Fisher M-Scope M-101 User manual

t
h
e
F
i
r
s
t
,
t
h
e
B
e
s
t
,
S
i
n
c
e
1
9
3
1
YEARS
M-101
Operating Manual
Rebar Locator & Metal Probe
FISHER RESEARCH LABORA-
TORY

Introduction ........................................................................... pg. 2
Control Panel ......................................................................... pg. 3
Operation ................................................................................ pg. 4
Principles of Operation ....................................................... pg. 5
Specifications......................................................................... pg. 6
CONTENTS

INTRODUCTION
The M-101 is a metal detector with a small search coil that pro-
vides a concentrated search signal. The M-101 will respond to all
types of metal (rebar, wire mesh, metal conduit, metallic trash,
metallic targets on the opposite side of surface to be scanned,
etc.) which may be associated with the area that is to be
searched. The M-101 will not respond to non-metallic targets such
as plastic or fiberglass. The M-101 is not designed to be a wire or
pipe tracer. Fisher Research manufactures other specific equip-
ment for that purpose.
1
2
Description
The M-101 comes ready to use for searching in floors, walls,
columns, and ceilings. The control housing is designed to
be chest or belt mounted for ease of use and comfort.
A carrying bag is included in the package.

CONTROL PANEL
Sensitivity
This control turns the M-101 On & Off. It also permits
a wide range of sensitivity to metal targets. MAXimum
position is normally used in the initial scanning and
locating operation. MINimum or reduced sensitivity is
used to help pinpoint metal objects.
Penetration
Controls the depth of penetration. This knob is free
spinning and does not have stops in either direction.
Meter
Gives a visual display of signal strength and Battery Test
Battery Test
Used to test the condition of the batteries in the M-101.
Battery Access
The M-101 is powered by two 9 volt batteries. Access to
the batteries is on the back of the detector.
3
PENETRATION
SENSITIVITY HEAD
PHONES
MIN
MAX
B
A
T
T
E
R
Y
T
E
S
T
INCREASE
DECREASE
M - 101

4
OPERATION
Turn the M-101 On (Sensitivity control knob). Depress the
Battery Test button. A response of 80 or more on the meter
indicates batteries are in an operable condition.
NOTE: Occasionally check the batteries during use, as weak
batteries could lead to reduced signal depth.
TEST BATTERIES
1.
Turn the M-101 On (Sensitivity control knob) to the RED
arrow. If there is a sound and meter reading, reduce (turn
counter-clockwise) the Penetration control, or move search
coil away from any nearby metal.
2.
Place search coil on the surface that is to be scanned. Con-
tinue to keep it away from any metal objects. Adjust the
Penetration control until the meter reads 10. (To increase
the meter reading, turn the Penetration control clockwise;
to decrease the meter reading, turn the control-counter clock-
wise.)
3.
Scan the area to be searched. When a maximum signal is
located, slowly reduce the Penetration control (turn counter-
clockwise) to narrow the response area. This narrow re-
sponse should be the center line of the target. It should be
directly underneath the red line on the search coil. (Note:
As you reduce the Penetration, be careful not to completely
cancel out the target.)
4.
If you find that it is difficult to get a narrow response, it
may be to your advantage to increase the distance from the
search coil to the target. Use a clean spacer such as a piece
of wood to elevate the coil. You may still need to adjust the
Sensitivity to pinpoint the target.
SCANNING

5
PRINCIPLES OF OPERATION
When the unit is properly tuned, the M-101 will locate ½inch
(1.25 cm) diameter rebar 8 to 9 inches (20 to 23 cm) from the
bottom of the search coil. A larger target can be located
deeper, a smaller target shallower.
With the M-101 initially tuned, the search pattern is wide
and deep (diagram A) , and as the operator reduces the
Sensitivity and Penetration, the search signal of the M-101
changes shape (diagram B). Thus, the idea for operation
is to reduce the search field so that only a small portion of
the signal is influenced by the metal target. Be aware that
if the target is to close to the coil, it is very difficult to get a
narrow response. This is when the use of a spacer will be
necessary.
Detectors electronic signal pattern

6
SPECIFICATIONS
Operating Frequency of Search Coil: .... 4.5 kHz
Sensitivity Adjustment Range: 12:1
Output Indication: ........ Meter - 1 milliamp, 1 - 100 linear scale
........................................... Speaker - 16 Ohm impedance
........................................... Headset (optional) - 8 Ohm impedance
Audio Frequency: .......... 450 Hz
Power Supply: ................ +/- 9 V, (2) 9V NEDA 1604
Coil Configuration: ....... Double D
Weight: ............................. 2.8 lbs (1.3 kg)
Dimensions: .................... Control Box ........... 3 x 5 x 6 inches (8 x 12 x 16 cm)
........................................... Handle ................... 0.75 x 23 inches (1.9 x 58.4 cm)
Shipping Weight: ........... 4 lbs (1.8 kg)
Shipping Dimensions: .. 26.5 x 6.25 x 6.25 inches (67 x 16 x 16 cm)
Subject to improvement or modification without notice.
Fisher Research Laboratory does not warrant suitability to specific use.
Fisher Research Laboratory shall in no event be liable for any direct, inciden-
tal, consequential or indirect damages.
