Flanders SwissAire R-1 Media SAR-1 Media User manual

19
FOR USE AS AN INTAKE FILTER
The SAR-1 media, made in Switzerland, provides
excellent filtration efficiency. This media wa created
to reduce air flow restriction while still maintaining a
high level of efficiency. This product is ideal in
crossdraft and downdraft booths where air velocity is
a concern.
The filter media is made from a blend of polyester
fibers coated with an ecologically sound tackifier,
and a scrim layer on the downstream side for added
strength and rigidity. The polyester fibers are fused
together through a special low-melt production line.
SAR-1 is made without the use of PVC or other
unfavorable chemicals. In a heated environment, it’s
these chemicals, and/or the tackifier and scrim
which can cause fiber discharge and heavy discol-
oration through the media (the browning effect). In
addition, the SAR-1 scrim layer resists discoloration
in a normal environment when compared to competi-
tive brands.
The scrim layer also helps reduce any fibers from
breaking off of the media during handling and instal-
lation. The scrim increases the strength of the
media and eliminates any sagging when loaded with
contaminants.
Rolls are cut on a razor sharp band saw and pads
are cut using a 5-1/4” rotary knife. This process vir-
tually eliminates any fiber shedding from abrasive
cutting techniques or carbon buildup from hot-wire
cutting.
Weight per square meter: 350 g/m2
Approximate thickness: .55 inches
Filter Clas: G4
Dust Holding Capacity 230 g/m2
Temperature Resistacne: 250 Deg. F
Inflammability Class: DIN 53438 F2/K3
0 150 300 450
0 50 100 150
100
90
80
70
60
50
40
30
20
10
0
2.00
1.50
1.40
1.20
.80
.40
0
Arrestance vs. Dust Fed
Pressure Loss vs. Dust Fed
Pressure loss vs. Rated Air Speed
SAR-1 Media
SwissAire R-1 Media

20
SAR1 Media Pads and Blankets
PA2826 SAR1M-22056 22"X56" MEDIA PAD SWISS'A R-1 10
PA1838 SAR1M-24108 24"X108" MEDIA PAD SWISS'A R-1 4
PA1839 SAR1M-24111 24"X111" MEDIA PAD SWISS'A R-1 5
PA1840 SAR1M-24156 24"X156" MEDIA PAD SWISS'A R-1 4
PA1841 SAR1M-25072 25"X72" MEDIA PAD SWISS'A R-1 2
PA1842 SAR1M-35035 35"X35" MEDIA PAD SWISS'A R-1 2
PA1843 SAR1M-37070 37"X70" MEDIA PAD SWISS'A R-1 3
PA2514 SAR1M-50068 50"X68" MEDIA PAD SWISS'A R-1 4
PA1844 SAR1M-51108 51"X108" MEDIA PAD SWISS'A R-1 4
PA1845 SAR1M-51156 51"X156" MEDIA PAD SWISS'A R-1 4
PA2924 SAR1M-52065 52"X65" MEDIA PAD SWISS'A R-1 3
PA1846 SAR1M-55108 55"X108" MEDIA PAD SWISS'A R-1 4
PA1847 SAR1M-55156 55"X156" MEDIA PAD SWISS'A R-1 4
PA1848 SAR1M-58058 58"X58" MEDIA PAD SWISS'A R-1 3
PA1849 SAR1M-58096 58"X96" MEDIA PAD SWISS'A R-1 3
PA1850 SAR1M-61108 61"X108" MEDIA PAD SWISS'A R-1 4
PA1851 SAR1M-61156 61"X156" MEDIA PAD SWISS'A R-1 4
PA1852 SAR1M-80100 80"X100" MEDIA PAD SWISS'A R-1 2
SAR1 Media Rolls
PA2459 SAR1R-20 20"X100' MEDIA SWISSAIRE R-1 1
PA2460 SAR1R-22 22"X100' MEDIA SWISSAIRE R-1 1
PA2461 SAR1R-25 25"X100' MEDIA SWISSAIRE R-1 1
PA2462 SAR1R-30 30"X100' MEDIA SWISSAIRE R-1 1
PA2463 SAR1R-36 36"X100' MEDIA SWISSAIRE R-1 1
PA2464 SAR1R-40 40"X100' MEDIA SWISSAIRE R-1 1
PA2465 SAR1R-48 48"X100' MEDIA SWISSAIRE R-1 1
PA2466 SAR1R-45 45"X100' MEDIA SWISSAIRE R-1 1
PA2467 SAR1R-55 55"X100' MEDIA SWISSAIRE R-1 1
PA2468 SAR1R-60 60"X100' MEDIA SWISSAIRE R-1 1
PA2469 SAR1R-80 80"X100' MEDIA SWISSAIRE R-1 1
PA2470 SAR1R-90.55 90.55"X100' MEDIA SWISSAIRE R-1 1
SAR1 Custom Media Pads
PA2952 SAR1M-CUSTOM MEDIA PAD SWISS'A R-1 CUSTOM SQ IN
SAR-1 Media
SwissAire R-1 Media
Item No. Model Description Qty/Case

21
FOR USE AS AN INTAKE FILTER
These self-supportive panels are made from the
SAR-1 media. A wire support is sealed between the
SAR-1 media layer and a 1/2” polyester prefilter
layer.
The filter media is made from a blend of polyester
fibers coated with an ecologically sound tackifier and
a scrim layer on the downstream side for added
strength and rigidity. The polyester fibers are fused
together through a special low-melt production line.
SAR-1 is made without the use of PVC or other
unfavorable chemicals. In a heated environment, it’s
these chemicals and/or the tackifier and scrim which
can cause fiber discharge and heavy discoloration
through the media (the “browning effect.”) In addi-
tion, the SAR-1 scrim layer resists discoloration in a
normal environment when compared to competitive
brands.
The scrim layer also helps reduce any fibers from
breaking off of the media during handling and instal-
lation. The scrim increases the strength of the
media and eliminates any sagging when loaded with
contaminants.
The wire support is made from a 9 gauge galvanized
wire with one to two cross pieces per frame. The
two media layers are dielectrically welded together
which seals the wire support inside the media layers.
The panels are available in single panels using one
single wire frame up to 2-” x 50” or in link panels
using two or more wire frames and one continuous
piece of media for easy installation. Special sizes
are available upon request.
One important feature of a panel is the quality of the
seal. If the media layers are not properly bonded
together, the filter can break apart during use and
cause mechanical problems in the booth. To prevent
this possiblity, the SAR-1 uses a full 1/4” sealing sur-
face for the is filter. Competitive products traditional-
ly use a 1/8” seal.
Weight per square meter: 350 g/m2
Approximate thickness: .55 inches
Filter Clas: G4
Dust Holding Capacity 230 g/m2
Temperature Resistacne: 250 Deg. F
Inflammability Class: DIN 53438 F2/K3
0 150 300 450
0 50 100 150
100
90
80
70
60
50
40
30
20
10
0
2.00
1.50
1.40
1.20
.80
.40
0
Arrestance vs. Dust Fed
Pressure Loss vs. Dust Fed
Pressure loss vs. Rated Air Speed
SAR-1 Panel
SwissAire Premium R-1 Panels

22
SAR1 Standard Size Single Panels
PA2046 SAR1P-1224 12X24 MEDIA PANEL SWISS'A R-1 24
PA2047 SAR1P-1520 15X20 MEDIA PANEL SWISS'A R-1 24
PA2048 SAR1P-1524 15X24 MEDIA PANEL SWISS'A R-1 24
PA2049 SAR1P-1616 16X16 MEDIA PANEL SWISS'A R-1 24
PA2050 SAR1P-1618 16X18 MEDIA PANEL SWISS'A R-1 24
PA2051 SAR1P-1620 16X20 MEDIA PANEL SWISS'A R-1 24
PA2052 SAR1P-1624 16X24 MEDIA PANEL SWISS'A R-1 24
PA2053 SAR1P-1625 16X25 MEDIA PANEL SWISS'A R-1 24
PA2054 SAR1P-1824 18X24 MEDIA PANEL SWISS'A R-1 24
PA2505 SAR1P16-2020 20X20 MEDIA PANEL SWISS'A R-1 16
PA2056 SAR1P20-2020 20X20 MEDIA PANEL SWISS'A R-1 20
PA2055 SAR1P-2020 20X20 MEDIA PANEL SWISS'A R-1 24
PA2057 SAR1P-2024 20X24 MEDIA PANEL SWISS'A R-1 24
PA2058 SAR1P-2024-20 20X24 MEDIA PANEL SWISS'A R-1 20
PA2059 SAR1P-2025 20X25 MEDIA PANEL SWISS'A R-1 24
PA2060 SAR1P-2025-18 20X25 MEDIA PANEL SWISS'A R-1 18
PA2061 SAR1P20-2025 20X25 MEDIA PANEL SWISS'A R-1 20
PA2062 SAR1P16-2025 20X25 MEDIA PANEL SWISS'A R-1 16
PA2063 SAR1P-2424 24X24 MEDIA PANEL SWISS'A R-1 24
PA2064 SAR1P-2424-20 24X24 MEDIA PANEL SWISS'A R-1 20
PA2065 SAR1P-2525 25X25 MEDIA PANEL SWISS'A R-1 24
SAR1 Standard Size Single Panels
Continously Linked
PA2066 SAR1P-1224C 12X24 SAR1 CONTINUOUS LINK 24
PA2067 SAR1P-1520C 15X20 SAR1 CONTINUOUS LINK 24
PA2068 SAR1P-1524C 15X24 SAR1 CONTINUOUS LINK 24
PA2069 SAR1P-1616C 16X16 SAR1 CONTINUOUS LINK 24
PA2070 SAR1P-1618C 16X18 SAR1 CONTINUOUS LINK 24
PA2071 SAR1P-1620C 16X20 SAR1 CONTINUOUS LINK 24
PA2072 SAR1P-1624C 16X24 SAR1 CONTINUOUS LINK 24
PA2073 SAR1P-1625C 16X25 SAR1 CONTINUOUS LINK 24
SAR-1 Panel
SwissAire Premium R-1 Panels
Item No. Model Description Qty/Case

23
SAR1 Standard Size Single Panels
Continously Linked
PA2074 SAR1P-1816C 18X16 SAR1 CONTINUOUS LINK 24
PA2075 SAR1P-1824C 18X24 SAR1 CONTINUOUS LINK 24
PA2076 SAR1P-2015C 20X15 SAR1 CONTINUOUS LINK 24
PA2077 SAR1P-2016C 20X16 SAR1 CONTINUOUS LINK 24
PA2078 SAR1P-2020C 20X20 SAR1 CONTINUOUS LINK 24
PA2079 SAR1P-2024C 20X24 SAR1 CONTINUOUS LINK 24
PA2080 SAR1P-2025C 20X25 SAR1 CONTINUOUS LINK 24
PA2081 SAR1P-2412C 24X12 SAR1 CONTINUOUS LINK 24
PA2082 SAR1P-2415C 24X15 SAR1 CONTINUOUS LINK 24
PA2083 SAR1P-2416C 24X16 SAR1 CONTINUOUS LINK 24
PA2084 SAR1P-2418C 24X18 SAR1 CONTINUOUS LINK 24
PA2085 SAR1P-2420C 24X20 SAR1 CONTINUOUS LINK 24
PA2086 SAR1P-2424C 24X24 SAR1 CONTINUOUS LINK 24
PA2087 SAR1P-2516C 25X16 SAR1 CONTINUOUS LINK 24
PA2088 SAR1P-2520C 25X20 SAR1 CONTINUOUS LINK 24
PA2089 SAR1P-2525C 25X25 SAR1 CONTINUOUS LINK 24
SAR1 Standard Size Link Panel
PA1879 SAR1L-12120-24 12X120 MED LINK PNL SWIS'A R-1 4
PA1880 SAR1L-12144-24 12X144 MED LINK PNL SWIS'A R-1 4
PA1876 SAR1L-1248-24 12X48 MED LINK PNL SWISS'A R-1 12
PA1877 SAR1L-1272-24 12X72 MED LINK PNL SWISS'A R-1 8
PA1878 SAR1L-1296-24 12X96 MED LINK PNL SWISS'A R-1 6
PA1887 SAR1L-15100-20 15X100 MED LINK PNL SWIS'A R-1 4
PA1888 SAR1L-15120-20 15X120 MED LINK PNL SWIS'A R-1 4
PA1889 SAR1L-15120-24 15X120 MED LINK PNL SWIS'A R-1 4
PA1890 SAR1L-15144-24 15X144 MED LINK PNL SWIS'S R-1 4
PA1881 SAR1L-1540-20 15X40 MED LINK PNL SWISS'A R-1 12
PA1882 SAR1L-1548-24 15X48 MED LINK PNL SWISS'A R-1 12
PA1883 SAR1L-1560-20 15X60 MED LINK PNL SWISS'A R-1 8
PA1884 SAR1L-1572-24 15X72 MED LINK PNL SWISS'A R-1 8
PA1885 SAR1L-1580-20 15X80 MED LINK PNL SWISS'A R-1 6
PA1886 SAR1L-1596-24 15X96 MED LINK PNL SWISS'A R-1 6
PA1904 SAR1L-16100-20 16X100 MED LINK PNL SWIS'A R-1 4
PA1905 SAR1L-16100-25 16X100 MED LINK PNL SWIS'A R-1 6
SAR-1 Panel
SwissAire Premium R-1 Panels
Item No. Model Description Qty/Case

24
SAR1 Standard Size Link Panel
PA1906 SAR1L-16120-20 16X120 MED LINK PNL SWIS'A R-1 4
PA1907 SAR1L-16120-24 16X120 MED LINK PNL SWIS'A R-1 4
PA1908 SAR1L-16125-25 16X125 MED LINK PNL SWIS'A R-1 4
PA1909 SAR1L-16140-20 16X140 MED LINK PNL SWIS'A R-1 3
PA1910 SAR1L-16144-24 16X144 MED LINK PNL SWIS'A R-1 4
PA1911 SAR1L-16150-25 16X150 MED LINK PNL SWIS'A R-1 4
PA1891 SAR1L-1632-16 16X32 MED LINK PNL SWISS'A R-1 12
PA1892 SAR1L-1636-18 16X36 MED LINK PNL SWISS'A R-1 12
PA1893 SAR1L-1640-20 16X40 MED LINK PNL SWISS'A R-1 12
PA1894 SAR1L-1648-24 16X48 MED LINK PNL SWISS'A R-1 12
PA1895 SAR1L-1650-25 16X50 MED LINK PNL SWISS'A R-1 12
PA1896 SAR1L-1654-18 16X54 MED LINK PNL SWISS'A R-1 8
PA1897 SAR1L-1660-20 16X60 MED LINK PNL SWISS'A R-1 8
PA1898 SAR1L-1664-16 16X64 MED LINK PNL SWISS'A R-1 6
PA1899 SAR1L-1672-18 16X72 MED LINK PNL SWISS'A R-1 6
PA1900 SAR1L-1672-24 16X72 MED LINK PNL SWISS'A R-1 8
PA1901 SAR1L-1675-25 16X75 MED LINK PNL SWISS'A R-1 8
PA1902 SAR1L-1680-20 16X80 MED LINK PNL SWISS'A R-1 6
PA1903 SAR1L-1696-24 16X96 MED LINK PNL SWISS'A R-1 6
PA1920 SAR1L-18120-24 18X120 MED LINK PNL SWIS'A R-1 4
PA1921 SAR1L-18144-24 18X144 MED LINK PNL SWIS'A R-1 4
PA1912 SAR1L-1832-16 18X32 MED LINK PNL SWISS'A R-1 12
PA1913 SAR1L-1848-16 18X48 MED LINK PNL SWISS'A R-1 8
PA1914 SAR1L-1848-24 18X48 MED LINL PNL SWISS'A R-1 12
PA1915 SAR1L-1864-16 18X64 MED LINK PNL SWISS'A R-1 6
PA1916 SAR1L-1872-24 18X72 MED LINK PNL SWISS'A R-1 8
PA1917 SAR1L-1880-16 18X80 MED LINK PNL SWISS'A R-1 4
PA1918 SAR1L-1896-16 18X96 MED LINK PNL SWISS'A R-1 4
PA1919 SAR1L-1896-24 18X96 MED LINK PNL SWISS'A R-1 6
PA1950 SAR1L-20100-20 20X100 MED LINL PNL SWIS'A R-1 4
PA1951 SAR1L-20105-15 20X105 MED LINL PNL SWIS'A R-1 3
PA1952 SAR1L-20112-16 20X112 MED LINK PNL SWIS'A R-1 3
PA1954 SAR1L-20120-20 20X120 MED LINK PNL SWIS'A R-1 4
PA1955 SAR1L-20120-24 20X120 MED LINK PNL SWIS'A R-1 4
PA1953 SAR1L-20120-15 20X120 MED LINL PNL SWIS'A R-1 3
SAR-1 Panel
SwissAire Premium R-1 Panels
Item No. Model Description Qty/Case

25
SAR1 Standard Size Link Panel
PA1956 SAR1L-20125-25 20X125 MED LINK PNL SWIS'A R-1 4
PA1957 SAR1L-20140-20 20X140 MED LINL PNL SWIS'A R-1 3
PA1958 SAR1L-20144-24 20X144 MED LINK PNL SWIS'A R-1 4
PA1959 SAR1L-20150-25 20X150 MED LINK PNL SWIS'A R-1 4
PA1922 SAR1L-2032-16 20X32 MED LINK PNL SWISS'A R-1 12
PA1923 SAR1L-2040-20 20X40 MED LINK PNL SWISS'A R-1 12
PA1924 SAR1L-2045-15 20X45 MED LINK PNL SWISS'A R-1 8
PA1926 SAR1L10-2046-23 20x46 MED LINK PNL SWIS'A R-1 10
PA1925 SAR1L-2046-23 20X46 MED LINK PNL SWISS'A R-1 12
PA1927 SAR1L-2046S-8 20X46 SOLID PANEL SWIS'A R-1 8
PA1932 SAR1L10-2048-24 20x48 MED LINK PNL SWIS'A R-1 10
PA1928 SAR1L-2048-24 20X48 MED LINK PNL SWISS'A R-1 12
PA1930 SAR1L8-2048-24 20x48 MED LINK PNL SWISS'A R-1 8
PA1929 SAR1L-2048S-12 20X48 SOLID PANEL SWISS'A R-1 12
PA1931 SAR1L8-2048S-8 20X48 SOLID PANEL SWISS'A R-1 8
PA1933 SAR1L10-2048S-10 20X48 SOLID PANEL SWISS'A R-1 10
PA1934 SAR1L-2048S-18 20X48 SOLID PANEL SWISS'A R-1 18
PA1935 SAR1L-2048S-24 20X48 SOLID PANEL SWISS'A R-1 24
PA1938 SAR1L10-2050-25 20x50 MED LINK PNL SWIS'A R-1 10
PA1936 SAR1L-2050-25 20X50 MED LINK PNL SWISS'A R-1 12
PA1937 SAR1L8-2050-25 20x50 MED LINK PNL SWISS'A R-1 8
PA1939 SAR1L-2060-15 20X60 MED LINK PNL SWISS'A R-1 6
PA1940 SAR1L-2060-20 20X60 MED LINK PNL SWISS'A R-1 8
PA1941 SAR1L-2064-16 20X64 MED LINK PNL SWISS'A R-1 6
PA1942 SAR1L-2072-24-6 20X72 MED LINK PNL SWISS'A R-1 6
PA1943 SAR1L-2072-24 20X72 MED LINK PNL SWISS'A R-1 8
PA1944 SAR1L-2075-25 20X75 MED LINK PNL SWISS'A R-1 8
PA1945 SAR1L-2080-16 20X80 MED LINK PNL SWISS'A R-1 4
PA1946 SAR1L-2080-20 20X80 MED LINK PNL SWISS'A R-1 6
PA1947 SAR1L-2090-15 20X90 MED LINK PNL SWISS'A R-1 4
PA1948 SAR1L-2096-16 20X96 MED LINK PNL SWISS'A R-1 4
SAR-1 Panel
SwissAire Premium R-1 Panels
Item No. Model Description Qty/Case

26
SAR1 Standard Size Link Panel
PA1949 SAR1L-2096-24 20X96 MED LINK PNL SWISS'A R-1 6
PA1984 SAR1L-24108-18 24X108 MED LINK PNL SWIS'A R-1 4
PA1985 SAR1L-24120-24 24X120 MED LINK PNL SWIS'A R-1 4
PA1986 SAR1L-24140-20 24X140 MED LINK PNL SWIS'A R-1 3
PA1987 SAR1L-24144-24 24X144 MED LINK PNL SWIS'A R-1 4
PA1960 SAR1L-2430-15 24X30 MED LINK PNL SWISS'A R-1 12
PA1961 SAR1L-2432-16 24X32 MED LINK PNL SWISS'A R-1 12
PA1962 SAR1L-2436-12 24X36 MED LINK PNL SWISS'A R-1 8
PA1963 SAR1L-2436-18 24X36 MED LINK PNL SWISS'A R-1 12
PA1964 SAR1L-2440-20 24X40 MED LINK PNL SWISS'A R-1 12
PA1965 SAR1L-2445-15 24X45 MED LINK PNL SWISS'A R-1 8
PA1966 SAR1L-2448-16 24X48 MED LINK PNL SWISS'A R-1 8
PA1967 SAR1L-2448-24 24X48 MED LINK PNL SWISS'A R-1 12
PA1968 SAR1L-2454-18 24X54 MED LINK PNL SWISS'A R-1 8
PA1969 SAR1L-2460-15 24X60 MED LINK PNL SWISS'A R-1 12
PA1970 SAR1L-2460-20 24X60 MED LINK PNL SWISS'A R-1 8
PA1971 SAR1L-2464-16 24X64 MED LINK PNL SWISS'A R-1 6
PA1972 SAR1L-2472-12 24X72 MED LINK PNL SWISS'A R-1 4
PA1973 SAR1L-2472-18 24X72 MED LINK PNL SWISS'A R-1 6
PA1974 SAR1L-2472-24-6 24X72 MED LINK PNL SWISS'A R-1 6
PA1975 SAR1L-2472-24 24X72 MED LINK PNL SWISS'A R-1 8
PA1976 SAR1L-2475-15 24X75 MED LINK PNL SWISS'A R-1 4
PA1977 SAR1L-2480-16 24X80 MED LINK PNL SWISS'A R-1 4
PA1978 SAR1L-2480-20 24X80 MED LINK PNL SWISS'A R-1 6
PA1979 SAR1L-2484-12 24X84 MED LINK PNL SWISS'A R-1 3
PA1980 SAR1L-2490-18 24X90 MED LINK PNL SWISS'A R-1 4
PA1981 SAR1L-2496-12 24X90 MED LINK PNL SWISS'A R-1 3
PA1982 SAR1L-2496-16 24X96 MED LINK PNL SWISS'A R-1 4
PA1983 SAR1L-2496-24 24X96 MED LINK PNL SWISS'A R-1 6
PA1999 SAR1L-25100-20 25X100 MED LINK PNL SWIS'A R-1 4
PA2000 SAR1L-25100-25 25X100 MED LINK PNL SWIS'A R-1 6
PA2001 SAR1L-25112-16 25X112 MED LINK PNL SWIS'A R-1 3
PA2002 SAR1L-25120-20 25X120 MED LINK PNL SWIS'A R-1 4
PA2003 SAR1L-25125-25 25X125 MED LINK PNL SWIS'A R-1 4
PA2004 SAR1L-25140-20 25X140 MED LINK PNL SWIS'A R-1 3
SAR-1 Panel
SwissAire Premium R-1 Panels
Item No. Model Description Qty/Case

27
SAR1 Standard Size Link Panel
PA2005 SAR1L-25150-25 25X150 MED LINK PNL SWIS'A R-1 4
PA1988 SAR1L-2532-16 25X32 MED LINK PNL SWISS'A R-1 12
PA1989 SAR1L-2540-20 25X40 MED LINK PNL SWISS'A R-1 12
PA1990 SAR1L-2548-16 25X48 MED LINK PNL SWISS'A R-1 8
PA1991 SAR1L-2550-25 25X50 MED LINK PNL SWISS'A R-1 12
PA1992 SAR1L-2560-20 25X60 MED LINK PNL SWISS'A R-1 8
PA1993 SAR1L-2564-16 25X64 MED LINK PNL SWISS'A R-1 6
PA1994 SAR1L-2572-24-6 25X72 MED LINK PNL SWISS'A R-1 6
PA1995 SAR1L-2575-25 25X75 MED LINK PNL SWISS'A R-1 8
PA1996 SAR1L-2580-16 25X80 MED LINK PNL SWISS'A R-1 4
PA1997 SAR1L-2580-20 25X80 MED LINK PNL SWISS'A R-1 6
PA1998 SAR1L-2596-16 25X96 MED LINK PNL SWISS'A R-1 4
SAR1 Custom Size Single Panels
PA1854 SAR1CS-099 CUSTOM PANEL SAR-1 0-099 12
PA1855 SAR1CS-149 CUSTOM PANEL SAR-1 100-149 12
PA1856 SAR1CS-199 CUSTOM PANEL SAR-1 150-199 12
PA1857 SAR1CS-249 CUSTOM PANEL SAR-1 200-249 12
PA1858 SAR1CS-299 CUSTOM PANEL SAR-1 250-299 12
PA1859 SAR1CS-349 CUSTOM PANEL SAR-1 300-349 12
PA1860 SAR1CS-399 CUSTOM PANEL SAR-1 350-399 12
PA1861 SAR1CS-449 CUSTOM PANEL SAR-1 400-449 12
PA1862 SAR1CS-499 CUSTOM PANEL SAR-1 450-499 12
PA1863 SAR1CS-549 CUSTOM PANEL SAR-1 500-549 12
PA1864 SAR1CS-599 CUSTOM PANEL SAR-1 550-599 12
PA1865 SAR1CS-649 CUSTOM PANEL SAR-1 600-649 12
PA1866 SAR1CS-699 CUSTOM PANEL SAR-1 650-699 12
PA1867 SAR1CS-799 CUSTOM PANEL SAR-1 700-799 12
PA1868 SAR1CS-899 CUSTOM PANEL SAR-1 800-899 12
PA1869 SAR1CS-999 CUSTOM PANEL SAR-1 900-999 12
PA1870 SAR1CS-1099 CUSTOM PANEL SAR-1 1000-1099 12
PA1871 SAR1CS-1199 CUSTOM PANEL SAR-1 1100-1199 12
SAR-1 Panel
SwissAire Premium R-1 Panels
Item No. Model Description Qty/Case

28
SAR1 Custom Size Single Panels
PA1872 SAR1CS-1299 CUSTOM PANEL SAR-1 1200-1299 12
PA1873 SAR1CS-1399 CUSTOM PANEL SAR-1 1300-1399 12
PA1874 SAR1CS-1499 CUSTOM PANEL SAR-1 1400-1499 12
PA1875 SAR1CS-1599 CUSTOM PANEL SAR-1 1500-1599 12
SAR1 Custom Size Link Panels
PA2006 SAR1LCST-0099 CUSTOM SAR-1 LINK 0-99 SQ" 6
PA2007 SAR1LCST-0199 CUSTOM SAR-1 LINK 100-199 SQ" 6
PA2008 SAR1LCST-0299 CUSTOM SAR-1 LINK 200-299 SQ" 6
PA2009 SAR1LCST-0399 CUSTOM SAR-1 LINK 300-399 SQ" 6
PA2010 SAR1LCST-0499 CUSTOM SAR-1 LINK 400-499 SQ" 6
PA2011 SAR1LCST-0599 CUSTOM SAR-1 LINK 500-599 SQ" 6
PA2012 SAR1LCST-0699 CUSTOM SAR-1 LINK 600-699 SQ" 6
PA2013 SAR1LCST-0799 CUSTOM SAR-1 LINK 700-799 SQ" 6
PA2014 SAR1LCST-0899 CUSTOM SAR-1 LINK 800-899 SQ" 6
PA2015 SAR1LCST-0999 CUSTOM SAR-1 LINK 900-999 SQ" 6
PA2016 SAR1LCST-1099 CUSTOM SAR-1 LINK 1000-1099SQ" 6
PA2017 SAR1LCST-1199 CUSTOM SAR-1 LINK 1100-1199SQ" 6
PA2018 SAR1LCST-1299 CUSTOM SAR-1 LINK 1200-1299SQ" 6
PA2019 SAR1LCST-1399 CUSTOM SAR-1 LINK 1300-1399SQ" 6
PA2020 SAR1LCST-1499 CUSTOM SAR-1 LINK 1400-1499SQ" 6
PA2021 SAR1LCST-1599 CUSTOM SAR-1 LINK 1500-1599SQ" 6
PA2022 SAR1LCST-1699 CUSTOM SAR-1 LINK 1600-1699SQ" 6
PA2023 SAR1LCST-1799 CUSTOM SAR-1 LINK 1700-1799SQ" 6
PA2024 SAR1LCST-1899 CUSTOM SAR-1 LINK 1800-1899SQ" 6
PA2025 SAR1LCST-1999 CUSTOM SAR-1 LINK 1900-1999SQ" 6
PA2026 SAR1LCST-2099 CUSTOM SAR-1 LINK 2000-2099SQ" 6
PA2027 SAR1LCST-2199 CUSTOM SAR-1 LINK 2100-2199SQ" 6
PA2028 SAR1LCST-2299 CUSTOM SAR-1 LINK 2200-2299SQ" 6
PA2029 SAR1LCST-2399 CUSTOM SAR-1 LINK 2300-2399SQ" 6
PA2030 SAR1LCST-2499 CUSTOM SAR-1 LINK 2400-2499SQ" 6
PA2031 SAR1LCST-2599 CUSTOM SAR-1 LINK 2500-2599SQ" 6
SAR-1 Panel
SwissAire Premium R-1 Panels
Item No. Model Description Qty/Case

29
SAR1 Custom Size Link Panel
PA2032 SAR1LCST-2699 CUSTOM SAR-1 LINK 2600-2699SQ" 6
PA2033 SAR1LCST-2799 CUSTOM SAR-1 LINK 2700-2799SQ" 6
PA2034 SAR1LCST-2899 CUSTOM SAR-1 LINK 2800-2899SQ" 6
PA2035 SAR1LCST-2999 CUSTOM SAR-1 LINK 2900-2999SQ" 6
PA2036 SAR1LCST-3099 CUSTOM SAR-1 LINK 3000-3099SQ" 6
PA2037 SAR1LCST-3199 CUSTOM SAR-1 LINK 3100-3199SQ" 6
PA2038 SAR1LCST-3299 CUSTOM SAR-1 LINK 3200-3299SQ" 6
PA2039 SAR1LCST-3399 CUSTOM SAR-1 LINK 3300-3399SQ" 6
PA2040 SAR1LCST-3499 CUSTOM SAR-1 LINK 3400-3499SQ" 6
PA2041 SAR1LCST-3599 CUSTOM SAR-1 LINK 3500-3599SQ" 6
PA2042 SAR1LCST-3699 CUSTOM SAR-1 LINK 3600-3699SQ" 6
PA2043 SAR1LCST-3799 CUSTOM SAR-1 LINK 3700-3799SQ" 6
PA2044 SAR1LCST-3899 CUSTOM SAR-1 LINK 3800-3899SQ" 6
PA2045 SAR1LCST-3999 CUSTOM SAR-1 LINK 3900-3999SQ" 6
SAR-1 Panel
SwissAire Premium R-1 Panels
Item No. Model Description Qty/Case
