Flash F7100519 User manual

LED MOVING HEAD
PIXEL ZOOM 7x40W
User Manual
F7100519

User Manual •
Please keep this User Manual for future
      
another user, be sure that they also receive
this instruction booklet.
Unpack and check carefully there is no
transportation damage before using the

Before operating, ensure that the voltage
and frequency of power supply match the

It’s important to ground the yellow/green
conductor to earth in order to avoid electric
shock.
Disconnect main power before servicing
and maintenance.


only, but always by taking its base.

Don’t operate it where the temperature is
higher than this.



          
replaced if they are visibly damaged.
In the event of serious operating problem,
     

carried out by unskilled people can lead to
damage or malfunction. Please contact the
nearest authorized technical assistance
center. Always use the same type spare
parts.
Do not connect the device to any dimmer
pack.
Do not touch any wire during operation
and there might be a hazard of electric
shock.
To prevent or reduce the risk of electrical
        
rain or moisture.

visibly damaged.
Do not look directly at the LED light

2. SAFETY INFORMATION
1. INTRODUCTION
    LED MOVING HEAD PIXEL ZOOM 7x40W.
        

WARNING!

LED MOVING HEAD PIXEL ZOOM 7x40W •Art No F7100519






system with big cooling fan.

holes on the bracket. Always ensure that

and slipping while operating. Always
ensure that the structure to which you
are attaching the unit is secure and is
        
5.1 Connecting DMX signal
     

4. INSTALLATION
5. CONNECTION
3. PRODUCT INFORMATION








the unit’s weight. Also always use a safety




of the touch of people and has no one pass
by or under it.
      



1
3
22
FEMALE
XLR
GROUND
DMX +
DMX -
MALE
XLR
3
1
CAUTION!     
DMX signal has to be terminated with a



DMX
Controller DMX 512 DMX 512

The connection is performed using

    
operated by qualified personnel.
6. HOW TO SET THE UNIT
5.2 Voltage specification
User Manual •
Input Voltage Total Power Frequency
100~240V 350W 50/60Hz
5.3 Connecting power supply
CAUTION!
be made only on the manufacturer or by a person with appropriate permissions.
Make sure that the power grid supply
parameters are consistent with device
parameters and limitations are not


to go into menu mode and press the UP/
 


button to choose the submenu, press the
     
return to the last menu.

9.1 CH17 Mode
9. DMX CHANNELS
LED MOVING HEAD PIXEL ZOOM 7x40W •Art No F7100519
CH Function Value Description
1Pan 0-255 0-5400
2Pan Fine 0-255
3Tilt 0-255 0-2200
4Tilt Fine 0-255
5Pan/Tilt Speed 0-255 Fast - Slow
6Zoom 0-255 Wide 45°- Narrow 5°
7Dimmer 0-255 0-100%
8Strobe 0 Open
1-84 Strobe
85-170 Pulse
171-255 Random
9Red 0-255 0-100%
10 Green 0-255 0-100%
11 Blue 0-255 0-100%
12 White 0-255 0-100%
13 CTC 0 Open
1-255 Warm - Cold
14 Color Macro 0 Open
1-30 Red
31-40 Green
62-92 Blue
93-123 White
124-154 Yellow
155-185 Magenta
186-216 Cyan
217-255 RGBW
15 Macro 0-20 Open
21-25 Red
26-31 Grean
32-37 Blue

User Manual •
38-43 White
44-49 Yellow
50-55 Magenta
56-61 Cyan
62-67 RGBW
68-73 Macro 1
74-79 Macro 2
80-85 Macro 3
86-91 Macro 4
92-97 Macro 5
98-103 Macro 6
104-109 Macro 7
110-115 Macro 8
116-121 Macro 9
122-127 Macro 10
128-133 Macro 11
134-139 Macro 12
140-145 Macro 13
146-151 Macro 14
152-157 Macro 15
158-163 Macro 16
164-169 Macro 17
170-175 Macro 18
176-181 Macro 19
182-187 Macro 20
188-193 Macro 21
194-199 Macro 22
200-205 Macro 23
206-211 Macro 24
212-217 Macro 25
218-255 Random
16 Macro Rate 0-255 Fast - Slow
17 Reset 0-244 Open
245-255 Reset

LED MOVING HEAD PIXEL ZOOM 7x40W •Art No F7100519
9.2 CH 21 Mode
CH Function Value Description
1Pan 0-255 0-540º
2Pan Fine 0-255
3Tilt 0-255 0-220º
4Tilt Fine 0-255
5Pan/Tilt Speed 0-255 Fast - Slow
6Zoom 0-255 Wide 45°- Narrow 5°
7Dimmer 0-255 0-100%
8Strobe 0 Open
1-84 Strobe
85-170 Pulse
171-255 Random
9Red 0-255 0-100%
10 Green 0-255 0-100%
11 Blue 0-255 0-100%
12 White 0-255 0-100%
13 CTC 0 Open
1-255 Warm - Cold
14 Color Macro 0 Open
1-30 Red
31-40 Green
62-92 Blue
93-123 White
124-154 Yellow
155-185 Magenta
186-261 Cyan
217-255 White
15 Macro 0-20 Open
21-32 Macro 1
33-45 Macro 2
46-58 Macro 3
59-71 Macro 4

CH Function Value Description
72-84 Macro 5
85-97 Macro 6
98-110 Macro 7
111-123 Macro 8
124-136 Macro 9
137-149 Macro 10
150-162 Macro 11
163-175 Macro 12
176-188 Macro 13
189-201 Macro 14
202-214 Macro 15
215-227 Macro 16
228-255 Macro 17
16 Macro Rate 0-255 Fast - Slow
17 Red background 0-255 0-100%
18 Green background 0-255 0-100%
19 Blue background 0-255 0-100%
20 White background 0-255 0-100%
21 Reset 0-244 Open
245-255 Reset
User Manual •

9.3 CH 41 Mode
CH Function Value Description
1Pan 0-255 0-540º
2Pan ne 0-255
3Tilt 0-255 0-220º
4Tilt ne 0-255
5Pan/Tilt speed 0-255 Fast - Slow
6Zoom 0-255 Wide 45°- Narrow 5°
7Dimmer 0-255 0-100%
8Strobe 0 Open
1-84 Strobe
85-170 Pulse
171-255 Random
91 Red 0-255 0-100%
10 1 Green 0-255 0-100%
11 1 Blue 0-255 0-100%
12 1 White 0-255 0-100%
13 2 Red 0-255 0-100%
14 2 Green 0-255 0-100%
15 2 Blue 0-255 0-100%
16 2 White 0-255 0-100%
17 3 Red 0-255 0-100%
18 3 Green 0-255 0-100%
19 3 Blue 0-255 0-100%
20 3 White 0-255 0-100%
21 4 Red 0-255 0-100%
22 4 Green 0-255 0-100%
23 4 Blue 0-255 0-100%
24 4 White 0-255 0-100%
25 5 Red 0-255 0-100%
26 5 Green 0-255 0-100%
27 5 Blue 0-255 0-100%
28 5 White 0-255 0-100%
LED MOVING HEAD PIXEL ZOOM 7x40W •Art No F7100519

CH Function Value Description
29 6 Red 0-255 0-100%
30 6 Green 0-255 0-100%
31 6 Blue 0-255 0-100%
32 6 White 0-255 0-100%
33 7 Red 0-255 0-100%
34 7 Green 0-255 0-100%
35 7 Blue 0-255 0-100%
36 7 White 0-255 0-100%
37 CTC 0 Open
1-255 Warm - Cold
38 Color Macro 0 Open
1-30 Red
31-40 Green
62-92 Blue
93-123 White
124-154 Yellow
155-185 Magenta
186-261 Cyan
217-255 White
39 Macro 0-20 Open
21-25 Red
26-31 Green
32-37 Blue
38-43 White
44-49 Yellow
50-55 Magenta
56-61 Cyan
62-67 White
68-73 Macro 1
74-79 Macro 2
80-85 Macro 3
86-91 Macro 4
User Manual •

CH Function Value Description
92-97 Macro 5
98-103 Macro 6
104-109 Macro 7
110-115 Macro 8
116-121 Macro 9
122-127 Macro 10
128-133 Macro 11
134-139 Macro 12
140-145 Macro 13
146-151 Macro 14
152-157 Macro 15
158-163 Macro 16
164-169 Macro 17
170-175 Macro 18
176-181 Macro 19
182-187 Macro 20
188-193 Macro 21
194-199 Macro 22
200-205 Macro 23
206-211 Macro 24
212-217 Macro 25
218-255 Random
40 Macro Rate 0-255 Fast - Slow
41 Reset 0-244 Open
245-255 Reset
LED MOVING HEAD PIXEL ZOOM 7x40W •Art No F7100519
