Fisher F-Pulse User manual

OWNER’S MANUAL
METAL DETECT NG P NPO NTER
Do not use “Z NC-CARBON” or “HEAVY DUTY” batteries

INDEX
F-Pulse features...................................................4
Battery
Low-Battery Warning........................................5
Critical Low-Battery..........................................5
Waterproof Design ...........................................6
Operation
On and Off .........................................................7
LED Flashlight...................................................7
Program the Alarm-type & Sensitivity-level .....8
Default Settings ............................................8-9
Re-Tune .........................................................10
Ground-Mineral Calibration............................10
Frequency Shifting....................................10-12
Re-Boot..........................................................12
Lost Mode and Auto Shutoff ..........................13
Tips on How to Use Pinpointer ..........................14
Specifications .....................................................14
Warranty................................................Back page
햳____________________________________

Congratulations on the purchase of
your new F-Pulse Pinpointer.
The F-Pulse was designed to be the best-
performing pinpointing probe on the market,
answering the call from treasure hunters who
demand a robust, modern design and a probe that
maintains high sensitivity in the most demanding
environments.
The F-Pulse is a waterproof, pulse induction
detector. An advanced pulse induction design allows
the F-Pulse to operate in environments where other
pinpointers fall short. Whether in heavily mineralized
soils or saltwater, this pinpointer goes deeper and
guarantees stable operation where competitive
products false or lose sensitivity.
Throw away your 9-volt batteries folks. Welcome
to the 21st century!
F-Pulse is ergonomic and features easy-to-use
one-button operation. t was designed by treasure
hunters to take your treasure hunting performance to
the next level.
___________________________________ 햴

Your F-Pulse pinpointer
offers many great features:
Function:
• Single-Button Operation
• Adjustable Sensitivity
• Rapid Retune
• Lost Alarm Feature
Performance:
• 360-degree Detection
• Waterproof to 6 feet
• High Sensitivity
• Automatic Ground
Calibration
Extras:
• Ruler (inches and CM)
• LED Flashlight, Adjustable
& Super-bright
• Auto Shutdown
• Molded Lanyard Loop
햵____________________________________
CONSTRUCTED FROM
SPECIAL ABRASION-
RESISTANT MATERIALS
(won’t wear through
like other pinpointers)
Comfortable
No-Slip
Handgrip
Power and
Programming
Adjustable
LED Light
Ruler in
nches and
Centimeters
360°
Detection

BATTERIES:
The F-Pulse operates on 2 AA alkaline, lithium or nickel-metal
hydride batteries (not included).You can also use high quality
rechargeable batteries. Expect approximately 25 hours of
operation from alkaline batteries.
Do not use “Zinc-carbon” or “Heavy-duty” batteries.
To replace batteries:
1. Use a coin or flathead screwdriver.
2. Rotate counterclockwise to remove cap.
3. nstall 2 AA batteries, positive-side down.
4. Rotate clockwise until snug to close and seal.
The battery compartment was designed to provide a snug fit
for the batteries. f you experience difficulties in removing
your batteries, tap the pinpointer against the palm of your
opposite hand to help dislodge the batteries.
Low-Battery Warning:
f your batteries are running low and need to be replaced,
you will hear a boop-boop-boop sound at power-down.
Critical Low-Battery:
f the batteries are totally spent, you’ll hear a boooooop
sound and the pinpointer will then turn itself off.
___________________________________ 햶

WARNING:
Submersing this
product to a depth
greater than 6 feet
and/or longer than
1 hour will void
warranty.
햷____________________________________
BATTERIES (CONTINUED):
Waterproof Design:
The F-Pulse is waterproof to a depth of 6 feet for 1 hour.
The rubber O-ring around the battery cap is vital to maintaining a
waterproof seal.
IMPO TANT:
Check the O-ring.
Make sure there is no debris on the O-ring or in the battery
cap threads.
2-AA
batteries
(not included)
Waterproof
Speaker
Sealed
Battery Cap
O-Ring

___________________________________ 햸
On and Off (tones described are at factory-default settings)
Power On: Quick-Press (press and release the
button, quickly)
• F-Pulse will beep and vibrate
• F-Pulse is ready to detect.
Power Off: Press-and-Hold the button.
• As soon as you hear the BEEP, release the button.
• The F-Pulse is off.
f you program the target-alarm to your own custom setting, your
programmed target-alarm will also be the indication you hear, or feel,
at power-on and power-off. For example: if you program the target
alarm to vibrate, the pinpointer will vibrate at turn-on and turn-off.
LED Flashlight
To adjust light illumination level:
1. Start with power off.
2. Press-and-Hold the button.
Continue to hold. Light will turn on and flash.
3. Continue to press-and-hold the button and observe the
different levels of brightness.
• As long as you continue to hold the button, the F-Pulse will
cycle from Off, to Bright, then Brighter and Brightest.
• At the brightest setting, the light will flash.
• The cycle will continue and repeat until you release the button.
4. elease the button at your desired level of illumination.
• Alarm will confirm program is set (beep, vibrate, or both).
5. Device is powered on and ready to hunt.
6. Your programmed level of illumination will be saved to memory,
even after power-down and after changing batteries.
OPERATION

햹____________________________________
Programming: Alarm and Sensitivity
The F-Pulse target alert can be audible, vibratory or both.
There are three different sensitivity levels: low, medium and high.
Default settings:
The default settings for this pinpointer are:
• LED: 70% brightness
• Alarm: Beep and vibrate
• Sensitivity: Medium
To program the alarm-type and sensitivity-level:
1. Start with power on.
2. Press-and-Hold the button.
Do not release the button at the first alarm (beep or vibrate).
f you release the button at the first alarm, the device
will turn off.
3. Following the power-down-alarm, hear the
programming-alarm: J NGLE-J NGLE-J NGLE.
4. elease the button when you hear JINGLE-JINGLE-
JINGLE
The device is now in programming mode
OPERATION

___________________________________ 햺
5. Press-and-release the button to change settings.
Each press of the button will advance to a different setting.
Each setting is indicated with beep(s), vibration(s) or both.
6. To choose a program, stop pressing the button at the
desired setting.
7. The device will confirm your setting with beep, vibrate or both.
8. Device is now ready to hunt.
There are 9 different program settings:
Sensitivity Detection Alert Programming Feedback
Low Audible 1 beep
Medium Audible 2 beeps
High Audible 3 beeps
Low Vibrate 1 vibrate
Medium Vibrate 2 vibrates
High Vibrate 3 vibrates
Low Audible + Vibrate 1 beep + 1 vibrate
Medium Audible + Vibrate 2 beeps + 2 vibrates
High Audible + Vibrate 3 beeps + 3 vibrates
OPERATION

햻____________________________________
e-Tune
f at any time during operation the F-Pulse alarms irregularly
or loses sensitivity, quickly press-and-release the button. This
Rapid Retune will return your pinpointer to stable operation.
Ground-Mineral Calibration
Calibrate the F-Pulse to operate in mineralized ground or
saltwater.
Calibration Procedure:
1. Start with power on.
2. Touch the tip of the probe to the soil, or submerge into the water.
3. Quickly press-and-release the button.
4. Unit responds with a beep confirming calibration is complete.
Interference (Frequency Shifting)
All metal detectors operate at different frequencies. t’s these
different frequencies that make certain detectors better at
detecting certain targets. The F-Pulse is designed to work with
the different frequencies of various detectors, and to enable the
user to calibrate the F-Pulse to a frequency that eliminates (or
minimizes) interference with your detector.
The factory default setting of the F-Pulse may interfere with your
metal detector, causing it or your pinpointer to beep irregularly.
OPERATION
