY
!8 ALIGNING INSIDE CABINETRY
@5 CABINET TRIMS
INSTALLATION — [A] FLEXIBLE SPRING CLIP METHOD
@6 CABINET TRIMS
INSTALLATION — [B] FIXED SCREW METHOD
@7 FINAL CHECKLIST
OR

3
IMPORTANT!
● It is very important for the installer to follow the instructions in this installation guide
to ensure proper installation and operation of the appliance. Ensure that you read the
installation guide thoroughly and understand all information.
● The water connection to your Ice and water appliance must be installed by a qualified
plumber or Fisher & Paykel trained and supported service technician andcomply with
all state and local laws.
● Installation and use MUST comply with all state and local plumbing codes. Checkwith
your local public works department for plumbing codes. You must follow their
guidelines as you install the water filtration system.
● To avoid serious illness or death, only connect your water filter to safe drinking water.
● The water filter cartridge needs to be changed when the replacement indicator icon
illuminates. This will happen every 6 months.
● If the water filtration system has been allowed to freeze, replace filter cartridge.
Failureto replace the disposable filter at recommended intervals may lead to reduced
filter performance and failure of the filter, causing property damage from water
leakage or flooding.
● In cases of excessively reduced filter life — we recommend that you consult a local
plumber or your water supplier for advice on suitable filtration requirements for the
water supplied to your home.
● Filter replacement is the consumer’s responsibility and will not be covered by the
warranty except in the case of faulty parts or materials within the filter cartridge.
● If the water has not created ice for some time or ice has an unpleasant taste or odor
dispose of ice and refer to the flushing instructions detailed in the installation section
ofthis user guide / installation guide. If unpleasant taste or odor persists, you may wish
tofit a new filter cartridge.
● Use new tubing supplied with the appliance. DO NOT reuse old tubing from old water
andice connections.
● Your water filtration system can withstand up to 120psi (827kPa) of water pressure.
Ensure the supplied pressure reducing valve is installed before installing the water
filtration system. DO NOT install if water pressure exceeds 120psi (827kPa).
To reduce the risk associated with property damage due to water leakage or flooding:
● DO NOT install systems in areas where ambient temperatures may go above 100°F
(38°C) or drop below 33°F (0.6°C).
● DO NOT install on hot water supply lines. The maximum operating water temperature
ofthis filter system is 100°F (38°C).
● DO NOT install where water hammer conditions may occur. If water hammer conditions
exist, you must install a water hammer arrester.
WARNING!
To reduce the risk associated with choking:
● DO NOT allow children under 3 years of age to have access to small parts during the
installation of the water filter.
1 SAFETY AND WARNINGS
!WARNING!
Electric Shock Hazard
Read and follow the safety and warnings
outlined in this installation guide before
operating this appliance.
Failure to do so can result in death, electric
shock, fire or injury topersons.
!WARNING!
Cut Hazard
Take care — panel edges are sharp. Failure to
use caution could result in injury or cuts.
!WARNING!
This appliance is top-heavy and must
be secured to prevent the possibility of
tippingforward.
To ensure that the appliance is stable under
all loading conditions, theanti-tip bracket
and fittings supplied must be installed
according tothe following installation steps
by a professional installer.

4
2 COMPONENTS
Internal box (Installation kit)
Located inside appliance
AAnti-tip bracket
assemblykit
Anti-tip bracket
(1)
Masonry plug
(4)
#10x40 Pan Head Philips Screw
#10x40 Pan Head Philips Screw
#10x40 cross-head screw
(4)
BDoor panel attachment
kit
Side bracket
(10)
Side strap
(10)
#8 x 16 Mush Washer Twin Thread Philips Screw
#8 x 16
Mush Washer
Twin Thread
Philips Screw
#8Gx16 countersunk screw
(36)
CDoor/drawer trim
installkit
Dual adhesive tabs (6 per each strip)
(12)
Side cover
(4)
Top cover
(2)
XInstall fasteners kit
M5 x 10 Pan Head Philips Screw
M5 x 10 Pan Head Philips Screw
#8 x 16 Mush Washer Twin Thread Philips Screw
#8 x 16
Mush Washer
Twin Thread
Philips Screw
M5x10 cross-head screw
(10)
#8Gx16 flat head screw
(2)
#8 x 19 Countersunk Twin Thread Posi Screw
#8 x 19
Countersunk
Twin Thread
Posi Screw
#8Gx19 twin thread screw (2)
Not used for this model
#12x12 Countersunk screw
(2)
YMiscellaneous
components
Hinge limiting pin
(1)
Power cord/water tube clip
(2)
External box
Located at back panel of appliance
Door side trim
(2)
Drawer side trim
(2)
Top trim
(1)
Toe kick grille
(1)
Drawer top trim
(1)
Double-sided door panel template
(1)
DCabinet side trim
installkit
Side trim bracket
(6)
Spring clip
(6)
#8 x 16 Mush Washer Twin Thread Philips Screw
#8 x 16
Mush Washer
Twin Thread
Philips Screw
#8x16 mush washer screw
(12)

5
2 COMPONENTS
Miscellaneous items (MI) pack
Located inside the appliance
USER GUIDE
NZ AU GB IE HK SG IN US
ACTIVESMART™
INTEGRATED REFRIGERATOR
RS90A, RS9120W,
RS36A72, RS36A80 & RS36W80 models
SERVICE & WARRANTY
SERVICE ET GARANTIE
ΣΈΡΒΙΣΚΑΙ ΕΓΓΎΗΣΗ
SERVIZIO E GARANZIA
SERVICE & GARANTIE
HUOLTO JA TAKUU
SERVICE OG GARANTI
保修和维修
服務和保修
ACTIVESMART™ INTEGRATED
SLIDE-IN REFRIGERATOR
RS90 & RS90AU models
INSTALLATIONGUIDE
NZ AU GB IE HK SG IN
844219B 02.19
User guide
(1)
Service and Warranty
(1)
Installation guide
(1)
Collet locking clip
(1)
Water filter
(1)
Filter cartridge tool
(1)
Toe kick filter
(1)
1/4" (6mm) adaptor
(1)
Ice and Water display
(Ice and Water models only)
Located inside the appliance
External display module
(1)
Water fittings kit
(Ice and Water models only)
Not supplied and can be purchased in your local hardware stores
1/4"(6mm) Compression nut
(1)
1/4"(6mm) Compression sleeve
(1)
1/4" (6mm) Tube insert
(1)
1/4" (6mm) plastic tubing
(1)

6
Supplied tools
Included in internal box
FPA spanner
(1)
Hex key
(1)
Required tools
Not included with appliance
Powered driver Flathead screwdriver
Hacksaw Cross-head screwdriver
Cutter Measuring tape
Ruler Pencil
2 COMPONENTS 3 TOOLS
Door handle kit
Not supplied and must be purchased separately. Select between the options below:
Professional rounded
door handle (3x)
Professional square
door handle (3x)
Contemporary round
door handle (3x)
Contemporary square
door handle (3x)
M5 x 25 Pan Head Socket Screw
M5 x 25 Pan Head Socket Screw
M5 x 25 Pan Head Socket Screw
M5 x 25 Pan Head Socket Screw
M5 x 25 Pan Head Socket Screw
M5 x 25 Pan Head Socket Screw
M5 x 25 Pan Head Socket Screw
M5 x 25 Pan Head Socket Screw
M5x25 pan head socket
screw (12x)
M5x25 pan head socket
screw (12x)
M5x25 pan head socket
screw (12x)
M5x25 pan head socket
screw (12x)
Door panel set
Not supplied and must be purchased separately
Stainless steel (Fisher & Paykel) door panel set:
Includes 2x French door panels and 1x drawer panel.
Custom door panel set:
Supplied by customer to match their cabinetry.
Applicable for Ice only appliance models.
Ice only door panel set
(RD36A72/RD32A72)
Ice and Water door panel set
(RD36A72U/RD32A72U)
M5 x 14 Mush Head SS Philips Screw
M5 x 14 Mush Head SS Philips Screw
M5 x 14 Mush Head SS Philips Screw
M5 x 14 Mush Head SS Philips Screw
M5x14 mush cross-head (SS) screw
(34)
M5x14 mush cross-head (SS) screw
(34)

7
b
F
G
c
D
A
H
E
b
F
G
4 APPLIANCE AND CAVITY DIMENSIONS
RS32A RS36A
APPLIANCE DIMENSIONS in mm in mm
AOverall height of appliance* 7 1 7/8 "1825" 717/8" 1825**
BOverall width of appliance 31 1/8" 790 35 1/16” 890
cOverall depth of appliance
(without door panels and hanging brackets) 23 11/16" 602 2311/16" 602
DOverall depth of appliance
(with hanging brackets only) 23 3/4" 604 23 3/4" 604
eDepth of toe kick (excluding front of door panel) 2" 50 2" 50
* Includes mounted rollers (20mm adjustment upwards)
RS32A RS36A
CAVITY DIMENSIONS in mm in mm
FOverall height of cavity 72 1829 72 1829
GOverall width of cavity 32 813 36 914
HOverall depth of cavity 25 635 25 635
IMinimum cabinetry gap clearance
from edge of appliance 3/16 43/16 4
JMinimum required finished return min 3 1/2 min 89 min 3 1/2 min 89
FRONT VIEW PROFILE VIEW
Flush install
Frameless: Finished return top and sides
Flush install
Framed: Finished return top and sides
IMPORTANT!
For ease of installation, ensure cavity width is consistent
top to bottom and height isconsistent left to right.
E
B
H
C
A
A
I
J G
C
B
F
F
F
D
K
F
Flush with front
of cabinetry
PLAN VIEW
J
E
B
H
C
ADA
J
I
L GF F
K
g
I
I
J
J
J
J
E
B
H
C
ADA
J
I
L GF F
K
g
I
I
J
J
J

8
FRAMELESS CABINETRY
(Aligns the appliance with the cabinetry)
Proud
installation
Flush
installation
Note: Drawings are only for reference and not the actual cavity width of the cabinetry.
FRAMED CABINETRY
(Aligns the appliance with the frame of the cabinetry)
5 CABINETRY OPTIONS

9
6 DOOR PANEL DIMENSIONS
IMPORTANT!
● Custom door panels can only be used for non-Water dispensing models.
● Custom door panels to be manufactured and fitted by cabinetmaker.
● Door handle kit must be purchased separately.
ISO VIEW
H
F
D
i
g
A
B
PROFILE VIEW
D
g
A
E
C
h
ISO VIEW
STAINLESS STEEL/CUSTOM DOOR PANELS RS32A72 RS36A72
DIMENSIONS in mm in mm
AHeight of each top door panel 44 3/16" 1123 44 3/16" 1123
BWidth of each top door panel 15 3/4" 400 17 3/4" 451
CGap between top door panels 3/16" 4 3/16" 4
DHeight of bottom drawer panel 23 7/16" 596 23 7/16" 596
eHeight from bottom of product to top of drawerpanel 27 1/2" 698 27 1/2" 698
fWidth of bottom drawer panel 31 11/16" 805 35 11/16" 906
gGap between top door panels and bottom drawer panel 3/16" 4 3/16" 4
hDepth of door and drawer panels (excluding handle)
Stainless steel
Custom
3/4"
5/8"-3/4"
19
16-19
3/4"
5/8"-3/4"
19
16-19
iHeight of toe kick (from bottom of drawer to floor) 3 15/16 100 4" 102
DOOR PANEL WEIGHT lbs kg lbs kg
Maximum weight of each top door panel (with handle) 22 10 22 10
Maximum weight of bottom drawer panel (with handle) 24 1/4 11 24 1/4 11
ISO VIEW
H
FD
g
A
B
PROFILE VIEW
I
C
h

10
7 CUSTOM DOOR PANEL INSTALLATION DIMENSIONS — RS32A72
Dimensions apply for the preparation and installation of custom door panels. For Dwg and Dxf files of the below panel preparation download the folder on http://thekitchentools.fisherpaykel.
com/downloads/.
Ensure handle is mounted
65mm from inner edge of panel
to the center — this will avoid
interference with brackets.
1 3/8" (34.7mm)
1 3/8" (34.7mm)
4 5/16" (364mm)
2 3/16" (54.8mm)
40" (1016mm)
Ø 2mm REF
12x Pilot holes recommended for bracket attachment.
(Do not penetrate front surface).
13 1/2" (342.3mm)
TOP PANEL — REAR VIEW
All measurements to be made
from inner bottom corner.
Forthe second panel mirror
and repeat dimensions using
inner bottom corner as the
reference point.
Ø 2mm REF
10x Pilot holes recommended
forbracket attachment.
(Do not penetrate front surface).
13 3/16" (335mm)
4 3/8" (111.5mm)
1 1/8" (29.1mm)
3 7/16" (87.2mm)
19 3/8" (492mm)
21 5/16" (542mm)
14 7/16" (366mm)
All measurements to be made
from top and centerline.
BOTTOM PANEL — REAR VIEW
Cut outs are located in attachment bracket for Fisher & Paykel handles only.
Iflocating custom handle in the shaded area above, ensure handle screw heads
are counter sunk into back of panel to avoid interference with hanging bracket.
415/16" (126.1mm) 615/16" (176.1mm)
2415/16" (633.6mm)
2615/16" (683.6mm)
385/8" (981mm)

11
7 CUSTOM DOOR PANEL INSTALLATION DIMENSIONS — RS36A72
Dimensions apply for the preparation and installation of custom door panels. For Dwg and Dxf files of the below panel preparation download the folder on thekitchentools.fisherpaykel.com.
Ø 3/32" (2mm) REF
10x Pilot holes recommended
forbracket attachment.
(Do not penetrate front surface).
153/16" (385mm)
51/16"
(128mm)
11/8"
(29.1mm)
37/16"
(87.2mm)
193/8" (492mm)
215/16" (542mm)
163/8" (416mm)
All measurements to be made
from top and centerline.
BOTTOM PANEL — REAR VIEW
Cut outs are located in attachment bracket for Fisher & Paykel handles only.
Iflocating custom handle in the shaded area above, ensure handle screw heads
are counter sunk into back of panel to avoid interference with hanging bracket.
Ensure handle is mounted
29/16" (65mm) from inner edge
of panel to the center — this will
avoid interference with brackets.
13/8" (34.7mm)
165/16" (414mm)
23/16" (54.8mm)
415/16" (126.1mm)
615/16" (176.1mm)
2415/16" (633.6mm)
2615/16" (683.6mm)
385/8" (981mm)
40" (1016mm)
Ø 3/32" (2mm) REF
12x Pilot holes recommended for bracket attachment.
(Do not penetrate front surface).
157/16" (392.3mm)
TOP PANEL — REAR VIEW
All measurements to be made
from inner bottom corner.
Forthe second panel mirror
and repeat dimensions using
inner bottom corner as the
reference point.

12
8 CUSTOM DOOR PANEL INSTALLATION TEMPLATE (RS32A72)
LEFT DOOR
PANEL SIDE
RIGHT DOOR
PANEL SIDE
This template is a single double-sided sheet used as a
guide to drill screw holes for installing your Custom door
and drawer panels. The actual template is included with
this installation guide.
Refer to ‘Door panel installation—Custom’, (page 30)
formoreinformation.
LH DOOR PANEL HINGE SIDE
LH DOOR PANEL HANDLE SIDE
HANGING BRACKET
HOLES
HANGING BRACKET
HOLES
FLIP FOR RIGHT
HAND DOOR PANEL
LH DOOR PANEL HANDLE SIDE
LH DOOR PANEL HINGE SIDE
SIDE BRACKET HOLES
SIDE BRACKET HOLES
DRAWER PANEL LEFT EDGE
DRAWER PANEL RIGHT EDGE
DRAWE PANEL HANGING
BRACKET HOLES
DRAWE PANEL HANGING
BRACKET HOLES
DRAWER PANEL LEFT EDGE
DRAWER PANEL RIGHT EDGE
DRAWE PANEL
SIDE BRACKET HOLES
DRAWE PANEL
SIDE BRACKET HOLES
LEFT PC PANEL BOTTOM EDGE
DRAWER PANEL TOP EDGE
HANGING BRACKET
HOLES
HANGING BRACKET
HOLES
RH DOOR PANEL HANDLE SIDE
RH DOOR PANEL HANDLE SIDE
RIGHT DOOR
PANEL TEMPLATE
849549
RH DOOR PANEL HINGE SIDE
RH DOOR PANEL HANDLE SIDE
SIDE BRACKET HOLES
SIDE BRACKET HOLES
FLIP FOR LEFT HAND DOOR
AND DRAWER HOLES
RH DOOR PANEL HINGE SIDE
RH DOOR PANEL HANDLE SIDE
SIDE BRACKET HOLES
SIDE BRACKET HOLES
RH DOOR PANEL BOTTOM EDGE
LEFT DOOR PANEL
AND DRAWER TEMPLATE
849549
LH DOOR PANEL HANDLE SIDE
LH DOOR PANEL HINGE SIDE
SIDE BRACKET HOLES
SIDE BRACKET HOLES
PRINT SPECIFICATION REVISIONS
DRWN DATE CHKD ECN REV
BJ 04/04/19 1
1
862946
GRAPHICS RS90 DOOR TEMPLATETITLE:
DRAWN: DATE:
SCALE: 1:1
FISHER & PAYKEL APPLIANCES LIMITED
GRAPHICS NO: REVISION:
BINIL JOSE 04/04/2019
400mm
LH DOOR PANEL HINGE SIDE
LH DOOR PANEL HANDLE SIDE
HANGING BRACKET
HOLES
HANGING BRACKET
HOLES
FLIP FOR RIGHT
HAND DOOR PANEL
LH DOOR PANEL HANDLE SIDE
LH DOOR PANEL HINGE SIDE
SIDE BRACKET HOLES
SIDE BRACKET HOLES
DRAWER PANEL LEFT EDGE
DRAWER PANEL RIGHT EDGE
DRAWE PANEL HANGING
BRACKET HOLES
DRAWE PANEL HANGING
BRACKET HOLES
DRAWER PANEL LEFT EDGE
DRAWER PANEL RIGHT EDGE
DRAWE PANEL
SIDE BRACKET HOLES
DRAWE PANEL
SIDE BRACKET HOLES
LEFT PC PANEL BOTTOM EDGE
DRAWER PANEL TOP EDGE
HANGING BRACKET
HOLES
HANGING BRACKET
HOLES
RH DOOR PANEL HANDLE SIDE
RH DOOR PANEL HANDLE SIDE
RIGHT DOOR
PANEL TEMPLATE
849549
RH DOOR PANEL HINGE SIDE
RH DOOR PANEL HANDLE SIDE
SIDE BRACKET HOLES
SIDE BRACKET HOLES
FLIP FOR LEFT HAND DOOR
AND DRAWER HOLES
RH DOOR PANEL HINGE SIDE
RH DOOR PANEL HANDLE SIDE
SIDE BRACKET HOLES
SIDE BRACKET HOLES
RH DOOR PANEL BOTTOM EDGE
LEFT DOOR PANEL
AND DRAWER TEMPLATE
849549
LH DOOR PANEL HANDLE SIDE
LH DOOR PANEL HINGE SIDE
SIDE BRACKET HOLES
SIDE BRACKET HOLES
PRINT SPECIFICATION REVISIONS
DRWN DATE CHKD ECN REV
BJ 04/04/19 1
1
862946
GRAPHICS RS90 DOOR TEMPLATETITLE:
DRAWN: DATE:
SCALE: 1:1
FISHER & PAYKEL APPLIANCES LIMITED
GRAPHICS NO: REVISION:
BINIL JOSE 04/04/2019
400mm

13
8 CUSTOM DOOR PANEL INSTALLATION TEMPLATE (RS36A72)
LEFT DOOR
PANEL SIDE
RIGHT DOOR
PANEL SIDE
This template is a single double-sided sheet used as a
guide to drill screw holes for installing your Custom door
and drawer panels. The actual template is included with
this installation guide.
Refer to ‘Door panel installation—Custom’, (page 29)
formoreinformation.
HANGING BRACKET
HOLES
HANGING BRACKET
HOLES
LEFT DOOR PANEL HINGE SIDE
LEFT DOOR PANEL HANDLE SIDE
LEFT DOOR PANEL
AND DRAWER TEMPLATE
849551
SIDE BRACKET HOLES
SIDE BRACKET HOLES
LEFT DOOR PANEL HINGE SIDE
LEFT DOOR PANEL HANDLE SIDE
FLIP FOR RIGHT
HAND DOOR PANEL
LH DOOR PANEL HANDLE SIDE
LH DOOR PANEL HINGE SIDE
SIDE BRACKET HOLES
SIDE BRACKET HOLES
FLIP FOR LEFT HAND DOOR
AND DRAWER HOLES
RH DOOR PANEL HINGE SIDE
RH DOOR PANEL HANDLE SIDE
SIDE BRACKET HOLES
SIDE BRACKET HOLES
RH DOOR PANEL BOTTOM EDGE
DRAWER PANEL LEFT EDGE
DRAWER PANEL RIGHT EDGE
DRAWE PANEL
SIDE BRACKET HOLES
DRAWE PANEL
SIDE BRACKET HOLES
DRAWER PANEL LEFT EDGE
DRAWER PANEL RIGHT EDGE
DRAWE PANEL HANGING
BRACKET HOLES
DRAWE PANEL HANGING
BRACKET HOLES
LEFT PC PANEL BOTTOM EDGE
DRAWER PANEL TOP EDGE
HANGING BRACKET
HOLES
HANGING BRACKET
HOLES
RH DOOR PANEL HANDLE SIDE
RH DOOR PANEL HANDLE SIDE
RIGHT DOOR
PANEL TEMPLATE
849551
RH DOOR PANEL HINGE SIDE
RH DOOR PANEL HANDLE SIDE
SIDE BRACKET HOLES
SIDE BRACKET HOLES
PRINT SPECIFICATION REVISIONS
DRWN DATE CHKD ECN REV
BJ 04/04/19 1
1
862947
GRAPHICS RS36A DOOR TEMPLATETITLE:
DRAWN: DATE:
SCALE: 1:1
FISHER & PAYKEL APPLIANCES LIMITED
GRAPHICS NO: REVISION:
BINIL JOSE 04/04/2019
400mm

14
9 DOOR CLEARANCE
90° DOOR OPENING115° DOOR OPENING
[FULL ROTATION]
A
BC
D
BCA
E
Wall
90° DOOR OPENING
90° DOOR OPENING115° DOOR OPENING
[FULL ROTATION]
A
BC
D
BCA
E
Wall
115° DOOR OPENING
(FULL INTERNAL ACCESS)
RS32A72 RS36A72
DIMENSIONS in mm in mm
ADepth of door (widest opening) measured from front of door 15 9/16" 395 171/2" 445
BDepth of drawer (open) measured from front of drawer, including handle 15 3/4" 400 153/4" 400
CDepth of drawer (open) measured from front of drawer, excluding handle 14 3/16" 360 14 3/16" 360
DMinimum door clearance* to adjacent wall (115° — full internal access) 11" 280 1113/16" 300
EMinimum door clearance* to adjacent wall (90° — reduced internal access) 3 15/16" 100 313/16" 100
* Measured from front cabinetry edge, includes 2mm cabinetry gap.
Insert hinge limiting pin
WARNING!
● Before opening the doors, ensure that the appliance is
stable.
● 
Follow these steps to avoid risks that can cause serious
injury or death.
For 90° door swing, a hinge limiting pin is supplied with
your appliance. This pin fits in the boreholes of the top
hinge (B).
1Open door to 90°.
2Insert the hinge limiting pin vertically into the bore hole.
– Apply a gentle tap to the pin if it does not
slide smoothly.

15
A
C
B
!
IMPORTANT!
● Electrical connection should be located in an adjacent cabinet to either side
oftheappliance or above the appliance cavity.
● We recommend to use an isolating switch that is easily accessible to the user
aftertheappliance is installed.
WARNING!
● Electrical shock hazard. Assume all parts are live.
● Disconnect supply before servicing and installation.
ELECTRICAL AND PLUMBING CONNECTIONS
1Recommended location for connections in adjacent area or unit
2Alternative location for connections above the cavity
3Alternative location for connections at rear of cavity
B
1
3
2
1
Electrical and water connections must be within this space if located
behind the appliance and must not protrude from the back wall.
RS32A72 RS36A72
ELECTRICAL AND PLUMBING DIMENSIONS in mm
AOverall height of supply area 4 5/16" 110 4 5/16" 110
BOverall width of supply area 2 15/16" 75 2 15/16" 75
CDistance from left side of cavity 5 1/16" 129 5 1/6" 129
DDistance from the floor 4 5/16" 110 4 5/16" 110
Note: Dimensions are based on minimum depth of cavity.
!
Do not locate water or electricity in this area, keep clear of connections.
!
CAUTION: Central area can only fit water outlet and electrical plug if they are placed within a recessed cavity.
* In this location the water tap needs to be recessed into the wall, the recess must allow for an 80mm bend radius for
the watertube.
C
A
D
Left side
of cavity
Floor
Optional electrical
and water connection
location*
b
!0 ELECTRICAL AND PLUMBING
31 1/2" (800mm)
31 1/2" (800mm)
5 15/16"
(150mm)
5 15/16"
(150mm)

16
!0 ELECTRICAL AND PLUMBING
RIGHT HAND SIDELEFT HAND SIDE
Power cord (excl. plug) — 31 1/2" (800mm)
Power cord (excl. plug)—8011/16" (2050mm)
Power cord (excl. plug)—8011/16" (2050mm)
Water inlet hose—125 3/16" (3180mm) Water inlet hose—1543/4" (3930mm)
Maximum distance of hose and power cord
ELECTRICAL SPECIFICATIONS
Supply 115VAC, 60Hz
Service 10 amp circuit
PLUMBING SPECIFICATIONS
Supply 1/4" (6mm) comp. Stainless steel braided hose
Pressure min. 22psi (150kPa)
max. 120psi (827kPa) @ 68°F (20°C)
Checking your appliance
1Detach accessories box taped to
back panel ofappliance.
Refer to 'Components' (page 5).
IMPORTANT!
Be aware when removing the
carton that the accessories box
may have dislodged from
the rear of the appliance during
transit.

17
4Restrain the appliance
to the cart with straps.
5Remove the brackets
on the other side of
the appliance.
6Tilt the appliance backward
onto the cart.
7Set aside the pallet and
push the cart to the
installation location.
2Tilt the appliance
slightly to the
opposite side.
3Insert the hand truck
under the side of the
appliance where the
brackets were removed.
Do NOT insert the hand
truck to the front or
back of the appliance.
Moving your appliance
1Remove the brackets from one side of the
appliance. (For single door models, remove the
brackets on the non-hinged side of the appliance.)
Note: Location of brackets depends on the
modelof your appliance.
USER GUIDE
NZ AU GB IE HK SG IN US
ACTIVESMART™
INTEGRATED REFRIGERATOR
RS90A, RS9120W,
RS36A72, RS36A80 & RS36W80 models
Water fittings and
Water filter kits Installation kit
2Remove the water fittings and water filter
kits, Installation kit, andMiscellaneous
itemspack from inside the appliance.
Refer to 'Components' (pages 4 – 5).
IMPORTANT!
● Be careful when unpacking to prevent damage to the surface of your appliance.
● Ensure that the appliance is stable to prevent from tipping over when unpacking.
● Do not open the doors to prevent the appliance from tipping over.
● The appliance is heavy and requires a minimum of 2persons to unpack and install.
● Ensure that the feet of the appliance are retracted.
● If the appliance is damaged, contact your Fisher & Paykel dealer.
● Take note of your model and registration numbers located at the lower right side of
theappliance. You will need these to request for servicing or repair of your appliance.
hand truck
Miscellaneous
items pack
!1 BEFORE INSTALLATION
Checking your appliance
1Detach accessories box taped to
back panel ofappliance.
Refer to 'Components' (page 5).
IMPORTANT!
Be aware when removing the
carton that the accessories box
may have dislodged from
the rear of the appliance during
transit.

18
!1 BEFORE INSTALLATION
IMPORTANT!
● Your appliance is fitted with front and rear rollers designed for moving the appliance
forward and backward. Donot move the appliance sideways as this may damage the
rollers or the floor covering / surface.
● The appliance must be installed by a qualified installer, or Fisher & Paykel trained and
supported service technician to avoid faulty electrical connection and water leaks.
● All connections for water, electrical power and grounding must comply with local codes
and ordinances and be made by licensed personnel when required.
● Avoid installation of the appliance/s under a ground fault circuit interrupter (GFCI).
● Ensure the appliance is installed properly. Improper installation that results in appliance
failure is not covered under the appliance warranty.
Check installation location
1Check the cabinetry
– Check the dimensions — height, width, depth, floor level,
finishedalcovereturns.
– Ensure that the ventilation openings in the cabinetry are clear of obstruction.
– For integrated installation, a finished return of solid material is required
across thetopand sides of the new or existing alcove.
– Refer to the ‘Appliance and cavity Dimensions’ (page 7) prior to installation
of the appliance.
2Check the power supply
– Ensure that there is a separate power outlet for the appliance.
– Avoid sharing the power point with other appliances to prevent the
appliancefromaccidentally switching off.
– For power requirements, refer to the information on the serial plate.
Thisislocated atthe front right-hand side of the drawer when open.
– Ensure your appliance is properly grounded (earthed).
– Connect the appliance to the electrical supply (115 VAC, 60 Hz) with fitted
plug andlead.
– We recommend to use an isolating switch that is easily accessible to
theuserafterthe appliance is installed.
– Follow the National Electrical Code and all local codes and ordinances
wheninstallingthis appliance.
3Check the water supply (for Ice and Water models only)
– Ensure that there is a separate water supply connection for the appliance.
– Your appliance must be installed by a qualified appliance installer as
incorrect plumbingcanlead to water leaks.
– Fisher & Paykel is not liable for damage (including water damage) caused
byfaultyinstallation or plumbing.
