Flash F7000499 User manual

USER MANUAL
LED Moving Head 30W
SPOT COLOR GOBO
F7000499

LED Moving Head 30W SPOT COLOR GOBO F7000499
www.flash-butrym.pl
1
Table of Contents
1Introduction......................................................................................................................................................2
2Safety information ...........................................................................................................................................2
3maintenance .....................................................................................................................................................2
4Product information ........................................................................................................................................2
4.1 Specification................................................................................................................................................2
5Installation........................................................................................................................................................3
6Connections......................................................................................................................................................3
6.1 Connecting DMX signal.............................................................................................................................4
6.2 Voltage specification.................................................................................................................................. 4
6.3 Connecting power supply........................................................................................................................4
7Operation manual............................................................................................................................................4
7.1 Control panel ..............................................................................................................................................4
7.2 Menu............................................................................................................................................................5
7.3 DMX channel list ........................................................................................................................................6

www.flash-butrym.pl
2
1INTRODUCTION
Thank you for purchasing LED Moving Head 30W SPOT COLOR GOBO. For safety reasons and to ensure
the trouble-free operation, carefully read the instructions.
2SAFETY INFORMATION
1. Installation should be done by qualified personnel in order to minimize the risk of accidental
electric shock
2. Disconnect the power supply before installation.
3. Before connecting the unit to the mains, make sure it is not damaged mechanically. If you
notice any signs of damage you should contact your dealer immediately. Do not connect the
device to the mains.
4. Do not use the device in high humidity conditions and at temperatures above 40° C
5. The device must be installed on stable structures.
3MAINTENANCE
1. For good ventilation regularly clean the fan and the fan cover
2. In order to prevent electronic components overheating do not turn on the device for 20
minutes after turning off.
4PRODUCT INFORMATION
4.1 Specification
Power supply voltage: 110 - 240V
Voltage frequency: 50/60Hz
Diode type: Standard LED
Number of diodes: 1
Diode power: 30W
Display: LED - 4 characters
Color: Color wheel - 7 colors + white
Dimming: Linear: 0 - 100%
GOBO wheel: 7 patterns + open
PAN range: 630°
TILT range: 180°
Number of DMX channels: 4 / 12
DMX standard: DMX 512
Control interface: 4 buttons
AC IN: IEC 320 - C14
DMX IN: XLR - 3 pin
DMX OUT: XLR - 3 pin
Cooling: Active
Height [cm]: 32,5
Width [cm]: 25
Depth [cm]: 27
Weight [kg]: 2,5

LED Moving Head 30W SPOT COLOR GOBO F7000499
www.flash-butrym.pl
3
5INSTALLATION
After removing the packaging, check if the device was not damaged during transport. Before connecting to
the mains, make sure that the device is securely mounted. The manufacturer is not responsible for damage
caused by unstable mounting.
Ensure proper connection to the mains and proper grounding. Make sure that the electrical parameters are
consistent with device requirements. All activities, including connecting the device to the mains must be
performed by qualified personnel.
6CONNECTIONS
The device is equipped with the following interfaces:
1. DMX (in/out): XLR 3-pin socket
2. Power (in): IEC - C14 socket

www.flash-butrym.pl
4
6.1 Connecting DMX signal
The connection is performed using cable with XLR-female -> XLR-Male plugs.
1
2
3
1
2
3
GROUND
DMX +
DMX -
FEMALE
XLR MALE XLR
DMX Controller
DMX 512 DMX 512
6.2 Voltage specification
Input Voltage
Total Power
Frequency
110~240V
75W
50/60Hz
6.3 Connecting power supply
The connection is performed using power cable with IEC –C13 connector (included).
The device must be operated by qualified personnel. Make sure that the power grid supply parameters are
consistent with device parameters and limitations are not exceeded.
CAUTION! In the case of cable damage do not attempt to repair. Replacement or repair can be made only
on the manufacturer or by a person with appropriate permissions.
7OPERATION MANUAL
7.1 Control panel
The control panel is equipped with display and 4 control buttons with the following functions:
1. MENU –choose option
2. UP –edit parameter
3. DOWN –edit parameter
4. ENTER –confirm changes

LED Moving Head 30W SPOT COLOR GOBO F7000499
www.flash-butrym.pl
5
7.2 Menu
Menu diagram:
Addr
A001-A512
512 address code
CHnd
11CH
11 channel mode
9CH
9 channel mode
SLnd
MAST
Master mode
SL 1
DMX mode
SL 2
Slave mode
SHnd
SH 0
Effect0
SH 1
Effect1
SH 2
Effect2
SH 3
Effect3
Soud
on
Sound control on
oFF
Sound control off
SEnS
0-99
Sound control sensitivity
bLAnd
bLAc
No 512 signal, signal off
Auto
No 512 signal, Auto mode
Soun
No 512 signal, Sound mode
HoLd
No 512 signal, Auto mode as last 512 state
LEd
OFF
Display screen off after 5 second
ON
Display screen on
dISP
no
Display downward
YES
Display upward
rPAN
no
X motor move clockwise
YES
X motor move anti-clockwise
rTiL
no
Y motor move clockwise
YES
Y motor move anti-clockwise
REST
YES
Reset

www.flash-butrym.pl
6
7.3 DMX channel list
9CH mode
Chanel
Function
Effect
CH 1
Pan
0-255: 0-630°
CH 2
Tilt
0-255: 0-180°
CH 3
Color change
0-139: Color change
140-255: Rainbow effect from slow to fast
CH 4
Gobo change
0-63: Gobo
64-127: Gobo shake
128-255: Gobo auto run from slow to fast
CH 5
Strobe
0-255: 0-10s
CH 6
Dimmer
0-255: 0-100%
CH 7
Pan/Tilt speed
0-255
CH 8
Auto mode
0-59: No function
60-84: Auto mode 1
58-109: Auto mode 2
110-134: Auto mode 3
135-159: Auto mode 4
160-184: Sound mode 1
158-209: Sound mode 2
210-234: Sound mode 3
CH 9
Reset
0-249: No function
250-255: Reset after 5s
11CH mode
Chanel
Function
Effect
CH 1
Pan
0-255: 0-630°
CH 2
Pan fine
0-255
CH 3
Tilt
0-255: 0-180°
CH 4
Tilt fine
0-255
CH 5
Color change
0-139: Color change
140-255: Rainbow effect from slow to fast
CH 6
Gobo change
0-63: Gobo
64-127: Gobo shake
128-255: Gobo auto run from slow to fast
CH 7
Strobe
0-255: 0-10s
CH 8
Dimmer
0-255: 0-100%
CH 9
Pan/Tilt speed
0-255
CH 10
Auto mode
0-59: No function
60-84: Auto mode 1
58-109: Auto mode 2
110-134: Auto mode 3
135-159: Auto mode 4
160-184: Sound mode 1
158-209: Sound mode 2
210-234: Sound mode 3
CH 11
Reset
0-249: No function
250-255: Reset after 5s
